IMPORTANT SAFETY INSTRUCTIONS
These instructions shall also be available on website: www.whirlpool.eu
YOUR SAFETY AND THE SAFETY OF OTHERS ARE VERY IMPORTANT
This manual and the appliance itself provide important safety messages, to be read and observed at all times.
This is the safety alert symbol, pertaining to safety, which alerts users to potential hazards to themselves and others.
All safety messages will follow the safety alert symbol and either the terms:
Indicates a hazardous situation which, if not avoided, will cause serious injury.
Indicates a hazardous situation which, if not avoided, could cause serious injury.
All Safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.
- The appliance must be disconnected from the power supply before carrying out any installation work.
-๎ Installation๎and๎maintenance๎must๎be๎carried๎out๎by๎a๎quali๎ฟed๎technician,๎in๎compliance๎with๎the๎manufacturerโs๎instructions๎and๎local๎safety๎regulations.๎Do๎not๎repair๎
or๎replace๎any๎part๎of๎the๎appliance๎unless๎speci๎ฟcally๎stated๎in๎the๎user๎manual.
If the information in this manual is not followed exactly, a ๎ฟre or explosion may result causing property damage or injury.
- Do๎not๎store๎or๎use๎gasoline๎or๎other๎๎ammable๎vapors๎and๎liquids๎in๎the๎vicinity๎of๎this๎appliance.
What to do if you smell gas:
- Do not try to light any appliance.
- Do not touch any electrical switch.
- Do not use any phone in your building.
- Immediately call your gas supplier from a neighborโs phone. Follow the gas supplierโs instructions.
- If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
- Use appliance in well ventilated rooms only.
The electrical and gas connections must comply with local regulations.
โข When the hob is installed, provide a multi-pole circuit breaker with a contact separation of at least 3 mm, that
provides full disconnection.
โข Regulations require that the appliance is grounded.
โข The๎power๎cable๎must๎be๎long๎enough๎for๎connecting๎the๎appliance,๎once๎๎ฟtted๎in๎its๎housing,๎to๎the๎power๎
supply.
โข Use๎only๎๎exible๎or๎rigid๎metal๎hose๎for๎gas๎connection.
โข If๎necessary,๎the๎electrical๎power๎cable๎must๎be๎replaced๎exclusively๎with๎a๎power๎cable๎having๎identical๎
characteristics๎to๎ the๎original๎ supplied๎by๎ manufacturer.๎This๎operation๎ must๎be๎ performed๎by๎ a๎quali๎ฟed๎
electrician.
โข The manufacturer cannot be held responsible for any injury to persons or animals or damage to property
arising from failure to comply with these requirements.
โข Do๎not๎use๎multiple๎plug๎adapters๎or๎extension๎cords.
โข Do๎not๎pull๎the๎power๎cable๎to๎disconnect๎it๎from๎the๎electrical๎supply.
โข The electrical components must not be accessible to the user after installation.
โข Do๎not๎touch๎the๎appliance๎with๎any๎wet๎part๎of๎the๎body๎and๎do๎not๎operate๎it๎when๎barefoot.
โข This๎hob๎(class๎3)๎is๎designed๎solely๎for๎private๎household๎use๎for๎cooking๎food.๎Do๎not๎use๎this๎appliance๎as๎
a๎space๎heater๎to๎heat๎or๎warm๎the๎room.๎Doing๎so๎may๎result๎in๎carbon๎monoxide๎poisoning๎and๎overheating๎
of the hob. The Manufacturer declines all responsibility for inappropriate use or incorrect setting of the controls.
โข The appliance and its accessible parts become hot during use. Care should be taken to avoid touching
heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This
appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or๎mental๎capabilities๎or๎lack๎of๎experience๎and๎knowledge๎if๎they๎have๎been๎given๎supervision๎or๎instruction๎
concerning use of the appliance in a safe way and understand the hazards involved. They shall not play with
the appliance. Cleaning and user maintenance shall not be made by children without supervision.
DANGER
RNINGWA
RNINGWA
400011181339
AE
UA
GR
IT
PT
ES
GB
KZ
RU
EN
BUILT-IN GAS HOB INSTRUCTIONS
โข The use of a gas appliance produces heat and humidity in the room. Make sure the room is well-ventilated,
or๎install๎an๎extractor๎hood๎with๎exhaust๎duct.
โข Domestic๎animals๎should๎be๎kept๎away๎from๎the๎appliance.
โข In case of prolonged use, additional ventilation may be necessary (by opening a window or increasing the
hood๎extraction๎speed).
โข After use, make sure the knobs are in off position and close the main gas supply cock or the gas cylinder valve.
โข Overheated๎oils๎and๎fats๎catch๎๎ฟre๎easily.๎Always๎remain๎vigilant๎when๎cooking๎foods๎rich๎in๎fat,๎oil๎or๎alcohol๎
(e.g. rum, cognac, wine).
โข Keep the packaging materials out of the reach of children.
โข Before cleaning or maintenance wait for hob to cool down.
โข Unattended๎cooking๎on๎a๎hob๎with๎fat๎or๎oil๎can๎be๎dangerous๎and๎may๎result๎in๎๎ฟre.๎NEVER๎try๎to๎extinguish๎
a๎๎ฟre๎with๎water,๎but๎switch๎off๎the๎appliance๎and๎then๎cover๎๎ame๎e.g.๎with๎a๎lid๎or๎a๎๎ฟre๎blanket.
โข Danger๎of๎๎ฟre:๎do๎not๎store๎items๎on๎the๎cooking๎surfaces.
SAVE THESE INSTRUCTIONS
INSTALLATION
After unpacking the hob, make sure that it has not been damaged during transport. In the event of problems, contact the dealer or your nearest After-sales Service.
These instructions are only valid for the countries whose symbols is given on the data plate (under the hob).
TECHNICAL INFORMATION FOR THE INSTALLER
โข This product can be embedded in a worktop 20 to 50 mm thick.
โข If there is no oven beneath the hob, insert a separator panel that has a surface at least equal to the opening in the work surface. This panel, that has
to close completely the cutout in order to avoid any contact with the bottom part of the hob, must be positioned at a maximum distance of 150 mm
below the upper surface of the work surface but, in no case less than 20 mm from the bottom of the hob. In the case that you intend to install an oven
beneath the hob, make sure that it is manufactured by Whirlpool and equipped with a cooling system. The manufacturer declines all liability if another
brand oven is installed beneath the hob.
โข Before installation, make sure that:
- the local gas delivery conditions (nature and pressure) are compatible with the settings of the hob (see the rating plate and injector table);
- the outer surfaces of the furniture or appliances adjacent to the hob are heat resistant according to local regulations;
-๎ this๎appliance๎is๎not๎connected๎to๎a๎fume๎exhaust๎device.๎It๎shall๎be๎installed๎in๎accordance๎with๎current๎installation๎regulations.๎Particular๎attention๎shall๎be๎given๎
to the relevant requirements regarding ventilation.
-๎ combustion๎products๎are๎discharged๎outdoors๎through๎speci๎ฟc๎hoods๎or๎wall๎and/or๎window๎mounted๎electrical๎fans.
GAS CONNECTION
This operation must be performed by a quali๎ฟed technician.
โข The gas supply system must comply with local regulations.
โข You๎can๎๎ฟnd๎speci๎ฟc๎local๎regulations๎for๎some๎countries๎in๎the๎paragraph๎โReference๎to๎Local๎Regulationsโ.If๎no๎
information concerning your Country is given, please ask details to your Installer.
โข The connection of the hob to the gas pipe network or gas cylinder must be made by means of a rigid copper or
steel๎pipe๎with๎๎ฟttings๎complying๎with๎local๎regulations,๎or๎by๎means๎of๎a๎continuous-surface๎stainless๎steel๎hose๎
complying with local regulations. Interpose gasket (B)๎in๎the๎elbow๎connection.The๎maximum๎length๎of๎the๎hose๎is๎2๎m.
โข FOR BELGIUM ONLY: It is necessary to replace the elbow connection (A) on the appliance, with the one supplied
(if present).
IMPORTANT: if a stainless steel hose is used, it must be installed so as not to touch any mobile part of the furniture. It must pass through an area where
there are no obstructions and where it is possible to inspect it on all its length.
โข After๎connection๎to๎the๎gas๎supply,๎check๎for๎leaks๎with๎soapy๎water.๎Light๎up๎the๎burners๎and๎turn๎the๎knobs๎from๎max๎position๎ to minimum position to check
๎ame๎stability.
ELECTRICAL CONNECTION.
This operation must be performed by a quali๎ฟed technician.
โข The electrical connections must comply with local regulations.
โข The earthing of this appliance is compulsory by law.
โข Do not use an extension cord.
IMPORTANT: the data relevant to the voltage and power absorption are indicated on the rating plate.
RNINGWA
L
Earth
(yellow/green)
N
EAVERTIZAR
EAVERTIZAR
ASSEMBLY
After having cleaned the perimeter surface, apply the supplied gasket to the hob as shown in the ๎ฟgure.
Position๎the๎hob๎in๎the๎worktop๎opening๎made๎respecting๎the๎dimensions๎indicated๎in๎the๎Instruction.
NOTE: the power supply cable must be long enough to permit its upward extraction.
To secure the hob, use the brackets (A) provided with it. Fit the brackets into the relevant bores shown by the arrow and fasten them by means of their screws in accordance
with๎the๎thickness๎of๎the๎worktop๎(see๎the๎following๎๎ฟgures).
Top 20 mm
Top 30-50 mm
ADJUSTMENT TO DIFFERENT TYPES OF GAS
This operation must be performed by a quali๎ฟed technician.
If the appliance is intended to operate with a different gas from the gas type stated on the rating plate and information label on the top of the hob, change the injectors.
Remove the information label and keep it with the instructions booklet.
Use pressure regulators suitable for the gas pressure indicated in the Instruction.
โข The๎gas๎nozzles๎must๎be๎changed๎by๎After๎Sales๎Service๎or๎a๎quali๎ฟed๎technician.
โข Nozzles๎not๎supplied๎with๎the๎appliance๎must๎be๎ordered๎from๎After๎Sales๎Service.
โข Adjust the minimum setting of the taps.
NOTE: when liquid petroleum gas is used (G30/G31), the minimum gas setting screw must be tightened as far as it will go.
IMPORTANT: should you experience dif๎ฟculty in turning the burners knobs, please contact the After Sales Service for the replacement of the burner tap
if found to be faulty.
REPLACING THE INJECTORS (see the injector table in the Instruction)
โข ).Remove grids (A
โข ).Extract๎burners๎(B
โข Using a socket spanner of the appropriate size unscrew the injector ( ), unscrew the injector to C
be replaced.
โข Replace it with the injector suitable for the new type of gas.
โข ).Re-assemble the injector in (D
โข ). If you have a multiple crown burner use side spanner to replace the injector (E
Before๎installing๎the๎hob,๎remember๎to๎af๎ฟx๎the๎gas๎calibration๎plate๎supplied๎with๎the๎injectors๎in๎
such๎a๎way๎that๎it๎covers๎the๎existing๎information๎relating๎to๎gas๎calibration.
ADJUSTING MINIMUM GAS SETTING OF TAPS
To ensure that the minimum setting is correctly adjusted, remove the knob and proceed as follows:
โข tighten๎screw๎to๎reduce๎the๎๎ame๎height๎(-);
โข loosen๎screw๎to๎increase๎the๎๎ame๎height๎(+)
The๎adjustment๎must๎be๎performed๎with๎the๎tap๎in๎minimum๎gas๎setting๎position๎(small๎๎ame)๎ .
โข The primary air of the burners does not need to be adjusted.
โข At๎this๎stage,๎light๎up๎the๎burners๎and๎turn๎the๎knobs๎from๎max๎position๎ to minimum position ๎to๎check๎๎ame๎stability.
Upon๎completion๎of๎adjustment,๎reseal๎using๎sealing๎wax๎or๎an๎equivalent๎material.
REFERENCE TO LOCAL REGULATIONS
GB
Provision for ventilation
The room in which the appliance is installed must have an air supply to current standards. B.S. 5440 - Part 2
All rooms require a permanent vent in addition to the openable window.
If there are other fuel burning appliances in the same room should be consulted to determine the air vent requirements.B.S. 5440 - Part 2
If the appliance is installed in a cellar or basement, it is advisable to provide an air vent of 65 cm, irrespective of the room volume.
RNINGWA
