Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: May 31, 2022 2:55 PM
Product ID
SV221HUC4K
Front
Rear
2 Port 4K 60Hz HDMI KVM Switch with one USB-C Host Port
Component Function
1Port Selection Button • Press the to switch Port Selection Button
between or PC 1 PC 2
2Console USB HID Ports
• Connect a (e.g. Human Interface Device (HID)
Keyboard, Mouse, Trackpad, Number Keypad, or
Drawing Tablet)
• Front (x2)
• USB 2.0 (480Mbps)
3PC 1 USB-C Host Port
• Connect to a with a Computer USB-C Port
• For full functionality USB-C Port Host Computer
must support DP-Alt Mode
4PC 1 Selection Indicator • Solid Blue: PC 1 is selected
5PC 2 USB Micro-B Host
Port • Connect to a or higher port on USB 2.0 PC 2
6PC 2 Selection Indicator • Solid Blue: PC 2 is selected
7PC 2 HDMI Input Port • Connect to an on HDMI Port PC 2
8Console HDMI Output
Port • Connect to an on a HDMI Input Display
Product Information
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit: www.StarTech.com/SV221HUC4K
Package Contents
• KVM Switch x 1
• USB-C Cable (1 m) x 1
• USB-A to Micro USB-B Cable (1 m) x 1
• HDMI Cable (1 m) x 1
• Quick-Start Guide x 1
35 7
2
1
8
4 6
Regulatory Compliance
FCC - Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could
void the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Warranty Information
This product is backed by a two-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss
of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the
product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the
limitations or exclusions contained in this statement may not apply to you.
Safety Measures
If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.
安全対策
製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。
Misure di sicurezza
Se il prodotto p2-ha un circuito stampato visibile, non toccare il prodotto quando è acceso.
Säkerhetsåtgärder
Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com
Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp
The Netherlands
Requirements
Source PCs
• USB-C DisplayPort Alt-mode enabled Computer x 1
• USB-A and HDMI enabled Computer x 1
Console
• HDMI Display x 1
• HDMI Cable x 1
• USB Mouse x 1
• USB Keyboard x 1
Installation
Connect the Console
Note: Power o all , , and before completing the Computers Displays Peripherals
following steps.
1. Connect an to the , located on the rear of the HDMI Display Console HDMI Output Port KVM
Switch HDMI Cable, using an (sold separately).
2. Connect a and a to the , located on the USB Mouse USB Keyboard Console USB HID Ports
front of the .KVM Switch
Connect the PCs
1. Connect the included from the , located on the front of the USB-C Cable PC 1 USB-C Host Port
KVM Switch USB-C Port PC 1, to an available on .
Note: For full functionality the must support DP-Alt ModeHost Computer USB-C Port
2. Connect the included from the located on USB Micro-B Cable PC 2 USB Micro-B Host Port,
the front of the , to an available on .KVM Switch USB port PC 2
3. Connect the included from the located on the front of the HDMI Cable PC 2 HDMI Input Port,
KVM Switch HDMI Output Port PC 2, to an available on .
