Seite 1/68

RD-8504

cover_8504:cover_8504 2009-09-21 오 11:28 페이지 1

ENGLISH

Introduction

: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

This symbol is intended to alert the user to the presence of

uninsulated "dangerous voltage" within the product's

enclosure that may be of sufficient magnitude to constitute

a risk of electric shock to persons.

This symbol is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in the literature accompanying the appliance.

Caution regarding installation

Note : For heat dispersal, do not install this unit in a confined space such as a bookcase or similar enclosure.

: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

CAUTION

WARNING

Units shipped to Australia are designed for operation on 240 V AC only.

To ensure safe operation, the three-pin plug supplied must be inserted only into a standard three-

pin power point which is effectively earthed through the normal household wiring. Extension cords

used with the equipment must be three-core and be correctly wired to provide connection to earth.

Improper extension cords are a major cause of fatalities. The fact that the equipment

operates satisfactorily does not imply that the power point is earthed and that the installation

is completely safe. For your safety, if in any doubt about the effective earthing of the power

point, consult a qualified electrician.

PAN-EUROPEAN UNIFIED VOLTAGE

All units are suitable for use on supplies 220-240 V AC.

FOR YOUR SAFETY

EUROPE

AUSTRALIA

220 V

240 V

Do not block ventilation openings or stack other equipment on the top.

READ THIS BEFORE OPERATING YOUR UNIT

CAUTION

• Leave a space around the unit for sufficient ventilation.

• Avoid installation in extremely hot or cold locations, or in an area

that is exposed to direct sunlight or heating equipment.

• Keep the unit free from moisture, water, and dust.

• Do not let foreign objects in the unit.

• The ventilation should not be impeded by covering the ventilation

openings with items, such as newspapers, table-cloths, curtains,

etc.

• No naked flame sources, such as lighted candles, should be

placed on the unit.

• Please be care the environmental aspects of battery disposal.

• The unit shall not be exposed to dripping or splashing for use.

• No objects filled with liquids, such as vases, shall be placed on

the unit.

• Do not let insecticides, benzene, and thinner come in contact

with the set.

• Never disassemble or modify the unit in any way.

■Notes on the AC power cord and the wall outlet.

• The unit is not disconnected from the AC power source(mains)

as long as it is connected to the wall outlet, even if the unit has

been turned off.

• To completely disconnect this product from the mains,

disconnect the plug from the wall socket outlet.

• When setting up this product, make sure that the AC outlet you

are using is easily accessible.

• Disconnect the plug from the wall outlet when not using the unit

for long periods of time.

Information for Users on Collection and Disposal of

Old Equipment and used Batteries

These symbols on the products, packaging, and/or

accompanying documents mean that used electrical and

electronic products and batteries should not be mixed

with general household waste. For proper treatment,

recovery and recycling of old products and used

batteries, please take them to applicable collection

points, in accordance with your national legislation.

By disposing of these products and batteries correctly,

you will help to save valuable resources and prevent any

potential negative effects on human health and the

environment which could otherwise arise from

inappropriate waste handling.

For more information about collection and recycling of

old products and batteries, please contact your local

municipality, your waste disposal service or the point of

sale where you purchased the items.

[Information on Disposal in other Countries outside the

European Union]

These symbols are only valid in the European Union. If

you wish to discard these items, please contact your

local authorities or dealer and ask for the correct method

of disposal.

Note for the battery symbol (bottom two symbol

examples):

The sign Pb below the symbol for batteries indicates that

this batteries contains lead.

RD-8504(G)_ENG_091217:RD-8504(G) 2009-12-21 오 11:36 페이지 2

ENGLISH

contents

• Introduction

READ THIS BEFORE OPERATING YOUR UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

• System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• Front Panel Controls 11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

• Universal Remote Controls 13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OPERATING COMPONENTS WITH REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

REMOTE CONTROL OPERATION RANGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

LOADING BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

USING FUNCTIONS OF REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

• Operations

LISTENING TO A PROGRAM SOURCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

SURROUND SOUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

ENJOYING SURROUND SOUND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

LISTENING TO RADIO BROADCASTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

LISTENING TO RDS BROADCASTS (FM ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

(RDS Tuner (Regional Option for some countries in Europe, etc))

RECORDING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

DIGITAL AUDIO RECORDING WITH MD RECORDER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

OTHER FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

ROOM 2 SOURCE PLAYBACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

• OSD Menu Settings 36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

SETTING THE SYSTEM SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

SETTING THE SPEAKER / ROOM EQ SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

SETTING THE INPUT SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

SETTING THE MULTI ROOM SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

SETTING THE SOUND PARAMETER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

SETTING THE ADVANCED VIDEO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

• Troubleshooting Guide 59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

• Specifications 60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

• Setup Code Table 61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
