- 1 -
Pedestal Installation Instructions
Instructions d'installation du socle
Instrucciones de instalaciĆ³ del pedestal
Components
X1 D
X4
B
X4 C
X4 E
X4 F
X5 G
X4 A
D -
2
D-1
Tools
Code No. : DC68-02436A-03
Wrench
Supplied with Washing
Machine or General Wrench
(9/16inch or 14mm)
Socket Wrench
[11/16 inch, or 17mm] Phillips Screwdriver Flat Screwdriver
0203-002150
DC60-60044A
DC60-40017A
6002-001313
D-1 : DC61-01811A
Guide-leg(A)
D-2 : DC61-01812A
Guide-leg(B)
DC61-01813B
ATLAS-02436A-03.indd 1 2007-09-20 ĀæĆĆĆ 2:17:36
- 2 -
ā¢ Remove the screw with a Phillips screwdriver
and the drawer.
ā¢ Retirez la vis Ć lāaide dāun tournevis Phillips
puis retirez le tiroir.
ā¢ Quite el tornillo con un destornillador Phillips
y saque el cajĆ³n.
ā¢ Clean the floor for the installation and put the
pedestal on the final location.
ā¢ Nettoyez lāendroit oĆ¹ lāappareil sera installĆ© et
placez-y le socle.
ā¢ Limpie el suelo donde va hacer la instalaciĆ³n y
ponga el pedestal en su ubicaciĆ³n final.
ā¢ (A) Level it with a wrench and (b) tighten up the lock
nut with a flat screw driver.
ā¢ (A) Mettez-le Ć niveau Ć lāaide dāune clĆ© anglaise puis
(b) serrez lāĆ©crou de blocage Ć lāaide dāun tournevis plat.
ā¢ (A) Nivelar con una llave inglesa y (b) ajustar las
contratuercas con un destornillador de punta plana.
1 2 3
D
ā¢ Remove the screws (3ea) on the back panel and
snap the guide-leg into the hole on the frame (4ea).
ā¢ Retirez les vis (3ea) du panneau arriĆØre et enfoncez
ce dernier dans les supports (4ea).
ā¢ Quite los tornillos (3ea) del panel posterior y
enganche las mƩnsulas (4ea).
ā¢ Put a soft pad (cardboard) on the floor to prevent
scratches during installation.
ā¢ Pendant lāinstallation, protĆ©gez le sol des griffures,
par exemple avec un carton.
ā¢ Ponga algo blando (un cartĆ³n) en el suelo para
evitar rayaduras durante la instalaciĆ³n.
ā¢ Put Washer/Dryer on the soft pad.
For the pedestal installation, the shipping bolts at the
back of the washer shall not be removed.
Remove them after putting the unit back to its upright
position (at Step 10).
ā¢ Placez le lave-linge/sĆØche-linge sur la protection.
Pour lāinstallation du socle, les vis de transport situĆ©es Ć
lāarriĆØre du lave-linge ne doivent pas ĆŖtre retirĆ©es.
Ne les enlevez quāune fois que lāappareil est replacĆ© en
position verticale (Ć lāĆ©tape 10).
ā¢ Coloque la lavadora o secadora sobre el cartĆ³n.
Para la instalaciĆ³n del pedestal, los tornillos de transporte
de la parte posterior de la lavadora no se deben quitar.
QuĆtelos despuĆ©s de poner la parte posterior de la
unidad en su posiciĆ³n vertical (en el paso 10).
456
ā¢ Installation for Dryer, go to step 7a.
ā¢ Pour lāinstallation du sĆ©choir, reportez-vous Ć lāĆ©tape 7a.
ā¢ InstalaciĆ³n de la secadora,ir al paso 7a.
ā¢ Installation for Washer, go to step 7b.
ā¢ Pour lāinstallation du lave- linge, reportez-vous Ć lāĆ©tape 7b.
ā¢ InstalaciĆ³n de la lavadora, ir al paso 7b.
Dryer/Nouvelle sƩcheuse Secadora
F
A
C
ā¢ Remove the leg assemblies (4ea) and snap the
Bracket-screw into the holes (4ea).
ā¢ Retirez les piĆØtements (4ea) et enfoncez les caches
carrƩs dans les orifices (4ea).
ā¢ Quite los montajes de las patas (4ea) y encaje los
tapones cuadrados en sus orificios (4ea).
ā¢ Put the pedestal on the bottom.
ā¢ Placez le socle en bas.
ā¢ Ponga el pedestal en la parte inferior.
ā¢ Secure them with screws (4ea). Go to Step 10.
ā¢ Fixez-les Ć lāaide de vis (4ea). Passez Ć lāĆ©tape 10.
ā¢ AsegĆŗrelo con los tornillos (4ea). Vaya al paso 10.
7a 8a 9a
ATLAS-02436A-03.indd 2 2007-09-20 ĀæĆĆĆ 2:17:38
- 3 -
Washer /Laveuse/ Lavadora
1
ā¢ Remove the leg assemblies (4ea).
ā¢ Otez les piĆØtements (4ea).
ā¢ Quite los montajes de las patas (4ea).
ā¢ Put the pedestal on the bottom.
ā¢ Placez le socle en bas.
ā¢ Ponga el pedestal en la parte inferior.
Caution / Attention / Precaui
Ć³n
ā¢
Make sure to tighten up all the bolts between the
washer and the pedestal until they cannot be
tightened up anymore.
ā Use a socket wrench.
ā¢
Veillez Ć serrer Ć fond tous les boulons entre le
lave-linge et le support.
ā Utilisez une clĆ© Ć douille.
ā¢ AsegĆŗrese de ajustar bien todos los pernos entre
la lavadora y el pedestal hasta que no se los pueda
ajustar mƔs.
ā Use una llave de cubo.
7b 8b 9b
G
ā¢ Put the assembled unit back to upright position.
ā¢ Replacez lāappareil en position verticale.
ā¢ Ponga la parte posterior de la unidad ensamblada
en posiciĆ³n vertical.
ā¢ Screw up (8ea) the back panel.
Make sure all the screws are completely fastened
to prevent buzzing noise during unit operation.
ā¢ Fixez le panneau arriĆØre Ć lāaide de vis (8ea).
Assurez-vous que toutes les vis sont correctement
serrĆ©es afin dāĆ©viter tout bourdonnement pendant
le fonctionnement.
ā¢ Atornille (8ea) el panel posterior.
AsegĆŗrese de que todos los tornillos estĆ©n bien
apretados para evitar ruidos de zumbidos
durante el funcionamiento.
ā¢ Put the assembled units to the installation sites.
ā¢ Posez les appareils assemblĆ©s Ć leur place
dƩfinitive.
ā¢ Ponga las unidades ensambladas en el lugar de
instalaciĆ³n.
10 11 12
ā¢ Check leveling and when needed, do additional
leveling.
ā¢ VĆ©rifiez quāils sont Ć niveau.
ā¢ Controle el nivel y, si es necesario, haga los ajustes
precisos.
13
ā¢ Put the legs on the same floor panels and
keep them away from the floor lines.
ā¢ Placez les pieds sur les mĆŖmes panneaux
de parquet, entre les rainures.
ā¢ Ponga las patas sobre los mismos paneles
del suelo y apĆ”rtelas de las lĆneas del suelo.
Test-1. ā¢ Put it into the Spin cycle and check its vibration.
ā¢ Mettez-le en cycle Essorage et contrĆ“lez ses
vibrations.
ā¢ Seleccione el ciclo Spin (Centrifugado) y verifique
si hay vibraciones.
Test-2. ā¢ If there is too much vibration, repeat the above.
ā¢ Sāil y a trop de vibrations, rĆ©pĆ©tez les opĆ©rations
ci-dessus.
ā¢ Si hay demasiadas vibraciones, repita los pasos
anteriores.
Tips for Wooden Panel Floor and Vibration Test / Conseils pour les sols en bois et Test de vibration /
Consejos para los suelos de paneles de madera y test de vibraciones
ATLAS-02436A-03.indd 3 2007-09-20 ĀæĆĆĆ 2:17:42
