SUPERMICR R
ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• Drivers & Utilities: https://www.supermicro.com/wdl/driver/
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2022 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P cackage ontents
X12SPO-NTF/-F
Quick Reference Guide Rev. 1.0c
• One Supermicro Motherboard
• Two SATA Cables
• One I/O Shield
• One Quick Reference Guide
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
F or your system to work ProPerly Please download aPProPriate,
drivers images user s manual From the links below/ / ' :
MNL-2226-QRG-10c
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
Connectors
Jumpers and Connectors
Back Panel I/O Connectors
Memory Support
Motherboard Layout and Features
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this
guide.
Note: Refer to Chapter 2 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
CPU Support
The X12SPO-NTF/-F motherboard supports a 3rd generation Intel® Xeon Scalable
Processors (Socket P+ (LGA4189)) processors with up to 40 cores and a thermal
design power (TDP) of up to 270W.
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled)
Pins 2-3 (Disabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JWD1 Watch Dog Timer Pins 1-2 (Reset)
Pins 2-3 (NMI)
Connector Description
BT1 Onboard CMOS Battery (To Clear CMOS, remove the battery,
short pins 1-2 for more than 10 seconds and install the battery.)
COM1/COM2 COM Port/COM Header
FAN1 - FAN5, FANA, FANB CPU/System Fan Headers
I-SATA0 - I-SATA7 Intel® PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)
IPMI_LAN Dedicated IPMI LAN Port
JD1 Power LED/Speaker (Pins 1-4: Speaker)
JF1 Front Control Panel Header
JIPMB1 4-pin BMC External I2C Header (for an IPMI card)
JL1 Chassis Intrusion Header
JNCSI1 NC-SI Header for IPMI Support
JNVI2C1 NVMe I²C Header
JPI2
C1 Power Supply SMBus I2C Header
JPWR1 24-pin ATX Power Connector
JPWR2 8-pin Power Connector
JPWR3 4-pin Power Connector
JRK1 Intel RAID Key Header
JSD1, JSD2 SATA DOM Power Connectors
JSEN1 System Front Inlet Temperature Sensor Header
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1, LAN2 LAN 10G/1G Base-T
(Intel X550 for 10G [-NTF] or I350 for 1G[-F]) Ports
M.2-H_1, M.2-H_2 M.2 M-Key 2280/22110 (supports PCIe 3.0 x4/SATA3) Slot
NVMe0 - NVMe9 PCIe 4.0 p1-x8 Slimline SAS Connectors
(NVMe4~9 for -NTF only)
SLOT6 CPU PCIe 4.0 X16 Slot
SP1 Onboard Buzzer
S-SATA0, S-SATA1 SATA 3.0 Ports with SATA DOM Power
S-SGPIO1 Serial Link General Purpose I/O Connection Header
UID Unit Identiîš¿er (UID) Switch
USB0/1 Back Panel Universal Serial Bus (USB) 2.0 Ports
USB2/3, USB4/5 Front Access USB 2.0 Headers
USB6/7 Back Panel USB 3.2 Gen 1 Ports
USB8/9 Front Accessible USB 3.2 Gen 1 Header
USB10 USB 3.2 Gen 1 Type-A Header
VGA VGA Port
LED Description Status
BMC_HB_LED BMC Heartbeat LED Blinking Green: BMC Normal
LED2 Unit Identiîš¿er (UID) LED Solid Blue: Unit Identiîš¿ed
LED_CATERR CATERR LED Solid Orange: System CATERR
POWER_LED Onboard Power LED Solid Green: Power On
= mounting hole
SAN MACBAR CODE
IPMI CODE MAC CODE
BIOS
LICENSE
DESIGNED IN USA
X12SPO-NTF/-F
REV: 2.0
JIPMB1 JSTBY1 JP1
JCPLD1
JVRM1 JWD1 JP2 JD1
USB2/3 USB4/5
USB8/9 (3.0)
S-SATA0
I-SATA0-3I-SATA4-7
JSD1 JSD2
S-SATA1
JL1
JF1
FANB
JLED1 S-SGPIO1 FANA FAN4 FAN3
JRK1
NVMe8/9
JTPM1
M.2-H_1
M.2H_2
USB10 (3.0)
BT1
COM2
JNCSI1
JPL1
UID
VGA
LAN2 LAN1
USB6/7 (3.0)
IPMI_LAN
USB0/1
COM1
FAN5
JSEN1
NVMe4/5 NVMe2/3 NVMe0/1
JPWR1 JPWR2 JPI2C1
NVMe6/7
DIMMG1
DIMMF1
DIMMH1
DIMME1
DIMMA1
DIMMC1
DIMMD1
DIMMB1
CPU SLOT6 PCIe 4.0 X16
FAN2 FAN1
JPWR3
BMC_HB_LED
POWER_LED
MH5
MH6 MH7
MH1
MH11
MH10
MH12
MH13
JNVI2C1
LED_CATERR
MH8
MH4
MH9
MH3
MH2
LED2
CPU
JPME2
SP1
PCH
621A
JBT1
BMC
AST2600
Jumpers
Power Button
UID LED
NIC1 Active LED
Reset Button
HDD LED
PWR LED
Reset
PWR
UID SW
3.3V Stby
Ground
19
X
Ground
X
3.3V Stby
20
1 2
Ground
Power Fail LED
NIC2 Active LED
NMI
3.3V
OH/Fan Fail LED
3.3V Stby
The X12SPO-NTF/-F Supports up to 2048GB of ECC RDIMM/LRDIMM/LRDIMM
(3DS) with speeds of up to 3200MHz in eight slots. See below for additional
memory information.
• It's recommended to use DDR4 memory of the same type, size and speed.
Mixed DIMM speeds can be installed. However, all DIMMs will run at the
speed of the slowest DIMM.
• The motherboard will not support odd-numbered modules except for a single
DIMM module necessary for board operation. For more information, refer to
https://www.supermicro.com/support/resources/memory/X12_memory_con-
îš¿g_guide.pdf.
• To achieve the best memory performance, a balanced memory population is
recommended.
• Memory capacity and frequency is CPU dependent.
Front Control Panel (JF1)
CPU and PHM Installation
1
1
1
2
1
3
Assemble the processor carrier assembly by
inserting the CPU into the processor carrier.
To form the processor heatsink module (PHM),
mount the processor carrier assembly onto the
heatsink and snap into place.
After assembling the PHM, mount it onto the
CPU socket of the motherboard. Use a T-30
Torx-bit screwdriver to gradually install four
screws into the mounting holes from #1-4.
A
B
Pin 1
Allow carrier to
latch onto C PU
Allow carrier to
latch onto C PU
Allow carrier to
latch onto C PU
Allow carrier to
latch onto C PU
Mounting the Processor
Heatsink Module onto
the CPU socket (on the
motherboard)
Use a torque
of 12 lbf-in
T30 Torx Screwdriver
T e screws in ighten th
the sequence of 1, 2, 3, 4
#1
#2
#3 #4
Prin ted T riang le
1 9876
4
3
2
10
LED Indicators
5
# # # #Description Description Description Description
1 4 7COM1 USB1 LAN1 10 UID Switch/BMC Reset
2 5 8IPMI LAN USB6 (3.2 Gen 1) LAN2
3 6 9USB0 USB7 (3.2 Gen 1) VGA
1 CPU, 8-DIMM Slots
Number of DIMMs Memory Population Sequence
1 DIMMA1
2 DIMMA1 / DIMME1
4 DIMMA1 / DIMME1 / DIMMC1 / DIMMG1
6 DIMMA1 / DIMME1 / DIMMC1 / DIMMG1 / DIMMB1 / DIMMF1
8DIMMA1 / DIMME1 / DIMMC1 / DIMMG1 / DIMMB1 / DIMMF1 /
DIMMD1 / DIMMH1
