GCO2D & GCO2C
GAS CONVECTION OVENS
MODEL
GCO2D ML-114569
GCO2C ML-114571
INSTALLATION &
OPERATION MANUAL
MODEL GCO2D
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
P.O. BOX 696
LOUISVILLE, KY 40201-0696
FORM 30975 Rev. D (12-07)
– 2 –
IMPORTANT FOR YOUR SAFETY
THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL GAS
EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND
ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL.
POST IN A PROMINENT LOCATION THE INSTRUCTIONS TO BE FOLLOWED IN THE
EVENT THE SMELL OF GAS IS DETECTED. THIS INFORMATION CAN BE OBTAINED
FROM THE LOCAL GAS SUPPLIER.
IMPORTANT
IN THE EVENT A GAS ODOR IS DETECTED, SHUT DOWN
UNITS AT MAIN SHUTOFF VALVE AND CONTACT THE
LOCAL GAS COMPANY OR GAS SUPPLIER FOR SERVICE.
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
Im pro pe r in s tal l at i on, adju s t m ent,
alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operating
and maintenance instructions thoroughly before
installing or servicing this equipment.
IN THE EVENT OF A POWER FAILURE, DO NOT ATTEMPT
TO OPERATE THIS DEVICE.
© VULCAN-HART COMPANY, 1996
– 3 –
INSTALLATION, OPERATION AND CARE OF
GCO2D & GCO2C
GAS CONVECTION OVENS
KEEP THIS MANUAL FOR FUTURE REFERENCE
GENERAL
Model GCO2D Gas Convection Oven is a single cavity oven, featuring a solid state temperature control
and 1-hour dial timer. Model GCO2C features a programmable controller. Each oven is equipped with a
25,000 BTU/hr burner and 1/2 HP (0.37 kw) electric motor. Porcelain interior is standard. Each oven is
furnished with five racks; additional oven racks are optional.
Two single ovens can be ordered with a stacking kit for mounting one oven on top of the other.
A single oven may be installed on an open stand with lower storage rack (optional).
Your Vulcan Gas Convection Oven is produced with quality workmanship and material. Proper installation,
usage and maintenance of your oven will result in many years of satisfactory performance.
It is suggested that you thoroughly read this entire manual and carefully follow all of the instructions
provided.
INSTALLATION
Before installing, verify that the electrical service and type of gas supply (natural or L.P.) agree with the
specifications on the oven rating plate, located on the inside of the top front cover. If the supply and
eqipment requirements do not agree, do not proceed with installation. Contact your dealer or Vulcan-Hart
Company immediately.
UNPACKING
This oven was inspected before leaving the factory. The transportation company assumes full responsibility
for safe delivery upon acceptance of the shipment. Immediately after unpacking the oven, check for
possible shipping damage. If this oven is found to be damaged, save the packaging material and contact
the carrier within 15 days of delivery.
Do not use the door or its handle to lift the oven.
LOCATION
The equipment area must be kept free and clear of combustibles. Clearance from combustible or non-
combustible construction of at least 3" (7.6 cm) on the sides and 3" (7.6 cm) at the back are required. The
installation location must allow adequate clearance for servicing and proper operation.
The oven must be installed so that the flow of combustion and ventilation air will not be obstructed.
Adequate clearance for air openings into the combustion chamber must be provided. Make sure there is
an adequate supply of air in the room to allow for combustion of gas at the oven burners.
