Owner’s Manual
SmartRack® NEMA 3R
Swinging Wall-Mount Cabinet
General-Use Industrial Control
Models: SRN3RG6US, SRN3RG9US, SRN3RG9USDP,
SRN3RG12US, SRN3RG12USDP
(Series Number: AG-0609)
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
Table of Contents
1. Important Safety Instructions 2
2. Overview 2
3. Feature Identification 3
4. Enclosure Installation 4
4.1 Preparation 4
4.2 Unpacking 4
4.3 Ground Connection 5
5. Enclosure Configuration 5
5.1 Door Locks 5
5.2 Cable Access and Management 5
5.3 Mounting Rails 6
5.4 Adjusting Mounting Rail Depth 6
6. Wall Mounting the Enclosure 7
7. Equipment Installation 10
8. Specifications 10
8.1 Unit Dimensions 10
8.2 Package Dimensions 10
9. Storage and Service 11
10. Warranty and Product Registration 11
Español 12
Francais 23
2
• The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install it
unassisted. Use a mechanical device such as a forklift or pallet jack to move the enclosure in the shipping container.
• Do not place any object on the enclosure, especially containers of liquid, and do not attempt to stack the enclosures.
• Inspect the shipping container and the enclosure for shipping damage. Do not use the enclosure if it is damaged.
• Leave the enclosure in the shipping container until it has been moved as close to the final installation location as possible.
• Leave adequate space at the front, rear, top and bottom of the enclosure for proper ventilation. Do not block, cover or insert
objects into the external ventilation openings of the enclosure.
• For permanent wall mounting, be sure to securely fasten the enclosure to the building structure before operation.
•
Use caution when cutting packing materials. The enclosure could be scratched, causing damage not covered by the warranty.
• Save all packing materials for later use. Repacking and shipping the enclosure without the original packing materials may
cause product damage that will void the warranty.
• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.
• This enclosure supports a maximum Conduit Trade Size 2 with a 2.5 inch hole.
• Use only NEMA 3R (or higher) rated conduit/fittings to maintain the enclosure’s environmental protection rating.
Swinging wall-mounted NEMA 3R enclosures accommodate all standard 19-inch rack-mount equipment, regardless of vendor,
and ship fully assembled for quick and easy deployment. They have a NEMA 3R rating for protection against falling dirt, rain,
sleet, snow, windblown dust, splashing water and external formation of ice. They feature adaptable, heavy-duty cabinets in various
heights. All models have a hinged design that lets the cabinet swing away from the wall bracket for easy equipment access.
Swinging wall-mounted NEMA 3R enclosures have variable mounting depths, ideal for servers. The cabinets include a lockable,
removable front door and hinged swing cabinet body for convenient maintenance.
1. Important Safety Instructions
2. Overview
SAVE THESE INSTRUCTIONS
This manual contains instructions and warnings that must be followed during the installation and operation of the
product described in this manual. Failure to comply may invalidate the warranty and cause property damage or
personal injury.
3
3. Feature Identification
Model SRN12G6US is shown. The other models have similar features, with the only differences being rack height and depth.
1 Rear Door
2 Front Door
3 Horizontal Rails
4 Vertical Mounting Rails
5 Internal Fans
6 Removable Cable Access Hole Covers
7 Fan Cover Panel
26
3
4
1
7
5
