Seite 1/63
1
Installation and system optimization guide:
The following manual and guides were carefully prepared by the SilverStone engineering team to help
you maximize the potential of your SilverStone product. Please keep this manual for future reference
when upgrading or performing maintenance on your system. A copy of this manual can also be
downloaded from our website at:
Disassemble chart
Connector deînition
Front I/O connector guide
Component size limitations
Recommended cooling device setup & selection
Installation guide
Speciîcation P.2
P.3
P.5
P.17
P.19
P.20
P.27
Protect your computer P.49
Upgrade and Maintenance P.39
Q&A P.50
h
ttp://ww
w
.s
ilv
e
r
s
t
o
n
e
t
e
k.
co
m
mputing
2
Material
Model
Motherboard
Drive Bay
Cooling System
Expansion Slot
Front I/O Port
Power Supply
Expansion Card
Dimension
Extra
*If you intend to utilize all hard drive slots, please remove all unused power supply cables.
These unused cables may cause problem with the installation. SSDs are highly recommended
in place of hard drives.
* Maximum length for PSU is 180mm, we recommend 160mm due to varying connector locations
on PSUs and the unique structure of SG10. We do not promise that all retail PSUs on the market
can be installed in the SG10. Please refer the guides provided in this manual to select your PSU.
Aluminum front panel, Steel body
SST-SG10B (black)
Micro ATX, Mini-DTX, Mini-ITX
Exposed
Internal
Rear
Top
Left
Right
4
USB 3.0 x 2 audio x 1 MIC x 1ă ă
Optional standard PS2(ATX) up to 180mm*
Compatible up to 13.3â long, width restriction-5.70"
354mm (D) x 220mm (W) x 295mm (H), 23 liters
Support two Kensington locks
12.7mm/9.5mm slim optical x 1
3.5" x 2 * , 2.5â x4*
1 x 120mm 1200rpm 22dBA
180mm Air Penetrator 600/900/1200rpm, 17/25/34dBA
(backward compatible with 140mm)
1 x 120mm 1200rpm 22dBA(backward compatible with 92mm)
2*80/92mm fan slot
80mm fan slot
R
e
d
e
f
i
n
i
ng performance in small form factor co
m
