Triple-Video Docking Station for Laptops - USB 3.0

StarTech ID: USB3DOCKH2DP

This triple-video docking station for laptops merges cutting-edge technology and high-quality hardware with

innovative design elements. It’s one of the first universal laptop docking stations to support three external

displays.

When coupled with your laptop display, the docking station makes it easy to create a high-performance, high-

resolution workstation with four displays in total, including one 4K DisplayPort™ display.

With its expanded display presence, this specialty docking station is ideal for a wide range of applications. It

offers a fast and easy way to maximize your laptop’s workable screen space, which is perfect for graphic and

web designers, animators, financial analysts and more.

A four-display workstation helps you get more done

The triple-video docking station uniquely integrates two video chipsets, making it possible to connect one

HDMI® and two DisplayPort monitors to your laptop. With four total displays, you can manage several programs

www.startech.com

1 800 265 1844

at once and avoid the nuisance of minimizing or rearranging windows. Plus it delivers 4K cinema resolution to

the first DisplayPort monitor.

This versatile docking station boosts your workflow with minimal impact on your budget, and it connects to your

laptop or Windows based tablet through just one USB 3.0 (also known as USB 3.1 Gen 1 - 5Gbps) cable.

4K Ultra HD delivers ultimate display potential

Why sacrifice image quality for display quantity? This top-of-the-line docking station offers the best of both

worlds. It features three video ports, including a DisplayPort connection that supports 4K x 2K (3840 x 2160p -

30Hz) Ultra HD resolution.

The docking station offers an enhanced method of upgrading the display capabilities of your computer. While

many laptop docks offer two video outputs, they often don’t support three external displays, or Ultra High

Definition.

The full-featured dock delivers crystal-clear image quality without sacrificing the total number of external monitor

connections, which is ideal for highly detailed and graphically intense applications.

Plenty of ports gives you everything you need

This triple-video docking station lets you connect up to 12 peripherals, to transform your laptop into a powerful,

full-sized workstation.

The dock also makes it easy to quickly charge your mobile devices, using the always-on fast-charge port. Plus,

with five USB 3.0 ports, a headset jack, separate 3.5mm audio and microphone ports, as well as an RJ45

Gigabit Ethernet port, you have all the connections you need with no complications or extra costs.

Unlike some docks, this easy-to-use docking station offers seamless, error-free driver installation that will have

you up and running fast.

The USB3DOCKH2DP is backed by a StarTech.com 2-year warranty and free lifetime technical support.

Maximum Supported Resolutions*

Video Output

Configuration

Max DisplayPort

Resolution

(Video 1)

Max HDMI

Resolution

(Video 2)

Max DisplayPort

Resolution

(Video 3)

DisplayPort 1

(Single Display) 3840 x 2160p (4K) N/A N/A

www.startech.com

1 800 265 1844

DisplayPort 2

(Single Display) N/A N/A 2560 x 1600p

HDMI

(Single Display) N/A 2560 x 1440p N/A

DisplayPort 1 and HDMI

(Two Displays) 3840 x 2160p (4K) 2560 x 1440p N/A

DisplayPort 2 and HDMI

(Two Displays) N/A 2048 x 1152p 2048 x 1152p

DisplayPort 1 and

DisplayPort 2

(Two Displays)

3840 x 2160p (4K) N/A 2560 x 1600p

DisplayPort 1, DisplayPort

2, HDMI

(Three Displays)

3840 x 2160p (4K) 2048 x 1152p 2048 x 1152p

*Lower resolutions are also supported. For example, if the max is 3840 x 2160p (4K), it also supports 2560 x

1600p and 2560 x 1440p.

Applications

Ideal for professionals who work with highly detailed graphics, including graphic and web designers,

animators, or engineers (CAD)

Scale your desktop across four displays — perfect for government, finance, marketing and sales

environments

Expand the connectivity of your laptop — compatible with Ultrabook, MacBook, Microsoft® Surface™ Pro

3, Lenovo® Yoga, and other Windows based tablets

Take full advantage of three monitors and Ultra HD technology, even if your laptop video card doesn't

natively support it

www.startech.com

1 800 265 1844

Produktspezifikationen

Marke:	StarTech.com
Kategorie:	Computer-Zubehör
Modell:	USB3DOCKH2DP
Kopfhörer-Anschluss:	3,5 mm
Breite:	82 mm
Tiefe:	270 mm
Gewicht:	376 g
AC-Netzadapter:	Ja
Mitgelieferte Kabel:	USB
Produktfarbe:	Schwarz, Silber
Übertragungstechnik:	Kabelgebunden
Höhe:	34 mm
AC Eingangsspannung:	100-240 V
Kopfhörerausgänge:	2
Gleichstrom-Anschluss (DC):	Ja
Betriebstemperatur:	0 - 40 °C
Relative Luftfeuchtigkeit in Betrieb:	0 - 90 %
Verpackungsbreite:	296 mm
Verpackungstiefe:	164 mm
Verpackungshöhe:	71 mm
Paketgewicht:	1034 g
Netzstandard:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Zertifizierung:	CE, FCC, DisplayLink, TAA, REACH
Vollduplex:	Ja
Stromverbrauch (Standardbetrieb):	32.5 W
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	1
Warentarifnummer (HS):	84733020
Betriebsanleitung:	Ja
Gehäusematerial:	Kunststoff
Anzahl HDMI-Anschlüsse:	1
Ethernet LAN Datentransferraten:	10,100,1000 Mbit/s
LED-Anzeigen:	Activity, Link
Temperaturbereich bei Lagerung:	-10 - 80 °C
Mac-Kompatibilität:	Ja
Auto MDI/MDI-X:	Ja
Unterstützt Mac-Betriebssysteme:	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 13.0 Ventura
Stromstecker-Typ:	Typ N
Anzahl Produkte pro Versandkarton:	10 Stück(e)
Länge des Versandkartons:	373 mm
Breite des Versandkartons:	363 mm
Höhe des Versandkartons:	395 mm
USB-Stecker:	USB Typ-A
Mikrofon-Eingang:	Ja
Unterstützung anderer Betriebsysteme:	ChromeOS
Kabelsperre-Slot:	Ja
Ausgangsstrom:	6.5 A
Ausgangsspannung:	5 V
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A:	5
Integrierter Kartenleser:	Nein
Nachhaltigkeitszertifikate:	RoHS
Eingangsstrom:	1.5 A
Markenkompatibilität:	Jede Marke
USB Datenübertragungsraten:	5000 Mbit/s
Kombinierter Kopfhörer-/Mikrofon-Anschluss:	Ja
Hostschnittstelle:	USB 3.2 Gen 1 (3.1 Gen 1) Type-A
Anzahl DisplayPort Anschlüsse:	2
Wake-on-LAN bereit:	Ja
Datenübertragungsrate:	5 Gbit/s
Anzahl der Mikrofoneingänge:	1
Kompatible Steckertypen:	AU, EU, UK, US
Chipsatz:	DisplayLink - DL-5910, VLI - VL812
Auflösung (maximal, digital):	3840 x 2160 Pixel
UASP-Unterstützung:	Ja
Ethernet/LAN:	Ja
