Installation Guide
Note: G36 is used as an example throughout the Guide. The image may dier from the actual product.
Gigabit VPN Router
Hardware Overview
For technical support and other information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
To ask questions, find answers, and communicate with TP-Link users or
engineers, please visit https://community.tp-link.com to join TP-Link
Community.
© 2023 TP-Link 7106510367 REV1.0.0
Reset: Press and hold the button for 5 seconds, and the SYS LED will
îž°ash quickly, indicating the device is being reset to its factory default
settings.
The router supports two conguration options:
Standalone Mode: Congure and manage the router by itself.
Controller Mode: Congure and manage network devices centrally. It is recommended in large-scale networks, which consist of a large number of devices such as
access points, switches, and gateways.
Note: When the router is managed by a controller, congurations of the router will be overridden by the controller.
Hardware Connection
Note: To connect to the internet via another RJ45 WAN port (ports 3-6),
congure your desired port to WAN, then connect the port to the internet
via an RJ45 cable. Refer to for more details.FAQ-Q1
Connect via Ethernet
Modem
Connect to Port 2
Internet
Connect via ber network
Fiber-Optic Cable SFP Module
Connect to SFP WAN Slot
Internet
Front Panel Back Panel
On: Power is on.
O: Power is o.
Indication
Slow Flashing:
System is running normally.
Quick Flashing:
The router is being reset.
On/O:
System is starting up or running abnormally.
For USB Modem:
Flashing: A modem is connected, and it is initializing.
On: The modem is loaded.
O: No modem is inserted, or it is corrupted or incompatible.
For USB Storage:
On: A USB storage device is inserted and identied.
O: No USB storage device is inserted, or it is corrupted or incompatible.
On: Running at 1000 Mbps, but no activity.
O: No device the corresponding port. is linked to
Flashing: Running at 1000 Mbps, and transmitting or receiving data.
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps, and transmitting or receiving data.
Green O: Not running at 1000 Mbps, or no device is connected to the
corresponding port.
Yellow On: Running at 100/10 Mbps, but no activity.
Yellow Flashing: Running at 100/10 Mbps, and transmitting or receiving data.
Yellow O: Not running at 100/10 Mbps, or no device is connected to the
corresponding port.
Yellow
Green
Software Conguration
Use the charger provided in the
package to power on the router
Kensington
Security Slot
Power SocketGrounding Terminal
Gigabit SFP WAN/LAN port connecting to an SFP module.
By default, it is a WAN port.
You can congure it to a LAN port on the management page.
USB 3.0 for USB modem and USB storage device.
Description
Gigabit RJ45 WAN port.
Gigabit RJ45 WAN/LAN ports.
By default, they are LAN ports connecting to local PCs or switches.
You can congure each port to a WAN port on the management page.
Secure the lock (not provided) into the security slot to prevent the device
from being stolen.
The router comes with a lightning protection mechanism.
Connect to the power outlet via the provided power adapter.
LED
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please contact
us.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Adapter shall be installed near the equipment and shall be easily accessible.
Place the device with its bottom surface downward.
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical Equipment
(Safety) Regulations 2016.
The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/.
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC, 2011/65/EU and
(EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/.
EU Declaration of Conformity
UK Declaration of Conformity
Frequently Asked Questions (FAQ)
Q1. What should I do if I want to change the mode of the WAN/LAN ports?
Follow the steps:
1. (Recommended) Refer to the Interface Description table of this guide for the default mode of
the WAN/LAN ports.
2. Connect a computer to a LAN port of this router. If your computer is congured with a xed IP
address, change it to Obtain an IP address automatically.
3. Log in to this router’s management page at 192.168.0.1. Go to Network > WAN > WAN Mode,
change the mode of the WAN/LAN ports by ticking the checkboxes, and click Save.
Q2. What should I do if I need to connect this router to a modem router?
Check the LAN IP address of the modem router rst. If the LAN IP address of the modem router is
192.168.0.1, which is the same as the default LAN IP address of this router, follow the steps to
change the LAN IP address of this router:
1. Connect a computer to a LAN port of this router. If your computer is congured with a xed IP
address, change it to Obtain an IP address automatically.
2. Log in to this router’s management page at , and go to 192.168.0.1 Network > LAN > LAN. In the
Network List section, change the IP address , and click 192.168.0.1 192.168.1.1 to OK.
Option 2: Controller Mode Choose a type of controller:
For the detailed congurations, refer to the User Guide of the controller. The guide can be found on the download center of our ocial website:
https://www.tp-link.com/support/download/.
Type 2: Omada Pro Cloud-Based Controller
Option 1: Standalone Mode
Connect a computer to a LAN port of the router with an RJ45 cable
properly. If your computer is congured with a xed IP, change it to Obtain
an IP address automatically.
1.
Open a web browser and type the default management address
192.168.0.1 Enter in the address eld of the browser, then press the key.
2.
For detailed congurations, refer to the User Guide of the router. The guide
can be found on the download center of our oîž±cial website:
https://www.tp-link.com/support/download/.
Create a username and a password for subsequent login attempts and
for security.
3.
Use the username and password set above to log in to the webpage.4.
After a successful login, you can congure the function by clicking the
setup menu on the left side of the screen.
5.
Router PC
In Standalone Mode, use a computer to congure and manage the router.
Note: Make sure the ports you select as WAN ports correspond to the real situation.
Type 1: Omada Pro Software Controller
If you want to use the software controller, get a PC with Windows or Linux OS,
contact the sales staff to get the installation package of Omada Pro Software
Controller, then install and launch it.
To manage your devices, the software controller needs to continually run on
your computer. Licenses need to be purchased additionally.
Switch
Router
AP
Clients
Controller
Omada Pro Software Controller
running on the Host PC
AP AP
Note: When conguring the router, make sure the ports you select as WAN ports
correspond to the real situation.
1. Make sure that Cloud Access is enabled on your controller and your
controller has been bound with your TP-Link ID.
2. Launch a web browser and enter https://omada.tplinkcloud.com in the
address bar. Log in with your TP-Link ID. A list of controllers that have been
bound with your TP-Link ID will appear. Then you can launch the controller
to adopt and manage devices.
Local Management
1. Launch the software controller on your PC. After the initiation process, the
controller automatically opens its web page. If not, click Launch a Browser
to Manage the Network.
2. On the controller’s web page, follow the wizard to complete the quick
setup.
Note:
The controller must have network access to your devices in order to find, adopt,
and manage them.
To download Omada Pro Software Controller successfully, it is recommended to
configure the router’s network to access the internet. Refer to Standalone Mode to
launch the management page and go to to complete the Network > WAN
configuration.
3. After the quick setup, the login page appears. Enter the username and
password you created and click . Then you can Log in adopt and manage
devices.
Remote Management
Note: Before you start, make sure that both your controller and PC can access the
internet.
1. Contact the sales staff to grant the Omada Pro Cloud-Based Controller
permission.
2. Launch a web browser and enter https://omada.tplinkcloud.com in the
address bar. Log in with your TP-Link ID.
3. Click + Add Controller Cloud-Based Controller and choose to add an
Omada Pro controller. Then you can launch the controller to adopt and
manage devices.
Omada Pro Cloud-Based Controller is a good alternative without the need to
install the software controller on a PC.
Licenses need to be purchased additionally.
Switch
Router
AP
Clients
AP APAP
Omada Cloud
* Management via Omada App
1. Download and install the TP-Link Omada app from App Store or
Google Play.
After configuring a software controller/cloud-based controller via the
web, you can use the Omada app to manage your controller.
2. Make sure that Cloud Access is enabled on your controller and your
controller has been bound with your TP-Link ID.
or
Scan for Omada Omada
3. Launch the Omada app and log in with your TP-Link ID. Then go to
Cloud Access. A list of controllers that have been bound with your
TP-Link ID will appear. Then you can launch the controller to adopt
and manage devices.
Note: For the cloud-based controller, skip step 2.
