Quick-start guide

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 11/30/2017

For the latest information, technical specications, and support for

this product, please visit www.StarTech.com/US100A20SFP

Package contents

• 1 x network adapter

• 1 x quick-start guide

Requirements

• USB-enabled computer with an available USB 2.0 port

• Any of the following operating systems:

• Microsoft Windows® 10, 8/8.1, 7

• Microsoft Windows Server® 2012, 2008, 2003

• macOS El Capitan (10.11), Yosemite (10.10), Mavericks (10.9),

Mountain Lion (10.8)

• Linux® kernel 3.5 to 4.11.x, LTS versions only

• 100Mbps SFP transceiver with your desired network connection

Operating system requirements are subject to change. For the latest

requirements, please visit www.StarTech.com/US100A20SFP.

US100A20SFP

USB 2.0 to 100Mbps Ethernet Network Adapter - Open SFP

*actual product may vary from photos

Product diagram

Link and activity LED

SFP slot

Built-in USB 2.0

cable

Installation

Notes:

• You may need to restart your computer during the software

installation process. Be sure to save any unsaved material before

you install the software.

• If you’re running Windows 7 (or lower), macOS or Linux, ensure

the network adapter is not connected to your computer until after

driver installation.

1. If you’re running Windows 7 (or lower), macOS or Linux, download

the latest software from the StarTech.com website:

http://www.StarTech.com/US100A20SFP.

Note: If you’re running Windows 8 (or later) proceed to step 5.

2. The software that corresponds with your operating system will be

compressed in a .zip folder. Download and extract the contents

of that folder to a location on your computer that’s easy to access,

such as your or folder. Desktop Downloads

3. Open the folder that corresponds with your specic operating

system and launch the installer le.

4. Follow the on-screen prompts to complete the installation, and if

instructed to do so, restart your computer.

5. Insert your 100Mbps SFP transceiver into the SFP slot on the card.

6. Connect a network interface cable to the SFP transceiver and to

your network.

7. Connect the built-in USB 2.0 cable to a USB port on your

computer.

About the LED indicators

The network adapter features two LED indicators:

• The Power LED illuminates to indicate that the adapter is receiving

power from the computer that it’s connected to.

• The Link and activity LED illuminates solid to indicate a network

connection link and blinks to indicate that data is being sent or

received.

Power LED
