5-048-863- (1)01
KD-32W830L
Reference Guide
Television
https://rd1.sony.net/help/tv/kusltnr2/h_usltn/
TV rear cover
(mm)
(kg)
KD-32W830L 730 437 75 4.8
(mm)
(kg)
KD-32W830L 730 465 188 5.0
Wall-Mount Bracket
MIC
The remote control shape, layout, availability
and function of remote control buttons may vary
depending on your region/country/TV model/
TV settings.*1
(Power)
TV: Display TV channel list or switch to input.
(Quick settings): Display Quick Settings.
(Input select): Display and select the
input source, etc.
(Control menu): Display the Control
menu.
/ / / / : On screen menu
navigation and selection.
(Back)
(Home)
(Google Assistant / Microphone):
Use Google Assistant*2*3 or voice search*3.
+ / – (Volume)
(Mute)*4
CH + / – (Channel)
(Dashboard): Display Dashboard.
(Guide): Display the digital program
guide of TV or Cable/Satellite box*
5.
App buttons
*1 For other remote control models, refer to the
online Help Guide for details.
*2 Only for limited region/country/model/
language.
*3 Google Assistant or voice search requires an
Internet connection.
*4 Accessibility shortcut is available by pressing
and holding (Mute).
*5 [Cable/Satellite box setup] setting is required.
8 – 11 (mm)
M4
© 2023 Sony Corporation
Note
•Instructions about “Installing the TV to the Wall”
are included within this TV’s instruction manual.
•Read the supplied safety documentation for
additional safety information.
Location of the identification label
Labels for the TV Model No. and Power Supply
rating are located on the rear of the TV.
For models with supplied AC adapter:
Labels for AC adapter Model No. and Serial No. are
located on the bottom of AC adapter.
This receiver complies with the minimum
requirements as specified in National
Telecommunications Commission,
Memorandum Circular 02-03-2016, Regarding
the Sale and Labeling of ISDB-T Receivers,
including Memorandum Circular No.
01-0302017, Amending Certain Provisions of
Section 2 of NTC Memorandum Circular No.
02-03-2016 (Sale and Labeling of ISDB-T
Receivers).
Installing the TV to the Wall
Using the optional Wall-Mount Bracket (SU-WL450)*
(not supplied)
To Customers:
For product protection and safety reasons, Sony
strongly recommends that installation of your TV
be performed by Sony dealers or licensed
contractors. Do not attempt to install it yourself.
To Sony Dealers and Contractors:
Provide full attention to safety during the
installation, periodic maintenance and
examination of this product.
Wall-Mount Bracket Installation Information
For instructions on Wall-Mount Bracket installation,
see the Installation Information (Wall-Mount
Bracket) on the product page for your TV model.
https://www.sony-asia.com/support
•Follow the instruction guide provided with the
Wall-Mount Bracket for your model. Sufficient
expertise is required in installing this TV,
especially to determine the strength of the wall
for withstanding the TV’s weight.
•Sony is not liable for any damage or injury caused
by mishandling or improper installation.
•Only qualified service personnel should carry out
wall-mount installations.
•For safety reasons, it is strongly recommended
that you use Sony accessories, including:
— Wall-Mount Bracket SU-WL450
•Be sure to use the screws supplied with the
Wall-Mount Bracket when attaching the Wall-
Mount Bracket to the TV set. The supplied screws
are designed as indicated by illustration when
measured from the attaching surface of the Wall-
Mount Bracket.
The diameter and length of the screws differ
depending on the Wall-Mount Bracket model.
Use of screws other than those supplied may
result in internal damage to the TV set or cause
it to fall, etc.
•Be sure to store the unused screws and Table-Top
Stand in a safe place until you are ready to attach
the Table-Top Stand. Keep the screws away from
small children.
* Only for limited region/country/model.
Troubleshooting
General troubleshooting for issues like: black
screen, no sound, frozen picture, TV does not
respond, or network is lost, do the following steps.
1 Restart your TV by pressing the power button
on the remote control until a menu appears.
Select Restart to restart the TV. If the TV does
not recover, try unplugging the AC power cord
(mains lead) then press the power button on the
TV and release it. Wait for two minutes, and plug
in the AC power cord (mains lead).
2 Refer to the Help menu shown below.
3 Connect your TV to the Internet and perform a
software update. Sony recommends you to
keep your TV software updated. Software
updates provide new features and performance
improvements.
4 Visit Sony support website (information
provided at the end of the supplied safety
documentation).
When you plug in the TV, the TV may not be
able to turn on for a while even if you press
the power button on the remote control or
the TV.
It takes time to initialize the system. Wait for about
one minute, then operate it again.
The remote control does not function.
•Replace the batteries.
The parental lock password has been
forgotten.
•Enter 4357 for the PIN and enter the new PIN.
For more information, refer to
the Help Guide.
Press (Home) on the remote
control and select [Help].
Specifications
System
Panel system
LCD (Liquid Crystal Display) Panel, LED Backlight
TV system
Analog: M
Digital: ISDB-T
Color system
NTSC/PAL N (Video Only)/PAL M (Video Only)
Channel coverage
Analog: UHF/VHF/Cable
Digital: UHF/VHF
Sound output (W)
10 + 10
Wireless technology
Protocol IEEE 802.11a/b/g/n/ac
Bluetooth® Version 5.0
Input/Output jacks
Antenna (aerial)/cable
75 ohm external terminal for VHF/UHF
/ VIDEO IN
Video/Audio input (phono jacks)
HDMI IN 1/2/3
Video:
1080p (30, 50, 60 Hz), 1080/24p, 1080i (50,
60 Hz), 720p (30, 50, 60 Hz), 720/24p, 576p, 576i,
480p, 480i, PC Formats* 1
Audio:
Two channel linear PCM: 32/44.1/48 kHz
16/20/24 bits, Dolby Audio
ARC (Audio Return Channel) (HDMI IN 3 only)*2
Two channel linear PCM: 48 kHz 16 bits, Dolby
Audio, Dolby Atmos
DIGITAL AUDIO OUT (OPTICAL)
Digital optical jack (Two channel linear PCM:
48 kHz 16 bits, Dolby Audio)
(Stereo mini jack)
Headphone
1, 2
USB port 1 support High Speed USB (USB 2.0)
USB port 2 support High Speed USB (USB 2.0)
LAN
10BASE-T/100BASE-TX connector (Depending on
the operating environment of the network,
connection speed may differ. The communication
rate and quality are not guaranteed.)
DC IN 19.5 V
AC adapter input
Power and others
Power requirements
19.5 V DC with AC adapter
Rating: Input 100 V - 240 V AC, 50/60 Hz
Screen size (measured diagonally) (Approx.)
(inches/cm)
32 / 80.0
Power consumption
Indicated on the rear of the TV
Standby power consumption*3*4 (W)
0.5
Display resolution (horizontal × vertical) (pixels)
1366 × 768
Output rating
500 mA (for USB)
Others
Optional accessories
Wall-Mount Bracket: SU-WL450
Operating temperature
0 ºC – 40 ºC
*1 Refer to the online Help Guide for details.
*2 Connect your audio system to the HDMI IN 3 to
route TV audio to your audio system.
*3 Specified standby power is reached after the TV
finishes necessary internal processes.
*4 Standby power consumption will increase when
your TV is connected to the network.
Note
•Support belt kit
FB
is not applied to Philippines.
•Optional accessories availability depends on
countries/region/TV model/stock.
•Design and specifications are subject to change
without notice.
•Subscriptions for services and applications may
be required and additional terms, conditions
and/or charges may apply when using Google
Assistant.
•Visit Sony website for more information on
product specifications.
Trademark Information
•Manufactured under license from Dolby
Laboratories. Dolby, Dolby Audio, and the
double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
