Seite 1/20
P/N:110401109612X
Preface
Limited Warranty and Liability
Thank you for purchasing this brand new product. In order to use this product
safely and correctly, please read this manual thoroughly, especially the safety
notes.
After reading this manual, it is recommended to keep the manual at an easily
accessible place, preferably close to the device, for future reference.
Uni-Trend guarantees that the product is free from any defect in material and
workmanship within one year from the purchase date. This warranty does not
apply to damage caused by accident, negligence, misuse, modification,
contamination or mishandling. The dealer shall not be entitled to give any other
warranty on behalf of Uni-Trend. If you need warranty service within the warranty
period, please contact your seller directly.
Uni-Trend will not be responsible for any special, indirect, incidental or subsequent
damage or loss caused by using this device.
Table of Contents
The UT161B/UT161D/UT161E is a handheld true RMS digital multimeter with
high reliability and security (UT161B/UT161D: 6000 counts; UT161E: 22000
counts). With large screen, high resolution analog pointer display, full scale
overload protection, and unique appearance design, it becomes a new practical
electrical measuring meter. The meter can measure AC/DC voltage/current,
resistance, diode, transistor hFE (UT161E), continuity, capacitance, frequency,
duty ratio, temperature (UT161D), etc. Featuring data transmission, data hold,
relative value measurement, peak measurement (UT161D/UT161E), internal
temperature alarm, low battery indication, backlight, auto power off, and NCV
functions, the meter is an ideal measuring tool for many application fields.
Open the package box and take out the meter. Please double check whether
the following items are missing or damaged.
1. User manual --------------------------------------------------- 1 pc
2. Test leads ------------------------------------------------------ 1 pair
3. Adapter socket (UT161D/UT161E) ---------------------- 1 pc
4. K-type thermocouple (UT161D) -------------------------- 1 pc
5. USB cable ----------------------------------------------------- 1 pc
6. Download operation guide --------------------------------- 1 pc
7. 1.5V AAA batteries ------------------------------------------- 4 pcs
If any of the above is missing or damaged, please contact your supplier
immediately.
I. Overview
II. Accessories
I. Overview -------------------------------------------------------------4
II. Accessories ----------------------------------------------------------4
III. Safety Instructions -------------------------------------------------5
IV. Electrical Symbols -------------------------------------------------6
V. External Structure -------------------------------------------------7
VI. LCD Display -------------------------------------------------------8
VII. Function Dial and Function Buttons --------------------------9
VIII. Operating Instructions -----------------------------------------11
IX. Specifications -----------------------------------------------------25
X. Maintenance --------------------------------------------------------35
