MD-CD1@$
Minidisc Deck/CD Player
OWNER'S MANUAL
2 TASCAM MD-CD1MKIII
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
For U.S.A.
ª
TO THE USER
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user
will be required to correct the interference at his own
expense.
CAUTION
Changes or modifications to this equipment not expressly
approved by TEAC CORPORATION for compliance could
void the user's authority to operate this equipment.
CAUTIONS ABOUT LASER RADIATION
ª
This product has been designed and manufactured
according to FDA regulations “title 21, CFR, chapter 1,
subchapter J, based on the Radiation Control for Health
and Safety Act of 1968,” and is classified as a class 1 laser
product. There is no hazardous invisible laser radiation
during operation because invisible laser radiation emitted
inside of this product is completely confined in the
protective housings.
The labels required in this regulation are shown at and 1
2.
21503-W
1
2
Cautions:
DO NOT REMOVE THE PROTECTIVE HOUSING USING A
•
SCREWDRIVER.
USE OF CONTROLS OR ADJUSTMENTS OR
•
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
IF THIS PRODUCT DEVELOPS TROUBLE, CONTACT YOUR
•
NEAREST QUALIFIED SERVICE PERSONNEL, AND DO
NOT USE THE PRODUCT IN ITS DAMAGED STATE.
CLASS 1M INVISIBLE LASER RADIATION WHEN OPEN
•
AND INTERLOCKS DEFEATED. DO NOT VIEW DIRECTLY
WITH OPTICAL INSTRUMENTS.
MD drive optical pickup:
Type : HPM-312S
Manufacturer : SHARP CORPORATION
Laser output : Playback 0.6 mW
Recording: According to TOC information.
(Approx. 4.5 mW on MMD-318)
Wavelength : 785 nm
Standard : IEC60825-1 Edidion 1.2-2001
CD drive optical pickup:
Type : SF-P151NVD
Manufacturer : Sanyo Electric Co,Ltd.
Laser output : Less Than 0.2 mW on the
objective lens
Wavelength : 790+10/–15 nm
Standard : IEC60825-1: 2007 / EN60825-1:2007
IMPORTANT SAFETY PRECAUTIONS
TASCAM MD-CD1MKIII 3
IMPORTANT SAFETY INSTRUCTIONS
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8 Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9 Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10 Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11 Only use attachments/accessories specified by the
manufacturer.
12 Use only with the cart, stand, tripod, bracket, or
table specied by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
13 Unplug this apparatus during lightning storms or
when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Do not expose this apparatus to drips or splashes.
•
Do not place any objects filled with liquids, such as
•
vases, on the apparatus.
Do not install this apparatus in a confined space such
•
as a book case or similar unit.
The apparatus draws nominal non-operating power
•
from the AC outlet with its POWER or STANDBY/ON
switch not in the ON position.
The apparatus should be located close enough to the
•
AC outlet so that you can easily grasp the power cord
plug at any time.
The mains plug is used as the disconnect device, the
•
disconnect device shall remain readily operable.
Products with Class I construction are equipped with a
•
power supply cord that has a grounding plug. The cord
of such a product must be plugged into an AC outlet
that has a protective grounding connection.
If the product uses batteries (including a battery pack
•
or installed batteries), they should not be exposed to
sunshine, fire or excessive heat.
CAUTION for products that use replaceable lithium
•
batteries: there is danger of explosion if a battery is
replaced with an incorrect type of battery. Replace only
with the same or equivalent type.
Caution should be taken when using earphones or
•
headphones with the product because excessive
sound pressure (volume) from earphones or head-
phones can cause hearing loss.
4 TASCAM MD-CD1MKIII
For European Customers
ª
CE Marking Information
a) Applicable electromagnetic environment: E4
b) Peak inrush current: 11 A
Disposal of electrical and electronic equipment
(a) All electrical and electronic equipment should be
disposed of separately from the municipal waste
stream via collection facilities designated by the
government or local authorities.
(b) By disposing of electrical and electronic equipment
correctly, you will help save valuable resources and
prevent any potential negative effects on human
health and the environment.
(c) Improper disposal of waste electrical and electronic
equipment can have serious effects on the
environment and human health because of the
presence of hazardous substances in the equipment.
(d) The Waste Electrical and Electronic Equipment (WEEE)
symbol, which shows a wheeled bin that has been
crossed out, indicates that electrical and electronic
equipment must be collected and disposed of
separately from household waste.
(e) Return and collection systems are available to end
users. For more detailed information about the
disposal of old electrical and electronic equipment,
please contact your city office, waste disposal service
or the shop where you purchased the equipment.
Disposal of batteries and/or accumulators
(a) Waste batteries and/or accumulators should be
disposed of separately from the municipal waste
stream via collection facilities designated by the
government or local authorities.
(b) By disposing of waste batteries and/or accumulators
correctly, you will help save valuable resources and
prevent any potential negative effects on human
health and the environment.
(c) Improper disposal of waste batteries and/or
accumulators can have serious effects on the
environment and human health because of the
presence of hazardous substances in them.
(d) The WEEE symbol, which shows a wheeled bin that
has been crossed out, indicates that batteries and/
or accumulators must be collected and disposed of
separately from household waste.
Pb, Hg, Cd
If a battery or accumulator contains more than the
specified values of lead (Pb), mercury (Hg), and/
or cadmium (Cd) as defined in the Battery Directive
(2006/66/EC), then the chemical symbols for those
elements will be indicated beneath the WEEE symbol.
(e) Return and collection systems are available to end
users. For more detailed information about the
disposal of waste batteries and/or accumulators,
please contact your city office, waste disposal service
or the shop where you purchased them.
WARNING
This is a Class A product. In a domestic environment, this
product may cause radio interference in which case the
user may be required to take adequate measures.
RACK-MOUNTING THE UNIT
ª
Use the supplied rack-mounting kit to mount the unit in a
standard 19-inch rack, as shown below.
Remove the feet of the unit before mounting.
NOTE
Leave 1U of space above the unit for ventilation.
•
Allow at least 10 cm (4 in) at the rear of the unit for
•
ventilation.
This appliance has a serial number located on the top
panel. Please record the model number and serial
number and retain them for your records.
Model number ______________________________
Serial number ______________________________
Safety Information
TASCAM MD-CD1MKIII 5
CAUTIONS ABOUT BATTERIES
ª
This product uses batteries. Misuse of batteries could
cause a leak, rupture or other trouble. Always abide by the
following precautions when using batteries.
Never recharge non-rechargeable batteries. The
•
batteries could rupture or leak, causing fire or injury.
When installing batteries, pay attention to the polarity
•
indications (plus/minus (+/–) orientation), and
install them correctly in the battery compartment as
indicated. Putting them in backward could make the
batteries rupture or leak, causing fire, injury or stains
around them.
When you store or dispose of batteries, isolate their
•
terminals with insulation tape or something like that to
prevent them from contacting other batteries or metallic
objects.
When throwing used batteries away, follow the
•
disposal instructions indicated on the batteries and the
local disposal laws.
Do not use batteries other than those specified. Do not
•
mix and use new and old batteries or different types of
batteries together. The batteries could rupture or leak,
causing fire, injury or stains around them.
Do not carry or store batteries together with small
•
metal objects. The batteries could short, causing leak,
rupture or other trouble.
Do not heat or disassemble batteries. Do not put them
•
in fire or water. Batteries could rupture or leak, causing
fire, injury or stains around them.
If the battery fluid leaks, wipe away any fluid on
•
the battery case before inserting new batteries. If
the battery fluid gets in an eye, it could cause loss
of eyesight. If fluid does enter an eye, wash it out
thoroughly with clean water without rubbing the eye
and then consult a doctor immediately. If the fluid
gets on a person’s body or clothing, it could cause skin
injuries or burns. If this should happen, wash it off with
clean water and then consult a doctor immediately.
The unit power should be off when you install and
•
replace batteries.
Remove the batteries if you do not plan to use the unit
•
for a long time. Batteries could rupture or leak, causing
fire, injury or stains around them. If the battery fluid
leaks, wipe away any fluid on the battery compartment
before inserting new batteries.
Do not disassemble a battery. The acid inside the
•
battery could harm skin or clothing.
Safety Information
For China
6 TASCAM MD-CD1MKIII
Contents
1 – Introduction ..............................................8
Features ..................................................................................8
Included items .....................................................................9
About this manual ..............................................................9
Trademarks ............................................................................9
Precautions for placement and use .............................. 9
Connecting the power ....................................................10
Cleaning the unit ...............................................................10
Beware of condensation .................................................10
About compact discs .......................................................10
Handling of compact discs .....................................10
Handling of MDs ...............................................................10
About the User Table of Contents (U-TOC) .............. 11
2 – Remote Control Unit ...............................12
Preparation of Remote Control Unit ..........................12
Inserting batteries ...................................................... 12
When to replace the batteries ............................... 12
Precautions about using batteries ....................... 12
Precautions about using the remote control ...12
3 – Connections .............................................13
Audio equipment ..............................................................13
Power source ......................................................................13
4 – Names and Functions of Parts ...............14
Front panel ..........................................................................14
Shared features ...........................................................14
CD Operation ...............................................................15
MD Operation ..............................................................16
Display ...................................................................................17
Rear Panel ............................................................................18
Remote Control Unit ........................................................19
CD Operation Section ...............................................20
MD Operation Section .............................................21
5 – Display Master and Remote Control
Master ....................................................22
Selecting the remote control master .........................22
Selecting the display master .........................................22
6 – Menu Operation ......................................23
Menu configuration .........................................................23
CD Menu ........................................................................23
MD Menu .......................................................................24
Operation basics ...............................................................25
7 – CD and MD Playback ...............................26
Discs for playback .............................................................26
Playback modes .................................................................26
Basic playback operation ...............................................26
About the monitor ...........................................................27
Using headphones .....................................................27
COMMON output .......................................................27
Display master and remote master settings ...........27
Track selection ...................................................................27
Using the skip function ............................................27
Selecting by track number .....................................27
Search .............................................................................27
Time Search function ......................................................28
Basic operation ...........................................................28
Operation variations .................................................28
Auto cue ...............................................................................28
Auto Ready ..........................................................................28
Repeat playback ................................................................29
A to B repeat playback ....................................................29
Continuous CD and MD playback ...............................29
Timer Playback ...................................................................29
Pitch control (CD only) ....................................................30
Single-track playback ......................................................30
Program playback .............................................................30
Deleting a programmed track ...............................31
Adding a track to the program ..............................31
Erase a CD or MD program .....................................31
Program limitations ...................................................31
Saving program data ................................................31
Random playback .............................................................31
Time display switching ...................................................32
End of disc/track warning ..............................................32
Playback functions for CD only ....................................32
Changing the key of playback ...............................32
Fade-in and fade-out ................................................32
Output volume............................................................33
MP3 and WAV file directory playback ........................33
Directory playback setting .....................................33
Setting MP3 ACTION .................................................33
MD group playback ..........................................................34
Group playback setting ...........................................34
8 – Dubbing from CD to MD .........................35
Basic dubbing operation ................................................35
Recording mode setting ................................................35
Dubbing speed setting ...................................................35
9 – MD recording from an external source 36 .
Basic recording ..................................................................36
Recording cautions ..........................................................37
Update (Move up) a track number ..............................37
Auto track function....................................................37
Update a track number manually ........................37
TASCAM MD-CD1MKIII 7
Update a track number after recording .............37
Fade-in and fade-out recording ..................................38
Prerecording (Time Machine recording) ..................38
Overwrite recording.........................................................38
Sync recording ...................................................................39
Checking remaining MD time ......................................39
10 – MiniDisc editing ....................................40
Editing operations ............................................................40
Tracks and points for editing .................................40
Canceling edits ...........................................................40
UNDO an edit operation (UNDO function) ..............40
Erase disc (ERASE DISC) ...................................................40
Erase track (ERASE TRK) ..................................................40
Selecting a track to be erased by playback ......40
Selecting a track to be erased on the menu ....40
Erase multiple tracks at once (ERASE MULTI) ..........41
Divide tracks (DIVIDE) ......................................................41
Combine tracks (COMBINE) ...........................................42
Move tracks (MOVE) .........................................................42
Creating a group ...............................................................42
Disc title when creating a group ..........................43
Deleting a group ...............................................................43
11 – Title input ..............................................44
Disc title input (TITLE) .....................................................44
Title input operation .................................................44
Track title input ..................................................................44
Group title input ................................................................45
12 – Using a Computer Keyboard ................46
Keyboard type setting ....................................................46
Title input by keyboard ...................................................46
Other keyboard operations ...........................................46
Direct track operation .....................................................47
13 – Locking the panel operations ..............48
Locking the entire panel ................................................48
Locking individual decks ................................................48
14 – Data settings/Service Data ...................49
Data communication settings ......................................49
Viewing service data ........................................................49
Initializing all data .............................................................49
15 – System Limitations ................................50
CD section ...........................................................................50
About MP3 and WAV files ........................................50
About CD-R/RW ..........................................................50
Copy control CD discs ...............................................50
MD section ..........................................................................50
16 – Messages and Troubleshooting ...........52
17 – Specifications ........................................53
MD deck ...............................................................................53
CD deck .................................................................................53
Input ratings (MD inputs) ...............................................53
Output ratings ....................................................................53
Control I/O ...........................................................................54
Audio performance ..........................................................54
General .................................................................................54
Dimensional drawing ......................................................54
Contents
8 TASCAM MD-CD1MKIII
1 – Introduction
Thank you very much for purchasing the TASCAM MD-
CD1MKIII MiniDisc Deck and CD Player.
Before connecting and using the unit, please take time to
read this manual thoroughly to ensure you understand
how to properly set up and connect the unit, as well as
the operation of its many useful and convenient functions.
After you have finished reading this manual, please keep
it in a safe place for future reference.
You can also download the Owner's Manual from the
TASCAM web site (http://tascam.com/).
Features
Equipped with an MD recorder and a CD player in a 2U
•
rack mount size
The MD recorder and a CD player can be operated
•
separately.
In addition to audio CDs, MP3 and WAV files (44.1 kHz,
•
16 bit) recorded on a CD-R, CD-RW, or CD-ROM can be
played back.
Compatible with four MD modes (STEREO, MONO, LP2,
•
and LP4). Also, you can record and play back files on an
MD with different modes.
A pitch control function with a range of –50% to +16%
•
(audio CD only). You can adjust the pitch between 0.1
and 1.0% in 0.1% increments.
You can adjust a key with a range of
• â6 to #6 in
semitone units without changing the playback speed.
(Audio CD only)
Auto cue function – The unit searches for the beginning
•
of a sound and the playback is put on standby.
(Adjusting range: by 6 dB between –72 and –24dB)
Auto ready function – After playing back a track, the
•
playback of the next track is put on standby.
Synchronized recording by input audio signal function
•
(MD only)
Pre-recording (“Time machine” recording) function (MD
•
only, time can be adjusted in one second increments
between one and six seconds).
Up to 100 discs worth of tracks (CD and MD) can be
•
programmed in the program memory.
Panel lock function
•
Compatible with CD-TEXT (While the playback is
•
stopped: The disc title is displayed/While the playback
is in progress: The track title is displayed)
Compatible with ID3 tag (only for a CD containing MP3
•
files)
Four playback modes for CD, and five for MD –
•
Continuous, Single, Program (up to 99 tracks for CD/25
tracks for MD), Random, and Group (MD only)
Five repeat playback modes - Normal, Single, Program
•
(up to 99 tracks for CD/25 tracks for MD), Random, and
A to B
Equipped with a digital volume control for CD output
•
(– ∞ and between –54 to +18 dB)
Fade-in/fade-out playback function (CD only, one
•
second increment between one and 30 seconds)
EOM function – A warning for the end of the track
•
or disc is displayed. (Audio CD and MD, time can be
adjusted in one second increments between one and
99 seconds.)
Time search function – The track and the playback
•
starting point can be specified using the number keys
on the remote control.
Power-on play function
•
Four time display modes – Elapsed/remaining track
•
time and Elapsed/remaining disc time (Only elapsed
track time is available for MP3/WAV files.)
Function for erasing discs/tracks, dividing/combining/
•
moving tracks, and editing titles (MD only)
Compatible with group creation and group playback
•
(MD only)
Overwrite recording function – Recording a new signal
•
over a recorded portion (MD only)
Automatic track increment by input level detection or
•
by track information from an S/PDIF input (MD only)
Manual track increment by pressing the RECORD
•
button during recording (MD only)
Input monitor function (MD only)
•
Equipped with digital volume (– ∞ and between
•
–54 and +18 dB) and analog volume (left/right
independent) for input signals (MD only)
Fade-in/fade-out recording function (one second
•
increments between one and 30 seconds: MD only)
Dubbing from a CD to an MD (entire disc or individual
•
tracks)
Dubbing a track title from CD-TEXT or ID3 tags
•
automatically
Fade-in/Fade-out dubbing function
•
Successive playback of MD and CD (playing back an
•
entire disc alternately and repeatedly)
Wireless remote control (supplied)
•
RS-232C serial remote control function
•
Compatible with a balanced I/O card (TASCAM LA-MC1:
•
separately purchased)
Unbalanced analog input/output (RCA) (Input: MD x 1,
•
Output: MD x 1, CD x 1)
S/PDIF optical digital input/output (Input: MD x 1,
•
Output: MD x 1, CD x 1) (SCMS)
S/PDIF coaxial digital input/output (Input: MD x 1,
•
Output: MD x 1, CD x 1) (SCMS)
Remote control possible from a PS/2 keyboard (You can
•
edit MD or enter a track title from the keyboard.)
Common output terminal to output both CD and MD
•
sound (You can select the output priority.)
Headphone output (Selectable from MD, CD, or
•
common)
TASCAM MD-CD1MKIII 9
Included items
The included items are listed below.
Take care when opening the package not to damage the
items. Keep the package materials for transportation in
the future.
Please contact the store where you purchased this unit
if any of these items are missing or have been damaged
during transportation.
Main unit
• ........................................................................................ 1
Power cord
• .................................................................................... 1
Wireless remote control (TASCAM RC-MC1)
• ...................... 1
AA batteries for the remote control unit
• ............................ 2
A rack-mounting screw kit
• ....................................................... 1
A warranty card
• ........................................................................... 1
Owner’s manual (this manual)
• ............................................... 1
NOTE
The batteries are not supplied for Taiwan.
About this manual
In this manual, we use the following conventions:
“MiniDisc” is abbreviated as “MD.”
•
The names of buttons and controls are given in the
•
following typeface: STOP.
Messages on the unit’s display are shown like this:
•
REPEAT
When the character display area shows information
•
about discs and tracks this is called the “information
display” mode.
CDs on which MP3 or WAV audio files are recorded may
•
be mentioned as “data CDs”.
Additional information is introduced in the styles
•
below when needed:
TIP
Useful hints when using the unit.
NOTE
Explanation of actions in special situation and
supplement.
CAUTION
Instructions that should be followed to avoid injury,
damage to the unit or other equipment, and loss of data.
Trademarks
TASCAM is a trademark of TEAC Corporation, registered
•
in the U.S. and other countries.
US and foreign patents licensed from Dolby
•
Laboratories Licensing Corporation.
MPEG Layer-3 audio coding technology licensed from
•
Fraunhofer IIS and Thomson.
Other company names, product names and logos
•
in this document are the trademarks or registered
trademarks of their respective owners.
Any data, including, but not limited to information,
described herein are intended only as illustrations
of such data and/or information and not as the
specifications for such data and/or information. TEAC
Corporation disclaims any warranty that any use
of such data and/or information shall be free from
infringement of any third party’s intellectual property
rights or other proprietary rights, and further, assumes
no liability of whatsoever nature in the event of any
such infringement, or arising from or connected with
or related to the use of such data and/or information.
This product is designed to help you record and
reproduce sound works to which you own the
copyright, or where you have obtained permission
from the copyright holder or the rightful licensor.
Unless you own the copyright, or have obtained the
appropriate permission from the copyright holder
or the rightful licensor, your unauthorized recording,
reproduction or distribution thereof may result in
severe criminal penalties under copyright laws and
international copyright treaties. If you are uncertain
about your rights, contact your legal advisor. Under no
circumstances will TEAC Corporation be responsible
for the consequences of any illegal copying performed
using the recorder.
Precautions for placement and
use
The operating temperature should be between 5°C and
•
40°C (41°F and 104°F).
Do not install in the following types of places. Doing
•
so could degrade the sound quality and/or cause
malfunctions.
Places with significant vibrations or that are
•
otherwise unstable
Near windows or other places exposed to direct
•
sunlight
Near heaters or other extremely hot places
•
Extremely cold places
•
1 – Introduction
10 TASCAM MD-CD1MKIII
Places with bad ventilation or high humidity
•
Very dusty locations
•
Make sure that the unit is mounted in a level position
•
for correct operation.
Do not place any object on the unit for heat dissipation.
•
Avoid installing this unit on top of any heat-generating
•
electrical device such as a power amplifier.
Connecting the power
Hold the power cord by the plug when connecting or
•
disconnecting it.
Insert the included power cord into the
• AC IN
connector completely.
Cleaning the unit
To clean the unit, wipe it gently with a soft dry cloth. Do
not wipe with chemical cleaning cloths, benzene, paint
thinner, ethyl alcohol or other chemical agents to clean
the unit as they could damage the surface.
Beware of condensation
If the unit is moved from a cold to a warm place, or
used immediately after a cold room has been heated or
otherwise exposed to a sudden temperature change,
condensation could occur. Should this happen, leave the
unit for one or two hours before turning the unit on.
About compact discs
In addition to audio CDs (CD-DA), the unit can play CD-R
and CD-RW discs on which audio CD, MP3, or WAV format
files are recorded. The CD player can also play 3-inch CDs.
Handling of compact discs
Always place the compact discs in the trays with their
•
label facing upward.
To remove a disc from its case, press down on the
•
center of the disc holder, then lift the disc out, holding
it carefully by the edges.
Avoid getting fingerprints on the signal side (the non-
•
label side). Grime and dust may cause skipping or
malfunction.
To clean the signal side of a disc, wipe gently with a soft
•
dry cloth from the center towards the outside edge.
Dirt on discs can lower the sound quality, so clean
them and always store them in a clean state.
Do not use any record spray, anti-static solutions,
•
benzene, paint thinner or other chemical agents to
clean CDs as they could damage the delicate playing
surface. It may cause CDs to become unplayable.
Do not affix any labels or stickers to the label side of
•
the disc and do not use any protective coating spray.
Do not insert discs that have adhesive remaining from
tape or stickers that have been removed. If they are
inserted into the player, they could stick to the internal
mechanism, requiring removal by a technician.
Never use a commercially available CD stabilizer. Using
•
stabilizers with this player will damage the mechanism
and cause it to malfunction.
Do not use cracked discs.
•
Only use circular compact discs. Avoid using non-
•
circular promotional, etc. discs.
Music discs with copy control, a copy-protection
•
system, have been released from several record
companies in an attempt to protect the copyright.
Since some of these discs do not comply with the CD
specifications, they may not be playable on the unit.
Handling of MDs
The MD itself is mounted inside a cartridge. Soiling or
warping of the cartridge could cause malfunction.
To ensure continued enjoyment of the contents of an MD,
please observe the following precautions.
After use, always return an MD to its case.
•
Do not open the shutter and touch the disc inside.
•
Moreover, forcing the shutter open could break the
MD.
Keep discs out of direct sunlight and places of high
•
heat and humidity.
Wipe dirt and grime from the cartridge surface with a
•
dry cloth.
When applying labels to an MD, apply them correctly
•
to the indicated locations. Loose or raised labels could
cause an MD to become stuck in the unit.
Do not layer labels on top of other labels.
•
Cartridge
Shutter
1 – Introduction
TASCAM MD-CD1MKIII 11
About the User Table of Contents
(U-TOC)
Recorded tracks on a recordable MD can be edited.
Information about recorded tracks, including their
starting and ending addresses and titles, is recorded in
something called the User Table of Contents (U-TOC). This
is overwritten when the disc is edited.
U-TO C Music data
Track order, start/end time of
each track, and other data are
recorded.
1 – Introduction
12 TASCAM MD-CD1MKIII
2 – Remote Control Unit
Preparation of Remote Control
Unit
Inserting batteries
1 Open the cover on the back of the remote control.
2 Insert two AA batteries with the correct ±
orientations.
3 Close the cover.
NOTE
The batteries are not supplied for Taiwan.
When to replace the batteries
Replace both batteries with new ones when the range
of the remote control becomes short or if the buttons
become unresponsive.
Precautions about using batteries
Misuse of batteries could cause them to leak, rupture or
otherwise be damaged. Please read and abide by the
precautions on the battery labels when using them. See
page 5 of this manual for additional precautions.
Precautions about using the remote
control
When using other devices controlled by infrared rays,
•
use of this remote control might operate these devices
by mistake.
Use the remote control within the following range.
•
Remote sensor
15˚ 15˚
Operation distance
Directly in front: ithin 7 meters W
15˚ left or right: Within 7 meters
TASCAM MD-CD1MKIII 13
3 – Connections
Before connecting the MD-CD1MKIII to other units,
please read their operation manuals thoroughly to ensure
proper connection. Connect the power cord only after all
connections have been made.
Audio equipment
Connecting analog audio equipment
ª
Connect analog stereo amplifiers, mixers and recorders
to the analog line inputs and outputs. There are input
terminals for the MD deck recording source and terminals
for both the CD and MD outputs, as well as a COMMON
output for the output signals of the CD deck, the MD
deck, or both. Selection of either deck’s output signals can
be performed on the SYSTEM sub-menu of the CD menu
under the “
COMMON?
” option.
NOTE
You can use this unit in a system configured with
•
balanced analog input/output only by attaching a
separately sold balanced analog input/output board
(TASCAM LA-MC1).
Connection cables are not supplied with this unit.
•
Do not bundle the line level sound signal cables with
•
the power or speaker cords as noise or diminished
sound quality could result.
Connecting digital audio equipment
ª
Digital stereo amplifiers, mixers and recorders can be
connected through the digital input/output terminals
(optical or coaxial).
NOTE
The MD-CD1MKIII features a sampling rate converter,
which enables you to digitally record signals not only at
a sampling rate of 44.1 kHz (a sampling rate for MD), but
also at sampling rates of 32 kHz or 48 kHz.
Power source
This unit has been designed to operate on the specified
power voltage only. Do not plug the power cord into
outlets of any other voltage.
TASCAM MD-CD1MKIII 15
fg h j kl ; z
xc v b n m
e r t y ui
opa s d
CD Operation
eKEY button / Indicator
When this button is pressed, the Indicator light goes
on and the Key Change function is turned on, allowing
you to change the musical key of Compact Disc
playback.
Refer to “Changing the key of playback” on page 32.
Even when the power is turned off, the key change
setting is retained.
rCD Tray
Compact Discs are placed here for loading.
tÔ/ buttonÂ
In normal mode, this button is used to skip back a
track or for review playback (search).
When playback is stopped, if this button is pressed
once, the previous track is selected; if it is pressed
continuously, the tracks are skipped backward at high
speed.
During playback, if this button is pressed once, the
beginning of the current track is cued, and playback
restarts; if it is pressed continuously, review playback
(search) is performed.
y¯ / button
In normal mode, this button is used to skip forward a
track or for cue playback (search).
When playback is stopped, if this button is pressed
once, the next track is selected; if it is pressed
continuously, the tracks are skipped forward at high
speed.
During playback, if this button is pressed once, the
beginning of the next track is cued, and playback
begins; if it is pressed continuously, cue playback
(search) is performed.
uCD button/indicator
When this button is pressed, the indicator goes on,
CD becomes the display master, and CD deck and disc
information (such as settings and time) are shown on
the display.
Even when the power is turned off, the display master
setting is retained.
iCD MENU button
This turns the CD Menu mode on or off. In CD Menu
mode, the indicator light flashes, CD menu options CD
are indicated on the display, and settings can be
performed.
NOTE
If the
• CD MENU button is pressed when the display
master is MD, the indicator stays lit, while the MD CD
indicator flashes.
If the
• CD MENU button is pressed when the display
master is CD ( indicator ON), the indicator will CD CD
begin flashing.
o PITCH Control/Indicator
Push this control to turn the pitch control function on
or off. When it is on, the indicator lights up, and pitch
can be adjusted between –50% and +16% by turning
the control. Even when the power is turned off, the
pitch control ON/OFF setting is retained.
pSTOP ( ) buttonª
During CD playback, press this button to stop
playback. When this button is pressed during
dubbing operation, both the MD and CD decks stop
simultaneously.
aPLAY ( ) buttonÁ
Press this button to start CD playback when the CD
deck is in stop or standby mode.
When this button is pressed during dubbing standby
mode, the CD deck starts playback, the MD deck starts
recording, and dubbing begins.
sREADY ( ) buttonπ
When this button is pressed during playback or while
stopped, the CD deck enters standby mode.
d OPEN/CLOSE ( ) buttonø
Press this button to open or close the CD tray.
4 – Names and Functions of Parts
16 TASCAM MD-CD1MKIII
MD Operation
fMD MENU button
This turns the MD Menu mode on or off. In MD Menu
mode, the indicator flashes, MD Menu options MD
are indicated on the display, and settings can be
performed.
NOTE
If the
• MD MENU button is pressed when the display
master is CD, the indicator stays lit, while the CD MD
indicator flashes.
If the
• MD MENU button is pressed when the display
master is MD ( indicator ON), the indicator will MD MD
begin flashing.
gMD button/indicator
When this button is pressed, the indicator goes on,
MD becomes the display master, and MD deck and
disc information (such as settings and time) are shown
on the display. Even when the power is turned off, the
display master setting is retained.
hÔ/ buttonÂ
In normal mode, this button is used to skip back a
track or for review playback (search).
When playback is stopped, if this button is pressed
once, the previous track is selected; if it is pressed
continuously, the tracks are skipped backward at high
speed.
During playback, if this button is pressed once, the
beginning of the current track is cued, and playback
restarts; if it is pressed continuously, review playback
(search) is performed.
During Title Input mode, this button is used to move
the cursor to the left.
j¯ / button
In normal mode, this button is used to skip forward a
track or for cue playback (search).
When playback is stopped, if this button is pressed
once, the next track is selected; if it is pressed
continuously, the tracks are skipped forward at high
speed.
During playback, if this button is pressed once, the
beginning of the next track is cued, and playback
begins; if it is pressed continuously, cue playback
(search) is performed.
During Title Input mode, this button is used to move
the cursor to the right.
kMD slot
Insert a MiniDisc here for playback or recording. With
the label side up, insert in the direction of the arrow.
lDUBBING button
This is used when dubbing from CD to MD. For details,
see “Dubbing from CD to MD” on page 35.
;INPUT SEL button
Select a recording source for the MD deck. The source
changes in the following order each time the key is
pressed:
ANALOG
œ
OPTICAL
œ
COAXIAL
During Dubbing mode, the CD output signal is
automatically selected as the source.
Even when the power is turned off, the input source
selection is retained.
zINPUT (L/R) controls
These controls are used to adjust the input level when
recording analog signals to MD. The left and right
channels may be independently controlled.
xEJECT ( ) buttonø
Press this to eject the MD.
cSTOP ( ) buttonª
Press this button to stop MD playback or recording.
If this button is pressed during dubbing, the MD deck
and the CD player stop simultaneously.
During MD Editing mode, when this button is pressed,
the Editing mode is cancelled, and the deck returns to
Normal mode.
vPLAY ( ) buttonÁ
Press this button to start playback when the MD deck
is in stop or standby mode.
When MD recording is in standby mode, pressing this
button starts MD recording.
When this button is pressed during dubbing standby
mode, the CD deck begins playback and the MD deck
begins recording, and dubbing begins.
bREADY ( ) buttonπ
When this button is pressed during MD playback or
while stopped, the MD deck enters standby mode.
When this button is pressed during MD recording, the
MD deck enters recording standby mode.
nRECORD ( ) button–
When this button is pressed and there is no MiniDisc
in the mechanism, the input signal can be monitored.
If a recordable MiniDisc is inserted into the mechanism
while it is stopped, when this button is pressed, the
MD deck enters recording standby mode, and the
input signal can be monitored.
When this button is pressed during recording, a track
mark is entered at that point and a new track is started.
mKEYBOARD connector
An IBM PC/AT compatible keyboard with PS/2 interface
can be connected to this terminal to enable certain
operations of the MD-CD1MKIII with the keyboard.
The key arrangement of a keyboard is divided into two
types: US and JP. The setting of this unit needs to be
configured. Check the specified keyboard type in the
menu settings. (See “Keyboard type setting” on page
46.)
4 – Names and Functions of Parts
TASCAM MD-CD1MKIII 17
This display shows various types of operation information,
including CD and MD disc information, deck operation
modes, and menu status. Disc and deck information for
either CD and MD are shown by pressing either the CD
button or the button, and the deck selected becomes MD
the display master. Also, the button or the CD MENU MD
MENU button can be pressed to call up the CD Menu or
the MD Menu.
,TOC
When the most recent TOC (Table of Contents) data
has not been recorded, this lights up red.
.Track number display
During playback or selection, the track number is
displayed.
/MP3
This indicator is lit when a data CD is in the CD deck.
!MD recording mode display (LP2, LP4, MONO)
This indicates the recording mode of the MD. If the
disc was recorded in Normal mode, it does not light
up.
During MD playback, the recording mode of the MD is
displayed.
@Counter display
Depending on the time display mode,
TOTAL
or
REMAIN
is lit. Counter display indication is in minutes
(three digits) and seconds (two digits).
#KEY
This lights when the CD deck’s Key Change function is
on.
$PITCH
This lights when the CD deck’s Pitch Control function
is on.
%A. CUE
This lights when the display master deck’s Auto Cue
function is on.
^A. READY
This lights when the display master deck’s Auto Ready
function is on.
&A. TRACK
This lights when the display master deck’s Auto Track
function is on.
It flashes during recording, in recording standby mode,
or when the Auto Track function is set to
Time
.
*Meter
This displays the playback level of either the CD or MD
deck, as well as the recording level of the MD deck.
(A-B
This lights when the display master deck’s A-B Repeat
function is on.
)REPEAT
This lights when the display master deck’s Repeat
function is on.
QSYNC
This lights during SYNC recording mode.
WREC
This lights when the MD deck is recording, or in
recording standby mode.
EOPTICAL
This lights when the MD input source is set to digital
(OPTICAL).
RCOAXIAL
This lights when the MD input source is set to digital
(COAXIAL).
TANALOG
This lights when the MD input source is set to analog.
YSINGLE
This lights when the display master deck is in single
playback mode.
URANDOM
This lights when the display master deck is in random
playback mode.
IPROGRAM
This lights when the display master deck is in program
playback mode.
OÁ
This lights when the display master deck is in playback
or recording mode. Also, when the Auto Cue function
is on, it flashes during Auto Cue point search.
Display
. / ! @ # $ % ^ & * (
W
Q
ER
TY
UI
O P A S DF
,
G
)
4 – Names and Functions of Parts
18 TASCAM MD-CD1MKIII
P π
This lights when the display master deck is in recording
standby or playback standby mode.
ADISC, GROUP, TRACK display
DISC
lights up when the display master deck has a
disc loaded and is stopped.
GROUP
lights up when the display master is the CD
deck and the Directory playback mode is on, or when
the display master is the MD deck and the group
playback mode is on.
TRACK
is indicated during playback or playback
standby.
SCharacter display
Disc information, track information, menu, message
and operation status are displayed.
D
This lights when the Timer Play function is on.
It flashes if a disc is not loaded when the Timer Play
function is on.
FCAPS,
These light during title input to indicate either CAPS or
Japanese character mode. In lower case letter mode,
there is no indication.
GEOM
This lights when the remaining track/disc time is less
than the EOM set value.
Rear Panel
K L Z:
H J
X
HDIGITAL INPUT MD (coaxial) Terminal
This is the digital input terminal (coaxial) for the MD
deck.
JDIGITAL OUTPUTS – MD – CD (coaxial) Terminals
These are the digital output terminals (coaxial). The
playback signals from the MD deck and the CD deck
are output through their respective digital output
terminals.
KANALOG INPUT MD (UNBALANCED) Terminals
The analog line input terminals for the MD deck are for
RCA pin jacks. Rated input level is –10 dBV.
LANALOG OUTPUTS – MD – COMMON – CD
(UNBALANCED) Terminals
The analog line output terminals are for RCA pin jacks.
Rated output level is –10 dBV.
MD: Outputs the MD deck signal. During playback, the
playback signal is output; during input monitoring, the
source signal is output.
COMMON: Outputs CD and MD signals. During
playback of both decks, the output signal depends on
the
COMMON?
option setting on the SYSTEM menu.
CD: Outputs the CD deck signal.
:DIGITAL INPUT MD (optical) Termainal
This is the digital (optical) input terminal for the MD
deck.
ZDIGITAL OUTPUTS – MD – CD (optical) Terminals
These are the digital output terminals (optical). The
playback signals from the MD deck and the CD deck
are output through their respective digital output
terminals.
XCONTROL I/O (RS-232C) Connector
RS-232C compatible serial control from an external
computer can be performed.
4 – Names and Functions of Parts
TASCAM MD-CD1MKIII 19
Remote Control Unit
1
2
34
6
7
89
0
q
5
e
w
r
ty
uio
p
n
l;
zx
cvm
,
.
/
b
j
asd
fg
h
@
k
!
Shared operation buttons
ª
CD/MD selector is used to select CD or MD deck 1
operation, while buttons and beyond are shared 2
operation buttons. and subsequent buttons control 3
the deck selected usign CD/MD selector as the 1
“remote control master”.
1CD/MD selector
Selects the remote control master. Refer to “Display
master and remote master settings” on page 27.
2 Number buttons (0 – 9)
These are used to select track numbers and for time
search. During MD Title Input mode, they can be
used to input letters, codes, numbers and Japanese
characters. Characters that can be input are indicated
above the buttons.
NOTE
Track number selection and time search can only be
•
performed for the display master deck. These functions
cannot be operated for the deck selected as the remote
control master.
While these buttons can also be used for character
•
input during title input operation, in this manual they
are referred to as “Number buttons.”
3P. MODE button
This selects the playback mode. During selection,
the playback mode is indicated on the display in the
following manner.
Continuous playback (in disc order): no indication
Single playback: SINGLE lights up
Program playback: PROGRAM lights up
Random playback: RANDOM lights up
For the modes apart from continuous playback,
refer to “Single-track playback” on page 30, “Program
playback” on page 30 and “Random playback” on page
31.
Even when the power is turned off, the playback mode
setting is retained.
4INS button
During MD Title Input mode, this button inserts a
space at the cursor position.
5DEL/CLR button
During track number input, the track number is
cleared when this button is pressed.
During program input, the selected program number
track is deleted.
During title input, the character at the cursor position
is deleted.
6NO button
This operates the same way as the button on the NO
unit.
7ENT/YES button
This operates the same way as the and YES ENTER
buttons on the unit.
8REPEAT button
This turns the Repeat Mode on and off. When it is on,
REPEAT
lights up in the display. Refer to “Repeat
playback” on page 29. Even when the power is turned
off, the Repeat Mode setting is retained.
9A-B REPEAT key
This turns the A-B Repeat Mode on and off, and is used
to set the section for repeat playback. Refer to “A to B
repeat playback” on page 29.
0AUTO CUE button
This turns the Auto Cue Mode on and off. When it is
on,
A.CUE
lights up in the display. Refer to “Auto cue”
on page 28. Even when the power is turned off, the
Auto Cue Mode setting is retained.
qAUTO READY button
This turns the Auto Ready Mode on and off. When it is
on,
A.READY
lights up in the display. Refer to “Auto
ready (of a specified track)” on page 28. Even when the
power is turned off, the Auto Ready Mode setting is
retained.
wDIR/GROUP button
When this button is pressed during stop, it turns on or
off the data CD directory playback mode (when the CD
deck is the remote control master) or the MD group
playback mode (when the MD deck is the remote
control master). Refer to “MP3 and WAV file directory
playback” on page 33, and “MD group playback” on
page 34.
e TIME button
This operates in the same way as the button on TIME
the unit.
4 – Names and Functions of Parts
20 TASCAM MD-CD1MKIII
rDISPLAY button
When pressed during stop mode, the current disc title
is displayed.
When pressed during playback or playback standby
mode, the current track title is displayed. Also, if the
CD/MD Selector is set to the side which is not the
current display master, pressing the DISPLAY button
will change the current display master setting.
tMENU buton
This button is used to turn on and off the Menu of the
current remote control master deck.
It operates in the same way as the and CD MENU MD
MENU buttons on the unit.
yMENU +/– button
During Menu Mode, this button is used to select menu
options and make settings. It operates in the same
way as the MULTI JOG dial on the unit. However, you
cannot select a track.
uFADER button
When pressed during CD playback standby, the sound
will fade in when playback resumes. When pressed
during CD playback, the sound will fade out.
When pressed during MD recording standby, the
sound will fade in when recording begins. When
pressed during MD recording, the recorded sound will
fade out.
iDUBBING button
This operates in the same way as the DUBBING button
on the unit. Refer to “Dubbing from CD to MD” on page
35.
oPITCH button
This operates in the same way as pressing the PITCH
button/dial on the CD operation section of the unit,
and is used to turn the pitch control on and off. Refer
to “Pitch control” on page 30. Even when the power is
turned off, the pitch control on/off setting is retained.
pPITCH +/– button
This operates in the same way as when rotating the
PITCH button/dial on the CD operation section of the
unit. When pitch control is on, the pitch value can be
set. Refer to “Pitch control” on page 30. Even when the
power is turned off, the pitch setting is retained.
CD Operation Section
aSEARCH buttonÔ
During playback or playback standby, press this button
continuously for review playback (search).
When a data CD is in the deck during stop mode, if
this button is pressed, the directory can be chosen
(backward direction).
sSEARCH button
During playback or playback standby, press this button
continuously for cue playback (search).
When a data CD is in the deck during stop mode, if this
button is pressed, the directory can be chosen (forward
direction).
dKEY button
This turns the Key Change function on and off. When it
is on, the musical key of CD playback can be changed.
Key change settings can be performed from the CD
menu. Refer to “Changing the key of playback” on page
32. Even when the power is turned off, the key change
settings are retained.
fSKIP buttonÂ
During normal playback, use this button to skip
through tracks in the reverse direction for selection.
During stop mode, press this button to skip through
tracks backwards, or press it continuously to skip at
high speed. During playback, press this button to skip
back to the start of the track in play.
gSKIP button¯
During normal playback, use this button to skip
through tracks in the forward direction for selection.
During stop mode, press this button to skip through
tracks forwards, or press it continuously to skip at high
speed. During playback, press this button to skip to
the start of the next track.
hSTOP ( ) buttonª
Operation is the same as with the button on the STOP
CD operation section of the unit.
jPLAY ( ) buttonÁ
Operation is the same as with the button on the PLAY
CD operation section of the unit.
kREADY ( ) buttonπ
Operation is the same as with the button on READY
the CD operation section of the unit.
4 – Names and Functions of Parts
TASCAM MD-CD1MKIII 21
MD Operation Section
lEDIT button
During normal operation, Menu mode and Title Input
mode, press this button to enter MD Edit mode. Refer
to “MiniDisc editing” on page 40.
When this button is pressed during MD Edit mode, the
unit returns to normal operation mode.
;TITLE button
During normal operation, Menu mode and MD Edit
mode, press this button to enter Title Input mode.
Refer to “Title input” on page 44.
When this button is pressed during Title Input mode,
the unit returns to normal operation mode.
zCHARA button
During Title Input mode, press this button to switch
between types of input characters. Refer to “Title
input” on page 44.
The type of character selected is indicated by the
display.
Lower case letters/code: no indication
Capital letters/code:
CAPS
Japanese:
xSYNC button
This button is used to turn SYNC recording on or
off. When on, recording is automatically started and
stopped depending upon the input signal level. Refer
to “Sync recording” on page 39.
When on, the
SYNC
indicator in the display lights up.
cGROUP SEARCH/SEARCH buttonÔ
During playback or playback standby, press this button
continuously for review playback (search).
When Group mode is on during stop mode, if this
button is pressed, groups can be chosen (backward
direction).
vGROUP SEARCH/SEARCH button
During playback or playback standby, press this button
continuously for cue playback (search).
When Group mode is on during stop mode, if this
button is pressed, groups can be chosen (forward
direction).
bAUTO TRACK button
During MD recording, this is used to set the Auto Track
function.
OFF
,
–**dB
or
Time
can be selected. Refer
to “Update (Move up) a track number” on page 37.
Even when the power is turned off, the settings are
retained.
nINPUT SEL button
Operation is the same as with the INPUT SELECT
button on the unit, and is used to choose the MD input
source. This button always functions, regardless of the
remote control master setting. Refer to “Input source
selection” on page 36.
mRECORD ( ) button–
Operation is the same as with the RECORD button on
the MD operation section of the unit.
,SKIP buttonÂ
During normal playback, use this button to skip
through tracks in the reverse direction for selection.
During stop mode, press this button to skip through
tracks backwards, or press it continuously to skip at
high speed. During playback, press this button to skip
back to the start of the track in play.
During title input mode, press this button to move the
cursor in the left direction.
.SKIP button¯
During normal playback, use this button to skip
through tracks in the forward direction for selection.
During stop mode, press this button to skip through
tracks forwards, or press it continuously to skip at high
speed. During playback, press this button to skip to
the start of the next track.
During title input mode, press this button to move the
cursor in the right direction.
/STOP ( ) buttonª
Operation is the same as with the button on the STOP
MD operation section of the unit.
!PLAY ( ) buttonÁ
Operation is the same as with the button on the PLAY
MD operation section of the unit.
@READY ( ) buttonπ
Operation is the same as with the button on READY
the MD operation section of the unit.
4 – Names and Functions of Parts
22 TASCAM MD-CD1MKIII
5 – Display Master and Remote Control Master
The MD-CD1MKIII is equipped with a CD deck and an MD
deck. Since the display and remote control buttons can be
used by either deck, this function determines which deck
is represented by their operation.
In this manual, the deck represented by the information in
the display is referred to as the “display master,” while the
deck being operated by the shared buttons on the remote
control unit is referred to as the “remote control master.”
Selecting the remote control
master
On the upper part of the remote control, there is a CD/
MD selector used to select the remote control master.
The shared buttons on the upper portion of the remote
control unit operate for the deck selected as the remote
control master.
CD/MD selector
Selecting the display master
The display master can be selected using the or CD MD
buttons. The or indicator lights up to show the CD MD
selection.
CD MD button button
CD indicator MD indicator
To switch the display master using the remote control, set
the selector to the desired position, then press CD/MD
the button.DISPLAY
DISPLAY button
CD/MD selector
NOTE
When using the shared buttons on the remote control
unit for operation, if the remote control master deck and
the display master deck are not the same, the results of
the operation will not be indicated on the display. To
confirm operation results, the remote control master deck
and the display master deck must be the same.
TASCAM MD-CD1MKIII 23
6 – Menu Operation
The various settings and editing operations possible with the MD-CD1MKIII are performed through menu options shown
on the display. Among the many menu setting options, some may be made directly using the buttons on the remote
control.
Menu configuration
There are menus for both CD and MD operation. Below each menu are sub-menus, and in each submenu there are menu
options. The menus are configured as shown below.
CD Menu
Menu option Function Manual reference Page
CD PLAY sub-menu (options for CD playback)
PLAY MODE Playback mode settings “Playback modes” 26
REPEAT Repeat mode settings “Repeat playback” 29
A_CUE LEVEL Auto Cue level setting “Auto cue” 28
A_CUE Auto Cue on/off “Auto cue” 28
A_READY Auto Ready on/off “Auto ready (of a specified track)” 28
PITCH STEP Pitch control variable pitch setting “Pitch control” 30
EOM TRK Track EOM mode and operation time “End of disc/track warning” 32
EOM DISC Disc EOM mode and operation time “End of disc/track warning” 32
TIMER PLAY Timer play on/off “Timer playback” 29
KEY LEVEL Key control level setting “Changing the key of playback” 32
DIR MODE Data CD directory playback mode on/off “MP3 and WAV file directory
playback”
33
MP3 ACTION Setting the error handling during MP3 file playback “Setting MP3 ACTION” 33
CD VOL FUNC sub-menu (CD volume function options)
PLAY VOLUME Output level setting “Output volume” 33
FADE IN Fade-in operation time setting “Fade-in and fade-out” 32
FADE OUT Fade-out operation time setting “Fade-in and fade-out” 32
FADE MODE Setting operation mode after fade-out end “Fade-in and fade-out” 32
SERIAL sub-menu (RS-232C data communication options)
BAUD RATE data transmission speed setting “Data settings/service data” 49
LENGTH data word length setting “Data settings/service data” 49
PARITY data parity bit setting “Data settings/service data” 49
STOP BIT data stop bit setting “Data settings/service data” 49
SYSTEM sub-menu (options for the unit)
KEYBOARD setting for keyboard type “Keyboard type setting” 46
COMMON CD/MD priority for COMMON output “Basic playback operation” 26
CD P_TIME Confirming total CD playing time “Data settings/service data” 49
MD P_TIME Confirming total MD playing time “Data settings/service data” 49
MD R_TIME Confirming total MD recording time “Data settings/service data” 49
IR REMOTE Disabling/Enabling remote control (RC-MC1) operation “Operation basics” 25
PANEL LOCK Disabling/Enabling panel operation "Locking the panel operations" 48
F_PRESET Resetting all data to initial default settings “Viewing service data” 49
CLEAR PROG Deleting a program Erase a CD or MD program 31
24 TASCAM MD-CD1MKIII
MD Menu
Menu option Function Manual reference Page
MD PLAY sub-menu (options for MD playback)
PLAY MODE Playback mode settings “Playback modes” 26
REPEAT Repeat mode settings “Repeat playback” 29
A_CUE LEVEL Auto Cue level setting “Auto cue” 28
A_CUE Auto Cue on/off “Auto cue” 28
A_READY Auto Ready on/off “Auto ready (of a specified track)” 28
EOM TRK Track EOM mode and operation time “End of disc/track warning” 32
EOM DISC Disc EOM mode and operation time “End of disc/track warning” 32
TIMER PLAY Timer play on/off “Timer playback” 29
GRP MODE Group playback mode on/off “MD group playback” 34
MD VOL FUNC sub-menu (MD volume function options)
REC VOLUME Input level setting “Basic recording” 36
FADE IN Fade-in operation time setting “Fade-in and fade-out recording” 38
FADE OUT Fade-out operation time setting “Fade-in and fade-out recording” 38
FADE MODE Setting operation mode after fade-out end “Fade-in and fade-out recording” 38
REC sub-menu (options for MD recording status)
REC MODE Recording mode setting “Basic recording” 36
REC SPEED Dubbing speed setting “Basic recording” 36
SYNC LEVEL Operation level setting of Sync recording “Sync recording” 39
SYNC Sync recording mode on/off “Sync recording” 39
A_TRK TIME Operation time setting of Auto track “Update (Move up) a track number” 37
A_TRK LEVEL Auto track operation level setting “Update (Move up) a track number” 37
A_TRK Auto track mode setting “Update (Move up) a track number” 37
PRE REC Pre recording time setting “Prerecording (Time Machine
recording)”
38
EDIT sub-menu (options for MD editing functions)
DIVIDE Dividing tracks “Divide tracks (DIVIDE)” 41
COMBINE Combining tracks “Combine tracks (COMBINE)” 42
MOVE Moving tracks “Move tracks (MOVE)” 42
GRP CREATE Creating groups “Creating a group” 42
GRP CANCEL Eliminating a group “Deleting a group” 43
ERASE DISC Erasing disc content “Erase disc (ERASE DISC)” 40
ERASE TRK Erasing a track “Erase track (ERASE TRK)” 40
ERASE MULTI Erasing multiple tracks at once "Erase multiple tracks at onece
(ERASE MULTI)
41
UNDO Undoing an editing operation “MiniDisc editing” 40
TITLE sub-menu (options for MD title editing functions)
TITLE INPUT Input of track or disc title “Title input” 44
TITLE GRP Input of a group title “Group title input” 45
CLEAR PROG Deleting a program Erase a CD or MD program 31
6 – Menu Operation
TASCAM MD-CD1MKIII 25
Operation basics
1 Select CD Menu or MD Menu.
Front panel operation:
Press the CD MENU button or the MD MENU button
to call up the desired menu.
Remote control operation:
Press the MENU button and either the CD Menu
or the MD Menu is called up, depending upon the
position of the CD/MD selector.
The sub-menu screen appears.
CD PLAY?
NOTE
In Menu mode, the
• CD or MD indicators flashes to
indicate which menu is called up.
When a menu is chosen for a deck that is not the
•
display master, the display master indicator will remain
lit, while the indicator for the menu mode deck will
begin flashing. If the menu for the display master deck
is selected, its indicator will begin flashing.
2 Select the desired sub-menu.
Front panel operation:
Use the MULTI JOG dial to select, then press the
MULTI JOG dial or the YES button.
Remote control operation:
Use the MENU –/+ button to select, then press the
ENT/YES button.
The screen for the selected menu option will be
displayed.
PLAY MODE?
NOTE
To return to the sub-menu selection screen from a menu
option selection screen, press the button on either NO
the front panel or the remote control unit.
3 Select the desired menu option.
Front panel operation:
Use the MULTI JOG dial to select, then press the
dial.
Remote control operation:
Use the MENU –/+ button to select, then press the
ENT/YES button.
The setting screen will be displayed.
Mode>Cont
NOTE
To return to the menu option selection screen, press the
NO button on either the front panel or the remote control
unit. However, if the button is pressed for an EDIT NO
menu option, you will exit the Menu mode.
4 Settings
Front panel operation:
Use the MULTI JOG dial to select, then press the
dial.
Remote control operation:
Use the MENU –/+ button to select, then press the
ENT/YES button.
NOTE
Some menu options exist for confirmation purposes
•
only, and setting cannot be performed.
For MD Editing Menu operation, refer to “MiniDisc
•
editing” on page 40.
For Title Menu operation, refer to “Title input” on page
•
44.
5 How to exit Menu mode after setting (or
confirmation), during menu option display.
Front panel operation:
Press the CD MENU or MD MENU button
corresponding to the current Menu mode.
Remote control operation:
Press the MENU button.
The or indicator will stop flashing.CD MD
NOTE
The
IR REMOTE?
option on the SYSTEM sub-menu of
the CD menu enables you to set the unit so that it will not
respond to remote control button operations (excluding
certain buttons). Set the option to
Enable
so that the
unit will respond to all remote control button operations.
6 – Menu Operation
26 TASCAM MD-CD1MKIII
7 – CD and MD Playback
The MD-CD1MKIII can play both CDs and MDs. Basic
playback and the operation of most playback functions
are virtually identical for the CD and MD decks. This
section will explain the shared playback functions first,
followed by playback functions for CD only, data CD
directory playback, and MD group playback.
Discs for playback
The CD and MD decks in the MD-CD1MKIII can play back
the types of discs listed below.
CD deck
Ordinary audio CDs available commercially (recorded in
CD-DA format)
CD-R and CD-RW discs recorded in CD-DA format, and
properly finalized
MP3 files recorded in ISO9660 format on CD-R and CD-RW
discs, and properly finalized.
MD deck
Audio MiniDiscs recorded in standard, LP2, LP4 and mono
modes.
Playback modes
There are four different playback modes for both the CD
deck and the MD deck. The mode selected is indicated on
the display.
Normal playback (continuous) mode: no indication
Single playback mode:
SINGLE
is lit
Program playback mode:
PROGRAM
red light is lit
Random playback mode:
RANDOM
red light is lit
The playback mode can be selected using the P. MODE
button on the remote control. Pressing the button
changes the playback mode in the following order:
Normal playback Single Program Randomœ œ œ
The playback mode appears on the display when
•
changed.
You can also select the playback mode using the
•
PLAY
MODE?
option in the PLAY sub-menu of the CD and
MD menus.
While the mode can be changed from any playback mode,
the explanation in this manual will assume the user is
starting from the normal playback (Continuous) mode.
Basic playback operation
CD:
ª
1 Push the POWER switch to turn on the unit.
The display will indicate
NO DISC
.
2 Press the OPEN/CLOSE button, and the CD tray
opens.
3 Place the CD in the tray, label side up.
4 Press the OPEN/CLOSE button again, and the CD
tray closes.
After a disc is set, the total playing time and number of
tracks will be displayed.
NOTE
At step 4 abouve, instead of the button, OPEN/CLOSE
if the button is pressed, the CD tray will close and PLAY
playback will begin, and if the button is pressed, READY
the CD tray will close and the unit will enter playback
standby mode.
5 Press the PLAY button.
The indication will light up, and playback begins Á
from track 1. The number of the current track in play is
indicated on the display.
6 To pause playback, press the READY button. The
π indication will light up, and the unit will enter
playback standby mode. To resume playback, press
the PLAY button.
7 To play a desired track, press either the or Â
¯ button on the front panel or on the remote
control. You can also use the number buttons on
the remote control. Refer to “Track selection” on
page 27.
8 To stop playback, press the STOP button.
9 To remove the disc, press the OPEN/CLOSE button.
MD:
ª
1 Push the POWER switch to turn on the unit.
The display will indicate
NO DISC
.
2 Insert the MiniDisc into the MD slot, in the direction
of the arrow, and with the label side up.
After a disc is inserted, the disc title (if there is one),
and the total playing time and number of tracks will
be displayed.
3 Press the PLAY button.
The indication will light up, and playback begins Á
from track 1. The number of the current track in play is
indicated on the display.
4 To pause playback, press the READY button. The
π indication will light up, and the unit will enter
playback standby mode. To resume playback, press
the PLAY button.
5 To play a desired track, press the or  ¯
button on the front panel or on the remote control.
TASCAM MD-CD1MKIII 27
You can also use the number buttons on the remote
control. Refer to “Track selection” on page 27.
6 To stop playback, press the STOP button.
7 To remove the MD, press the EJECT button.
About the monitor
Using headphones
Plug the headphone cord into the PHONES jack located
under the switch. Use the source selection switch POWER
to choose the desired source, and adjust the volume with
the volume control. If the source selection switch is set to
COMMON, both CD and MD sources can be monitored.
When both decks output a signal, the monitored source
depends on the
COMMON?
option setting on the SYSTEM
menu.
CAUTION
When using headphones, take care not to turn the volume
too high. Listening at high volumes for extended periods
of time may result in permanent hearing damage.
COMMON output
Signals are output from both the CD and MD decks
through the rear panel COMMON terminal and the
headphone terminal with the source switch set to
“
COMMON
”.
However, if both decks are outputting signals, priority
is given to signals from the deck (
CD
or
MD
) set in
COMMON?
in the SYSTEM submenu of the CD menu.
NOTE
Priority is given to the deck set in
COMMON?
for the
COMMON output source.
Display master and remote
master settings
For simple playback operation, the front panel buttons
or the remote control buttons can be used. However, to
ensure that the deck and disc information is properly
shown on the display, the ‘display master’ setting must
be selected for the deck in use. Also, when performing
various playback operations by remote control, the
‘remote control master’ setting must be selected for the
deck in use. Refer to “Display master and remote control
master” on page 22.
To prevent operation errors, we recommend that the
display master and the remote control master be set for
the same deck.
Track selection
Using the skip function
Select desired tracks for playback with the skip buttons
( / ) on the front panel or on the remote control. Â ¯
After selecting the track, press the buttons to start PLAY
playback, or the buttons to cue the track and READY
enter playback standby mode.
To restart playback from the beginning of the track in
play, press the button once. To skip to the previous Â
track, press twice.Â
To skip to the next track, press once.¯
Selecting by track number
Using the number buttons on the remote control, the
number of the desired track can be entered directly.
Even numbers with two or three digits can be entered
easily. For example:
Track 9: press ‘9’ and 009 will be displayed.
Track 12: press ‘1’ and ‘2’ and 012 will be displayed.
Track 103: press ‘1’ and ‘0’ and ‘3’ and 103 will be displayed.
After input, press the button to start playback, or PLAY
the button to cue the track and enter playback READY
standby mode.
NOTE
A computer keyboard allows you to select a track number
more easily for the 10 tracks from the beginning of the
disc using the “direct track” function. (See “12 Using a
computer keyboard – Direct track operation” on page 47 )
Search
During playback or playback standby, this function
enables the search of a desired portion within a track for
playback.
Front panel operation: press the
• Â ¯/ search
button continuously. Be sure to hold the button down;
if you quickly release it, the Skip function will operate.
Remote control operation: continuously press the
•
Ô / search button.
NOTE
The Search function does not operate with data CDs.
7 – CD and MD Playback
28 TASCAM MD-CD1MKIII
Time Search function
By specifying time from the start of a certain track, you
can start playback from a specified point of a specified
track.
Basic operation
1 During stop, playback or playback standby modes,
use the number buttons on the remote control to
input the three-digit track number (such as 002
for track 2), then the desired elapsed time (***min
**sec) from the start of that track.
Example: To specify 1 min 30 sec from the start of
track 2, input “002 001 30.”
NOTE
This function is not available in random playback mode,
•
program playback mode, or group playback mode.
For data CDs, time cannot be specified within a track.
•
However, if you input the three-digit track number,
playback will begin from the start of that track.
During input, the counter in the display will flash.
•
Regardless of the time display mode, the time from the
•
start of the specified track is displayed.
When the final digit is entered, the desired position is
automatically located. During stop or playback modes,
playback will begin from the desired point. During
playback standby mode, at the desired point the unit
will enter playback standby mode.
NOTE
If a point which does not exist is selected, setting
operation will be cancelled.
Operation variations
Even if the final second is not input, playback will begin
from the selected point after pressing the button. PLAY
Or, if you press the button, the unit will enter the READY
playback standby mode at the selected point.
Track search
This is explained in the “Specifying by track number” part
of “Track selection” on page 27.
After inputting the three-digit track number, press the
PLAY button to begin playback of that track, or the
READY button to cue the track and enter playback
standby mode.
Specifying to the minute
After inputting the three-digit track number and the
number of minutes after the start of the track, press
the button to begin playback of that track, or PLAY
the button to cue the track and enter playback READY
standby mode.
Example: To specify 1 min 00 sec from the start of track 2,
input “002 001.”
NOTE
Following the above example, if “0021” is input, the same
position will be located.
Auto cue
When the auto cue function is turned on, when a track is
selected, the point where sound begins (not where the
track begins) on that track is located, and the unit enters
playback standby mode. Then, when the button is PLAY
pressed, playback begins at exactly that point.
Auto cue on/off and the sound start position detection
level can be set separately for CD and MD.
NOTE
Auto Cue functions only for MD tracks recorded in the
•
ST mode. For MD tracks recorded in MONO, LP2 or LP4
modes, the Auto Cue function will only cue to the very
beginning of the track.
During the stop mode, to cue to the start of sound on
•
track one, just press the button.READY
Turning the Auto Cue function on and off
Press the button on the remote control to turn AUTO CUE
this function of display master on and off.
You can also use the
A_CUE?
option on the PLAY sub-
menu of the MD menu or CD menu to turn the Auto Cue
function on and off for each deck. (Default position: OFF)
When the Auto Cue function is on,
A.CUE
is lit on the
display.
Even when the power is turned off, the Auto Cue setting is
maintained.
Setting the sound start position detection level
Use the
A_CUE LEVEL?
option on the PLAY
submenu of the MD menu or CD menu to set the
sound start position detection level. Settings can be
made independently for each deck. The level can be set
between –72 dB and –24 dB in 6 dB increments.
NOTE
When the Auto Cue point is being searched, the arrow Á
flashes in the display, and audio output is muted.
Auto Ready
When the Auto Ready function is on, after each track is
played, playback standby mode is entered at the start of
the next track. Even when the Skip function is used to skip
tracks, playback standby mode is entered at the start of
the selected track.
NOTE
When the Auto Cue function is also on, playback standby
mode is entered at the start of the sound on the selected
track, and not the beginning of that track.
7 – CD and MD Playback
TASCAM MD-CD1MKIII 29
Turning the Auto Ready function on and off
Press the AUTO READY button on the remote control to
turn the function of display master on and off.
You can also use the
A_READY
? option on the PLAY
sub-menu of the MD menu or CD menu to turn the Auto
Ready function on and off for each deck. (Default position:
OFF)
When the Auto Ready function is on,
A.READY
is lit on
the display.
Even when the power is turned off, the Auto Ready setting
is maintained.
Repeat playback
Press the button on the remote control to turn REPEAT
on the Repeat mode. In this mode, all the tracks on the
disc are played continuously. During playback, if the
Repeat mode is turned on, playback continues as before,
and when the last track finishes, playback resumes from
the first track. If Repeat mode is turned on when the deck
is stopped, press the button to begin operation.PLAY
You can also use the
REPEAT?
option in the PLAY sub-
menu of the MD and CD menus to turn the Repeat mode
on and off for each deck.
Combining the Repeat mode with the Program, Single-
track playback and Random playback functions will
enable Program Repeat, Single-track Repeat and Random
Repeat operations, respectively.
A to B repeat playback
If a specific portion between two points on the disc is
specified, that portion can be played back repeatedly.
1 During playback, press the A-B REPEAT button on
the remote control at the beginning of the desired
portion on the disc.
A-
flashes on the display.
2 At the end of the desired portion on the disc, press
the A-B REPEAT button on the remote control
again.
REPEAT
and
A-B
are lit up on the display, and the
desired A-B section will be played repeatedly.
To cancel A-B Repeat mode and resume normal
playback
Press the A-B REPEAT button once more.
When the STOP button is pressed, the specified A-B
section is cancelled.
NOTE
A-B repeat playback does not function for two different
•
tracks of a CD.
A-B repeat playback does not function for data CDs.
•
Continuous CD and MD playback
With this function, when one deck finishes, the other deck
begins play.
1 Turn on the CONT PLAY switch on the front panel.
2 Play a CD or MD.
When the disc finishes playback, the disc in the other
deck begins playing automatically.
When that disc finishes, the first disc is played again,
and the playback cycle continues.
NOTE
During Continuous Play, the deck currently in playback
•
automatically becomes the display master.
When the Repeat Mode is turned on, Repeat playback
•
is performed instead of continuous playback. That is,
Repeat Mode has priority over the Continuous Play
function.
To cancel Continuous Play operation, press the
STOP button.
Timer Playback
By using an external timer, you can set the MD-CD1MKIII
to play the loaded disc automatically when the unit is
turned on by the timer.
1 First, plug the power cord of the MD-CD1MKIII into
the power outlet of the timer.
2 Load a CD or an MD into the unit.
3 Use the
TIMER PLAY?
option on the PLAY sub-
menu of the MD or CD menu to turn the timer
function on for the desired deck.
When Timer Play has been turned on, the timer icon
lights up in the display.
4 Set the timer to the desired time. Consult the
timer’s operation manual for details.
At the set time, the power to the MD-CD1MKIII will be
turned on, and playback will automatically begin.
NOTE
Only one deck can be selected for timer playback. This
deck will become the display master during Timer Play
operation.
7 – CD and MD Playback
30 TASCAM MD-CD1MKIII
Pitch control (CD only)
When playing back an audio CD, the pitch (or speed) of
the playback can be varied. Pitch can be varied –50% to
+16% for CD.
NOTE
Pitch control does not function for data CDs.
Front panel operation
1 During stop, playback or playback standby mode,
press the PITCH control to turn the Pitch Control
function on.
2 Rotate the PITCH control knob to set the pitch.
NOTE
Use the
PITCH STEP?
option in the PLAY sub-menu of
the CD menu to adjust the pitch control steps from 0.1%
to 1.0% in 0.1% increments. (Default: 0.1%)
Remote control operation
1 During stop, playback or playback standby mode,
press the PITCH button to turn the Pitch Control
function on.
2 Use the PITCH –/+ button to set the pitch.
Pitch is adjusted in 0.1% increments.
NOTE
Pitch control only functions during normal playback.
•
During recording, pitch control does not function.
When turning the pitch control on and off during
•
playback, sound output is cut for a short instant.
Single-track playback
This function enables playback of just a single track.
During stop mode, press the P. MODE button on
the remote control, and
SINGLE
lights up in the
display.
Stops playback after playback of a track has finished.
NOTE
If the Repeat function is also on, the selected track will
•
be played repeatedly.
You can also use the
•
PLAY MODE?
option in the
PLAY sub-menu of the MD and CD menus to set the
Single track playback mode.
Even when the power is turned off, the Single-track
•
playback mode settings are retained.
Program playback
This function enables playback of selected tracks in any
desired order. Up to 99 tracks can be selected from a CD,
or up to 25 tracks from an MD, for Program playback.
Programs of up to 100 discs including CD and MD can be
retained.
1 During stop mode, press the P. MODE button on
the remote control until
PROGRAM
is indicated on
the display.
The program number and total program playing
time will be shown on the character display. The
highest program number among the currently
registered programs appears on the program
number display immediately after the mode is
changed.
0p 0m 0s
Program number
Total program playing time
NOTE
You can also use the
•
PLAY MODE?
option in the
PLAY sub-menu of the MD and CD menus to set the
Program Playback mode.
The total program playing time does not appear for
•
data CDs.
Before setting up a program, press the
• STOP ( ) ª
button to enter stopped status.
2 Use the number buttons on the remote control to
select each desired track for program playback,
then press the ENT/YES button.
The track number will be entered into the program.
NOTE
To set the program by front panel operation, use the
MULTI JOG dial to select the track number, then press the
dial to add the track to the program.
3 Repeat the above step 2 until the desired program
is completed.
As the program is being created, the program number
and total program playing time is revised on the
display.
To confirm program contents, press the skip buttons
during playback or playback standby.
NOTE
If the total program playing time exceeds 999 min 59 sec,
“
- - - m - - s
” is displayed.
4 When program setting is completed, press the
PLAY button to begin playback of the tracks in the
programmed order.
7 – CD and MD Playback
TASCAM MD-CD1MKIII 31
Deleting a programmed track
1 During STOP mode, use the skip button to select
the track for deletion.
The track number will be shown in the display.
2 Press the DEL/CLR button.
NOTE
Right after STOP, if the button is pressed, the DEL/CLR
last track programmed will be deleted.
Adding a track to the program
1 During STOP mode, using the skip buttons, skip
to the programmed track before the position you
wish to add a track.
The track number should be shown on the display.
Example:
To add a new 3rd track (between 2nd and 3rd), display
the 3rd track (“3p”) of the program.
2 Use the number buttons to input the track number
of the track to be added.
3 Press the ENT/YES button on the remote control.
NOTE
Right after STOP, if the number of the track to be
•
added is input, and the button on the remote ENT/YES
control is pressed, the track will be added to the end of
the program.
To add a track to the program by front panel operation,
•
use the MULTI JOG dial to select the track number,
then press the dial.
Erase a CD or MD program
Insert the CD or MD for which you want to erase a
program into the deck.
1 Set the playback mode to Program.
2 Select “CLEAR PROG?” from the CD or MD menu.
Sure?
appears.
If the playback mode is not Program,
Can't Sel!
appears and you cannot select the option.
3 Press the MULTI JOG dial (or YES key) on the unit or
the ENT/YES key on the remote control.
The program is erased. When the erasing is complete,
Complete
appears.
NOTE
The program is also erased if all tracks in the program are
erased using the button.DEL/CLR
Program limitations
With an MD, if the Group playback mode is on,
•
programs that include more than one group cannot be
created.
With data CDs, if the Directory playback mode is on,
•
programs that include more than one directory cannot
be created.
The same track may be repeated in a program.
•
When 99 CD tracks (or 25 MD tracks) are entered into a
•
program, if you attempt to add a track,
PGM Full!
will be displayed, and no more tracks can be added.
Saving program data
Programs of up to 100 discs including CD and MD can
•
be retained.
For data CD, a single program uses double the usual
•
capacity, so the maximum number retainable will be
lower.
If a created program exceeds the capacity, other
•
programs will be automatically erased starting from
the oldest.
Programs on the currently inserted disc can be erased
•
using the menu.
CDs are distinguished by the total number of tracks (or
•
files) and total recording time (total capacity in the case
of data CD).
MDs are distinguished by the total number of tracks
•
and recorded time.
Discs with the same total number of tracks and the
•
same total recording time (total capacity in the case of
data CD) are regarded as identical.
Random playback
In this mode, the deck will play back all the tracks on
the disc in completely random order, regardless of track
number.
1 During stop mode, press the P. MODE button on
the remote control until
RANDOM
is indicated on
the display.
NOTE
You can also use the
PLAY MODE?
option in the PLAY
sub-menu of the MD and CD menus to set the Random
Playback mode.
2 Press the PLAY button.
Random playback starts. Playback stops when all the
tracks have been played once.
NOTE
Even when the power is turned off, the deck will remain in
RANDOM mode.
7 – CD and MD Playback
32 TASCAM MD-CD1MKIII
Time display switching
During MD or audio CD playback (or playback standby),
when the button on either the front panel or the TIME
remote control is pressed, the time display will switch
through several modes in the following order.
Elapsed track time: no display light indication
Remaining track time:
REMAIN
is lit in the display
Elapsed disc time:
TOTAL
is lit in the display
Remaining disc time:
TOTAL
and
REMAIN
are lit in the
display
NOTE
During MD playback, the remaining disc time
•
indication, as with CD, shows the playback time
remaining until the end of the disc. Please note that
this may differ from the remaining time indicated when
recording the MD.
When stopped, the total recording time is shown,
•
regardless of the status of the
TOTAL
and
REMAIN
indicators.
When playing a data CD, elapsed track time is always
•
displayed, and the button does not operate. TIME
For details on time display during recording and
•
recording standby on an MD deck, please refer to
“Checking remaining MD time” on page 39.
Even when the power is turned off, the time display
•
mode setting is retained.
End of disc/track warning
When nearing the end of a track or disc, a warning
indication is shown on the display.
The number of seconds before the track/disc end that the
warning is displayed can be set beforehand, so that when
playback reaches that point, the
EOM
warning will begin
flashing on the display.
To set the warning display time, use the
EOM TRK?
or
EOM DISC
options on the PLAY submenu of the MD and
CD menus. Each can be set between 1 and 99 seconds
in 1-second increments, or the warning display can be
turned off.
NOTE
The
EOM
warning function does not work with data CDs.
Playback functions for CD only
The following playback functions are for CD only, and are
not available for MD playback.
Changing the key of playback
The key of the music can be changed during CD playback.
Please note that this feature does not operate with data
CDs.
1 Use the
KEY LEVEL?
option on the PLAY sub-
menu of the CD menu to change the key. The
playback key can be raised or lowered 1/2 octave in
half-tone increments.
Selection values: 0 (no change), 1 to 6, #1 to #6â â
2 Press the KEY button on the front panel to turn the
Key Change function on.
The
KEY
indication lights up in the display.
NOTE
Each time the
• KEY button is pressed, the function is
switched on or off. When the function is on, instead
of an
On
indication, the key selected (in operation 1
above) is indicated on the display. For example:
Key
â
2
In this condition, when a CD is played back, the key
of the music is changed while the speed of the music
remains the same.
Even when the power is turned off, the key change
•
setting is retained.
When the Key Change function is on, even if the Pitch
•
Control function is used to change the playback speed,
the key of playback will remain fixed at the preset
key. (Even if the key level is 0 (zero), the Key Change
function can be turned on.)
When using the key control function, playback sound
•
may occasionally sound like vibrating. This is a result of
a special process applied to CD playback sound and is
normal.
Fade-in and fade-out
When this function is on, when CD playback begins the
song fades in, and when playback finished the song fades
out.
1 To set the fade operation, use the menu options
shown below. They can be found under the VOL
FUNC sub-menu in the CD menu.
FADE IN
The length of the fade in to the normal level can be
set between 1 and 30 seconds in 1-second increments.
(Default setting: 3 seconds).
FADE OUT
The length of the fade out into complete silence
can be set between 1 and 30 seconds in 1-second
increments.
7 – CD and MD Playback
TASCAM MD-CD1MKIII 35
8 – Dubbing from CD to MD
The MD-CD1MKIII makes it easy to dub from CD to MD.
Selected tracks or the entire disc can be dubbed.
Basic dubbing operation
First, load the CD to be used as the dubbing source into
the CD deck, then insert a recordable MiniDisc into the
MD deck.
NOTE
Copy-protected CDs cannot be dubbed.
To dub the entire CD
While the CD deck is stopped, press the button DUBBING
on either the front panel or the remote control.
To dub a selected track on the CD
During playback of the desired track, or when that track is
cued and the deck is in playback standby mode, press the
DUBBING button on either the front panel or the remote
control.
The track is selected for dubbing.
Start dubbing
Dubbing can be started when preparation is complete
and
Dubbing Wait
stops blinking.
Dubbing is started by pressing the button on the PLAY
CD or MD control panel.
Fade-in recording is performed if the button on FADER
the remote control is pressed instead of the button. PLAY
(The speed changes to
NORMAL
if it has been set to
HIGH
.)
NOTE
If the level is set to anything other than 0dB in
REC
VOLUME?
,
Vol> xx.xdB
blinks instead of
Dubbing
Wait
”. (xx.x: Setting value)
In this case, check the level as necessary.
Stop dubbing
Pressing the button stops dubbing.STOP
Dubbing ends in a fade-out if the button on the FADER
remote control is pressed instead of the button. STOP
(If dubbing started with a fade-in or if the speed is set to
NORMAL
)
If the end of a disc (when the entire disc is dubbed) or
track (when a track is dubbed) is reached, the normal stop
operation is performed even if dubbing started with a
fade-in.
NOTE
Dubbing is performed at the specified speed (see
•
below).
For the fade-in/fade-out time setting, see “Fade-in and
•
fade-out recording” on page 38.
Recording mode setting
Using the
REC MODE?
option on the REC submenu
of the MD menu, select the recording mode from the
following choices.
ST: standard stereo
recording mode
default, with no display
indication
MONO monaural recording
mode
MONO
lights up in the
display
LP2 half-speed stereo
recording mode
LP2
lights up in the
display
LP4 quarter-speed stereo
recording mode
LP4
lights up in the
display
NOTE
In MONO mode, the same signals are output from the
•
left and right channels of the headphone terminal and
rear panel audio output terminal.
In MONO mode, the recording time is twice that in ST
•
mode.
The recording time in LP2 mode is twice that in ST
•
mode.
The recording time in LP4 mode is four times that in ST
•
mode.
The remaining MD recording time indicated depends
•
upon the recording mode setting.
Recordings made in different recording modes can be
•
combined on the same disc.
Since a special data compression technology is used
•
for LP4 mode (quarter-time recording for four times
the recording time in stereo), there is the very slight
possibility of spikes of noise being generated. If sound
quality is an important consideration, we do not
recommend the use of the LP4 mode.
Dubbing speed setting
Use the
REC SPEED?
option on the REC submenu of
the MD menu to select either
NORMAL
or
HIGH
speed
dubbing.
NORMAL
: dubbing is performed during regular playback.
HIGH
(default setting): dubbing speed depends on the
source disc and start mode, as indicated below.
source disc Start mode dubbing speed
Audio CD Normal 4X speed
Audio CD Fade in Actual speed
Data CD ––– Actual speed
TIP
To listen while dubbing, select
•
NORMAL
. For faster
dubbing, select
HIGH
.
When Rec Speed is set to
•
NORMAL
, MD dubbing
is possible even if the Key Change or Pitch Control
functions have been used for CD playback.
38 TASCAM MD-CD1MKIII
Fade-in and fade-out recording
At the beginning and end of MD recording, fade-in and
fade-out effects can be performed.
Before following the procedure below, make sure that
basic recording preparations have been completed, a
recordable disc is inserted, and the deck is in stop mode.
1 Set operation using the following menu options on
the VOL FUNC sub-menu of the MD menu.
FADE IN
The length of the fade in to the normal level can be
set between 1 and 30 seconds in 1-second increments.
(Default setting: 3 seconds).
FADE OUT
The length of the fade out into complete silence
can be set between 1 and 30 seconds in 1-second
increments. (Default setting: 3 seconds).
FADE MODE
The deck can be set to continue recording (“Rec”) or
enter recording standby mode (“Ready”) after fadeout
is completed.
2 In recording standby mode, press the FADER
button on the remote control.
Recording begins and the sound fades in.
After the preset fade-in time, the sound is at normal
level.
3 During recording, press the FADER button on the
remote control when you wish to fade-out the
sound.
Fade-out begins, and after the preset fade-out
time, there is silence. After it becomes silent,
depending upon the Fade mode setting, recording
continues or the deck enters recording standby
mode.
NOTE
Fade-in or fade-out only may be selected.
•
The Prerecording function cannot be performed
•
together with fade-in recording. For details, refer to the
following section.
The unit adjusts the level for fade-in/fade-out in the
•
digital realm, but the volume of the monitor sounds
output through headphones or of signals output
through the ANALOG OUTPUTS DIGITAL terminal or
OUTPUTS terminal does not change.
Prerecording (Time Machine
recording)
This function makes it possible to start recording up to
6 seconds before the time the recording operation is
actually started. It operates by holding the input signal
in a buffer memory that can be set to contain up to 6
seconds of data representing a normal stereo input signal.
Before following the procedure below, make sure that
basic recording preparations have been completed, a
recordable disc is inserted, and the deck is in stop mode.
1 Set the time value for the amount of data to be
stored in the buffer using the
PRE REC?
option
on the REC sub-menu of the MD menu.
Setting values range from 1 to 6 seconds in
1-second increments, as well as OFF. The default
setting is OFF.
OFF: The Prerecording function does not operate.
1 sec to 6 sec settings: The buffer will hold the
corresponding seconds of signal.
2 Press the RECORD button to enter recording
standby mode.
3 Press the PLAY buton to start recording.
The signal will be recorded from the number of
seconds set before the button is pressed.PLAY
4 Press the STOP button to stop recording.
NOTE
When performing fade-in recording (explained in a
previous section), the prerecording function is not
possible.
Overwrite recording
The overwrite recording function allows you to
automatically delete and overwrite a previously recorded
portion after the specified position.
Before following the procedure below, make sure that
basic recording preparations have been completed, a
recordable disc is inserted, and the deck is in stop mode.
1 Locate the point at which you wish to begin
overwrite recording, press the READY button, and
the deck will go into playback standby mode.
To start overwrite recording from the beginning of
a certain track, use the SKIP button or the number
buttons to select the track, then press the READY
button.
To start overwrite recording from the middle of a
certain track, use the SKIP buttons or the number
buttons to select the desired track, then press the
PLAY button to begin playback (you can also use
the Search function). At the desired point, press
the READY button.
9 – MD recording from an external source
Produktspezifikationen
| Marke: | Tascam |
| Kategorie: | CD-Player/Recorder |
| Modell: | MD-CD1MK3 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Tascam MD-CD1MK3 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung CD-Player/Recorder Tascam
14 Oktober 2024
24 September 2024
16 August 2024
14 August 2024
12 August 2024
7 August 2024
4 August 2024
2 August 2024
29 Juli 2024
27 Juli 2024
Bedienungsanleitung CD-Player/Recorder
- CD-Player/Recorder Samsung
- CD-Player/Recorder Clatronic
- CD-Player/Recorder Basetech
- CD-Player/Recorder Exibel
- CD-Player/Recorder Lexibook
- CD-Player/Recorder Manta
- CD-Player/Recorder Philips
- CD-Player/Recorder SilverCrest
- CD-Player/Recorder Sony
- CD-Player/Recorder Panasonic
- CD-Player/Recorder Clas Ohlson
- CD-Player/Recorder LG
- CD-Player/Recorder Roland
- CD-Player/Recorder Camry
- CD-Player/Recorder AEG
- CD-Player/Recorder Yamaha
- CD-Player/Recorder Denver
- CD-Player/Recorder ECG
- CD-Player/Recorder König
- CD-Player/Recorder MarQuant
- CD-Player/Recorder Renkforce
- CD-Player/Recorder Telefunken
- CD-Player/Recorder Thomson
- CD-Player/Recorder Trevi
- CD-Player/Recorder Blaupunkt
- CD-Player/Recorder Grundig
- CD-Player/Recorder Kenwood
- CD-Player/Recorder Sharp
- CD-Player/Recorder Pyle
- CD-Player/Recorder Tronic
- CD-Player/Recorder Aiwa
- CD-Player/Recorder AudioSonic
- CD-Player/Recorder Auna
- CD-Player/Recorder Coby
- CD-Player/Recorder DIFRNCE
- CD-Player/Recorder Lenco
- CD-Player/Recorder Denon
- CD-Player/Recorder Mpman
- CD-Player/Recorder Pioneer
- CD-Player/Recorder JBL
- CD-Player/Recorder JVC
- CD-Player/Recorder Krüger And Matz
- CD-Player/Recorder Muse
- CD-Player/Recorder Onkyo
- CD-Player/Recorder Technics
- CD-Player/Recorder Akai
- CD-Player/Recorder Hitachi
- CD-Player/Recorder Hyundai
- CD-Player/Recorder Orava
- CD-Player/Recorder Reflexion
- CD-Player/Recorder Kärcher
- CD-Player/Recorder Sencor
