LED TV

Installation manual

Thank you for purchasing this Samsung

product. To receive more complete service,

please register your product at

www.samsung.com/register

Model Serial No.

470/670

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product

appearance. Product design and speciﬁcations may be changed without notice.

Instruction

This TV is provided with interactive functionality through a set-back box (SBB/STB) connected to the TV, and with other TVs in a computer

controlled system for hotels and other hospitality businesses.

yInteractive: When the TV is powered-up initially, it sends a command to identify the SBB/STB. If identiﬁed, the TV switches to ONLINE

mode and full control is through the SBB/STB. If the TV is in ONLINE mode, it stops receiving IR (Samsung remote) commands and acts

according to the interface protocol.

yStand-Alone: If SBB/STB is not identiﬁed, the TV should be switched to STAND-ALONE mode with restricted operations.

Operational Modes

When this TV (in Hotel mode) is operated with a SBB/STB, it is in one of two states:

yONLINE or STAND-ALONE. In the STAND-ALONE state, the TV will act as a Hotel TV, but without active communication. This prevents

guests from trying to cheat the system by disconnecting the SBB/STB.

Power

Hotel Mode On

Hotel TV Stand-alone

Mode

Online Mode

Poll Rate 20/sec

SBB/STB Online if

one success within

10 attempts

SBB/STB

Online-10

consecutive

fails

SBB/STB

Status-

Attempt

every 2secs

To set the details for Stand-alone or interactive mode, refer to pages 29-33(Setting the hotel option data: Stand-alone mode and Interactive

mode)

ySome operations may be restricted to prevents guests from “cheating” the TV system.

yNo main menu (Interactive mode) or Channel Menu, Plug & Play in Main Menu (Stand-Alone mode)

yLimited Volume and Panel key lock or unlock

Still image warning

Avoid displaying still images (like jpeg picture ﬁles) or still image elements (like TV Programme such as TV Programmeme logos, the panorama

or 4:3 image format, stock or news bars at the bottom of the screen etc.) on the screen. Constantly displaying still pictures can cause uneven

wear of the screen phosphor, which will affect the image quality. To reduce risk of this effect, please follow the recommendations below:

yAvoid displaying the same TV channel for long periods.

yAlways try do display any image over the full screen, use the TV set picture format menu for the best possible match.

yReduce the brightness and contrast values to the minimum require values to achieve the desired picture quality. Exceeding these values

may speed up the burnout process.

yFrequently use all TV features designed to reduce image retention and screen burnout, refer to the appropriate user manual section for

more details.

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation.

Failing to do so may result in ﬁre or a problem with the product due to an increase in the internal temperature of the product.

✎When using a stand or wall-mount, use parts provided by Samsung Electronics only.

yIf you use parts provided by other manufacturers, it may result in a problem with the product or an injury due to the product falling.

✎The appearance may differ depending on the product.

Installation with a stand. Installation with a wall-mount.

10 cm

10 cm 10 cm

10 cm

Contents

ENGLISH

English

yAccessories 4 .............................................................................................................................................

yInstalling the LED TV Stand 4 ......................................................................................................................

yAssembling the swivel (32 inch TVs or larger) 9 ...........................................................................................

yViewing the Connection Panel 10 ..................................................................................................................

yUsing the TV’s Controller 19 ..........................................................................................................................

yViewing the Remote Control 20 .....................................................................................................................

yConnecting the TV with SBB 22 ....................................................................................................................

yConnecting the Bathroom Speakers 24 ........................................................................................................

yConnecting the MediaHub HD 26 .................................................................................................................

yConnecting the RJP (Remote Jack Pack) 27 .................................................................................................

ySetting the Hotel Option Data 29 ..................................................................................................................

yInstalling the Wall Mount 55 ..........................................................................................................................

ySecuring the TV to the Wall 56 ......................................................................................................................

yAnti-theft Kensington Lock 56 .......................................................................................................................

ySpeciﬁcations 57 ..........................................................................................................................................
