Quick Installation Guide
AC1900 MU-MIMO Wi-Fi Router
* Images may dier from actual products.
If your internet comes from an Ethernet outlet, connect the router’s WAN port to it, then follow Step 4 and Step 5.
If you want to configure this new router as an access point to extend your network, refer to the Access Point Mode
section on the back page.
Connect the Hardware
Flip the page over to complete network setup.
Connect the power adapter to
the router and turn it on.
Note: If the 2.4 GHz LED and 5 GHz LED are off, press and hold the
WPS/Wi-Fi On/Off button on the back for more than 5 seconds. Both the
LEDs should turn on.
Power
On
Internet
On
2.4 GHz
On
5 GHz
On
Check for the following LEDs to confirm the
hardware connection, then refer to the next
section to set up the internet.
Modem
Power adapter
Router
Unplug your modem, and remove
the backup battery if it has one.
Connect the powered-off modem
to the router’s WAN port with an
Ethernet cable.
Power on the modem, and
then wait about 2 minutes
for it to restart.
Power adapter
Set up with videos:
Scan the QR code or visit
https://www.tp-link.com/support/setup-video/#wi-îž®-routers
to search for the setup video of your product.
WAN
POWER
Power ON / OFF
©2024 TP-Link 7106510996 REV2.0.0
Need Help?
Q1. What should I do if I cannot access the web management page?
Reboot your router and try again.
If the computer is set to a static IP address, change its settings to obtain an IP
address automatically.
Verify that is correctly entered in the web browser. Alternatively, http://tplinkwifi.net
enter in the web browser and press .http://192.168.0.1 http://192.168.1.1 or Enter
Use another web browser and try again.
Disable and enable the network adapter being used.
Q2. What should I do if I cannot access the internet?
Reboot your modem and router, then try again.
Check if the internet is working normally by connecting a computer directly to the
modem using an Ethernet cable. If it is not, contact your internet service provider.
Log in to the web management page of the router, and go to the Network Map to
check whether the internet IP address is valid or not. If it is not, check the hardware
connection or contact your internet service provider.
For cable modem users, log in to the web management page of the router. Go to
Advanced Network Internet MAC Clone Clone Current Device MAC > > > , select
and click . Then reboot both the modem and the router. SAVE
Q3. How do I restore the router to its factory default settings?
With the router powered on, use a pin to press and hold the button on the RESET
back until the Power LED blinks.
Log in to the web management page of the router, go to Advanced > System >
Backup & Restore > Factory Default Restore FACTORY RESTORE, and click . The
router will restore and reboot automatically.
Q4. What should I do if I forget my web management page password?
If you are using a TP-Link ID to log in, click Forgot password on the login page and
then follow the instructions to reset it.
Alternatively, refer to to reset your router, then visit to create Q3 http://tplinkwiîž®.net
a new login password.
Q5. What should I do if I forget my wireless network password?
If you have not changed the default wireless password, it can be found on the label
at the bottom of the router.
Connect a computer directly to the router using an Ethernet cable. Log in to the
router’s web management page at , and go tohttp://tplinkwi.net Wireless >
Wireless Settings to retrieve or reset your wireless password.
Method 1: Via TP-Link Tether App
1. Download the Tether app.
Scan for Tether Tether
or
Launch a web browser, and enter http://tplinkwifi.net http://192.168.0.1 or
in the address bar. Create a password to log in.
Follow the step-by-step instructions to set up the internet connection and
register for the TP-Link Cloud service.
2. Connect the router to the internet.
Note: If the login window does not appear, please refer to of Q1 Need Help? in this guide.
a
b
Method 2: Via a Web Browser
Wired
Turn off the Wi-Fi on your computer and connect to the router using an
Ethernet cable.
1. Connect your device to the router (wired or wireless).
Wireless
Find the SSID (network name) and wireless password printed on the label
at the bottom of the router.
a
Click the network icon of your computer or go to Wi-Fi settings of your
smart device, and then select the SSID to join the network.
b
Access Point Mode
If you already have a router, you can switch this new router to Access Point
mode to extend your existing network. Follow the steps below.
1. Power on the router.
2. Connect the router’s to your existing router’s Ethernet port WAN port
via an Ethernet cable as shown above.
3. Connect a computer to the router via an Ethernet cable or wirelessly by
using the (network name) and SSID Wireless Password printed on the
label at the bottom of the router.
4. Launch a web browser, and enter http://tplinkwifi.net in the address bar.
Create a password to log in.
5. Quick Setup Change ModeRun the , click in the top right corner then
select Access Point Mode.
Note: You can also Advanced Operation Mode Access Point Modego to > to switch to .
6. Wait for the router to reboot, then log in and follow the Quick Setup to
complete the setup.
Set Up the Network 2
Existing Router
net4EInternet
Ethernet
New Router Clients
2. Open the Tether app and log in with your TP-Link ID.
Note: If you don’t have an account, create one first.
3. Tap the button in the Tether app and select Wireless
Router > Standard Routers. Follow the steps to
complete the setup and connect to the internet.
Button Explanation
DESCRIPTIONBUTTON
Press and hold for 1 second to enable the WPS function.
Press and hold for about 5 seconds to turn on or o the
wireless function of the router.
WPS/
Wi-Fi On/O
Press and hold this button until the Power LED blinks to
reset the router to its factory default settings.
RESET
WAN
Choose Your Device Type
Gaming Router
Range Extender
Wireless Router
Note: Due to Tether app updates,
your actual user interface and
pathway may differ from those
depicted here.
Safety Information
Keep the device away from water, fire, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service,
please contact us.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Do not use the device where wireless devices are not allowed.
Adapter shall be installed near the equipment and shall be easily accessible.
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of the Radio Equipment Regulations 2017.
The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/
For technical support, replacement services, user guides, and other
information, please visit https://www.tp-link.com/support, or simply scan the
QR code.
Let’s Get Started
http://tplinkwiîž®.net
