Washing Machine
User manual
WD**BB******
DC68-04463N-00
Untitled-3 1 2023-05-19()  5:23:11
English
English2
Contents
Safety information 4
What you need to know about the safety instructions 4
Important safety symbols 4
Important safety precautions 5
Critical installation warnings 8
Installation cautions 10
Critical usage warnings 10
Usage cautions 11
Critical cleaning warnings 14
Installation 15
What’s included 15
Installation requirements 17
Step-by-step installation 19
Before you start 28
Initial setup 28
Laundry guidelines 29
Detergent drawer guidelines 32
Operations 35
Control panel 35
Operating a cycle 37
Cycle overview 38
Options 41
Settings 44
Special features 46
SmartThings 48
Open Source Announcement 49
Maintenance 50
Drum Clean+ 50
Emergency drain 51
Cleaning 52
Defrosting your washing machine 55
Care against an extended time of disuse 55
Untitled-3 2 2023-05-19()  5:23:11
English
English 3
Troubleshooting 56
Checkpoints 56
Information codes 60
Specifications 63
Fabric care chart 63
Protecting the environment 64
Specification sheet 65
Untitled-3 3 2023-05-19()  5:23:11
English
Safety information
English6
6. For appliances with ventilation openings in the base, that a carpet
must not obstruct the openings;
7. For use in Europe: Children of less than 3 years should be kept away
unless continuously supervised.
8. CAUTION: In order to avoid a hazard due to inadvertent resetting of
the thermal cut-out, this appliance must not be supplied through an
external switching device, such as a timer, or connected to a circuit
that is regularly switched on and off by the utility.
9. The tumble dryer is not to be used if industrial chemicals have been
used for cleaning.
10. The lint trap has to be cleaned frequently, if applicable.
11. Lint must not to be allowed to accumulate around the tumble dryer.
(not applicable for appliances intended to be vented to the exterior of
the building)
12. Adequate ventilation has to be provided to avoid the back flow of
gases into the room from appliances burning other fuels, including
open fires.
13. Do not dry unwashed items in the tumble dryer.
14. Items that have been soiled with substances such as cooking oil,
acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes
and wax removers should be washed in hot water with an extra
amount of detergent before being dried in the tumble dryer.
Untitled-3 6 2023-05-19()  5:23:12
English
English 7
15. Items such as foam rubber (latex foam), shower caps, waterproof
textiles, rubber backed articles and clothes or pillows fitted with foam
rubber pads should not be dried in the tumble dryer.
16. Fabric softeners, or similar products, should be used as specified by
the fabric softener instructions.
17. The final part of a tumble dryer cycle occurs without heat (cool down
cycle) to ensure that the items are left at a temperature that ensures
that the items will not be damaged.
18. Remove all objects from pockets such as lighters and matches.
19. WARNING: Never stop a tumble dryer before the end of the drying
cycle unless all items are quickly removed and spread out so that the
heat is dissipated.
20. Exhaust air must not be discharged into a flue which is used for
exhausting fumes from appliances burning gas or other fuels.
21. The appliance must not be installed behind a lockable door, a sliding
door or a door with a hinge on the opposite side to that of the tumble
dryer, in such a way that a full opening of the tumble dryer door is
restricted.
22. WARNING: The appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that is
regularly switched on and off by a utility.
Untitled-3 7 2023-05-19()  5:23:12
English
Safety information
English8
23. This appliance is intended to be used in household only and it is not
intended to be used such as:
staff kitchen areas in shops, offices and other working
environments;
farm houses;
by clients in hotels, motels and other residential type
environments;
bed and breakfast type environments;
areas for communal use in blocks of flats or in launderettes.
Critical installation warnings
WARNING
The installation of this appliance must be performed by a qualified technician or service company.
Failure to do so may result in electric shock, fire, an explosion, problems with the appliance, or injury.
The appliance is heavy, therefore take care when lifting it.
Plug the power cord firmly into a wall socket that meets local electrical specifications. Use the socket for
this appliance only, and do not use an extension cord.
Sharing a wall socket with other appliances using a power strip or extending the power cord may result
in electric shock or fire.
Ensure that the power voltage, frequency, and current are the same as those of the product
specifications. Failure to do so may result in electric shock or fire.
Remove all foreign substances such as dust or water from the power plug terminals and contact points
using a dry cloth on a regular basis.
Unplug the power plug and clean it with a dry cloth.
Failure to do so may result in electric shock or fire.
Plug the power plug into the wall socket so that the cord is running towards the floor.
If you plug the power plug into the socket in the opposite direction, the electric wires within the cable
may be damaged and this may result in electric shock or fire.
Keep all packaging materials out of the reach of children as these may be dangerous.
If a child places a bag over its head, it may suffocate.
When the appliance, power plug or power cord is damaged, contact your nearest service centre.
This appliance must be properly grounded.
Untitled-3 8 2023-05-19()  5:23:12
English
English 9
Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
This may result in electric shock, fire, an explosion, or problems with the appliance.
Never plug the power cord into a socket that is not grounded correctly and make sure that it is in
accordance with local and national regulations.
Do not install this appliance near a heater or any inflammable material.
Do not install this appliance in a humid, oily or dusty location, or in a location exposed to direct sunlight or
water (rain drops).
Do not install this appliance in a location exposed to low temperatures.
Frost may cause the tubes to burst.
Do not install this appliance in a location where gas may leak.
This may result in electric shock or fire.
Do not use an electric transformer.
This may result in electric shock or fire.
Do not use a damaged power plug, damaged power cord, or loose wall socket.
This may result in electric shock or fire.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power
cord between objects, or push the power cord into the space behind the appliance.
This may result in electric shock or fire.
Do not pull the power cord when unplugging the power plug.
Unplug the power plug by holding the plug.
Failure to do so may result in electric shock or fire.
This appliance should be positioned so that the power plug, the water supply taps, and the drain pipes are
accessible.
Following the repair by a non-authorized service provider, self-repair or non-professional repair of the
product, Samsung is not liable for any damage to the product, any injury or any other product safety issue
caused by any attempt to repair the product which does not carefully follow these repair and maintenance
instructions. Any damage to the product caused by an attempt to repair the product by any person other
than a Samsung certified service provider will not be covered by the warranty.
Untitled-3 9 2023-05-19()  5:23:12
English
Safety information
English10
Installation cautions
CAUTION
This appliance should be positioned in such a way that the power plug is easily accessible.
Failure to do so may result in electric shock or fire due to electric leakage.
Install your appliance on a solid, level floor that can support its weight.
Failure to do so may result in abnormal vibrations, movement, noise, or problems with the appliance.
Critical usage warnings
WARNING
If the appliance is flooded, turn off the water & power supplies immediately and contact your nearest
service centre.
Do not touch the power plug with wet hands.
Failure to do so may result in electric shock.
If the appliance generates a strange noise, a burning smell, or smoke, unplug the power cord immediately
and contact your nearest service centre.
Failure to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the
power plug. Do not touch the appliance or power cord.
Do not use a ventilating fan.
A spark may result in an explosion or fire.
Remove the washing machine door lever before disposing the appliance.
If trapped inside the appliance, children may suffocate to death.
Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the washing machine
before using it.
Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or other
inflammable or explosive substances.
This may result in electric shock, fire, or an explosion.
Do not open the washing machine door by force while it is operating (high-temperature washing/drying/
spinning).
Water flowing out of the washing machine may result in burns or cause the floor to be slippery. This
may result in injury.
Opening the door by force may result in damage to the appliance or injury.
Do not touch the power plug with wet hands.
This may result in electric shock.
Do not turn the appliance off by unplugging the power cord while an operation is in progress.
Plugging the power cord into the wall socket again may cause a spark and result in electric shock or fire.
Untitled-3 10 2023-05-19()  5:23:12
English
English 11
Do not let children climb in or onto the appliance.
This may result in electric shock, burns or injury.
Do not insert your hand or a metal object under the washing machine while it is operating.
This may result in injury.
Do not unplug the appliance by pulling the power cord. Always grip the plug firmly and pull it straight out
of the outlet.
Damage to the power cord may cause a short-circuit, fire and/or electric shock.
Do not attempt to repair, disassemble, or modify the appliance yourself.
Do not use a fuse (such as copper, steel wire, etc.) other than a standard fuse.
When the appliance needs to be repaired or reinstalled, contact your nearest service centre.
Failure to do so may result in electric shock, fire, problems with the appliance, or injury.
If the water supply hose comes loose from the water tap and floods the appliance, unplug the power cord.
Failure to do so may result in electric shock or fire.
Unplug the power cord when the appliance is not being used for long periods of time or during a thunder or
lightning storm.
Failure to do so may result in electric shock or fire.
If any foreign substance enters into the appliance, unplug the power cord and contact your nearest
Samsung Customer Service.
This may result in electric shock or fire.
Do not let children (or pets) play in or on your washing machine. The washing machine door does not open
easily from the inside and children may be seriously injured if trapped inside.
Usage cautions
CAUTION
When the washing machine is contaminated by a foreign substance such as detergent, dirt, food waste,
etc., unplug the power cord and clean the washing machine using a damp, soft cloth.
Failure to do so may result in discolouration, deformation, damage, or rust.
The front glass may be broken by a strong impact. Take care when using the washing machine.
If the glass is broken, it may result in injury.
Open the water tap slowly after a long period of non-use, water supply failure, or when reconnecting the
water supply hose.
The air pressure in the water supply hose or the water pipe may damage a part of the appliance or result
in a water leak.
If a draining error occurs during an operation, check if there is a draining problem.
If the washing machine is used when it is flooded because of a draining problem, it may result in electric
shock or fire.
Untitled-3 11 2023-05-19()  5:23:12
English
Safety information
English12
Insert the laundry into the washing machine completely so that the laundry does not get caught in the
door.
If laundry gets caught in the door, it may result in damage to the laundry or the washing machine, or
result in a water leak.
Turn the water supply off when the washing machine is not being used.
Ensure that the screws on the water supply hose connector are properly tightened.
Ensure that the rubber seal and front door glass are not contaminated by a foreign substance (e.g. waste,
thread, hair, etc.).
If a foreign substance is caught in the door or the door is not completely closed, it may cause a water
leak.
Open the water tap and check if the water supply hose connector is firmly tightened and that there is no
water leak before using the appliance.
If the screws on the water supply hose connector are loose, it may result in a water leak.
The appliance you have purchased is designed for domestic use only.
Using the appliance for business purposes qualifies as an appliance misuse. In this case, the appliance will
not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to
Samsung for malfunctions or damages resulting from such misuse.
Do not stand on the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance.
This may result in electric shock, fire, problems with the appliance, or injury.
Do not spray volatile material such as insecticide onto the surface of the appliance.
As well as being harmful to humans, this may result in electric shock, fire or problems with the
appliance.
Do not place objects that generate electromagnetic fields near the washing machine.
This may result in injury due to a malfunction.
Water drained during a high-temperature wash or drying cycle is hot. Do not touch the water.
This may result in burns or injury.
Draining time may vary depending on the water temperature. If the water temperature is too high, the
draining process starts after the water cools down.
Do not wash, spin, or dry water-proof seats, mats, or clothing (*) unless your appliance has a special cycle
for washing these items.
(*): Woollen bedding, rain covers, fishing vests, ski pants, sleeping bags, diaper covers, sweat suits, and
bicycle, motor cycle and car covers, etc.
Do not wash thick or hard mats even if the washing machine mark is on the care label. This may result in
injury or damage to the washing machine, walls, floor, or clothing due to abnormal vibrations.
Do not wash throw rugs or doormats with rubber backing. The rubber backing may come off and stick to
inside the drum, and this may result in malfunction such as a drainage error.
Untitled-3 12 2023-05-19()  5:23:12
English
English 13
Do not operate the washing machine when the detergent drawer is removed.
This may result in electric shock or injury due to a water leak.
Do not touch the insides of the drum during or just after drying as it is hot.
This may result in burns.
The door glass becomes hot during washing and drying. Therefore, do not touch the door glass.
Also, do not allow children to play around the washing machine or touch the door glass.
This may result in burns.
Do not insert your hand into the detergent drawer.
This may result in injury as your hand may be caught by the detergent input device.
Remove the liquid detergent guide (applicable models only) when using powdered detergent.
If not, water may leak through the front of the detergent drawer.
Do not place any objects (such as shoes, food waste, animals) other than laundry into the washing machine.
This may result in damage to the washing machine, or injury and death in the case of pets due to the
abnormal vibrations.
Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc.
This may result in electric shock or injury.
Do not wash laundry contaminated by oils, creams or lotions usually found in skincare shops or massage
clinics.
This may cause the rubber seal to become deformed and result in a water leak.
Do not leave metal objects such as safety pins, hair pins or bleach in the drum for long periods of time.
This may cause the drum to rust.
If rust starts appearing on the surface of the drum, apply a (neutral) cleansing agent to the surface and
use a sponge to clean it. Never use a metal brush.
Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry contaminated by dry
cleaning detergent.
This may result in spontaneous combustion or ignition due to the heat from the oxidation of the oil.
Do not use water from water cooling/heating devices.
This may result in problems with the washing machine.
Do not use natural hand-washing soap for the washing machine.
If it hardens and accumulates inside the washing machine, it may result in problems with the appliance,
discolouration, rust, or bad odours.
Place socks and brassieres in a washing net and wash them with the other laundry.
Do not wash large laundry items such as bedding in the washing net.
Failure to do so may result in injury due to abnormal vibrations.
Do not use hardened detergent.
If it accumulates inside the washing machine, it may result in a water leak.
Untitled-3 13 2023-05-19()  5:23:12
English
English 17
Installation requirements
Electrical supply and grounding
Use an individual branch circuit specific to the
washing machine.
To ensure proper grounding, the washing machine
comes with a power cord featuring a three-prong
grounding plug for use in a properly installed and
grounded outlet.
Check with a qualified electrician or service
person if you are not sure about the grounding.
Do not modify the provided plug. If it does not fit
the outlet, call a qualified electrician to install a
suitable outlet.
WARNING
Do NOT use an extension cord.
Use only the power cord that comes with the
washing machine.
Do NOT connect the ground wire to plastic
plumbing, gas lines, or hot water pipes.
Improperly connected grounding conductors
may cause electric shock.
Water supply
A proper water pressure for this washing machine
is between 50 kPa and 800 kPa. Water pressure
less than 50 kPa may cause the water valve to not
close completely, or it may take longer to fill the
drum, causing the washing machine to turn off.
Water taps must be within 120 cm from the rear
of the washing machine so that the provided inlet
hoses reach the washing machine.
To reduce the risk of leaks:
Make sure water taps are easily accessible.
Turn off the taps when the washing machine is
not in use.
Check for any leaks at the water inlet hose
fittings on a regular basis.
CAUTION
Before using the washing machine for the first
time, check all connections at the water valve and
taps for any leaks.
Drain
Samsung recommends a standpipe 60-90 cm
high. The drain hose must be connected through
the hose clip to the standpipe, and the standpipe
must fully cover the drain hose.
Untitled-3 17 2023-05-19()  5:23:13
English
Installation
English18
Flooring
For best performance, the washing machine must
be installed on a solid floor. Wood floors may need
to be reinforced to minimise vibration and/or
unbalanced loads. Carpeting and soft tile surfaces
do not resist vibration well and may cause the
washing machine to move slightly during the spin
cycle.
CAUTION
Do NOT install the washing machine on a platform
or a poorly supported structure.
Water temperature
Do not install the washing machine in areas where
water may freeze as the washing machine always
retains some water in its water valves, pumps,
and/or hoses. Frozen water left in the connection
parts may cause damage to belts, the pump, and
other components of the washing machine.
Alcove installation
Minimum clearance for stable operation:
Sides 25 mm
Top 25 mm
Rear 50 mm
Front 550 mm
If both the washing machine and a dryer are
installed in the same location, the front of the
alcove must have at least a 550 mm unobstructed
air opening. Your washing machine alone does not
require a specific air opening.
Untitled-3 18 2023-05-19()  5:23:13
English
English 19
Step-by-step installation
NOTE
While unpacking the washing machine, lift the washing
machine from the foam base. Make sure the drum
support was removed from the bottom of the washing
machine.
STEP 1Select a location
Location requirements:
Solid, level surface without carpeting or flooring that may obstruct ventilation
Away from direct sunlight
Adequate room for ventilation and wiring
The ambient temperature is always higher than the freezing point (0 °C)
Away from a heat source
NOTE
To prevent excessive vibration while operating the washing machine, consider stability before anything
else.
Install your washing machine on a solid and level floor.
Do not install your washing machine on soft floors or floor coverings.
If you install your washing machine on a wood floor, install a water-resistance wooden panel
(min 1.18 in. / 30 mm thick) to the floor. Also, we recommend installing your washing machine on the
corner of the wood floor.
Untitled-3 19 2023-05-19()  5:23:14
English
Installation
English20
STEP 2Remove the shipping bolts
Unpack the product package and remove all shipping bolts.
NOTE
Number of shipping bolts may differ depending on the model.
WARNING
Packaging materials can be dangerous to children. Dispose all packaging material (plastic bags,
polystyrene, etc.) out of children’s reach.
To avoid injury, cover the holes with bolt caps after removing the shipping bolts. Do not move the
washing machine without the shipping bolts in place. Assemble the shipping bolts before moving the
washing machine to another location. Keep the shipping bolts in a safe place for future use.
1. Locate the shipping bolts (marked with circle in the
figure) on the rear side of the washing machine.
2. Using the supplied spanner, loosen all the shipping
bolts by turning them anticlockwise.
NOTE
You must keep the shipping bolts for future use.
B
3. Insert the to the holes (marked with bolt caps (B)
circle in the figure).
Untitled-3 20 2023-05-19()  5:23:14
English
English 21
STEP 3Adjust the levelling feet
1. Gently slide the washing machine into position.
Excessive force may damage the levelling feet.
2. Level the washing machine by manually adjusting
the levelling feet.
3. When levelling is complete, tighten the nuts using
the spanner.
Untitled-3 21 2023-05-19()  5:23:14
English
Installation
English22
CAUTION
When installing the product make sure the levelling feet
is not pressing the power cord.
CAUTION
Make sure all the levelling feet are seating on the floor surface to avoid the washing machine from moving
or generating noise due to vibration. Then, check if the washing machine is rocking. If the washing machine
is not rocking, tighten the nuts.
STEP 4Connect the water hose
The provided water hose may differ depending on the model. Please follow the instruction according to the
provided water hose.
Connecting to a threaded water tap
1. Connect the water hose to the water tap, and then
turn it to the right to tighten.
CAUTION
Before connecting the water hose, make sure there is
a rubber washer in the hose connector. Do not use the
hose if the washer is damaged or missing.
2. Connect the other end of the water hose to the inlet
valve on the back of the washing machine, and then
turn it to the right to tighten.
Untitled-3 22 2023-05-19()  5:23:15
English
English 23
3. Slowly open the water tap and check if there are any
leaks around the connection areas. If there are water
leaks, repeat step 1 and 2.
WARNING
If there is a water leak, stop operating the washing machine and disconnect it from the electrical supply.
Then, contact a local Samsung service centre in case of a leak from the water hose, or contact a plumbing
technician in case of a leak from the water tap. Otherwise, this may cause electric shock.
CAUTION
Do not stretch the water hose by force. If the hose is too short, replace the hose with a longer, high-
pressure hose.
Connecting to a non-threaded water tap
A
B
1. Remove the adaptor (A) from the water hose (B).
2. Use a Phillips screwdriver to loosen four screws on
the adaptor.
Untitled-3 23 2023-05-19()  5:23:15
English
Installation
English24
C
3. Hold the adaptor and turn part (C) in the arrow
direction to loosen it by 5 mm (*).
C
4. Insert the adaptor onto the water tap, and then
tighten the screws while lifting the adaptor.
5. Turn part (C) in the arrow direction to tighten it.
D
6. While pulling down on the water hose, part (D)
connect the water hose to the adaptor. Then, release
part (D). The hose fits into the adaptor with a clicking
sound.
7. To complete connecting the water hose, see 2 and 3
on the Connecting to a threaded water tap section.
NOTE
After connecting the water hose to the adaptor, pull the water hose down to check if it is connected
properly.
Use a popular type of water taps. If the tap is square-shaped or too big, remove the spacer ring before
inserting the tap into the adaptor.
Untitled-3 24 2023-05-19()  5:23:15
English
English 25
For models with an additional hot water inlet:
1. Connect the red end of the hot water hose to the hot
water inlet on the back of the machine.
2. Connect the other end of the hot water hose to the
hot water tap.
Check valve (applicable models only)
Before connecting the water hose to a water tap, connect
the supplied check valve to the water tap and then
connect the water hose.
Aqua stop hose (applicable models only)
A
The aqua stop hose alerts users of a risk of water leaks.
It senses the water flow and turns red on the centre
indicator (A) in case of a leak.
NOTE
The end of the aqua stop hose must be fitted to the water tap and not the machine.
Untitled-3 25 2023-05-19()  5:23:16
English
Installation
English26
STEP 5 Position the drain hose
The drain hose can be positioned in three ways:
A
Over the edge of a wash basin
The drain hose must be placed between 60 cm and 90
cm (*) above from the floor. To keep the spout of the
drain hose bent, use the supplied plastic hose guide
(A). Secure the guide to the wall using a hook to ensure
stable drainage.
In a drain pipe
The drain pipe should be between 60 cm and 90 cm high
(*). It is advisable to use a 65 cm high vertical pipe.
To ensure the drain hose stays in position, use the
plastic hose guide provided (see the figure).
To prevent the siphoning of water flow during
drainage, make sure to insert the drain hose 15 cm in
the drain pipe.
To prevent the drain hose from moving around,
secure the hose guide to the wall.
Drain standpipe requirements:
Minimum diameter of 5 cm
Minimum carry-away capacity of 60 litres per minute
Untitled-3 26 2023-05-19()  5:23:16
English
English 27
In a sink drain pipe branch
The drain pipe branch must be above the sink siphon
so that the end of the hose is at least 60 cm above the
ground.
(*) : 60 cm
CAUTION
Remove the lid on the sink drain pipe branch before
connecting the drain pipe to it.
STEP 6 Power on
Plug the power cord into a wall socket that is correctly rated, grounded, and protected by a fuse or circuit
breaker. Then, tap to turn on the washing machine.
A
NOTE
Door latch (lever) (A) is originally designed to be loose
a little, because it may make the door latch be inserted
into the door more easily.
NOTE
If the door is locked during installation, plug the power cord, and turn on the power. The door will unlock.
Untitled-3 27 2023-05-19()  5:23:16
English
English28
Before you start
NOTE
Before doing your laundry for the first time, you must run a complete wash cycle without any items in the
drum.
Initial setup
When you turn on the washing machine for the first time, the screen shows the initial setup process.
Follow the on-screen instructions to complete it.
Initial setup will not repeat after you’ve finalized it. In order to finalize the initial setup, you must run a
wash cycle at least once.
The initial setup includes language selection, calibration, and a brief tutorial.
Tap or turn the to skip to the next screen.Navigation dial
Run Calibration
Initial setup includes the calibration process which comes after the language selection. You must
proceed calibration before using the washing machine.
Empty the drum, and then tap and hold to start calibration.
When calibration is complete, power turns off and then turns on automatically.
If you want to proceed calibration again, tap and hold for 3 seconds to enter and select Settings
Calibration.
01 02 03 Language selection Calibration Welcome screen
Turn dial & Tap O
Suomi
English Empty drum before
calibrating
[Tap O to skip]
Welcome!
04 Tutorial
Let’s explore
your new washer!
[Tap O to skip]
All Done!
A washer that knows you!
Untitled-3 28 2023-05-19()  5:23:17
English
English 29
Laundry guidelines
STEP 1Sort
Sort the laundry according to these criteria:
Care Label: Sort the laundry into cottons, mixed fibres, synthetics, silks, wools, and rayon.
Colour: Separate whites from colours.
Size: Mixing different sized items together in the drum improves the washing performance.
Sensitivity: Wash delicate items separately using an Easy Iron option for pure, new woollen items,
curtains, and silk items. Check the labels on the items.
NOTE
Make sure to check the care label on the clothing, and sort them accordingly before starting the wash.
STEP 2Empty pockets
Empty all the pockets of your laundry items
Metal objects such as coins, pins, and buckles on clothing may damage other laundry items as well as
the drum.
Turn clothing with buttons and embroideries inside out
If trousers or jacket zippers are open while washing, the drum may be damaged. Zippers should be
closed and fixed with a string.
Clothing with long strings may become entangled with other clothes. Make sure to tie the strings
before starting the wash.
STEP 3Use a laundry net
Brassieres (machine washable) must be placed in a laundry net. Metal parts of the brassieres may break
through and tear other laundry items.
Small, light clothing such as socks, gloves, stockings, and handkerchiefs may become caught around
the door. Place them inside a fine laundry net.
Do not wash the laundry net by itself without other laundry. This may cause abnormal vibrations that
could move the washing machine and result in injury.
STEP 4Prewash (if necessary)
Select the Prewash option for the selected cycle if the laundry is heavily soiled. Do not use the Prewash
option when detergent is manually added into the drum.
Untitled-3 29 2023-05-19()  5:23:17
English
Before you start
English30
STEP 5 Determine the load capacity
Do not overload the washing machine. Overloading may cause the washing machine to not wash properly.
For the load capacity for the type of clothing, see page 38.
NOTE
When washing bedding or bedding covers, the wash time may be lengthened or the spin efficiency may be
reduced. For bedding or bedding covers, the recommended maximum spin cycle speed is 800 rpm, and the
load capacity is 2.0 kg or less.
CAUTION
Unbalanced laundry may reduce the spinning performance.
Do not slam the door. Close the door gently. Otherwise, the door may not be closed properly.
CAUTION
Make sure the laundry is fully inserted in the drum and
not caught in the door.
STEP 6 Apply a proper detergent type
The type of detergent depends on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash
temperature, and degree of soiling. Make sure to use the laundry detergent that is designed for automatic
washing machines.
NOTE
Follow the detergent manufacturers recommendations based on the weight of the laundry, the degree
of soiling, and the hardness of the water in your local area. If you are not sure about the water hardness,
contact a local water authority.
Do not use detergent that tends to be hardened or solidified. This detergent may remain after the rinse
cycle, blocking the drain outlet.
CAUTION
When washing wool using the Wool cycle, use a detergent dedicated to wool items. If used with the Wool
cycle, powder detergent may remain on the laundry and discolour the laundry.
Untitled-3 30 2023-05-19()  5:23:18
English
English 31
Laundry capsules
To get the best results from using laundry capsules, please follow these instructions.
1. Put the capsule in the bottom of the empty drum
towards the rear.
2. Put the laundry in the drum on top of the capsule.
CAUTION
For cycles using cold water or cycles that complete in less than one hour, the capsule may not dissolve
completely.
Untitled-3 31 2023-05-19()  5:23:18
English
Before you start
English32
Detergent drawer guidelines
The washing machine provides a three-compartment dispenser: the left compartment for the main wash,
the front-right for fabric softeners, and the rear-right for the preliminary wash.
A
1. Prewash compartment: Apply prewash detergent.
2. Main-wash compartment: Apply main-wash
detergent, water softener, soaking detergent, bleach,
and/or stain removers.
3. Softener compartment: Apply additives such as
fabric softener. Do not exceed the max line (A).
NOTE
The actual appearance of the softener guide may differ
with the model.
CAUTION
Do not open the detergent drawer while the washing
machine is operating.
Do not use the following types of detergent in the
drawer:
-Tablet or capsule types
-Ball or net types
To prevent the compartment from clogging,
concentrated or highly-enriched agents (fabric
softener or detergent) must be diluted with water
before being applied.
When Delay End is selected, do not apply detergent
directly into the drum. Otherwise, this may discolour
the laundry. Use the detergent drawer when Delay
End is selected.
Be careful not to spill fabric softener on the worktop
or the control panel.
Untitled-3 32 2023-05-19()  5:23:18
English
English 33
To apply washing agents to the manual dispenser
A
1. Slide open the detergent drawer.
2. Apply laundry detergent to the main-wash
compartment as instructed or recommended by
the manufacturer. To use liquid detergent, see page
34. Do not exceed the max line (A) when adding
detergent.
A
3. Apply fabric softener to the softener
compartment. Do not exceed the max line (A).
Softener is dispensed into the wash during the final
rinse.
4. If you want to prewash, apply prewash detergent
to the prewash compartment as instructed or
recommended by the manufacturer.
5. Close the detergent drawer.
Untitled-3 33 2023-05-19()  5:23:19
English
Before you start
English34
CAUTION
Do not apply powder detergent to the liquid
detergent guide.
Concentrated fabric softener must be diluted with
water before applied.
Do not apply main-wash detergent to the softener
compartment.
To use liquid detergent (applicable models only)
A
First insert the provided liquid detergent guide in
the main-wash compartment. Then, apply liquid
detergent to the guide below the marked max line (A).
NOTE
Insert the liquid detergent guide only after you
remove the detergent drawer from the washing
machine by pressing release lever (A).
After a wash, some liquid detergent may remain in
the detergent drawer.
CAUTION
Do not use the Prewash function when you use liquid
detergent.
Remove the liquid detergent guide when you use
powder detergent.
Untitled-3 34 2023-05-19()  5:23:19
English
English 35
Operations
NOTE
The cycle and function names that appeared in this manual may differ from your product.
Control panel
WD**B*7*****, WD**B*5*****
01 03
02
04
10
05 06 07 08 09
WD**B*9*****
01 03
02
04
10
11
05 06 07 08 09
01 Power
Tap to turn the washing machine on or off.
If you do not manipulate the control panel for 10 minutes after the washing
machine is turned on, the washing machine automatically turns off.
The washing machine automatically turns off when the cycle completes.
CAUTION
Do not tap to turn the washing machine off while the wash cycle is in
progress. Tap and hold to pause the cycle first, and then tap to turn the
washing machine off.
02 Navigation dial
Turn the navigation dial left or right to navigate through cycles and functions.
When you turn the navigation dial, LCD displays your selection (such as cycle,
option, and setting).
03 Start/Pause Tap and hold to start or pause an operation.
Untitled-3 35 2023-05-19()  5:23:20
English
Operations
English36
04 Display
The display shows current cycle information and estimated time remaining, or
an information message when a problem occurs.
NOTE
The actual washing time may differ from the estimated time initially displayed
on the control panel upon cycle selection.
05 OK Tap to confirm your selection of function or setting.
06 Temp. Tap to change the water temperature for the selected cycle.
The indicator above the button indicates the default or selected setting.
07 Rinse Tap to change the rinse count for the selected cycle.
The indicator above the button indicates the default or selected setting.
08 Spin Tap to change the spin speed for the selected cycle.
The indicator above the button indicates the default or selected setting.
09 Options Tap to enter the Options menu.
Tap and hold for 3 seconds to enter the Settings menu.
10 Smart Control
Tap to activate or deactivate the Smart Control function.
Tap and hold to enter pairing mode to connect to the SmartThings app.
When the Smart Control function is activated, you can control your washing
machine remotely using the SmartThings app on your smartphone or tablet
(Android or iOS).
11 Quick Drive
(WD**B*9*****
models only)
Tap to activate or deactivate the Quick Drive function. You can reduce the
overall washing time of the selected cycle settings. Quick Drive may not be
available for certain cycles.
Icon descriptions
Wi-Fi This icon indicates that the washing machine is connected to Wi-Fi.
Smart Control This icon indicates that Smart Control is on.
For more information, see page 46.
Door Lock
This icon indicates the door is locked and cannot be opened.
The door locks automatically during a cycle and this indicator turns on.
You can open the door when this icon disappears.
Child Lock This icon indicates that Child Lock is on.
For more information, see page 43.
Untitled-3 36 2023-05-19()  5:23:20
English
English 37
Operating a cycle
WD**B*7*****, WD**B*5*****
2
5 3 4
61
WD**B*9*****
2
5 3 4 5
61
1. Tap turn on the washing machine.
2. Turn the to select the cycle you want. Navigation dial
-For more information, see page 38.
3. Tap , , or to change the default cycle settings.
4. Tap , and then turn the to select additional function in the Navigation dial Options menu.
-For more information, see page 41.
5. Tap to change the settings for selected additional function.
-For WD**B*9***** model, you can tap Quick Drive to turn on or off the function.
-Not all cycles have additional functions available.
6. Tap and hold to start operation.
-Once you set the cycle you want, the screen displays a brief cycle description, maximum laundry
load, and cycle time. You can also check the cycle progress, remaining cycle time, and information
codes.
Untitled-3 37 2023-05-19()  5:23:21
English
Operations
English38
Cycle overview
Cycle Description Max load
(kg)
Cotton
For cottons, bed linens, table linens, underwear,
towels, or shirts. The washing time and the rinse
count are automatically adjusted according to the
load.
For cleaning lightly soiled cotton items at a nominal
temperature of 20 °C.
Max
AI Wash (applicable models
only)
Adjusts the amount of detergent and the cycle
according to the load and the soil severity. This cycle
is best used with the Auto Dispense function.
Max
15' Quick Wash
For lightly soiled items in less than 2.0 kg that you want
to wash quickly.
Use less than 20 g of detergent. Using more than 20
g of detergent may leave detergent residue.
For liquid detergent, use a max of 20 ml of liquid
detergent.
2
Super Speed
Fast completion for everyday items such as
underwear and shirts.
The cycle time will differ depending on the water
supply conditions, load, and type of laundry.
5
Less Microfiber Use this cycle to reduce the amount of microfibers
generated during washing synthetic clothes. 2
Super Eco Wash Low temperature ecobubble cycle helps reduce
power consumption. 6
E Cotton
Optimal performance with lower energy for cotton
fabrics, bed linens, table linens, underwear, towels,
or shirts.
For energy saving, the actual washing temperature
may be lower than specified.
Max
Synthetics For fabrics that are made of polyester (diolen,
trevira), polyamide (perlon, nylon), or the like. 6
Delicates For best performance, use suitable detergent for
delicates or silk. 2
Towels For bath towels, washcloths, and mats. 6
Bedding For bed spreads, bed sheets, bedding covers, etc.
For best results, wash only 1 type of bedding. 2.5
Untitled-3 38 2023-05-19()  5:23:21
English
English 39
Cycle Description Max load
(kg)
Shirts For shirts, blouses that are made of cotton, synthetic
fiber. 2
Hygiene Steam
Cotton and linen fabric which have been in direct
contact with the skin, such as underwear.
For optimum hygiene results select a temperature of
60 °C or above.
Steam cycles feature allergy care and bacteria
elimination (sterilize).
6
Wool
Specific for machine-washable wool.
The Wool cycle features fine pulsating and soaking
to protect the wool fibres from shrinkage/distortion.
A neutral detergent is recommended.
2
Outdoor
For outdoor clothes, skiwear, and sportswear that
are made of functional materials such as spandex,
stretch, and micro-fibre.
2
Colors
Featuring additional rinses and reduced spinning to
ensure that the laundry is washed gently and rinsed
thoroughly.
6
Silent Wash For reducing operating noise and vibration. 6
Cloudy Day For optimum spin drying at high humid condition. Max
Rinse+Spin Featuring an additional rinse process after applying
fabric softener to the laundry. Max
Drain/Spin
For draining the water inside the drum and running
an additional spin process to effectively remove
moisture from laundry.
Max
Wash+Dry
For cleaning normally soiled cotton items which are
declared to be washable at 40 °C or 60 °C, together
in the same cycle, and to dry them in such a way
that it can be immediately stored in a cupboard. This
cycle is used to assess the compliance with the EU
Ecodesign legislation for wash and dry.
8
Cotton Dry For general drying. 8
Synthetics Dry A low temperature drying cycle for heat-sensitive
items. 4
Untitled-3 39 2023-05-19()  5:23:21
English
Operations
English40
Cycle Description Max load
(kg)
Drum Clean+
Cleans the drum by removing dirt and bacteria from
it.
Cleans the rubber door gasket by removing dirt from
the gasket.
Perform once every 40 washes with no detergent or
bleach applied. Notification message appears after
every 40 washes.
Make sure the drum is empty.
Do not use any cleaning agents for cleaning the
drum.
-
Air Wash This cycle is useful for removing bad odours. 1
NOTE
15' Quick Wash+Dry: For quickly washing and drying a few synthetic clothes up to 1 kg.
Super Speed+Dry: For blended fabric items up to 4 kg. The drying results may vary depending on the
types of fibres, and the rate of each fibre in the blend fabric. Drying results are better for items with a
higher polyester content. Additional drying may be needed depending on the volume and thickness of
the item.
-The maximum load (4.0 kg) was tested in compliance with IEC standards (3 cotton pillows, 3 cotton
towels, 5 easy care pillows, 11 easy care shirts).
Untitled-3 40 2023-05-19()  5:23:21
English
English 41
Options
Using Options
1. Tap .
2. Turn the to select the desired additional function.Navigation dial
3. Tap to change the selected function’s settings or start the function.
NOTE
To return to the main screen, tap again or turn the to select and tap Navigation dial Back .
If the selected function is not supported, the "Currently not supported" message is displayed, and the
button is not activated.
When you select an additional function, a brief help message appears for the first ten times of use.
Dry
You can add a drying process at the end of a wash cycle.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select , and then tap Navigation dial Dry .
4. Turn the or tap repeatedly to select the desired drying time.Navigation dial
-You can select from Off 30min, Auto, , 1hr 00min 1hr 30min 2hr 00min 3hr 00min, , , , or 4hr 00min.
5. Tap and hold .
Prewash
You can add a preliminary washing cycle before the main wash cycle.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select Navigation dial Prewash, and then tap .
4. Tap and hold .
Intensive
For badly soiled laundry. The operation time for each cycle is longer than normal.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select Navigation dial Intensive, and then tap .
4. Tap and hold .
Untitled-3 41 2023-05-19()  5:23:21
English
Operations
English42
Bubble Soak
This function helps remove a wide variety of stubborn stains. With Bubble Soak selected, laundry is
thoroughly soaked in water bubbles for effective washing.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select , and then tap Navigation dial Bubble Soak .
4. Tap and hold .
My Cycles
Add or remove cycles to create a personal cycle list.
1. Tap .
2. Turn the to select Navigation dial My Cycles, and then tap .
-You can only edit a cycle to create a personal cycle when the washing machine is not operating.
3. Turn the to select a desired cycle.Navigation dial
4. Tap to add or remove the selected cycle.
-Addition and removal of the course is saved automatically.
5. Once you finish creating My Cycles, tap to return to the cycles screen.
NOTE
The Drum Clean+ cycles cannot be removed from the cycles list.
You can also edit My Cycles in the SmartThings app.
Untitled-3 42 2023-05-19()  5:23:21
English
English 43
Delay End
You can set the washing machine to finish your wash automatically at a later time, choosing a delay of
between 1 to 24 hours (in 1 hour increments). The hour displayed indicates the time the wash will finish.
1. Select a cycle and change the cycle settings as necessary.
2. Tap .
3. Turn the to select Navigation dial Delay End, and then tap .
4. Turn the to select the desired time, and then tap Navigation dial .
5. Tap and hold .
-Status shows in the display and the washing machine tumbles the drum to sense the weight of the
load (if load sensing is preset for the selected cycle). When load sensing is complete, the display
shows the remaining time until the end of the wash cycle.
-To cancel Delay End, tap to restart the washing machine.
Real-life case
You want to finish a two-hour cycle 3 hours later from now. For this, you add the Delay End option to
the current cycle with the 3-hour setting, and press Start/Pause at 2:00 p.m. Then, what happens? The
washing machine starts operating at 3:00 p.m., and ends at 5:00 p.m. Provided below is the time line for
this example.
2:00 pm
Set Delay End to 3 hours
3:00 pm
Start
5:00 pm
End
Child Lock
To prevent children or infants from accidentally starting or setting the washing machine, Child Lock locks
all buttons except for and .
1. Tap .
2. Turn the to select Navigation dial Child Lock, and then tap .
3. Tap to select On or Off.
-The Child Lock icon turns on when the function is on.
NOTE
When Child Lock is on, all buttons are disabled except for and . The washing machine door also
locks.
Tapping a button while Child Lock is on triggers an alarm with the message.Child Lock On
You cannot open the door after a wash cycle when the Child Lock is on. Turn the function off before
opening the door to take out the laundry.
Untitled-3 43 2023-05-19()  5:23:22


Produktspezifikationen

Marke: Samsung
Kategorie: Waschmaschine
Modell: WD11BB904DGH

Brauchst du Hilfe?

Wenn Sie Hilfe mit Samsung WD11BB904DGH benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten




Bedienungsanleitung Waschmaschine Samsung

Bedienungsanleitung Waschmaschine

Neueste Bedienungsanleitung für -Kategorien-
