PJD6252L/PJD6551W/PJD7326/
PJD7526W/PJD7720HD
DLP Projector
User Guide
Model No. VS16443/VS15913/VS16444/VS16445/VS16483
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
ZZZYLHZVRQLFFRP LQ (QJOLVKRULQ VSHFL¿F ODQJXDJHV XVLQJWKH 5HJLRQDOVHOHFWLRQ
box in the upper right corner of our website. “Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual”
i
Compliance Information
FCC Statement
This device complies with part 15 of FCC Rules. Operation is subject to the follow-
ing two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses, and can radiate radio frequency energy, and
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
yReorient or relocate the receiving antenna.
yIncrease the separation between the equipment and receiver.
yConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
yConsult the dealer or an experienced radio/TV technician for help.
Warning:<RXDUHFDXWLRQHGWKDWFKDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHG
by the party responsible for compliance could void your authority to operate the
equipment.
For Canada
CAN ICES-3 (B)/NMB-3(B)
CE Conformity for European Countries
The device complies with the EMC Directive 2014/30/EU and Low Voltage
Directive 2014/35/EU.
Following information is only for EU-member states:
The mark is in compliance with the Waste Electrical and Electronic
Equipment Directive 2012/19/EU (WEEE).
The mark indicates the requirement NOT to dispose the equipment
including any spent or discarded batteries or accumulators as unsorted
municipal waste, but use the return and collection systems available.
If the batteries, accumulators and button cells included with this equipment,
display the chemical symbol Hg, Cd, or Pb, then it means that the battery
has a heavy metal content of more than 0.0005% Mercury or more than,
0.002% Cadmium, or more than 0.004% Lead.
ii
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this unit near water.
6. Clean with a soft, dry cloth.
7. Do not block any ventilation openings. Install the unit in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
RURWKHUGHYLFHVLQFOXGLQJDPSOL¿HUVWKDWSURGXFHKHDW
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade and the third
SURQJDUHSURYLGHGIRU\RXUVDIHW\,IWKHSURYLGHGSOXJGRHVQRW¿WLQWR\RXU
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs.
Convenience receptacles and the point where they exit from the unit. Be sure
that the power outlet is located near the unit so that it is easily accessible.
 2QO\XVHDWWDFKPHQWVDFFHVVRULHVVSHFL¿HGE\WKHPDQXIDFWXUHU
 8VHRQO\ZLWKWKHFDUWVWDQGWULSRGEUDFNHWRUWDEOHVSHFL¿HGE\
the manufacturer, or sold with the unit. When a cart is used, use
caution when moving the cart/unit combination to avoid injury from
tipping over.
13. Unplug this unit when unused for long periods of time.
 5HIHUDOOVHUYLFLQJWRTXDOL¿HGVHUYLFHSHUVRQQHO6HUYLFLQJLVUHTXLUHGZKHQWKH
unit has been damaged in any way, such as: if the power-supply cord or plug is
damaged, if liquid is spilled onto or objects fall into the unit, if the unit is exposed
to rain or moisture, or if the unit does not operate normally or has been dropped.
iii
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive
2011/65/EU of the European Parliament and the Council on restriction of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Directive) and is deemed to comply with the maximum concentration values issued
by the European Technical Adaptation Committee (TAC) as shown below:
Substance
Proposed Maximum
Concentration
Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex III
of the RoHS2 Directives as noted below:
Examples of exempted components are:
1. 0HUFXU\LQFROGFDWKRGHÀXRUHVFHQWODPSVDQGH[WHUQDOHOHFWURGHÀXRUHVFHQW
lamps (CCFL and EEFL) for special purposes not exceeding (per lamp):
(1) Short length ( 500 mm): maximum 3.5 mg per lamp.≦
(2) Medium length ( 500 mm and 1,500 mm): maximum 5 mg per lamp.＞≦
(3) Long length ( 1,500 mm): maximum 13 mg per lamp.＞
2. Lead in glass of cathode ray tubes.
3. /HDGLQJODVVRIÀXRUHVFHQWWXEHVQRWH[FHHGLQJE\ZHLJKW
4. Lead as an alloying element in aluminium containing up to 0.4% lead by weight.
5. Copper alloy containing up to 4% lead by weight.
6. Lead in high melting temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead).
7. Electrical and electronic components containing lead in a glass or ceramic other
than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.
iv
Copyright Information
Copyright © ViewSonic ® Corporation, 2016. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks
of Microsoft Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered
trademarks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association.
DPMS and DDC are trademarks of VESA.
PS/2, VGA and XGA are registered trademarks of International Business Machines
Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors
or omissions contained herein; nor for incidental or consequential damages resulting
from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves
WKHULJKWWRFKDQJHSURGXFWVSHFL¿FDWLRQVZLWKRXWQRWLFH,QIRUPDWLRQ
ment may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means,
for any purpose without prior written permission from ViewSonic Corporation.
Product Registration
To fulfill possible future product needs, and to receive additional product information
as it becomes available, please visit your region section on ViewSonic’s website to
register your product online.
The ViewSonic CD also provides an opportunity for you to print the product
registration form. Upon completion, please mail or fax to a respective ViewSonic
office. To find your registration form, use the directory “:\CD\Registration”.
Registering your product will best prepare you for future customer service needs.
Please print this user guide and fill the information in the “For Your Records” section.
For additional information, please see the “Customer Support” section in this guide.
For Your Records
Product Name: PJD6252L/PJD6551W/PJD7326/PJD7526W/PJD7720HD
ViewSonic DLP Projector
Model Number: VS16443/VS15913/VS16444/VS16445/VS16483
Document Number: PJD6252L/PJD6551W/PJD7326/PJD7526W/PJD7720HD_
UG_ENG Rev. 1B 05-04-16
Serial Number: ________________________________________
Purchase Date: ________________________________________
Product disposal at end of product life
The lamp in this product contains mercury which can be dangerous to you and the
environment. Please use care and dispose of in accordance with local, state or
federal laws.
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic
website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx
1
Table of contents
Important safety
instructions .......................2
Introduction......................4
Projector features ................................. 4
Shipping contents................................. 5
Projector exterior view......................... 6
Controls and functions ......................... 7
Positioning your
projector..........................12
Choosing a location............................ 12
Projection dimensions ........................13
Connection ......................16
Connecting a computer or monitor .... 17
Connecting Video source devices ...... 18
Playing sound through the projector.. 20
Using the cable management cover (for
selected models).................................21
Operation ........................22
Starting up the projector.....................22
Using the menus................................. 23
Utilizing the password function ......... 24
Switching input signal........................26
Adjusting the projected image ........... 27
Magnifying and searching for details. 29
Selecting the aspect ratio ................... 30
Optimizing the image......................... 31
Setting the presentation timer ............35
Hiding the image................................ 36
Locking control keys.......................... 36
Creating your own startup screen....... 36
Operating in a high altitude
environment....................................... 37
Using the CEC function..................... 37
Using the 3D functions ...................... 38
Controlling the projector through a LAN
environment (for selected models) .... 39
Using the projector in standby mode. 46
Adjusting the sound ........................... 46
Shutting down the projector .............. 48
Menu operation.................................. 49
Maintenance ...................59
Care of the projector.......................... 59
Using the dust filter (optional accessory)
........................................................... 59
Lamp information.............................. 61
Troubleshooting .............64
Specifications ..................65
Projector specifications...................... 65
Dimensions ........................................ 67
Ceiling mount installation ................. 67
Tripod mount installation .................. 67
Timing chart ...................................... 68
Copyright information...72
Appendix.........................73
IR control table .................................. 73
RS232 command table....................... 74
2
Important safety instructions
Your projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that you
follow the instructions mentioned in this manual and marked on the product.
Safety Instructions
1. Please read this manual before you operate your projector. Save it for future
reference.
2. Do not look straight at the projector lens during operation. The intense light beam
may damage your eyes.
3. Refer servicing to qualified service personnel.
4. Always open the lens shutter or remove the lens cap when the projector lamp is
on.
5. In some countries, the line voltage is NOT stable. This projector is designed to operate
safely within a mains voltage between 100 to 240 volts AC, but could fail if power
cuts or surges of ±10 volts occur. In areas where the mains voltage may fluctuate
or cut out, it is recommended that you connect your projector through a power
stabilizer, surge protector or uninterruptible power supply (UPS).
6. Do not block the projection lens with any objects when the projector is under
operation as this could cause the objects to become heated and deformed or even
cause a fire. To temporarily turn off the lamp, press BLANK on the projector or
remote control.
7. The lamp becomes extremely hot during operation. Allow the projector to cool for
approximately 45 minutes prior to removing the lamp assembly for replacement.
8. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps
beyond the rated life could cause them to break on rare occasions.
9. Never replace the lamp assembly or any electronic components unless the projector is
unplugged.
10. Do not place this product on an unstable cart, stand, or table. The product may fall,
sustaining serious damage.
11. Do not attempt to disassemble this projector. There are dangerous high voltages inside
which may cause death if you should come into contact with live parts. The only user
serviceable part is the lamp which has its own removable cover.
Under no circumstances should you ever undo or remove any other covers. Refer
servicing only to suitably qualified professional service personnel.
12. Do not place this projector in any of the following environments.
- Space that is poorly ventilated or confined. Allow at least 50 cm clearance from walls
and free flow of air around the projector.
- Locations where temperatures may become excessively high, such as the inside of a
car with all windows rolled up.
- Locations where excessive humidity, dust, or cigarette smoke may contaminate optical
components, shortening the projector's life span and darkening the picture.
- Locations near fire alarms
- Locations with an ambient temperature above 40°C / 104°F
- Locations where the altitudes are higher than 3000 m (10000 feet).
3
13. Do not block the ventilation holes. If the ventilation holes are seriously obstructed,
overheating inside the projector may result in a fire.
- Do not place this projector on a blanket, bedding or any other soft surface.
- Do not cover this projector with a cloth or any other item.
- Do not place inflammables near the projector.
14. Always place the projector on a level, horizontal surface during operation.
- Do not use if tilted at an angle of more than 10 degrees left to right, nor at angle of
more than 15 degrees front to back. Using the projector when it is not fully horizontal
may cause a malfunction of, or damage to, the lamp.
15. Do not stand the projector on end vertically. Doing so may cause the projector to fall
over, causing injury or resulting in damage to the projector.
16. Do not step on the projector or place any objects upon it. Besides probable physical
damage to the projector, doing so may result in accidents and possible injury.
17. Do not place liquids near or on the projector. Liquids spilled into the projector may
cause it to fail. If the projector does become wet, disconnect it from the power
supply's wall socket and call your local service center to have the projector serviced.
18. This product is capable of displaying inverted pictures for ceiling mount installation.
Use only qualified ceiling mount kit for mounting the projector and ensure it is
securely installed.
19. When the projector is under operation, you may sense some heated air and odor from
its ventilation grill. It is a normal phenomenon and not a product defect.
20. Do not use the Security bar for transporting or installation. It should be used with a
commercially available theft prevention cable.
Safety instructions for ceiling mounting of the
projector
We want you to have a pleasant experience using your projector, so we need to bring this
safety matter to your attention to prevent damage to person and property.
If you intend to mount your projector on the ceiling, we strongly recommend that you use a
proper fitting projector ceiling mount kit and that you ensure it is securely and safely
installed.
If you use an inappropriate projector ceiling mount kit, there is a safety risk that the
projector may fall from the ceiling due to an improper attachment through the use of the
wrong gauge or length screws.
You can purchase a projector ceiling mount kit from the place you purchased your projector.
We recommend that you also purchase a separate security cable and attach it securely to
both the anti-theft lock slot on the projector and the base of the ceiling mount bracket. This
will perform the secondary role of restraining the projector should its attachment to the
mounting bracket become loose.
4
Introduction
Projector features
The projector integrates high-performance optical engine projection and a user-friendly
design to deliver high reliability and ease of use.
The projector offers the following features.
• Dynamic mode adjusting the power consumption of the lamp according to the
brightness of the image being projected
• Power saving function decreasing the power consumption of the lamp by up to 70%
when no input signal can be detected for a set period of time.
• Presentation timer for better control of time during presentations
•LAN Settings allowing management of projector status from a remote computer (for selected
models)
• Supports 3D display
• Color Management allowing color adjustments to your liking
• Less than 0.5W power consumption when power saving mode is turned on
• Screen Color correction allowing projection on surfaces of several predefined colors
• Quick auto search speeding up the signal detecting process
• Color modes providing choices for different projection purposes
• Selectable quick power off function
• One-key auto-adjustment to display the best picture quality
• Digital keystone correction and 4 corner adjustment (for selected models) to correct
distorted images
• Adjustable color management control for data/video display
• Ability to display 1.07 billion colors
• Multi-language On-Screen Display (OSD) menus
• Switchable normal and economic modes to reduce the power consumption
• Component HDTV compatibility (YPb rP )
• HDMI CEC (Consumer Electronics Control) function allows synchronized power ON/
OFF operation between the projector and a CEC-compatible DVD player device
connected to the HDMI input of the projector
The apparent brightness of the projected image will vary depending on the ambient lighting
conditions, selected input signal contrast/brightness settings, and is directly proportional to
projection distance.
The lamp brightness will decline over time and may vary within the lamp manufacturers
specifications. This is normal and expected behavior.
5
Shipping contents
Carefully unpack and verify that you have all of the items shown below. If any of these
items are missing, please contact your place of purchase.
Standard accessories
The supplied accessories will be suitable for your region, and may differ from those
illustrated.
Optional accessories
1. Replacement lamp (RLC-092 for PJD6252L. RLC-093 for PJD6551W. RLC-104 for
PJD7326. RLC-105 for PJD7526W. RLC-100 for PJD7720HD.)
2. Soft carry case
3. VGA-Component adapter
4. Dust filter
Projector Power Cord
VGA Cable (for selected models) Multi-language User
Manual CD Quick Start Guide
Remote Control & Batteries
Cable management
cover (for selected
models)
6
Projector exterior view
1. External control panel
(See "Projector" on page 7 for
details.)
2. Lamp cover
3. Vent (heated air exhaust)
4. Front IR remote sensor
5. Adjuster foot
6. Focus and Zoom rings
7. HDMI/MHL port
8. Projection lens
9. Audio signal output socket
10. Audio signal input socket 2/
Microphone
11. Audio signal input socket 1
12. S-Video input socket
13. Video input socket
14. HDMI port
15. RGB signal output socket
16. RGB (PC)/Component video
(YPbPr/YCbCr) signal input
socket-2
17. RGB (PC)/Component video
(YPbPr/YCbCr) signal input
socket-1
18. Mini USB port
19. RS-232 control port
20. RJ45 LAN input port
21. AC power cord inlet
22. Security bar for anti-theft lock slot
Warning
• THIS APPARATUS MUST BE EARTHED.
• When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring,
or connect the power plug to an easily accessible socket-outlet near the unit. If a fault should
occur during operation of the unit, operate the disconnect device to switch the power supply
off, or disconnect the power plug.
1
2
3
4
5
6
8
7
Front/upper side
PJD7720HD
PJD6252L/PJD6551W/PJD7326/PJD7526W
22
21
15 18
19 20
17
13 1412109 11 16
Rear/lower side
7
Controls and functions
Projector
1. Focus ring
Adjusts the focus of the projected image.
2. Zoom ring
Adjusts the size of the projected image.
3. Menu
Turns on the On-Screen Display (OSD)
menu.
Exit
Goes back to previous OSD menu, exits
and saves menu settings.
4. / / / (Keystone keys)
Manually corrects distorted images
resulting from an angled projection.
Left/Right/Up/Down
Selects the desired menu items and makes
adjustments.
5. Power
Toggles the projector between standby
mode and Power ON.
6. Source
Displays the source selection bar.
(Help)
Displays the HELP menu by a long press
for 3 seconds.
7. Enter
Enacts the selected On-Screen Display
(OSD) menu item.
Displays the Corner Adj. page. (PJD7326/
PJD7526W only)
8. (My Button)
Allows user to define a short cut key on
this button, and the function item is
selected in OSD menu.
9. (Power indicator light)
Lights up or flashes when the projector is
under operation.
10. (Temperature indicator light)
Lights up red if the projector's
temperature becomes too high.
11. (Lamp indicator light)
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem.
12. Color Mode
Selects an available picture setup mode.
13. / (Keystone keys)
Manually corrects distorted images
resulting from an angled projection.
14. Left
Selects the desired menu items and makes
adjustments.
Blank
Hides the screen picture.
15. Right
Selects the desired menu items and makes
adjustments.
(Panel Key Lock)
Activates panel key lock. To unlock the
panel keys, long press for 3 seconds on .
1
2
3
4
5
6
7
4
8
9
10
11
412
4
1
2
3
14
5
6
7
8
9
10
11
1512
PJD7326/PJD7526W PJD6252L/PJD6551W/PJD7720HD
13
13
8
Remote control
To use the remote mouse control keys
(Page Up, Page Down, , and ), see
"Using the remote mouse control" on
page 10 for details.
1. Power
Toggles the projector between standby
mode and Power ON.
2. Source selection keys
• /COMP1 COMP2
Selects D-Sub / Comp. 1 or D-Sub /
Comp. 2 source for display.
•HDMI
Selects HDMI source for display.
3. Auto Sync
Automatically determines the best
picture timings for the displayed
image.
4. / / / (Keystone keys)
( )PJD7326/PJD7526W
/ (Keystone keys) (PJD6252L/
PJD6551W/PJD7720HD)
Manually corrects distorted images
resulting from an angled projection.
Left/Right/Up/Down
Selects the desired menu items and
makes adjustments.
5. Enter
Enacts the selected On-Screen Display
(OSD) menu item.
Displays the Corner Adj. page.
(PJD7326/PJD7526W only)
6. Menu
Turns on the On-Screen Display
(OSD) menu.
7. (Left mouse button)
Performs the same function as the left
mouse button when the mouse mode is
activated.
Only available when a PC input signal
is selected.
8. (Right mouse button)
Performs the same function as the
right mouse button when the mouse
mode is activated.
Only available when a PC input signal
is selected.
COMP1 COM P2 HDMI
So urce
PgUp
Mo use Pat t er n Blank
PgDn
Eco
Mo de
Co lo r
Mo de
Audio
Mo de
Au t o
Sy nc
Men u Exi t
E n t er
1
2
6
7
3
4
15
16
18
21
22
14
17
19
20
25
23
26
24
5
8
12
9
13
10
11
4
44
COMP1 COM P2 HDM I
So urc e
Enter
Men u 3D Exit
PgUp
Mouse
Pa t tern
Bla nk
PgDn
Ec o
Mo de
Co lo r
Mo de
Au t o
Sync
1
2
6
7
3
4
5
8
28
9
13
10
11
4
4
15
16
18
21
22
14
27
19
20
25
23
29
24
4
PJD7326/PJD7526W
PJD6252L/PJD6551W PJD7720HD
9
Operating the LASER pointer
The Laser Pointer is a presentation aid for professionals. It emits colored light when you
press it. The laser beam is visible. It is necessary to press and hold Laser for continuous
output.
Do not look into the laser light window or shine the laser light beam on yourself or others. See
the warning messages on the back of the remote control prior to using it.
The laser pointer is not a toy. Parents should be mindful of the dangers of laser energy and
keep this remote control out of the reach of children.
Remote control code
The projector can be assigned to 8 different remote control codes, 1 to 8. When several
adjacent projectors are in operation at the same time, switching the remote control codes
9. Mouse
Switches between the normal and mouse
modes.
PgUp PgDn, , , : active after pressing
Mouse. An icon appears on the screen to
indicate the activation of the mouse mode.
Only available when a PC input signal is
selected.
10. (Panel Key Lock)
Activates panel key lock. To unlock the
panel keys, press
11. (Presentation Timer)
Displays the presentation timer settings
menu.
12. (Volume)
Displays the volume adjustment bar.
13. Eco Mode
Selects a lamp mode.
14. LED indicator
15. (My Button)
Allows user to define a short cut key on the
remote control, and the function item is
selected in OSD menu.
16. Source
Displays the source selection bar.
17. Laser
Emits visible laser pointer light for
presentation purposes.
18. Exit
Goes back to previous OSD menu, exits
and saves menu settings.
19. PgUp (Page Up)/PgDn (Page Down)
Operates your display software program
(on a connected PC) which responds to
page up/down commands (like Microsoft
PowerPoint) when the mouse mode is
activated.
Only available when a PC input signal is
selected.
20. Pattern
Displays embedded test pattern.
21. Blank
Hides the screen picture.
22. (Help)
Displays the HELP menu.
23. (Mute)
Toggles the projector audio between on
and off.
24. (Zoom)
Displays the zoom bar that magnifies or
reduces the projected picture size.
25. Color Mode
Selects an available picture setup mode.
26. Audio Mode
Selects an audio mode.
27. 3D
Displays the 3D settings menu.
28. (Volume Up)
Increases the volume level.
29. (Volume Down)
Decreases the volume level.
10
can prevent interference from other remote controls. Set the remote control code for the
projector first before changing that for the remote control.
To switch the code for the projector, select from among 1 to 8 in the SYSTEM SETTING:
ADVANCED > Remote Control Code menu.
To switch the code for the remote control, press ID set and
the number button corresponding to the remote control
code set in the projector OSD together for 5 seconds or
more. The initial code is set to 1. When the code is
switched to 8, the remote control can control every
projector.
If different codes are set on the projector and remote control,
there will be no response from the remote control. When that
happens, a message will display to remind you to switch the
code for the remote control.
Using the remote mouse control
The capability of operating your computer with the remote control gives you more
flexibility when delivering presentations.
1. Connect the projector to your PC or notebook with a USB cable prior to using the
remote control in place of your computer’s mouse. See "Connecting a computer" on
page 17 for details.
2. Set the input signal to D-Sub / Comp. 1 or D-Sub / Comp. 2.
3. Press Mouse on the remote control to switch from the normal mode to the mouse
mode. An icon appears on the screen to indicate the activation of the mouse mode.
4. Perform the desired mouse controls on your remote control.
• To move the cursor on the screen, press / / / .
• To left-click, press .
• To right-click, press .
• To operate your display software program (on a connected PC) which responds to
page up/down commands (like Microsoft PowerPoint), press PgUp/PgDn.
• To return to the normal mode, press Mouse again or other keys except for the
mouse related multi-function keys.
Remote control effective range
The Infra-Red (IR) remote control is located on the front
of the projector. The remote control must be held at an
angle within 30 degrees perpendicular to the projector's
IR remote control sensor to function correctly. The
distance between the remote control and the sensor should
not exceed 8 meters (~ 26 feet).
Make sure that there are no obstacles between the remote
control and the IR sensor on the projector that might
obstruct the infra-red beam.
COMP1 COMP2 HDMI
S ource
PgUp
Mouse Patt e rn Blank
PgDn
Eco
Mode
Color
Mode
Audio
Mode
Auto
S ync
Me nu Exi t
Ent e r
Eco
Mode Color
Mode
Audio
Mode
COMP1 COMP2 HDMI
Sourc e
Ent e r
Me nu 3D Exit
PgUp
Mouse
Patte rn
Blank
PgDn
Eco
Mode Color
Mode
Auto
Sy nc
PJD7326/PJD7526W
PJD6252L/PJD6551W
Eco
Mode Color
Mode
PJD7720HD
App rox. 30°
11
Replacing the remote control batteries
1. To open the battery cover, turn the remote control over to view its back, press on the
finger grip on the cover and pull it up in the direction of the arrow as illustrated.
2. Remove any existing batteries (if necessary) and install two AAA batteries observing
the battery polarities as indicated in the base of the battery compartment. Positive (+)
goes to positive and negative (-) goes to negative.
3. Refit the cover by aligning it with the base and pushing it back down into position.
Stop when it clicks into place.
WARNING
• Avoid leaving the remote control and batteries in an excessive heat or humid environment
like the kitchen, bathroom, sauna, sunroom or in a closed car.
• Replace only with the same or equivalent type recommended by the battery manufacturer.
• Dispose of the used batteries according to the manufacturer's instructions and local
environment regulations for your region.
• Never throw the batteries into a fire. There may be danger of an explosion.
• If the batteries are drained or if you will not be using the remote control for an extended
period of time, remove the batteries to avoid damage to the remote control from possible
battery leakage.
14
PJD6551W/PJD7526W
(a) Screen
Size
[inch (cm)]
16:10 image on a 16:10 Screen 16:10 image on a 4:3 Screen
(b) Projection
distance [m (inch)] (c) Image
height
[cm (inch)]
(d) Vertical
offset
[cm (inch)]
(b) Projection
distance [m (inch)]
(c) Image
height
[cm
(inch)]
(d) Vertical
offset
[cm (inch)]
min. max. min. max.
60 (152) 2.0 (79) 2.2 (87) 81 (32) 0.0 (0.0) 1.9 (74) 2.1 (82) 76 (30) 0.0 (0.0)
70 (178) 2.3 (92) 2.6 (101) 94 (37) 0.0 (0.0) 2.2 (87) 2.4 (95) 89 (35) 0.0 (0.0)
80 (203) 2.7 (105) 2.9 (115) 108 (42) 0.0 (0.0) 2.5 (99) 2.8 (109) 102 (40) 0.0 (0.0)
90 (229) 3.0 (118) 3.3 (130) 121 (48) 0.0 (0.0) 2.8 (111) 3.1 (123) 114 (45) 0.0 (0.0)
100 (254) 3.3 (131) 3.7 (144) 135 (53) 0.0 (0.0) 3.1 (124) 3.5 (136) 127 (50) 0.0 (0.0)
120 (305) 4.0 (157) 4.4 (173) 162 (64) 0.0 (0.0) 3.8 (149) 4.2 (163) 152 (60) 0.0 (0.0)
150 (381) 5.0 (197) 5.5 (217) 202 (79) 0.0 (0.0) 4.7 (186) 5.2 (204) 191 (75) 0.0 (0.0)
180 (457) 6.0 (236) 6.6 (260) 242 (95) 0.0 (0.0) 5.7 (223) 6.2 (245) 229 (90) 0.0 (0.0)
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(c)
(b)
(e)
(f)
(d)
(f): Center of lens(e): Screen
• 16:10 image on a 16:10 screen
• 16:10 image on a 4:3 screen
(a)
(d)
(c)
(b)
(e)
(f)
15
PJD7720HD
There is 3% tolerance among these numbers due to optical component variations. It is
recommended that if you intend to permanently install the projector, you should physically
test the projection size and distance using the actual projector in situ before you permanently
install it, so as to make allowance for this projector's optical characteristics. This will help you
determine the exact mounting position so that it best suits your installation location.
(a) Screen
Size
[inch (cm)]
16:9 image on a 16:9 Screen 16:9 image on a 4:3 Screen
(b) Projection
distance [m (inch)] (c) Image
height
[cm (inch)]
(d) Vertical
offset
[cm (inch)]
(b) Projection
distance [m (inch)]
(c) Image
height
[cm
(inch)]
(d) Vertical
offset
[cm (inch)]
min. max. min. max.
50 (127) 1.6 (64) 1.8 (71) 62 (25) 5 (2.0) 1.5 (59) 1.6 (65) 57 (23) 4.6 (1.8)
60 (152) 2.0 (77) 2.2 (85) 75 (29) 6 (2.4) 1.8 (71) 2.0 (78) 69 (27) 5.5 (2.2)
70 (178) 2.3 (90) 2.5 (99) 87 (34) 7 (2.7) 2.1 (83) 2.3 (91) 80 (32) 6.4 (2.5)
80 (203) 2.6 (103) 2.9 (113) 100 (39) 8 (3.1) 2.4 (94) 2.6 (104) 91 (36) 7.3 (2.9)
90 (229) 2.9 (116) 3.2 (127) 112 (44) 9 (3.5) 2.7 (106) 3.0 (117) 103 (41) 8.2 (3.2)
100 (254) 3.3 (128) 3.6 (141) 125 (49) 10 (3.9) 3.0 (118) 3.3 (130) 114 (45) 9.1 (3.6)
110 (279) 3.6 (141) 3.9 (155) 137 (54) 11 (4.3) 3.3 (130) 3.6 (143) 126 (50) 10.1 (4.0)
120 (305) 3.9 (154) 4.3 (170) 149 (59) 12 (4.7) 3.6 (142) 4.0 (156) 137 (54) 11.0 (4.3)
130 (330) 4.2 (167) 4.7 (184) 162 (64) 13 (5.1) 3.9 (153) 4.3 (169) 149 (59) 11.9 (4.7)
140 (356) 4.6 (180) 5.0 (198) 174 (69) 14 (5.5) 4.2 165 4.6 (182) 160 (63) 12.8 (5.0)
150 (381) 4.9 (193) 5.4 (212) 187 (74) 15 (5.9) 4.5 (177) 4.9 (195) 171 (68) 13.7 (5.4)
(c)
(b)
(e)
(f)
(d)
(a)
(a)
(c)
(b)
(e)
(f)
(d)
(a)
(c)
(b)
(e)
(f)
(d)
(f): Center of lens(e): Screen
• 16:9 image on a 16:9 screen
• 16:9 image on a 4:3 screen
(a)
(d)
(c)
(b)
(e)
(f)
16
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
In the connections shown below, some cables may not be included with the projector (see
"Shipping contents" on page 5). They are commercially available from electronics stores.
The connection illustrations below are for reference only. The rear connecting jacks available
on the projector vary with each projector model.
For detailed connection methods, see pages 17-20.
5 7748 16 31 2
9
PJD7720HD
PJD6252L/PJD6551W/PJD7326/PJD7526W
7
Notebook or
desktop computer
Speakers
or
A/V device
Monitor
(DVI)
(VGA)
Microphone
or
17
Connecting a computer or monitor
Connecting a computer
1. Take the supplied VGA cable and connect one end to the D-Sub output socket of the
computer.
2. Connect the other end of the VGA cable to the COMPUTER IN 1 or COMPUTER
IN 2 signal input socket on the projector.
3. If you wish to use the remote mouse control function, take a USB cable and connect
the larger end to the USB port of the computer, and smaller end to the MINI USB
socket on the projector. See "Using the remote mouse control" on page 10 for details.
Many notebooks do not turn on their external video ports when connected to a projector.
Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a
function key labeled CRT/LCD or a function key with a monitor symbol on the notebook. Press
FN and the labeled function key simultaneously. Refer to your notebook's documentation to
find your notebook's key combination.
Connecting a monitor
If you want to view your presentation close-up on a monitor as well as on the screen, you
can connect the MONITOR OUT signal output socket on the projector to an external
monitor with a VGA cable following the instructions below:
1. Connect the projector to a computer as described in "Connecting a computer" on page
17.
2. Take a suitable VGA cable (only one supplied) and connect one end of the cable to the
D-Sub input socket of the video monitor.
Or if your monitor is equipped with a DVI input socket, take a VGA to DVI-A cable
and connect the DVI end of the cable to the DVI input socket of the video monitor.
3. Connect the other end of the cable to the MONITOR OUT socket on the projector.
The MONITOR OUT output only works when COMPUTER IN 1 connection is made to the
projector.
To use this connection method when the projector is in standby mode, turn on the Active VGA
Out function under the SOURCE > Standby Settings menu.
1. VGA cable
2. VGA to DVI-A cable
3. USB cable
4. Component Video to VGA (D-Sub)
adapter cable
5. S-Video cable
6. Video cable
7. Audio cable
8. HDMI cable
9. HDMI/MHL dongle
18
Connecting Video source devices
You can connect your projector to various Video source devices that provide any one of the
following output sockets:
• HDMI
• Component Video
• S-Video
• Video (composite)
You need only connect the projector to a Video source device using just one of the above
connecting methods, however each provides a different level of video quality. The method
you choose will most likely depend upon the availability of matching terminals on both the
projector and the Video source device as described below:
Best video quality
The best available video connection method is HDMI. If your source device is equipped
with an HDMI socket, you can enjoy uncompressed digital video quality.
See "Connecting an HDMI device" on page 19 for how to connect the projector to an HDMI
source device and other details.
If no HDMI source is available, the next best video signal is Component video (not to be
confused with composite video). Digital TV tuner and DVD players output Component
video natively, so if available on your devices, this should be your connection method of
choice in preference to (composite) video.
See "Connecting a Component Video source device" on page 19 for how to connect the
projector to a component video device.
Better video quality
The S-Video method provides a better quality analog video than standard composite Video.
If you have both composite Video and S-Video output terminals on your Video source
device, you should elect to use the S-Video option.
See "Connecting an S-Video source device" on page 20 for how to connect the projector to
an S-Video device.
Least video quality
Composite Video is an analog video and will result in a perfectly acceptable, but less than
optimal result from your projector, being the least video quality of the available methods
described here.
See "Connecting a composite Video source device" on page 20 for how to connect the
projector to a composite Video device.
Connecting audio
The projector has built-in mono speaker(s) which is designed to provide basic audio
functionality accompanying data presentations for business purposes only. It is not designed
for, nor intended for stereo audio reproduction use as might be expected in home theater or
home cinema applications. Any stereo audio input (if provided), is mixed into a common
mono audio output through the projector speaker.
If you wish, you can make use of the projector (mixed mono) speaker in your presentations,
and also connect separate amplified speakers to the Audio Out socket of the projector. The
audio output is a mixed mono signal and controlled by the projector Volume and Mute
settings.
20
Connecting an S-Video source device
Examine your Video source device to determine if it has an unused S-Video output socket
available:
• If so, you can continue with this procedure.
• If not, you will need to reassess which method you can use to connect to the device.
1. Take an S-Video cable and connect one end to the S-Video output socket of the Video
source device.
2. Connect the other end of the S-Video cable to the S-VIDEO socket on the projector.
The projector is only capable of playing mixed mono audio, even if a stereo audio input is
connected. See "Connecting audio" on page 18 for details.
If the selected video image is not displayed after the projector is turned on and the correct
video source has been selected, check that the Video source device is turned on and
operating correctly. Also check that the signal cables have been connected correctly.
If you have already made a Component Video connection between the projector and this S-
Video source device using Component Video connections, you need not connect to this
device using an S-Video connection as this makes an unnecessary second connection of
poorer picture quality. See "Connecting Video source devices" on page 18 for details.
Connecting a composite Video source device
Examine your Video source device to determine if it has a set of unused composite Video
output sockets available:
• If so, you can continue with this procedure.
• If not, you will need to reassess which method you can use to connect to the device.
1. Take a Video cable and connect one end to the composite Video output socket of the
Video source device.
2. Connect the other end of the Video cable to the VIDEO socket on the projector.
The projector is only capable of playing mixed mono audio, even if a stereo audio input is
connected. See "Connecting audio" on page 18 for details.
If the selected video image is not displayed after the projector is turned on and the correct
video source has been selected, check that the Video source device is turned on and
operating correctly. Also check that the signal cables have been connected correctly.
You need only connect to this device using a composite Video connection if Component Video
and S-Video inputs are unavailable for use. See "Connecting Video source devices" on page
18 for details.
Playing sound through the projector
You can make use of the projector (mixed mono) speaker in your presentations, and also
connect separate amplified speakers to the AUDIO OUT socket of the projector.
If you have a separate sound system, you will most likely want to connect the audio output
of your Video source device to that sound system, instead of to the mono audio projector.
You can also use a microphone to output the sound through the projector speaker when the
SYSTEM SETTING: ADVANCED > Audio Settings > Audio In 2 menu is set to
Microphone. See "Adjusting the Audio In 2 setting (for selected models)" on page 47 for
details.
Once connected, the audio can be controlled by the projector On-Screen Display (OSD)
menus. See "Adjusting the sound" on page 46 for details.
21
About the microphone input
• If you wish to use a microphone, connect a 3.5 mini jack cable microphone to the
projector.
• You can use a wireless microphone as long as a wireless module is attached to the
projector’s microphone input jack and it works well with the associated devices. To
ensure a quality use of the wireless microphone, it is recommended that your
microphone conforms to the specifications listed in the table below.
• There are two ways to adjust microphone volumes.
• Directly set microphone volume levels in the SYSTEM SETTING:
ADVANCED > Audio Settings > Microphone Volume menu.
• Set projector volume levels in the SYSTEM SETTING: ADVANCED > Audio
Settings > Audio Settings > Audio Volume menu, or press (Volume) on the
remote control. (The projector volume setting will affect the microphone volume.)
• If the microphone is not working, check the volume setting and cable connection.
• You might get feedback noise from the microphone when you are too close to the
speaker of the projector. Move the microphone away from the speaker of the projector.
The greater volume you require, the greater distance you need to be away from the
speaker to prevent the noise.
Using the cable management cover (for selected
models)
This cable management cover helps you to conceal and organize the cables connected to the
back of the projector. It is especially useful when the projector is ceiling-mounted or wall-
mounted.
1. Make sure that all the cables are properly
connected to the projector.
2. Attach the cable management cover to the
back of the projector.
3. Tighten the screws that secure the cable
management cover.
Signal Parameter Min Type Max
Microphone
Transducer Principle Dynamic
Impedance 300 1K ohm
Frequency response 600 16k Hz
22
Operation
Starting up the projector
1. Plug the power cord into the projector and into a
wall socket. Turn on the wall socket switch
(where fitted).
2. (If available) Remove the lens cap.
3. Press Power to start the projector. As soon as
the lamp lights up, a "Power On Ring Tone" will
be heard. The Power indicator light stays blue
when the projector is on.
(If necessary) Rotate the focus ring to adjust the image clearness.
If the projector is still hot from previous activity, it will run the cooling fan for approximately 60
seconds before energizing the lamp.
To maintain the lamp life, once you turn the projector on, wait at least 5 minutes before turning
it off.
To turn off the ring tone, see "Turning off the Power On/Off Ring Tone" on page 47 for details.
4. If the projector is activated for the first time, select your OSD language following the
on-screen instructions.
5. Switch all of the connected equipment on.
6. The projector will start to search for input signals. The current input signal being
scanned appears in the upper left corner of the screen. If the projector doesn't detect a
valid signal, the message 'No Signal' will continue to be displayed until an input
signal is found.
You can also press Source to select your desired input signal. See "Switching input
signal" on page 26 for details.
If the frequency/resolution of the input signal exceeds the projector's operating range, you will
see the message 'Out of Range' displayed on a blank screen. Please change to an input signal
which is compatible with the projector's resolution or set the input signal to a lower setting.
See "Timing chart" on page 68 for details.
24
Utilizing the password function
For security purposes and to help prevent unauthorized use, the projector includes an option
for setting up password security. The password can be set through the On-Screen Display
(OSD) menu. For details of the OSD menu operation, please refer to "Using the menus" on
page 23.
You will be inconvenienced if you enable the password function yet forget the password
somehow. Do make a note of your password, and keep the note in a safe place for later recall.
Setting a password
Once a password has been set and the power on lock is enabled, the projector cannot be used
unless the correct password is entered every time the projector is started.
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Advanced
> Security Settings menu.
2. Press Enter and the Security Settings page is displayed.
3. Highlight Power On Lock and select On by pressing /.
4. As pictured to the right, the four arrow keys
( , , , ) respectively represent 4 digits (1,
2, 3, 4). According to the password you desire to
set, press the arrow keys to enter six digits for the
password.
5. Confirm the new password by re-entering the
new password.
Once the password is set, the OSD menu returns
to the Security Settings page.
6. To leave the OSD menu, press Exit.
If you forget the password
If the password function is activated, you will be asked
to enter the six-digit password every time you turn on
the projector. If you enter the wrong password, the
password error message as pictured to the right is
displayed lasting for 5 seconds, and the message
'INPUT PASSWORD' follows. You can retry by
entering another six-digit password, or if you did not record the password in this user
manual, and you absolutely do not remember it, you can use the password recall procedure.
See "Entering the password recall procedure" on page 25 for details.
If you enter an incorrect password 5 times in succession, the projector will automatically
shut down in a short time.
INPUT PASSWORD
BackMENU
Password Error
Please try again.
25
Entering the password recall procedure
1. Press and hold Auto Sync on the remote control
for 3 seconds. The projector will display a coded
number on the screen.
2. Write down the number and turn off your
projector.
3. Seek help from the local service center to decode
the number. You may be required to provide
proof of purchase documentation to verify that
you are an authorized user of the projector.
The "XXX" shown in the above screenshot are numbers that vary depending on different
projector models.
Changing the password
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Advanced
> Security Settings > Change Password menu.
2. Press Enter. The message 'INPUT CURRENT PASSWORD' is displayed.
3. Enter the old password.
• If the password is correct, another message 'INPUT NEW PASSWORD' is
displayed.
• If the password is incorrect, the password error message is displayed lasting for
5 seconds, and the message 'INPUT CURRENT PASSWORD' is displayed
for your retry. You can press Exit to cancel or try another password.
4. Enter a new password.
5. Confirm the new password by re-entering the new password.
6. You have successfully assigned a new password to the projector. Remember to enter
the new password next time the projector is started.
7. To leave the OSD menu, press Exit.
The digits being input will be displayed as asterisks on-screen. Do make a note of your
password, and then keep the note in a safe place for later recall.
Disabling the password function
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Advanced
> Security Settings > Power On Lock menu.
2. Press / to select Off.
3. The message 'INPUT PASSWORD' is displayed. Enter the current password.
• If the password is correct, the OSD menu returns to the Security Settings page
with 'Off' shown in the row of Power On Lock. You will not have to enter the
password next time you turn on the projector.
• If the password is incorrect, the password error message is displayed lasting for
5 seconds, and the message 'INPUT PASSWORD' is displayed for your retry.
You can press Exit to cancel or try another password.
Though the password function is disabled, you need to keep the old password in hand should
you ever need to re-activate the password function by entering the old password.
Please write down the recall code,
and contact ViewSonic
Customer Center.
Recall code:
X X X X
RECALL PASSWORD
ExitMENU
26
Switching input signal
The projector can be connected to multiple devices at the same time. However, it can only
display one full screen at a time.
Be sure the Quick Auto Search function in the SOURCE menu is On if you want the
projector to automatically search for the signals.
You can also manually select the desired signal by
pressing one of the source selection keys on the
remote control, or cycle through the available input
signals.
1. Press Source. A source selection bar is
displayed.
2. Press / until your desired signal is
selected and press Enter.
Once detected, the selected source information
will be displayed on the screen for seconds. If
there are multiple devices connected to the
projector, repeat steps 1-2 to search for another
signal.
Please see "Projector specifications" on page 65 for
the native display resolution of this projector. For best
display picture results, you should select and use an
input signal which outputs at this resolution. Any
other resolutions will be scaled by the projector
depending upon the 'aspect ratio' setting, which may
cause some image distortion or loss of picture clarity.
See "Selecting the aspect ratio" on page 30 for
details.
Changing HDMI input settings
In the unlikely event that you connect the projector
to a device (like a DVD or Blu-ray player) via the
projector’s HDMI input and the projected picture
displays wrong colors, please change the color space
to an appropriate one that fits the color space setting
of the output device.
To do this:
1. Open the OSD menu and go to the PICTURE > HDMI Settings menu.
2. Press Enter.
3. Highlight HDMI Format and press / to select a suitable color space according
to the color space setting of the output device connected.
•RGB: Sets the color space as RGB.
•YUV: Sets the color space as YUV.
•Auto: Sets the projector to detect the color space setting of the input signal
automatically.
4. Highlight HDMI Range and press / to select a suitable HDMI color range
according to the color range setting of the output device connected.
•Enhanced: Sets the HDMI color range as 0 - 255.
PJD6252L/PJD6551W/
PJD7326/PJD7526W
PJD7720HD
28
Correcting keystone
Keystoning refers to the situation where the projected image becomes a trapezoid due to
angled projection.
To correct this, besides adjusting the height of the projector, you will need to manually
correct it following one of these steps.
• Using the remote control
1. Press / / / to display the Keystone
correction page.
2. Press to correct keystoning at the top of
the image. Press to correct keystoning at
the bottom of the image. Press to correct
keystoning at the right side of the image.
Press to correct keystoning at the left side
of the image.
• Using the OSD menu
For PJD6252L/PJD6551W/PJD7720HD:
1. Open the OSD menu and go to the
DISPLAY > Keystone menu.
2. Press Enter. The Keystone correction page is displayed.
3. Press to correct keystoning at the top of the image or press to correct
keystoning at the bottom of the image.
For PJD7326/PJD7526W:
1. Open the OSD menu and go to the DISPLAY > Keystone menu.
2. Press Enter. The Keystone correction page is displayed.
3. Highlight Vertical and press to correct keystoning at the top of the image or press
to correct keystoning at the bottom of the image.
4. You can also highlight Horizontal and press to correct keystoning at the right side
of the image. Press to correct keystoning at the left side of the image.
Press /Press /
Press / Press /
(PJD7326/PJD7526W only)
29
Adjusting 4 corners (PJD7326/PJD7526W)
You can manually adjusts the shape and size of an image that is unevenly rectangular on all
sides.
1. To display the Corner Adj. page, you can do
one of the followings:
i. Press Enter.
ii. Open the OSD menu and go to the
DISPLAY > Corner Adj. menu and
press Enter. The Corner Adj. page is
displayed.
2. Press / / / to select the corner you
wish to adjust and press Enter.
3. Press / to select an adjustment method
that suits your need and press Enter.
4. As indicated on the screen ( / for a 45-
degree angle adjustment and / / / for
a 90-degree angle adjustment), press / /
/ to adjust its shape and size. You can
press Menu or Exit to go back to a previous
step. A long press for 2 seconds on Enter will
reset the settings on the corner that you chose.
Adjusting keystone will reset the Corner Adj. settings.
After the Corner Adj. settings have been modified, some aspect ratios or timings are not
available. When that happens, reset the settings on all 4 corners.
The following messages will appear:
Magnifying and searching for details
If you need to find the details on the projected picture, magnify the picture. Use the
direction arrow keys for navigating the picture.
• Using the remote control
1. Press on the remote control to display the Zoom bar.
2. Press repeatedly to magnify the picture to a desired size.
3. To navigate the picture, press Enter to switch to the paning mode and press the
directional arrows ( , , , ) to navigate the picture.
Corner Adj.
Press [Menu/Exit] to save or exit.
[Corner Adj.] will be reset if adjust [Keystone].
Hold [Enter] for 2 sec. to reset.
A long press for 2 seconds on
Enter when this page displays
will reset the settings on all 4
corners.
Corner Adj.
Press [Enter] after selection.
Press [Menu/Exit] to return.
Hold [Enter] for 2 sec. to reset.
Indicates the corner that you
selected.
Please re-set the corner adj.
or switch to other aspect ratio
Screen Color
Aspect Ratio
Corner Adj.
Phase
H. Size
Zoom
Off
Auto
MENU Exit
Keystone
16
0
Analog RGB
Position
30
4. To reduce size of the picture, press Enter to switch back to the zoom in/out
functionality, and press repeatedly until it is restored to the original size. You can
also press Auto Sync on the remote control to restore the picture to its original size.
• Using the OSD menu
1. Open the OSD menu and go to the DISPLAY > Zoom menu.
2. Press Enter. The Zoom bar is displayed.
3. Repeat steps 2-4 in the section of Using the remote control above.
This adjustable range may vary depending on different aspect ratios.
The picture can only be navigated after it is magnified. You can further magnify the picture
while searching for details.
Selecting the aspect ratio
The 'aspect ratio' is the ratio of the image width to the image height. Most analog TV and
computers are in 4:3 ratio, and digital TV and DVDs are usually in 16:9 ratio.
With the advent of digital signal processing, digital display devices like this projector can
dynamically stretch and scale the image output to a different aspect than that of the image
input signal.
To change the projected image ratio (no matter what aspect the source is):
1. Open the OSD menu and go to the DISPLAY > Aspect Ratio menu.
2. Press / to select an aspect ratio to suit the format of the video signal and your
display requirements.
About the aspect ratio
In the pictures below, the black portions are inactive areas and the white portions are active
areas. OSD menus can be displayed on those unused black areas.
1. Auto: Scales an image proportionally to fit the
projector's native resolution in its horizontal
width. This is suitable for the incoming image
which is neither in 4:3 nor 16:9 and you want to
make most use of the screen without altering the
image's aspect ratio.
2. 4:3: Scales an image so that it is displayed in the
center of the screen with a 4:3 aspect ratio. This
is most suitable for 4:3 images like computer
monitors, standard definition TV and 4:3 aspect
DVD movies, as it displays them without aspect
alteration.
3. 16:9 (PJD6252L/PJD7326/PJD7720HD):
Scales an image so that it is displayed in the
center of the screen with a 16:9 aspect ratio. This
is most suitable for images which are already in
a 16:9 aspect, like high definition TV, as it
displays them without aspect alteration.
16:10 picture
15:9 picture
4:3 picture
16:9 picture
31
4. 16:10 (PJD6551W/PJD7526W): Scales an
image so that it is displayed in the center of the
screen with a 16:10 aspect ratio. This is most
suitable for images which are already in a 16:10
aspect, as it displays them without aspect
alteration.
5. Panorama (PJD6551W/PJD7526W/
PJD7720HD): Scales a 4:3 image vertically and
horizontally in a non-linear manner so that it
fills the screen.
6. 2.35:1: Scales an image so that it is displayed in
the center of the screen with a 2.35:1 aspect
ratio without aspect alteration.
7. Anamorphic (PJD6551W/PJD7526W/
PJD7720HD): Scales a 2.35:1 aspect image so
that it fills the screen.
Optimizing the image
Selecting a picture mode
The projector is preset with several predefined picture modes so that you can choose one to
suit your operating environment and input signal picture type.
To select an operation mode that suits your need, you can follow one of the following steps.
• Press Color Mode repeatedly until your desired mode is selected.
• Go to the PICTURE > Color Mode menu and press / to select a desired mode.
Picture modes for different types of signals
The picture modes available for different types of signals are listed below.
1. Brightest mode: Maximizes the brightness of the projected image. This mode is
suitable for environments where extra-high brightness is required, such as using the
projector in well lit rooms.
2. Dynamic mode: Is designed for presentations under daylight environment to match
PC and notebook coloring. In addition, the projector will optimize the image quality
using the dynamic PC function in accordance with the projected contents.
16:10 picture
4:3 picture
2.35:1 picture
2.35:1 picture
32
3. Standard mode: Is designed for presentations under daylight environment to match
PC and notebook coloring.
4. ViewMatch sRGB mode: Switches between high brightness performance and
accurate color performance.
5. Movie mode: Is appropriate for playing colorful movies, video clips from digital
cameras or DVs through the PC input for best viewing in a blackened (little light)
environment.
6. DICOM SIM mode (PJD7326/PJD7526W): Recommended for DICOM format files
in simulation mode.
DICON SIM mode is only for training or reference. It not used for actual diagnosis.
DICOM represents for the Digital Imaging and Communications in Medicine. This is a standard
created by the American College of Radiology and the National Electrical Manufacturers
Association. This standard specifies the method of digital image data to be transferred from
one system to another.
Selectable lamp modes may vary depending on the Color Mode selected.
Using Screen Color
In the situation where you are projecting onto a colored surface such as a painted wall which
may not be white, the Screen Color feature can help correct the projected picture’s colors to
prevent possible color difference between the source and projected pictures.
To use this function, go to the DISPLAY > Screen Color menu and press / to select a
color which is closest to the color of the projection surface. There are several precalibrated
colors to choose from: Whiteboard, Greenboard, and Blackboard. The effects of these
settings may vary depending on different models.
This function is only available when a PC or HDMI input signal is selected.
Fine-tuning the image quality in user modes
According to the detected signal type, there are some user-definable functions available.
You can make adjustments to these functions based on your needs.
Adjusting Brightness
Go to the PICTURE > Brightness menu and press / .
The higher the value, the brighter the image. And the
lower the setting, the darker the image. Adjust this
control so the black areas of the image appear just as
black and that detail in the dark areas is visible.
Adjusting Contrast
Go to the PICTURE > Contrast menu and press /.
The higher the value, the greater the contrast. Use this
to set the peak white level after you have previously
adjusted the Brightness setting to suit your selected
input and viewing environment.
Adjusting Color
Go to the PICTURE > Advanced > Color menu and press /.
Lower setting produces less saturated colors. If the setting is too high, colors on the image
will be overpowering, which makes the image unrealistic.
50
-30 +80
-30 0+40
33
This function is only available when the input signal is S-Video, Video, YPbPr (digital) or
YCbCr (digital).
Adjusting Tint
Go to the PICTURE > Advanced > Tint menu and press /.
The higher the value, the more reddish the picture becomes. The lower the value, the more
greenish the picture becomes.
This function is only available when the input signal is S-Video, Video, YPbPr (digital) or
YCbCr (digital).
Adjusting Sharpness
Go to the PICTURE > Advanced > Sharpness menu and press /.
The higher the value, the sharper the picture becomes. The lower the value, the softer the
picture becomes.
This function is only available when the input signal is S-Video, Video, YPbPr (digital) or
YCbCr (digital).
Adjusting Brilliant Color
Go to the PICTURE > Advanced > Brilliant Color menu and press /.
This feature utilizes a new color-processing algorithm and system level enhancements to
enable higher brightness while providing truer, more vibrant colors in the projected picture.
It enables a greater than 50% brightness increase in mid-tone images, which are common in
video and natural scenes, so the projector reproduces images in realistic and true colors. If
you prefer images with that quality, select a level that suits your need. If you don’t need it,
select Off.
Reducing image noise
Go to the PICTURE > Advanced > Noise Reduction menu and press /.
This function reduces electrical image noise caused by different media players. The higher
the setting, the less the noise.
This function is only available when a PC, Video or S-Video input signal is selected.
Selecting a gamma setting
Go to the PICTURE > Advanced > Gamma menu and select a preferred setting by
pressing /.
Gamma refers to the relationship between input source and picture brightness.
Selecting a Color Temperature
Go to the PICTURE > Color Temp. menu and press /.
The options available for color temperature settings vary according to the signal type
selected.
1. Cool: With the highest color temperature, Cool makes the image appear the most
bluish white than other settings.
2. Neutral: Makes images appear bluish white.
3. Normal: Maintains normal colorings for white.
4. Warm: Makes images appear reddish white.
Setting a preferred color temperature
1. Go to the PICTURE > Color Temp. menu.
34
2. Press / to select Cool, Neutral, Normal or Warm and press Enter.
3. Press / to highlight the item you want to change and adjust the values by
pressing /.
• / /Red Gain Green Gain Blue Gain: Adjusts the contrast levels of Red, Green,
and Blue.
• / /Red Offset Green Offset Blue Offset: Adjusts the brightness levels of Red,
Green, and Blue.
This function is only available when a PC input signal is selected.
Color Management
Only in permanent installations with controlled lighting levels such as boardrooms, lecture
theaters, or home theaters, should color management be considered. Color management
provides fine color control adjustment to allow for more accurate color reproduction, should
you require it.
If you have purchased a test disc which contains various color test patterns and can be used
to test the color presentation on monitors, TVs, projectors, etc., you can project any image
from the disc on the screen and enter the Color Management menu to make adjustments.
To adjust the settings:
1. Open the OSD menu and go to the PICTURE > Advanced > Color Management
menu.
2. Press Enter and the Color Management page is displayed.
3. Highlight Primary Color and press / to select a color from among Red, Yellow,
Green, Cyan, Blue, or Magenta.
4. Press to highlight Hue and press / to select its range. Increase in the range
will include colors consisted of more proportions of its two adjacent colors.
Please refer to the illustration to the right for
how the colors relate to each other.
For example, if you select Red and set its
range at 0, only pure red in the projected
picture will be selected. Increasing its range
will include red close to yellow and red close
to magenta.
5. Press to highlight Saturation and adjust
its values to your preference by pressing /
. Every adjustment made will reflect to the
image immediately.
For example, if you select Red and set its
value at 0, only the saturation of pure red will
be affected.
Saturation is the amount of that color in a video picture. Lower settings produce less
saturated colors; a setting of “0” removes that color from the image entirely. If the saturation
is too high, that color will be overpowering and unrealistic.
6. Press to highlight Gain and adjust its values to your preference by pressing /.
The contrast level of the primary color you select will be affected. Every adjustment
made will reflect to the image immediately.
7. Repeat steps 3 to 6 for other color adjustments.
8. Make sure you have made all of the desired adjustments.
RED
BLUE
GREEN
Yellow
Cyan
Magenta
35
9. Press Exit to exit and save the settings.
Setting the presentation timer
Presentation timer can indicate the presentation time on the screen to help you achieve
better time management when giving presentations. Follow these steps to utilize this
function:
• Using the remote control
1. Press on the remote control and press repeatedly or / to select a Timer
Period.
2. Press Enter or wait for 3 seconds to activate the timer.
3. To display the Presentation Timer page, select Advanced.
• Using the OSD menu
1. Go to the SYSTEM SETTING: BASIC > Advanced > Presentation Timer menu.
2. Press Enter to display the Presentation Timer page.
3. Highlight Timer Period and decide the time period by pressing /. The length of
time can be set from 1 to 5 minutes in 1-minute increments and 5 to 240 minutes in 5-
minute increments.
If the timer is already on, the timer will restart whenever the Timer Period is reset.
4. Press to highlight Timer Display and choose if you want the timer to show up on
the screen by pressing ./
5. Press to highlight Timer Position and set the timer position by pressing /.
6. Press to highlight Timer Counting Direction and select your desired counting
direction by pressing /.
7. Press to highlight Sound Reminder and decide if you want to activate sound
reminder by pressing /. If you select On, a double beep sound will be heard at
the last 30 seconds of counting down/up, and a triple beep sound will be produced
when the timer is up.
8. To activate the presentation timer, press and press / to highlight Start
Counting and press Enter.
9. A confirmation message displays. Highlight Yes and press Enter to confirm. You will
see the message “Timer is On” displaying on the screen. The timer starts counting
when the timer is on.
Selection Description
Always Displays the timer on screen throughout the presentation
time.
1 min/2 min/3 min Displays the timer on screen in the last 1/2/3 minute(s).
Never Hides the timer throughout the presentation time.
Top-Left Bottom-Left Top-Right Bottom-Right
Selection Description
Count Up Increases from 0 to the preset time.
Count Down Decreases from the preset time to 0.
36
To cancel the timer, perform the following steps:
1. Press on the remote control or go to the SYSTEM SETTING: BASIC >
Advanced > Presentation Timer menu.
2. Highlight Off. Press Enter. A confirmation message displays.
3. Highlight Yes and press Enter to confirm. You will see the message “Timer is Off”
displaying on the screen.
Hiding the image
In order to draw the audience's full attention to the presenter, you can press BLANK to hide
the screen image. Press any key on the projector or remote control to restore the image. The
word 'BLANK' appears at the lower right corner of the screen while the image is hidden.
You can set the blank time in the SYSTEM SETTING: BASIC > Blank Timer menu to
let the projector return the image automatically after a period of time when there is no action
taken on the blank screen.
Once Blank is pressed, the projector enters Eco mode automatically.
CAUTION
Do not block the projection lens from projecting as this could cause the blocking object to
become heated and deformed or even cause a fire.
Locking control keys
With the control keys on the projector locked, you can prevent your projector settings from
being changed accidentally (by children, for example). When the Panel Key Lock is on, no
control keys on the projector will operate except Power.
1. Press (Panel Key Lock), or go to the SYSTEM SETTING: ADVANCED >
Advanced > Panel Key Lock menu
2. Press / to select On.
3. A confirmation message is displayed. Select Yes to confirm.
To release panel key lock, press and hold on the projector for 3 seconds.
You can also use the remote control to enter the SYSTEM SETTING: ADVANCED >
Advanced > Panel Key Lock menu and press / to select Off.
Keys on the remote control are still functional when panel key lock is enabled.
If you press Power to turn off the projector without disabling panel key lock, the projector
will still be in locked status the next time it is turned on.
Creating your own startup screen
In addition to selecting the projector preset startup screen from among Black, Blue, or
ViewSonic screen, you can make your own startup screen that is a picture projected from
your computer or video source.
To create your own startup screen:
1. Project the picture you want to use as your startup screen from either a computer or
video source.
2. Open the OSD menu and go to the SYSTEM SETTING: BASIC > Screen Capture
menu.
3. Press Enter.
38
Using the 3D functions
This projector features 3D function which enables you to enjoy 3D movies, videos, and
sporting events in a more realistic way by presenting the depth of the images. You need to
wear a pair of 3D glasses to view 3D images.
If the 3D signal is input from an HDMI 1.4a compatible device, the projector detects the
signal for 3D Sync information and once detected, it projects images in 3D format
automatically. In other cases, you may need to manually select a 3D Sync format for the
projector to project 3D images correctly.
To select a 3D Sync format:
1. Press 3D on the remote control to access the 3D Settings menu or go to the
SOURCE > 3D Settings menu.
2. Press Enter. The 3D Settings page is displayed.
3. Highlight 3D Sync and press Enter.
4. Press to select a 3D Sync setting and then press Enter to confirm.
When the 3D Sync function is on:
• The brightness level of the projected image will decrease.
• The Color Mode cannot be adjusted.
• The Zoom function can only magnify the pictures to limited sizes.
If you discover the inversion of the 3D image depth, set the 3D Sync Invert function to “Invert”
to correct the problem.
39
Controlling the projector through a LAN
environment (for selected models)
The projector supports Crestron® software. With correct settings for the LAN Control
Settings menu, you can manage the projector from a computer using a web browser when
the computer and the projector are properly connected to the same local area network.
Configuring the LAN Control Settings
If you are in a DHCP environment:
1. Take a RJ45 cable and connect one end to the RJ45 LAN input jack of the projector
and the other end to the RJ45 port.
2. Open the OSD menu and go to the SOURCE > LAN Control Settings menu.
3. Press Enter. The LAN Control Settings page is displayed.
4. Highlight LAN Control Settings and press / to select DHCP ON.
5. Press to highlight Apply and press Enter.
6. Please wait for around 15 - 20 seconds, and then re-enter the LAN Control Settings
page. The Projector IP Address, , Subnet Mask Default Gateway, and DNS Server
settings will be displayed. Note down the IP address displayed in the Projector IP
Address row.
If the Projector IP Address still does not appear, contact your network administrator.
If the RJ45 cables are not properly connected, the Projector IP Address, Subnet Mask, Default
Gateway, and DNS Server settings will display 0.0.0.0. Make sure the cables are properly
connected and perform the procedures above again.
If you need to connect to the projector in its standby mode, set LAN Control to On in the
SOURCE > Standby Settings menu.
If you are in a non-DHCP environment:
1. Repeat steps 1-3 above.
2. Highlight LAN Control Settings and press / to select Static IP.
3. Contact your ITS administrator for information on the Projector IP Address, Subnet
Mask, Default Gateway, and DNS Server settings.
4. Press to select the item you want to modify and press Enter.
5. Press / to move the cursor and the press /to enter the value.
6. To save the settings, press Enter. If you do not want to save the settings, press Exit.
7. Press to highlight Apply and press Enter.
(An example of connection)
40
If the RJ45 cables are not properly connected, the Projector IP Address, Subnet Mask, Default
Gateway, and DNS Server settings will display 0.0.0.0. Make sure the cables are properly
connected and perform the procedures above again.
If you wish to connect to the projector in its standby mode, be sure you have selected Static
IP and obtained the Projector IP Address, Subnet Mask, Default Gateway, and DNS Server
information when the projector is on.
Controlling the projector through a web browser
Once you have the correct IP address for the projector and the projector is on or in standby
mode, you can use any computer that is on the same local area network to control the
projector.
If you are using Microsoft Internet Explorer, make sure it is version 7.0 or higher.
The screen shots in this manual are for reference only, and may differ from the actual design.
1. Enter the address of the projector in the address bar of your browser and press Enter.
2. The main page of the Network Control appears.
Accessing to Network Settings or Email Alert page requires Administrator password. The
default password is "0000".
3. This page allows you to make adjustments to the AMX and SNMP settings. In the
AMX device discover row, when ON is selected, the projector can be detected by
controllers of AMX connected to the same network. For the Details of AMX Device
Discovery, visit the AMX web site at http://www.amx.com/.
5
4
3
41
4. If your projector is connected to a network which supports Simple Mail Transfer
Protocol (SMTP), you can configure it to alert you via email on significant events.
5. The Crestron (e-Control) page displays the Crestron e-Control user interface. See
"About Crestron e-Control®" on page 43 for details.
42
Please pay attention to the limitation of input length (including space and other punctuation
keys) in the list blow:
/ > < $ % + \ ' " are prohibited.
Category Item Input Length Maximum Number
of Characters
Network Settings
Network
DHCP/Manual (N/A)
IP Address XXX.XXX.XXX.XXX
Subnet Mask XXX.XXX.XXX.XXX
Gateway XXX.XXX.XXX.XXX
DNS Server XXX.XXX.XXX.XXX
AMX device discovery (N/A)
Password
Administrator (N/A)
New Password 4
Confirm Password 4
SNMP
SysLocation 22
SysName 22
SysContact 22
Email Alert
Email Setting
To 40
Cc 40
Subject 40
From 40
SMTP Setting
Server 30
User Name 21
Password 14
Alert Condition
Fan Error (N/A)
Lamp Error (N/A)
Over Temperature (N/A)
Lamp Time Alert (N/A)
Submit (N/A)
Issue Test Mail (N/A)
43
About Crestron e-Control®
1. The Crestron e-Control® page provides a variety of virtual keys to control the
projector or adjust the projected pictures.
i. These buttons function the same as the ones on the OSD menus or remote control.
See "2. PICTURE menu" on page 54 and "Projector" on page 7 for details.
ii. To switch between input signals, click on your desired signal.
The Menu button can also be used to go back to previous OSD menus, exit and save menu
settings.
The source list varies according to the connectors available on the projector.
When you use the projector control panel or remote control to change the OSD menu settings,
it may take a while for the web browser to synchronize these changes with the projector.
2. The tools page allows you to manage the projector, configure the LAN control
settings and secure access of remote network operation on this projector.
i. This section is only used with the Crestron Control System. Please contact
Creston or refer to its user manual for setup information.
ii. You can name the projector, keep track of its location and the person in charge of
it.
i
i
i
ii
You can press
/ to
reveal more
buttons.
i iv
iii
ii
v
vi
44
iii. You can adjust the LAN Control Settings.
iv. Once set, access to the remote network operation on this projector has been
password-protected.
v. Once set, access to the tools page has been password-protected.
To prevent errors, only input the English alphabet and digits on the tools page.
After making the adjustments, press the Send button and the data will be saved for the
projector.
vi. Press Exit to go back to the remote network operation page.
Please pay attention to the limitation of input length (including space and other punctuation
keys) in the list blow:
Category Item Input Length Maximum Number of
Characters
Crestron Control
IP Address 16
IP ID 4
Port 5
Projector
Projector Name 32
Location 32
Assigned To 32
Network Configuration
DHCP (Enabled) (N/A)
IP Address 16
Subnet Mask 16
Default Gateway 16
DNS Server 16
User Password
Enabled (N/A)
New Password 26
Confirm 26
Admin Password
Enabled (N/A)
New Password 26
Confirm 26
45
3. The info page displays the information and status of this projector.
4. After pressing the button “Contact IT Help”, the HELP DESK window will appear in
the upper right corner of the screen. You will be able to deliver messages to
RoomView™ software administrators/users who connect to the same local area
network.
For more information, visit http://www.crestron.com & www.crestron.com/getroomview.
**Crestron RoomView
On the “Edit Room” page, enter the IP Address (or hostname) as shown on the projector’s
on-screen display (OSD) menu, and “02” for IPID, “41794” for the reserved Crestron
control port.
About Crestron RoomView™ setting and command method, please access below website to
get RoomView™ User Guide and more information:
http://www.crestron.com/products/roomview_connected_embedded_projectors_devices/
resources.asp
Press Exit to
go back to the
remote network
operation page.
46
PJLink™, SNMP, AMX and Xpanel formats supported
This projector is PJLink™, SNMP V.1, AMX or Xpanel V1.10 compliant. For details,
please follow its user guide or website respectively to control and manage projectors.
Using the projector in standby mode
Some of the projector functions are available in standby mode (plugged in but not turned
on). To use these functions, be sure you have turned on the corresponding menus under
SOURCE > Standby Settings, and the cable connections are correctly made. For the
connection methods, see the Connection chapter.
Active VGA Out (for selected models)
Selecting On outputs a VGA signal when the COMPUTER IN 1 and COMPUTER OUT
sockets are correctly connected to devices. The projector outputs the signal received only
from COMPUTER IN 1.
Active Audio Out
Selecting On outputs an audio signal when the AUDIO IN 1 socket is correctly connected
to a proper device.
LAN Control (for selected models)
Selecting On allows the projector to provide the network function when it is in standby
mode. See "Controlling the projector through a LAN environment (for selected models)" on
page 39 for details.
Adjusting the sound
The sound adjustments made as below will have an effect on the projector speaker. Be sure
you have made a correct connection to the projector audio input/output jacks. See
"Connection" on page 15 for more details.
Adjusting the audio mode
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Audio
Settings > Audio Mode menu.
2. Press / to select a preferred audio mode.
If available, you can press Audio Mode on the remote control to select a preferred audio mode.
Muting the sound
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Audio
Settings > Mute menu.
2. Press / to select On.
If available, you can press on the remote control to toggle the projector audio between on
and off.
Adjusting the sound level
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Audio
Settings > Audio Volume menu.
2. Press / to select a desired sound level.
If available, you can press // on the remote control to adjust the projector’s sound
level.
47
Adjusting the Audio In 2 setting (for selected models)
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Audio
Settings > Audio In 2 menu.
2. Press / to decide the audio input source for the AUDIO IN 2/MIC port. This
will affect the connection method for different devices, and where the sound is from.
• When Audio is selected:
The selected input signal determines which sound will be played by the projector speaker, and
which sound will be output from the projector when AUDIO OUT is connected. For instance, if
you select a D-Sub / Comp. 1 source, the projector can play the sound received from AUDIO IN
1.
• When Microphone is selected:
Adjusting the microphone sound level
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Audio
Settings > Microphone Volume menu.
2. Press / to select a desired sound level.
This function is only available when the SYSTEM SETTING: ADVANCED > Audio Settings >
Audio In 2 menu is set to Microphone.
Turning off the Power On/Off Ring Tone
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Audio
Settings > Power On/Off Ring Tone menu.
2. Press / to select Off.
The only way to change Power On/Off Ring Tone is setting On or Off here. Setting the sound
mute or changing the sound level will not affect the Power On/Off Ring Tone.
Device COMPUTER IN 1 COMPUTER IN 2 Video/S-Video
Audio input port AUDIO IN 1 AUDIO IN 2 AUDIO IN 2
The projector can play
the sound from... AUDIO IN 1 AUDIO IN 2 AUDIO IN 2
Audio output port AUDIO OUT AUDIO OUT AUDIO OUT
Device COMPUTER IN 1 COMPUTER IN 2 Video/S-Video
Audio input port AUDIO IN 1 AUDIO IN 1 AUDIO IN 1
The projector can play
the sound from...
• AUDIO IN 1
• MIC
• AUDIO IN 1
• MIC
• AUDIO IN 1
• MIC
Audio output port AUDIO OUT AUDIO OUT AUDIO OUT
48
Shutting down the projector
1. Press Power and a confirmation message is
displayed prompting you.
If you don't respond in a few seconds, the
message will disappear.
2. Press Power a second time.
3. Once the cooling process finishes, a "Power
Off Ring Tone" will be heard. Disconnect the
power cord from the wall socket if the
projector will not be used in an extended
period of time.
To turn off the ring tone, see "Turning off the Power On/Off Ring Tone" on page 47 for details.
CAUTION
• To protect the lamp, the projector will not respond to any commands during the cooling
process.
• To shorten the cooling time, you can also activate the Quick Power Off function. See
"Quick Power Off" on page 55 for details.
• Do not unplug the power cord before the projector shutdown sequence is complete.
51
Main menu Sub-menu Options
4.
SYSTEM
SETTING:
BASIC
My Button
Auto (PJD6252L/PJD6551W/PJD7326/
PJD7526W)/Projection (Projector Position)/
Menu Position/Color Temp./Brightness/
Contrast/3D Settings/Screen Color/Splash
Screen/Message/Quick Auto Search/CEC/DCR/
Closed Caption (PJD6252L/PJD6551W/
PJD7326/PJD7526W)/Power Saving/Freeze/
INFORMATION/Aspect Ratio
Advanced
Pattern
Off/Test Card/Note Pad
/World Map/Stave/
Trellis Chart
Message On/Off
Presentation Timer
Timer Period
Timer Display
Timer Position
Timer Counting
Direction
Sound Reminder
Start Counting/Off
5.
SYSTEM
SETTING:
ADVANCED
High Altitude Mode On/Off
DCR On/Off
Audio Settings
Audio Mode Standard/Speech/
Entertainment
Mute On/Off
Audio Volume
Audio In 2 (PJD6252L/
PJD6551W/PJD7326/
PJD7526W)
Audio/Microphone
Microphone Volume
Power On/Off Ring
Tone On/Off
Closed Caption
(PJD6252L/
PJD6551W/
PJD7326/
PJD7526W)
Closed Caption Enable On/Off
Caption Version CC1/CC2/CC3/CC4
52
Main menu Sub-menu Options
5.
SYSTEM
SETTING:
ADVANCED
Lamp Settings
Lamp Mode Normal/Eco/Dynamic/
SuperEco
Reset Lamp Hours
Lamp Hours
Filter Settings
Filter Mode On/Off
Reset Filter Hours
Filter Hours
Remote Control Code 1/2/3/4/5/6/7/8
Advanced Security Settings Change Password
Power On Lock
Panel Key Lock Off/On
Reset Settings Reset/Cancel
6.
INFORMATION Current System Status
•Source
•Color Mode
•Resolution
•Color System
• IP Address
(PJD6252L/PJD6551W/
PJD7326/PJD7526W)
• MAC Address
(PJD6252L/PJD6551W/
PJD7326/PJD7526W)
•Firmware Version
54
Function Description
Advanced
Color
See "Adjusting Color" on page 32 for details.
Tint
See "Adjusting Tint" on page 33 for details.
Sharpness
See "Adjusting Sharpness" on page 33 for details.
Gamma
See "Selecting a gamma setting" on page 33 for details.
Brilliant Color
See "Adjusting Brilliant Color" on page 33 for details.
Noise Reduction
See "Reducing image noise" on page 33 for details.
Color Management
See "Color Management" on page 34 for details.
Reset Color
Settings Returns all color settings to the factory preset values.
Quick Auto
Search See "Switching input signal" on page 26 for details.
3D Settings See "Using the 3D functions" on page 38 for details.
Standby
Settings
See "Using the projector in standby mode" on page 46 for
details.
Auto Power On
Computer (PJD6252L/PJD6551W/PJD7326/PJD7526W)
Selecting Enable allows the projector to turn on automatically
once the VGA signal is fed through the VGA cable.
CEC
See "Using the CEC function" on page 37 for details.
Direct Power On
Selecting On allows the projector to turn on automatically
once the power is fed through the power cord.
2. PICTURE menu
3. SOURCE menu
55
Function Description
Smart Energy
Auto Power Off
See "Setting Auto Power Off" on page 61 for details.
Sleep Timer
See "Setting Sleep Timer" on page 61 for details.
Power Saving
See "Setting Power Saving" on page 61 for details.
Smart Restart
Selecting Enable enables you to restart the projector
immediately within 120 seconds after turning it off. After 120
seconds, if the projector is not turned on again, it will directly
enter the standby mode.
It takes some time to initiate this function. Make sure
the projector has been turned on for more than 4
minutes. If the projector is resumed by using the Smart
Restart feature, this function can be executed
immediately.
When Enable is selected, the Quick Power Off function
will be automatically set to “Enable”.
Quick Power
Off
Selecting Enable enables the function and the projector will
not enter the cooling process after being shut down. Selecting
Disable disables the function and the projector will enter
normal cooling process after being shut down.
If you attempt to restart the projector right after it’s been
turned off, it may not be turned on successfully and will
rerun its cooling procedure.
When Disable is selected, the Smart Restart function
will be automatically turned off.
Lamp SPA
Mode
(PJD7326/
PJD7526W)
Selecting Enable sets the projector’s cooling time after being
shut down to 180 seconds. If Disable is selected, the cooling
procedure will depend on the Smart Restart and Quick
Power Off settings.
When Enable is selected, the Smart Restart and Quick
Power Off functions will be automatically turned off.
LAN Control
Settings
(PJD6252L/
PJD6551W/
PJD7326/
PJD7526W)
See "Controlling the projector through a LAN environment
(for selected models)" on page 39 for details.
3. SOURCE menu
56
Function Description
Language Sets the language for the On-Screen Display (OSD) menus.
See "Using the menus" on page 23 for details.
Projector
Position See "Choosing a location" on page 12 for details.
Menu Settings
Menu Display Time
Sets the length of time the OSD will remain active after your
last key press. The range is from 5 to 30 seconds in 5-second
increments.
Menu Position
Sets the On-Screen Display (OSD) menu position.
Blank Timer See "Hiding the image" on page 36 for details.
Splash Screen Allows you to select which logo screen will be displayed
during projector start-up.
Screen Capture See "Creating your own startup screen" on page 36 for
details.
My Button Sets a hotkey on remote control.
Advanced
Pattern
The projector can display several test patterns. It helps you
adjust the image size and focus and check that the projected
image is free from distortion.
Message
Selecting On displays the current information on the screen
when the projector is detecting or searching for a signal.
Presentation Timer
See "Setting the presentation timer" on page 35 for details.
4. SYSTEM SETTING: BASIC menu
57
Function Description
High Altitude
Mode
A mode for operation in high altitude areas. See "Operating in
a high altitude environment" on page 37 for details.
DCR
Enables or disables the DCR (Dynamic Contrast Ratio)
function. Selecting On enables the function and the projector
will automatically switch the lamp mode between normal and
economic modes according to the input image detected.
This function is only available when a PC input signal is
selected.
After enabling DCR, frequent lamp mode switching may
shorten lamp life and noise level will vary during
operation.
Audio Settings See "Adjusting the sound" on page 46 for details.
Closed Caption
(PJD6252L/
PJD6551W/
PJD7326/
PJD7526W)
Closed Caption Enable
Activates the function by selecting On when the selected
input signal carries closed captions.
• Captions: An on-screen display of the dialogue, narration,
and sound effects of TV programs and videos that are
closed captioned (usually marked as "CC" in TV listings).
This function is only available when a Composite video
or S-Video input signal is selected and its system format
is NTSC.
Caption Version
Selects a preferred closed captioning mode. To view captions,
select CC1, CC2, CC3, or CC4 (CC1 displays captions in the
primary language in your area).
Lamp Settings
Lamp Mode
See "Setting Lamp Mode as Eco" on page 61 for details.
Reset Lamp Hours
Resets the lamp timer after new lamp is installed. For
changing the lamp, please contact qualified service personnel.
Lamp Hours
See "Getting to know the lamp hour" on page 61 for details on
how the total lamp hour is calculated.
Filter Settings See "Using the dust filter (optional accessory)" on page 59 for
details.
5. SYSTEM SETTING: ADVANCED menu
58
Function Description
Remote Control
Code See "Remote control code" on page 9 for details.
Advanced
Security Settings
See "Utilizing the password function" on page 24 for details.
Panel Key Lock
See "Locking control keys" on page 36 for details.
Reset Settings
Returns all settings to the factory preset values.
The following settings will still remain: Keystone,
OverScan, Language, Projector Position, High Altitude
Mode, Security Settings, Remote Control Code, 3D Sync.
Current System
Status
Source
Shows the current signal source.
Color Mode
Shows the selected mode in the PICTURE menu.
Resolution
Shows the native resolution of the input signal.
Color System
Shows input system format.
IP Address (PJD6252L/PJD6551W/PJD7326/PJD7526W)
Shows the IP address of your projector.
MAC Address (PJD6252L/PJD6551W/PJD7326/
PJD7526W)
Shows the MAC Address of your projector.
MAC Address stands for Media Access Control Address,
which is a physical layer address used to uniquely
identify a network node.
Firmware Version
Shows the current firmware version.
5. SYSTEM SETTING: ADVANCED menu
6. INFORMATION menu
59
Maintenance
Care of the projector
You need to keep the lens and/or filter (optional accessory) clean on a regular basis.
Never remove any parts of the projector. Contact your dealer when any part of the projector
needs replacing.
Cleaning the lens
Clean the lens whenever you notice dirt or dust on the surface.
• Use a canister of compressed air to remove dust.
• If there is dirt or smears, use lens-cleaning paper or moisten a soft cloth with lens
cleaner and gently wipe the lens surface.
CAUTION
Never rub the lens with abrasive materials.
Cleaning the projector case
Before you clean the case, turn the projector off using the proper shutdown procedure as
described in "Shutting down the projector" on page 48 and unplug the power cord.
• To remove dirt or dust, wipe the case with a soft, lint-free cloth.
• To remove stubborn dirt or stains, moisten a soft cloth with water and a neutral pH
detergent. Then wipe the case.
CAUTION
Never use wax, alcohol, benzene, thinner or other chemical detergents. These can damage the
case.
Storing the projector
If you need to store the projector for an extended time, please follow the instructions below:
• Make sure the temperature and humidity of the storage area are within the
recommended range for the projector. Please refer to "Specifications" on page 65 or
consult your dealer about the range.
• Retract the adjuster foot.
• Remove the battery from the remote control.
• Pack the projector in its original packing or equivalent.
Transporting the projector
It is recommended that you ship the projector with its original packing or equivalent.
Using the dust filter (optional accessory)
CAUTION
• It is recommended to clean the dust filter every 100 hours after the dust filter is installed.
• Be sure to turn off the projector and unplug it from power source before installing or
detaching the filter.
60
• If your projector is ceiling-mounted or is not easily accessible, pay special attention to
your personal safety when replacing the dust filter.
Installing the dust filter
1. Be sure to turn off the projector and unplug it
from power source.
2. As the arrows shown to the right, fit the filter
by aligning and inserting it into the projector
slots. Make sure it clicks into place.
For first time installation:
3. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED > Filter
Settings menu.
4. Press Enter and the Filter Settings page is displayed.
5. Highlight Filter Mode and press / to select On. The filter timer starts counting
and the projector will remind you to clean the filter when the filter is in use for over
100 hours.
Set Filter Mode to On only when using the projector after the dust filer (optional accessory) is
properly attached. Failing to do so will result in a shorter lamp life.
Obtaining the filter hour information
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED >
Filter Settings menu.
2. Press Enter. The Filter Settings page is displayed.
3. You will see the Filter Hours information on the menu.
Cleaning the dust filter
1. Be sure to turn off the projector and unplug it from power source.
2. Press the latches on the dust filter and remove the filter from the projector.
3. Use a small vacuum cleaner or a soft brush to sweep the dust on the filter away.
4. Re-install the dust filter.
Resetting the filter timer
5. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED >
Filter Settings menu.
6. Press Enter and the Filter Settings page is displayed.
7. Highlight Reset Filter Hours and press Enter. A warning message is displayed
asking if you want to reset the filter timer.
8. Highlight Reset and press Enter. The lamp time will be reset to '0'.
CAUTION
Remember to set Filter Mode to Off in the SYSTEM SETTING: ADVANCED > Filter Settings
menu when using the projector with the dust filter removed. Setting Filter Mode to Off does
not reset the filter timer. The timer will continue counting the next time you fit the filter back on
and set Filter Mode to On.
61
Lamp information
Getting to know the lamp hour
When the projector is in operation, the duration (in hours) of lamp usage is automatically
calculated by the built-in timer.
To obtain the lamp hour information:
1. Open the OSD menu and go to the SYSTEM SETTING: ADVANCED >
Lamp Settings menu.
2. Press Enter and the Lamp Settings page is displayed.
3. You will see the Lamp Hours information on the menu.
4. To leave the menu, press Exit.
Extending lamp life
The projection lamp is a consumable item. To keep the lamp life as long as possible, you
can do the following settings via the OSD menu.
Setting Lamp Mode as Eco
Using Eco mode reduces system noise and power consumption by 20%. If the Eco mode is
selected, the light output will be reduced and result in darker projected pictures.
Setting the projector in Eco mode also extends the lamp operation life. To set Eco mode, go
to the SYSTEM SETTING: ADVANCED > Lamp Settings > Lamp Mode menu and
press / to select Eco.
Setting Auto Power Off
This function allows the projector to turn off automatically after a set period of time once no
input source is detected to prevent unnecessary waste of lamp life.
1. Open the OSD menu and go to the SOURCE > Smart Energy menu.
2. Press Enter and the Smart Energy page is displayed.
3. Highlight Auto Power Off and press /.
4. If the preset time lengths are not suitable for your need, select Disable. The projector
will not automatically shut down in a certain time period.
Setting Sleep Timer
This function allows the projector to turn off automatically after a set period of time to
prevent unnecessary waste of lamp life.
1. Open the OSD menu and go to the SOURCE > Smart Energy menu.
2. Press Enter and the Smart Energy page is displayed.
3. Highlight Sleep Timer and press / .
4. If the preset time lengths are not suitable for your presentation, select Disable. The
projector will not automatically shut down in a certain time period.
Setting Power Saving
The projector lowers the power consumption if no input source is detected after 5 minutes to
prevent unnecessary waste of lamp life. You can further decide if you would like the
projector to turn off automatically after a set period of time.
1. Open the OSD menu and go to the SOURCE > Smart Energy menu.
2. Press Enter and the Smart Energy page is displayed.
62
3. Highlight Power Saving and press /.
4. When Enable is selected, the projector lamp will be changed to Eco
mode after no signal is detected for 5 minutes.
The lamp power will be changed to SuperEco mode after no
signal is detected for 20 minutes.
Timing of replacing the lamp
Please install a new lamp or consult your dealer when the Lamp indicator light lights up.
An old lamp may cause a malfunction in the projector and in some instances the lamp may
explode.
CAUTION
The Lamp indicator light and Temperature indicator light will light up if the lamp becomes too
hot. Turn the power off and let the projector cool for 45 minutes. If the Lamp indicator light or
Temperature indicator light still lights up after turning the power back on, please contact your
dealer. See "Indicators" on page 63 for details.
Replacing the lamp
Turn the power off and disconnect the projector from the power outlet. Please contact
qualified service personnel for changing the lamp.
Type number:
• PJD6252L: RLC-092
• PJD6551W: RLC-093
• PJD7326: RLC-104
• PJD7526W: RLC-105
• PJD7720HD: RLC-100
63
Indicators
Light Status & Description
Power events
Blue
Flashing Off Off Stand-by mode
Blue Off Off Powering up
Blue Off Off Normal operation
Blue
Flashing Off Off Normal power-down cooling (3 sec)
Red Off Off Downloading
Blue Blue Blue Burn in off
Lamp events
Blue
Flashing Off Red First Lamp-Lit error cooling (60 sec)
Off Off Red Lamp error in normal operation (30 sec)
Blue Off Red CW start fail (30 sec)
Thermal events
Off Red Off Fan 1 error (the actual fan speed is +25% outside the
desired speed.)
Off Red Red Fan 2 error (the actual fan speed is +25% outside the
desired speed.)
Off Red Blue Fan 3 error (the actual fan speed is +25% outside the
desired speed.)
Off Red Purple Fan 4 error (the actual fan speed is +25% outside the
desired speed.)
Red Red Red Thermal sensor 1 open error (the remote diode has an
open-circuit condition.)
Red Red Blue Thermal sensor 2 open error (the remote diode has an
open-circuit condition.)
Blue Red Red Thermal sensor 1 short error (the remote diode has an
short-circuit condition.)
Off Red Blue Thermal sensor 2 short error (the remote diode has an
short-circuit condition.)
Purple Red Red Temperature 1 error (over limited temperature)
Purple Red Blue Temperature 2 error (over limited temperature)
Off Blue Red Fan IC #1 I2C connection error
