Supermicro X12SDV-14C-SPT8F Bedienungsanleitung
Supermicro
Hauptplatine
X12SDV-14C-SPT8F
Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Supermicro X12SDV-14C-SPT8F (1 Seiten) in der Kategorie Hauptplatine. Dieser Bedienungsanleitung war für 6 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/1
SUPERMICR R
ContaCt nformatIon I
• Manuals: http://www.supermicro.com/support/manuals
• Drivers & Utilities: https://www.supermicro.com/wdl/driver/
• Safety: http://www.supermicro.com/about/policies/safety_information.cfm
© 2022 Supermicro Computer Inc. All rights reserved. Reproduction of this document whether in part or in whole is strictly prohibited without Supermicro's written
consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing; however, it is not guaranteed.
P CaCkage ontents
X12sDV-4C/8C/14C/16C/20C-sPt8f
Q r g 1.0uICk eferenCe uIDe a
• One Supermicro Motherboard
• One Quick Reference Guide
• One I/O Shield
• Two SATA Cables
• Website: www.supermicro.com
• General Information: marketing@supermicro.com
• Technical Support: support@supermicro.com
• Phone: +1 (408) 503-8000, Fax: +1 (408) 503-8008
f or your system to work ProPerly Please DownloaD aPProPrIate,
DrIVers Images user s manual from the lInks below/ / ' :
MNL-2440-QRG-10a
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
• One COM Port Cable
• One OCuLink Cable (SATA)
• One OCuLink Cable (U.2)
Jumper Description Default Setting
JBM1 IPMI Share LAN Pins 1-2 Open (Enabled)
JBM2 IPMI Dedicated LAN Enable/Disable Pins 1-2 Open (Enabled)
JBT1 CMOS Clear Open (Normal)
JNS1 OCuLink to SATA 3.0 or PCIe 3.0
Selection Pins 2-3 (PCIe x4)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN1–LAN4 Enable/Disable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPT1 Onboard TPM Enable/Disable Pins 1-2 (Enabled)
JPTG1 LAN5/6 (10GbE) Enable/Disable Pins 1-2 (Enabled)
JWD1 Watch Dog Timer Pins 1-2 (Reset)
JTPM1
JMD1
JBT1
I-SGPIO1
I-SATA1
I-SATA0
JSLIM1
JSLIM2
JSTBY1
JSD1
BT1
JSMB1
J10G_PWR
JRK1
JPH1
JTGLED2
JLANLED1_1
JSFPLED1
JPI2C1
JD1
JGP1
JPCIe6
LEDT2 LEDT4
JPT1
JPF1
JNS1
JPG1
JPTG1
JVRM1
JWD1
JPME2
JPL1
COM1
JPV1
LEDT3 LEDT1
LED3
LED2
LED1
JMD1_SRW1
JMD1_SRW2
MH1
MH6
MH5
MH3
JL1
JOPPS
JBM2
JPWR1
JIPMB1
JNVI2C1
JF1
FAN2
FAN4
FAN1
FANB FANA
FAN3
JBM1
P1_NVME0
Aspeed
2600
Intel
X550
Intel
I350
PWR
LED
HDD
LED
NIC1
FF
OH
ON
NIC2
XRSTPWR
JF1:
USB 4/5(3.0)
IPMI_LAN
SUPERDOM
LEDPWR
JTPM1:TPM/PORT80
PCIe 4.0X8
PCIe 4.0X8
CPU SLOT6 PCIe 4.0 X16
LAN1/2LAN3/4
LAN5/6
LEDBMC
USB 0/1USB 2/3
UID
DIMMC1
DIMMD1
LAN7/8
CPU
DIMMA1
DIMMB1
VGA
PRESS FIT
DESIGNED IN USA BAR CODE
X12SDV-4C-SPT8F
REV:1.01
Jumpers and Connectors
CPU and Memory Support
Motherboard Layout and Features
Note: Graphics shown in this quick reference guide are for illustration only. Your components may or may not look exactly the same as drawings shown in this guide. Note: Refer to Chapter 1 of the User Manual for detailed information on jumpers, connectors,
and LED indicators.
Note: Refer to Chapter 2 of the User Manual for detailed information on memory support and CPU/
motherboard installation instructions.
= mounting hole
LED Indicators
LED Description Status
LED2 UID LED Solid Blue: Unit Identiîš¿ed
LED3 Overheat (OH)/Fan Fail/
Power Fail LED
Solid Red: Overheat
Blinking Red: Power Fail or Fan
Fail
LEDBMC BMC Heartbeat Blinking Green: BMC Normal
LEDPWR Onboard Power LED Solid Green: Power On
Connector Description
BT1 Onboard Battery
COM1 COM Header
FAN1–FAN4, FANA, FANB CPU/System Fan Headers
I-SATA0, I-SATA1 Intel® PCH SATA 3.0 Ports (I-SATA0 has built-in SATA
DOM Power on Pin 8)
I-SGPIO1 Serial Link General Purpose I/O Header
IPMI LAN Dedicated IPMI LAN Port
JD1 Speaker (Pins 1-3: Power LED, Pins 4-7: Speaker)
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JIPMB1 System Management Bus Header (for IPMI only)
JL1 Chassis Intrusion Header
JLANLED1_1 LAN3/4 Activity LED Header
JMD1 M.2 M-Key 2242/2280 (PCIe x4/SATA) Slot
JMD1_SRW1, JMD1_SRW2 M.2 Holding Screws
JNVI 2C1 Non-Volatile Memory (NVMe) I2C Header
JOPPS Reserved for One Pulse Per Second
JPH1 4-pin HDD Power Connector
JPI2C1 Power I2C System Management Bus (Power SMB)
Header
JPWR1 24-pin ATX Power Connector (Required)
JPV1 8-pin CPU Power Connector (Required)
JRK1 Intel RAID Key Header
JSD1 SATA DOM Power Connectors
JSFPLED1 LAN7/8 Activity LED Header
JSLIM1, JSLIM2 PCIe 4.0 p1-x8 SlimSAS Connector
Front Control Panel
Connectors and LED Indicators
Connectors
Connector Description
JSTBY1 Standby Power Header
JTGLED2 LAN5/6 Activity LED Header
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1/2, LAN3/4 1GbE RJ45 LAN Ports
LAN5/6 10GbE RJ45 LAN Ports
LAN7/8 25G SFP28 LAN Ports
P1_NVME0 OCuLink Connector (to four SATA3.0 or PCIe 3.0 x4)
SLOT6 CPU1 PCIe 4.0 p1-x16 Slot
UID Unit Identiîš¿er Switch
USB0/1, USB2/3 Front Accessible USB 2.0 Headers
USB4/5 Back Panel USB 3.0 Ports
VGA VGA Port
Power Button
OH/Fan Fail/PWR Fail LED
NIC1 Activity LED
Reset Button
HDD LED
PWR LED
Reset
PWR
3.3V Stby
Ground
15
3.3V Stby
16
1 2
Ground
NIC2 Activity LED
Power Fail LED
UID LED
+3.3V
3.3 V
+3.3V Stby
The X12SDV-SPT8F series motherboard supports an Intel Xeon D-2700 Proces-
sor with up to 20 cores and a TDP of 65-120W.
The motherboard supports up to 256GB of ECC RDIMM and up to 512GB
LRDIMM DDR4 memory with speeds of up to 2933MT/s in four memory slots.
Connectors
13
12
Back Panel I/O Connectors
# # # #Description Description Description Description
1. 5. LAN1 LAN5 13IPMI LAN 9 UID Switch
2. USB5 6. LAN4 10 SFP28 LAN8
3. USB4 7. LAN3 11 SFP28 LAN7
4. LAN2 8. LAN6 12 VGA Port
1
9
8
7
6
5
4
3
210
11
Jumpers
Note: For better compatibility with the motherboard, it is recom-
mended to use 5VSB 4A or more for the ATX power supply.
