Quick start guide

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

Manual Revision: 10/14/2015

For the latest information, technical specications, and support for

this product, please visit www.startech.com/SDOCKU313E.

Packaging contents

• 1 x USB 3.1 and eSATA SSD and HDD docking station

• 1 x universal power adapter (NA/EU/UK/AU)

• 1 x USB cable

• 1 x eSATA cable

• 1 x quick start guide

System requirements

• Computer system with an available USB Type A port or an eSATA

port

• A 2.5 in. or 3.5 in. SATA hard drive (HDD) or solid-state drive (SSD)

The SDOCKU313E is OS independent and doesn’t require any

additional drivers or software.

Note: To obtain the maximum USB throughput, you must use a

computer with a USB 3.1 Gen 2 (10Gbps) port.

System requirements are subject to change. For the latest

requirements, please visit www.startech.com/SDOCKU313E.

SDOCKU313E

USB 3.1 (10Gbps) and eSATA Docking Station for SATA Drives

*actual product may vary from photos

Product diagram

Front view

Power button and LED

Drive slot

Eject button

Rear view

DC power connector

USB 3.1 type B

connector (host)

eSATA connector

Installation

Connect the dock

Warning! Drives and storage enclosures should be handled carefully,

especially when they’re transported. If you’re not careful with your

drives, you may lose data as a result. Always handle storage devices

with caution.

1. Connect the external power adapter from the dock to a power

outlet.

2. Do one of the following:

• Connect the included USB cable from the dock to a USB port on

your computer system. Your computer can either be turned on

or turned o when you connect the USB cable.

• Connect the included eSATA cable from the dock to an eSATA

port on your computer system. Your computer can either be

turned on or turned o when you connect the USB cable.

Install a drive

Before you install a drive, make sure that the dock is turned o.

1. Carefully align a 2.5 in. or 3.5 in. SATA drive with the drive slot on

the dock, so that the SATA power and data connectors on the

drive are aligned with the corresponding connectors that are

inside of the drive slot.

2. Insert the 2.5 in. or 3.5 in. SATA drive into the slot.

3. Press the Power button to turn on the dock. The LED indicator

should light up to indicate that the dock is turned on.

After the drive is installed and the dock is turned on, your computer

automatically recognizes the drive and it’s accessible as though the

drive is installed internally in the system. If your computer doesn’t

automatically recognize the drive, see the Prepare a drive for use

topic.

About driver installation

No driver or software installation is required for this product because

the dock is natively supported and the drivers are already installed.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the

equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and

access our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for

repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not

allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Prepare a drive for use

If you install a drive that already has data on it, after you plug in the

drive, it appears under My Computer Computer or with a drive letter

assigned to it.

If you install a brand-new drive that doesn’t contain any data, you

must prepare the drive for use.

If you use a computer that’s running a version of Windows®, do the

following:

1. On the taskbar, click the Windows icon.

2. In the eld, type .Search disk management

3. In the search results, click .Disk Management

4. Locate the disk that is labeled . To conrm that the Unallocated

drive is the correct one, check the drive capacity.

5. Right-click the section of the window that says and Unallocated

click .New Partition

6. To initialize the drive in the format of your choice, complete the

on-screen instructions.

When the drive is successfully installed, it appears under My

Computer Computer or with a drive letter assigned to it.

Remove a drive

Note: Make sure that the drive isn’t being accessed by the computer

before you proceed.

1. To remove the drive from the operating system, do one of the

following:

• On computers running a version of Windows, click Safely

Remove Device.

• On computers running a version of Mac OS, drag the drive to

the icon.trash can

For more information, see the documentation that came with your

operating system.

2. Press the button on the top of the dock and wait for the Power

dock to nish powering down.

3. To release the drive, press the button on the top of the dock.Eject

4. Pull the drive from the drive slot.
