For Gasoline Powered

Pressure Washers

Quick Start Guide

1. This quick start guide is not a replacement for the owner’s manual. Be sure to download and read

the owners manual before operating the machine for the rst time.

2. Read all the information in the safety section of this document and all related user manuals before

operating the machine.

3. Perform the procedures outlined in this quick start guide before operating the machine.

Notes: Contact Us:

To obtain a full manual, including your warranty terms, scan the

code or text the number on the Learn More label on the machine,

or visit https://www.simpsoncleaning.com, or contact Customer

Support at 1-877-362-4271 or email: cservice@fna-group.com

If you have any questions regarding the unpacking,

assembly, or use of your pressure washer, please

have your model number and serial number ready,

then contact customer support at 1-877-362-4271

or email .cservice@fna-group.com

SAMPLE

Attempting to start the engine incorrectly or using the

pressure washer incorrectly can result in engine and/

or pressure washer damage, and may cause serious

injury or death. To avoid these hazards, be sure to

read, understand, and follow the steps outlined in

the OPERATING CHECKLIST section of the owner’s

manual before starting the engine, and follow all the

guidelines for proper use of the pressure washer.

This product has many parts that move at high

speeds. Moving parts can cause crushing injuries,

broken bones, severe lacerations, and/or traumatic

amputations. To prevent injury, never place ngers,

hands, feet, or other body parts near running engine.

Never operate product with covers, shrouds, or other

guards removed. Do not wear loose-tting clothing,

dangling drawstrings, or any other hanging items

that could become entangled in moving parts while

operating. Tie up long hair and remove jewelry before

operating.

The high pressures created by a pressure washer

can cause uid injection injuries, severe lacerations,

amputations, and / or death. To avoid these hazards,

always aim the spray gun and lance in a safe direction

when using a pressure washer and never attempt to

touch a leak in a high-pressure hose or tting.

Gasoline is highly ammable and gasoline vapors are

extremely explosive. Fire and explosions can cause

severe burns and/or death. Keep gasoline away from

ames, sparks, and other ignition sources. Refuel

outdoors in a well-ventilated area with the engine

stopped and cool. Wipe up any spilled gasoline

and allow engine to dry before starting. Keep a re

extinguisher handy while refueling. Do not operate

engine with leaks in the fuel system. Do not store

gasoline near other ammable materials.

Pressure washing with volatile, ammable, or

corrosive liquids could cause pressure washer

damage, re, or explosion resulting in severe injury

and/or death. To avoid these hazards, use only

approved soaps and chemicals, do not attempt to

pressure wash with volatile, ammable, or corrosive

liquids, and NEVER use bleach.

Engine exhaust contains carbon monoxide, an

odorless, colorless, poisonous gas. Running an

engine indoors will kill you in minutes. Never use this

product inside a house, garage, or any other kind of

enclosure even if doors and windows are open. Run

engine outside at least 20 feet (6 meters) away from

windows, doors, and vents. Carefully consider wind

direction and air currents when using this product

outside to avoid breathing in engine exhaust. Always

use a carbon monoxide detector in any occupied

buildings near the running engine.

OPERATION

CHECKLIST MOVING PARTS

INJECTION INJURY

REFUELING

VOLATILE LIQUIDS

TOXIC FUMES

Untrained persons, young children, and pets can

be seriously injured or killed if allowed to incorrectly

operate or play with a running pressure washer.

To avoid these hazards, be sure anyone operating

the pressure washer receives proper instructions,

understands safe operation, and has read the

owner’s manual before operating this product. Do

not let children operate the pressure washer without

parental supervision. Keep young children and pets

away from the pressure washer while it is running.

Always turn o󰀨 the pressure washer before leaving

the area.

UNTRAINED

OPERATION

Transporting the pressure washer in an enclosed

space on a transport vehicle where temperatures can

rise may cause fuel to vaporize and leak. Gasoline is

highly ammable and gasoline vapors are extremely

explosive. Fire and explosions can cause severe

burns and/or death. To avoid these hazards, secure

the pressure washer in a well ventilated area out of

direct sunlight and other heat sources and do not

transport the pressure washer on rough roads unless

the fuel has been drained beforehand.

TRANSPORTATION

Failure to inspect this product and before use

could result in product damage, serious injury,

and/or death. To avoid these hazards, inspect the

pressure washer before each use. Check for loose

or damaged parts, signs of oil or fuel leaks, missing

guards, plugged cooling vents, or any other condition

that may a󰀨ect proper operation. Repair or replace

all damaged or defective parts and keep all safety

guards in place and in proper working order before

using the pressure washer.

INSPECT

Safety:

Indicates a potentially hazardous situation which, if not avoided, could result in property damage, serious injury, and/ or death.

Indicates a hazardous situation, which if not avoided, could result in property damage and/or minor to moderate injury.

Indicates information considered important but not directly hazard related.

NOTE: Be sure to read understand the safety information listed below. Each box contains one of three words: WARNING, CAUTION,

or NOTICE each of these words indicates a di󰀨erent level of hazard severity and is followed by information about specic hazards, the

consequences of the hazards, and instructions on how to avoid the hazards. Failure to heed these symbols and the information provided with

them could result in property damage, injury, and/or death.

1 (888) 123-4 67

SAMPLE

CAUTION:

NOTICE

WARNING:

WARNING: WARNING:

WARNING:

WARNING: WARNING:

WARNING:

IMPORTANT!

Page 2 of 4 Part Number 7117172 / English REV 11 - 3/2023

The low oil sensor (if equipped) will automatically

stop the engine when the oil level falls below the safe

limit. To avoid an unexpected shutdown, check the

oil level regularly, ll to the upper limit, and always

operate engine on a level surface.

LOW OIL SENSOR

Rapid retraction (also known as kickback) of the

engine recoil starter cord will pull your hand and

arm towards the engine faster than you can let go

of the handle resulting in sprains, broken bones,

lacerations, and/or traumatic amputations. Kickback

is caused by damage to the engine crankshaft key,

compression release failure, and/or improper starting

techniques. To avoid kickback follow the appropriate

maintenance schedule and starting instructions listed

in the owner’s manual and have engine repair work

done by an authorized service center.

RAPID RETRACTION

PUMP PURGING

A running engine produces heat. The surfaces of

the engine, other related components, and engine

exhaust gas get hot enough to cause mild moderate

burns or ignite materials on contact. To avoid burns,

do not touch engine surfaces or exhaust gases while

operating and allow engine to cool completely before

moving, touching, or performing any maintenance.

To avoid a re, keep all ammable materials at least

ve feet away from all sides of the product.

HOT SURFACES

Assembly / Connecting Hoses:

Unpacking:

1. Place the shipping carton on a solid, at surface.

2. Carefully cut the top of the carton open.

3. Carefully cut each corner of the carton from top to bottom.

4. Lay each side of the carton at on the ground.

5. Remove everything from the carton.

This product and the engine exhaust can expose you to chemicals which

are known to the state of California to cause cancer, birth defects, or other

reproductive harm. For more information on California Proposition 65, go to

www.P65Warnings.ca.gov.

CALIFORNIA PROPOSITION 65 WARNING

WARNING:

NOTICE NOTICE

High-pressure spray can damage plants and other

surfaces. To avoid damaging plants, cover them

before spraying near them. To avoid damaging

surfaces. Refer to the Nozzle Selection table in this

manual for correct nozzle and test surfaces before

spraying to make sure they are strong enough to

withstand high-pressure spray.

SPRAY DAMAGE

NOTICE

The engine is shipped from the factory without oil.

Running the engine without oil will result in severe

engine damage and void the warranty. To avoid

causing engine damage and voiding the warranty, ll

the engine with the recommended oil type.

FILL ENGINE OIL

BEFORE USING

NOTICE

Oil is a major factor in the performance and service

life of any engine. Using the incorrect oil may damage

the engine and void the warranty. To avoid causing

engine damage and voiding the warranty, check and

change oil as required using the correct engine oil.

USE CORRECT

ENGINE OIL

NOTICE

Operating the engine with a high-altitude carburetor

jet kit at an altitude below 5000 feet (1524 meters)

will cause the engine to run too hot. Overheating the

engine could result in serious engine damage. To

avoid this hazard, make sure the correct carburetor

kit is installed and the air/fuel mixture is set correctly

for your altitude.

ALTITUDE

NOTICE

Water can damage the pressure washer engine

components if allowed to enter through cooling slots

or other holes. Damage caused by water intrusion is

not covered under warranty. To avoid engine water

damage, do not use a pressure washer, garden

hose, or any other sources of running water to clean

the pressure washer engine, and never submerge

the pressure washer engine in any liquids.

CLEANING

NOTICE

Turning o󰀨 the water supply to your pump with the

engine running will damage the pump. Damage

caused by running the pump without water is not

covered under warranty. To avoid this hazard always

turn o󰀨 the engine before shutting o󰀨 the water

supply.

PUMP DAMAGE

NOTICE

Old gasoline can create deposits that clog fuel

systems causing hard starting and poor performance.

Damage caused by old fuel is not covered by

warranty. To minimize deposits, avoid old fuel related

performance issues, and prevent costly repair work,

do not use gasoline that is older than 30 days.

OLD GASOLINE

NOTICE

It is important to prevent gum deposits from forming

in essential fuel system parts, such as the carburetor,

fuel lter, fuel hose or tank during storage. Alcohol-

blended fuels (also called gasohol, ethanol, or

methanol) attract moisture, which leads to separation

and formation of acids during storage. Acidic fuel and

gum deposits can damage the engine’s fuel system

while in storage. Damage caused by the use of old,

stale, or contaminated fuel are not covered under

warranty.

GASOLINE STORAGE

NOTICE

Using chemical cleaners and/or corrosive liquids

can damage the pressure washer seals and internal

components. Damage caused by chemical cleaners

and corrosive liquids is not covered under warranty.

To avoid these hazard, only used approved cleaning

chemicals, never use bleach, and always run clean

water through the pressure washer after using

cleaning chemicals.

CHEMICAL

CLEANERS

NOTICE

The use of fuel system cleaning additives can

damage the engine and fuel systems. Damage

caused by the use of fuel system cleaning additives

is not covered by warranty. To avoid engine and fuel

system damage, do not use any fuel system cleaning

additives.

GASOLINE ADDITIVES

NOTICE

Using gasoline with an alcohol blend greater than

10% (E10) will damage the engine. Damage caused

by using an alcohol blend of 15% (E15), 85% (E85),

or any other alcohol blend higher than 10% (E10)

is not covered under warranty. To avoid engine

damage caused by an alcohol blend that is too high,

use gasoline with 10% (E10) alcohol or lower.

ALCOHOL BLENDS

NOTICE

Overlling the fuel tank can result in carbon canister

damage (if equipped), poor engine performance, and

void the warranty. To avoid these hazards, do not ll

the fuel tank above the maximum level.

DO NOT OVERFILL

FUEL TANK

NOTICE

Running the pressure washer for more than two

minutes without the spray gun trigger pulled will

overheat the pump and possibly cause damage. The

thermal relief valve will open and spray water to help

cool the pump as it overheats. To avoid overheating

the pump, shut o󰀨 the machine if not being used for

longer than two minutes.

PUMP DAMAGE

NOTICE

CAUTION:

Hot oil can cause serious burns. To prevent getting

burned when changing or checking the engine oil,

use gloves to prevent hot oil from touching skin and

change oil when the engine is warm from but not hot.

HOT OIL

CAUTION:

This appliance is not intended to be used by persons

(including children) with reduced physical, sensory, or

mental capabilities, or lack of experience and knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person responsible

for their safety.

NOTICE

Children should be supervised to ensure that they do not

play with the appliance.

Running a pressure washer pump without water will

severely damage the pump seals and other internal

components. To avoid this hazard, make sure your

water supply is uninterrupted, provides at least

5 GPM at 20 PSI, and always purge the air your

pressure washer pump before starting the engine.

Refer to the ‘Assembly / Connecting Hoses’ section

of this quick-start guide to learn how to purge the

pump of air.

Anytime the pressure washer may endure freezing

temperatures, remaining water needs to be drained

from the pump, high-pressure hose and spray gun

assembly. Drain the hose, spray gun and pump as

explained in the pressure washer Use and Care

Manual. It is suggested to purge the pump of water

by using Simpson® Pump Guard or equivalent pump

protectant.

FREEZE DAMAGE

NOTICE

A RED shipping plug is in the pump that must be replaced with a BLACK

breather cap. The cap is easy to replace with the following steps:

1. Using a bladed screw driver, remove the RED shipping plug from

the top of the pump.

2. Hand thread the BLACK breather cap into the pump.

3. Snug the cap with your ngers.

1. Add the pump breather cap. (If applicable)

RED shipping plug

BLACK breather cap

11. Remove fuel cap, ll fuel tank with fresh gasoline, then

replace fuel cap. Be careful not to cross-thread the gun

and lance.

Thread the high-pressure hose onto

the spray gun inlet.

Upper Limit

Lower Limit

Upper Limit

Engine Oil Dipstick

Lower Limit

Full NOTE: Fill with engine

o󰀨 and cool. Do not over

ll fuel tank.

Page 3 of 4 REV 11 - 3/2023

Part Number 7117172 / English

7. Insert the male QC plug on the spray gun

into the female QC connector on the high-

pressure hose.

4. Make sure the inlet screen is

clean, inside the pump inlet, and

has the convex side facing out.

5. Turn on the water supply and run it for 30

seconds to purge any dirt or debris from the supply

hose. Then, turn o󰀨 the water supply and thread

the water supply hose into the pump inlet.

OROR

10. Select the

correct nozzle for

your cleaning job per

nozzle selection chart

in this document and

install it onto the lance

by pulling the quick-

connect coupler back,

inserting the nozzle,

then releasing the

coupler allowing it to

snap back in place.

6. Insert the male quick-connect (QC) plug on the high-

pressure hose into the female QC outlet on the pump or thread

the high-pressure hose onto the pump outlet.

Slide the handle onto

the frame then secure

it with the included

knobs and bolts.

9. Turn on the

water supply, aim

the spray gun in a

safe direction, then

squeeze and hold

the trigger for at

least 30 seconds or

until the water runs

steady and all the air

is purged from the

pump and hoses.

When completed,

engage the trigger

lock.

2. Press and hold

buttons then slide

handle onto frame until

buttons click into place.

Thread the high-pressure hose onto

the spray gun inlet.

This pressure washer was

shipped from the factory without

oil in the engine. Running the

engine without oil will result in

severe engine damage and void

the warranty. To avoid these

hazards, ll the engine with the

recommended oil type before

starting.

1. Place machine on a level surface then remove the engine oil dipstick by unscrewing it.

2. Fill the engine

with the correct

oil per the engine

owner’s manual.

The oil level should

be towards the

high mark on the

dipstick. Replace

the dipstick when

the engine is full.

Fill Engine With Oil:

Engine Oil Dipstick

3. Install the spray gun holster (if applicable) onto

the handle using the included knob and bolt.

Note: For units that have

a second dashboard,

see page 4 of this

document for assembly.

NOTICE

8. Secure the lance to the gun by carefully

turning the coupler on the spray gun until

the coupler stops rotating. Do not over

tighten. Most of the threads on the lance

will not be visible if the lance and gun are

properly assembled. Be careful not to

cross-thread the gun and lance.

WARNING!

The threads on the lance and

gun coupler can be easily cross threaded

resulting in an improper assembly. An

improper assembly of the gun and lance

can result in personal injury. Do not use

if the threads on the gun coupler and or

lance are cross

threaded.

Trigger shown in

the locked position.

Remember to always

lock the trigger when

not in use.
