Seite 1/15
LASER CLEAN
INSTRUCTION MANUAL
MODEL
LC-40
IMPORTANT
READ AND UNDERSTAND INSTRUCTIONS BEFORE USING HEATER.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
CONTENTS
SPECIFICATIONS 1
PART NAME 1
OPERATION 5
EMERGENCY MESSAGE 10
ROUTINE MAINTENANCE 11
TROUBLESHOOTING 12
LONG TERM STORAGE 13
a
SPECIFICATIONS
1
MODEL
HEAT RATING
FUEL TANK CAPACITY
BURNING TIME
DIMENSIONS(W x D x H)
WEIGHT
VOLTAGE / FREQUENCY
ELECTRICAL CONSUMPTION
LC-40
14,300 BTU / 3,600 Kcal
3,800 BTU / 960 Kcal
7.6 lit.
19.0 ~69.0 hrs.
550 x 328 x 445 mm
12.0 kg
230V AC, 50 HZ
Igniter : 320 W
Continuous : 36 W
High
Low
* Matching Room Size to HEAT RATING
•Because the “Heat Load” of an area to be
heated is influenced by so many factors, it is
impossible to specify a heater output to an
exact room size.
•If you use a heater too large for the area to
be heated, the temperature you desire will
be reached quickly. In such cases, to avoid
overheating the area, the heater must be
turned off frequently, or doors opened to
other areas of the house, or windows to the
outside opened to cool the area.
•If you use a heater too small for the area to
be heated, it will take much longer to reach
the desired temperature, in fact it may not
be reached at all depending on the outside
weather conditions.
PART NAME
BEFORE USING HEATER, FAMILIARIZE YOURSELF WITH THE FOLLOWING OPERATING
CONTROLS AND PART NAMES.
MAIN BODY
Front panel
Louver
operation panel
Removable fuel tank
Circulation
fan
Room
thermistor
Power supply
cord
Air filter
Carrying
handle
Top plate
2
2 0 : 1 5
set room
key-lock timer save hour min. extension
timer save vent. fuel
temp.
clock
Adjustment Keys
Temperature Lamp
Key-lock Button
Save KeyTimer Key Extension Key
ON/OFF Button / Lamp
Fuel Lamp
Ventilation Lamp
Save Lamp
Timer Lamp
Key-lock Lamp
Clock Lamp Digital Indicator
OPERATION PANEL
ON/OFF Lamp —flashing : Preheating mode
constant : Heater in operation
key-lock Lamp —constant : Childproof Lock is on.
Temperature Lamp —constant : The Digital Indicator shows Set temperature
and Room temperature.
Clock Lamp —constant : The Digital Indicator shows current time.
Timer Lamp —constant : Heater in operation in timer mode.
Save Lamp —constant : The operation is in Save mode operation.
Ventilation Lamp —flashing : Oxygen level in room is insufficient. Heater
shuts off automatically.
Fuel Lamp —constant : Fuel tank empty. Only 10 minutes burning time
remaining. Digital indicator shows the
remaining burning time in minutes.
You can hear the alarm every 2 minutes.
flashing : Heater extinguished due to lack of fuel. (10
seconds alarm)
