AMPLIFIERS
R150X2 R250X1
R250X4 R300X4 R400-4D
R500X1D R600-4D R600X5
R750-1D R1200-1D
Installation & Operation
Installation assistance availible at:
www.rockfordfosgate.com/rftech
ROCKFORDFOSGATE.COM
600 South Rockford Drive • Tempe, Arizona 85281 United States
Direct: (480) 967-3565 • Toll Free: (800) 669-9899
Printed in China
121412 BCF
1230-57810-02
32
Dear Customer,
Congratulations on your purchase of the world’s finest brand of car audio
products. At Rockford Fosgate we are fanatics about musical reproduc-
tion at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand craftsmanship and critical testing
procedures, we have created a wide range of products that reproduce
music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rockford
Fosgate product installed by an Authorized Rockford Fosgate Dealer,
as we provide specialized training through Rockford Technical Training
Institute (RTTI). Please read your warranty and retain your receipt and
original carton for possible future use.
Great product and competent installations are only a piece of the puzzle
when it comes to your system. Make sure that your installer is using
100% authentic installation accessories from Rockford Fosgate in your
installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! After all,
your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
jackets.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other
countries, call +001-480-967-3565 or FAX +001-480-966-3983.
Table of Content
If, after reading your manual, you still have questions regarding this prod-
uct, we recommend that you see your Rockford Fosgate dealer. If you need
further assistance, you can call us direct at 1-800-669-9899. Be sure to
have your serial number, model number and date of purchase available
when you call.
Safety
This symbol with “WARNING” is intended to
alert the user to the presence of important in-
structions. Failure to heed the instructions will
result in severe injury or death.
This symbol with “CAUTION” is intended to
alert the user to the presence of important in-
structions. Failure to heed the instructions can
result in injury or unit damage.
•To prevent injury and damage to the unit, please read and follow the
instructions in this manual. We want you to enjoy this system, not get
a headache.
•If you feel unsure about installing this system yourself, have it installed
by a qualified Rockford Fosgate technician.
•Before installation, disconnect the battery negative (-) terminal to
prevent damage to the unit, fire and/or possible injury.
Introduction Specications
©2013 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE, PUNCH, and associated logos where applicable are registered trademarks of Rockford
Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Specifications subject to change without notice.
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
PRATIQUEZ UNE ÉCOUTE SANS RISQUES
Une exposition continue à des niveaux de pression acoustique upérieurs à
100 dB peut causer une perte d’acuité auditive permanente. Les systèmes
audio de forte puissance pour auto peuvent produire des niveaux de
pression acoustique bien au-delà de 130 dB. Faites preuve de bon sens et
pratiquez une écoute sans risques
PRACTIQUE EL SONIDO SEGURO
El contacto continuo con niveles de presión de sonido superiores a 100
dB puede causar la pérdida permanente de la audición. Los sistemas de
sonido de alta potencia para automóviles pueden producir niveles de
presión de sonido superiores a los 130 dB. Aplique el sentido común y
practique el sonido seguro.
PRAKTIZIEREN SIE SICHEREN SOUND
Fortgesetzte Geräuschdruckpegel von über 100 dB können beim
Menschen zu permanentem Hörverlust führen. Leistungsstarke
Autosoundsysteme können Geräuschdruckpegel erzeugen, die weit über
130 dB liegen. Bitte wenden Sie gesunden Menschenverstand an und
praktizieren Sie sicheren Sound.
OSSERVATE LE REGOLE DEL SUONO SENZA PERICOLI
La costante esposizione a livelli di pressione acustica al di sopra dei
100dB possono causare la perdita permanente dell’udito. I sistemi
audio ad alta potenza possono produrre livelli di pressione acustica ben
superiori ai 130dB. Si consiglia il buon senso e l’osservanza delle regole
del suono senza pericoli
2 Introduction
3 Specifications
4-5 Design Features
6-16 Installation
Installation Considerations
Mounting Locations
Battery and Charging
Wiring the System
17 Operation
Adjusting Gain
Adjusting Crossover Frequency
Input Switch
Variable Phase
Punch EQ (Variable & Selectable)
Remote Punch Level Control
18 Troubleshooting
19-26 Additional Languages
French
Spanish
German
Italian
28 Limited Warranty Information
CEA 2006
Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines
mean your amplifier’s output power ratings are REAL POWER numbers, not inflated marketing ratings.
Mode R150X2 R250X4 R300X4 R400-4D R600-4D R600X5 R250X1 R500X1D R750-1D R1200-1D
Rated Power -
Continuous
Power Rating
(RMS) Measured
@ 14.4V
50x2 @ 4 ohms
75x2 @ 2 ohms
150x1 @ 4 ohms*
40x4 @ 4 ohms
60x4 @ 2 ohms
125x2 @ 4 ohms*
50x4 @ 4 ohms
75x4 @ 2 ohms
150x2 @ 4 ohms*
75x4 @ 4 ohms
100x4 @ 2 ohms
200x2 @ 4 ohms*
100x4 @ 4 ohms
150x4 @ 2 ohms
300x2 @ 4 ohms*
50x4 @ 4 ohms
75x4 @ 2 ohms
150x2 @ 4 ohms*
Sub: 200x1 @ 4 ohms
Sub: 300x1 @ 2 ohms
150x1 @ 4 ohms
250x1 @ 2 ohms
300x1 @ 4 ohms
500x1 @ 2 ohms
250x1 @ 4 ohms
500x1 @ 2 ohms
750x1 @ 1 ohm
400x1 @ 4 ohms
800x1 @ 2 ohms
1200x1 @ 1 ohm
Crossover
Slope
12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/Oct
Crossover
Frequency
Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz Variable 50Hz-250Hz
SS: 15Hz-40Hz
Variable 50Hz-250Hz
SS: 15Hz-40Hz
Punch EQ Variable 0 -+12dB @
45Hz
Selectable 0/+6dB/+12dB
@ 45Hz
Selectable 0/+6dB/+12dB
@ 45Hz
Variable 0 -+18dB @
45Hz
Variable 0 -+18dB @
45Hz
Selectable 0/+6dB/+12dB
@ 45Hz
Sub: Variable 0 -+12dB
@ 45Hz
Variable 0 -+12dB @
45Hz
Variable 0 -+12dB @
45Hz
Variable 0 -+18dB @
45Hz
Variable 0 -+18dB @
45Hz
Operating
Voltage
9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC 9-16VDC
Frequency
Response
20Hz-20kHz 20Hz-20kHz 20Hz-20kHz 20Hz-20kHz 20Hz-20kHz 20Hz-20kHz 20Hz-250Hz 20Hz-250Hz 20Hz-250Hz 20Hz-250Hz
Battery Fuse
Rating (not
supplied)
20A 50A 50A 50A 100A 80A 30A 50A 100A 150A
THD+N @
Rated Power
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 4 ohms
<1.0% @ 2 ohms
F/R:
<1.0% @ 4 ohms
<1.0% @ 2 ohms
Sub:
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 1 ohm
<1.0% @ 4 ohms
<1.0% @ 2 ohms
<1.0% @ 1 ohm
Input Sensitivity 150mV-4V Low Level
450mV-12V High Level
150mV-4V Low Level
450mV-12V High Level
150mV-4V Low Level
450mV-12V High Level
150mV-4V 150mV-4V 150mV-4V Low Level
450mV-12V High Level
150mV-4V Low Level
450mV-12V High Level
150mV-4V Low Level
450mV-12V High Level
150mV-4V 150mV-4V
Input Imped-
ance
20k 20k 20k 20k 20k 20k 20k 20k 20k 20k
S/N Ratio CEA
2006
>80dB >80dB >80dB >70dB >70dB F/R: > 80dB
Sub: >80dB
>80dB >80dB >75dB >75dB
S/N Ratio @
Rated Power
>100dB >100dB >100dB >90dB >90dB F/R: >100dB
Sub: >100dB
>100dB >100dB >100dB >100dB
Channel
Separation
>50dB >50dB >50dB >50dB >50dB >50dB N/A N/A N/A N/A
Common Mode
Rejection Ratio
>40dB >55dB >40dB >55dB >55dB >55dB >40dB >55dB >55dB >55dB
Damping Factor >200dB >200dB >200dB >200dB >200dB F/R: >200dB
Sub: >200dB
>200dB >200dB >200dB >200dB
Dimensions
(LxWxH)
11.2” x 6.8” x 2”
(28.5cm x 17.2cm x 5.1 cm)
11.2” x 6.8” x 2”
(28.5cm x 17.2cm x 5.1 cm)
13.2” x 6.8” x 2”
(33.5cm x 17.2cm x 5.1 cm)
9.1” x 6.8” x 2”
(23.1cm x 17.2cm x 5.1 cm)
11.1” x 6.8” x 2”
(28.2cm x 17.2cm x 5.1 cm)
13.2” x 6.8” x 2”
(33.5cm x 17.2cm x 5.1 cm)
11.2” x 6.8” x 2”
(28.5cm x 17.2cm x 5.1 cm)
8.5” x 6.8” x 2”
(21.6cm x 17.2cm x 5.1 cm)
9.1” x 6.8” x 2”
(23.1cm x 17.2cm x 5.1 cm)
11.1” x 6.8” x 2”
(28.2cm x 17.2cm x 5.1 cm)
* Rated power when amplifier is wired in a bridged configuration.
54
REMGND B+
BRIDGEDBRIDGED
+–+–
RIGHTLEFT
FRONT
+–+–
RIGHTLEFT
REAR
L
R
FRONT
HIGH LEVEL
INPUT
FRONTREAR
REARSUB
REMOTE PUNCH LEVEL
SUB
+–
L+R+
L-
R-
50 250
FREQ. Hz GAIN
1
3 9
11
5 7
X-OVER
LP - AP - HP
PUNCH EQ.
2/4/5 CH.
SWITCH
PWR/
PRT
FRONT
50 250
FREQ. Hz GAIN
1
3 9
11
5 7
X-OVER
LP - AP - HP
PUNCH EQ.
0dB +6dB +12dB 0dB +6dB +12dB
REAR
50 250
FREQ. Hz GAIN
1
3 9
11
5 7
SUB
PUNCH EQ.
MIN MAX
PHASE
0˚ - 180˚ 2 CH. - 4 CH. - 5 CH.
Design Features Design Features
illus.-1.1
Gain Control
The gain control is used to match the output of the
audio source.
Punch EQ - Selectable
This selectable control works along with the
crossover switch on the amplifier, boosting the
bass frequencies.
Variable Phase
The variable 0-180˚ phase control allows the listener
to change the arrival time of the subwoofer sound
waves relative to the same frequencies from the main
speakers.
Power/Protect LED
Power LED illuminates blue when the unit is turned on. Protect/
Thermal LED illuminates red when amplifier overheats or short
circuits. The amplifier will automatically shut down if this occurs.
Speaker Terminals
The Speaker Terminals are nickel-plated
set-screw wire connectors (+ and -) will
accommodate 8 AWG.
RCA Input/Pass-Thru Jacks
The RCA Inputs/Pass-Thru Jacks are nickel-plated to resist the signal degradation
caused by corrosion. The Pass-Thru provides a convenient source for daisy-chaining
an additional amplifier without running an extra set of RCA cables from the front of the
vehicle to the rear amplifier location.
Punch EQ - Variable
This variable control works along with the crossover
switch on the amplifier, boosting the bass frequencies.
Power/REM Terminals
The Power and Ground Terminals are nickel-plat-
ed set-screw wire connectors and will accommo-
date 4 AWG. The REM Terminal is a nickel-plated
set-screw wire connector and will accommodate
8 AWG.
Input Switch
Setting this switch to the connected inputs aligns the
output signal accordingly or can supplement signal to
additional channels when not connected.
Crossover Switch
Selectable switch for Low-Pass (LP) or
All Pass (AP) or High-Pass (HP)
Variable Crossover
A built-in 12dB/octave Butterworth filter with a crossover
point variable from 50Hz to 250Hz. (R750-1D & R1200-1D
have an additional 12dB/octave Infrasonic filter with a cross-
over point variable from 15Hz to 40Hz SS)
Remote Punch Level Control
Remotely control the subwoofer output
level of the amplifier.
High Level Inputs - Optional Inputs
Accepts High Level speaker signal when utilizing
the 4-pin Molex harness provided.
Produktspezifikationen
| Marke: | Rockford Fosgate |
| Kategorie: | Autoradio |
| Modell: | R600-4D |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Rockford Fosgate R600-4D benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Autoradio Rockford Fosgate
5 Oktober 2024
24 September 2024
23 September 2024
23 September 2024
23 September 2024
28 August 2024
28 August 2024
28 August 2024
28 August 2024
28 August 2024
Bedienungsanleitung Autoradio
- Autoradio Clatronic
- Autoradio Sanyo
- Autoradio Manta
- Autoradio Medion
- Autoradio Nedis
- Autoradio Philips
- Autoradio SilverCrest
- Autoradio Sony
- Autoradio Tevion
- Autoradio Panasonic
- Autoradio LG
- Autoradio AEG
- Autoradio Maginon
- Autoradio Technaxx
- Autoradio Denver
- Autoradio ECG
- Autoradio MarQuant
- Autoradio Renkforce
- Autoradio Telefunken
- Autoradio Trevi
- Autoradio Blaupunkt
- Autoradio Grundig
- Autoradio Kenwood
- Autoradio Daewoo
- Autoradio Pyle
- Autoradio Telestar
- Autoradio Aiwa
- Autoradio Auna
- Autoradio Caliber
- Autoradio Lenco
- Autoradio Pioneer
- Autoradio JBL
- Autoradio JVC
- Autoradio Krüger And Matz
- Autoradio Muse
- Autoradio Vieta
- Autoradio Hifonics
- Autoradio Akai
- Autoradio Dual
- Autoradio Hyundai
- Autoradio MT Logic
- Autoradio Orava
- Autoradio Orion
- Autoradio Skoda
- Autoradio Varta
- Autoradio Elta
- Autoradio Sencor
- Autoradio Biltema
- Autoradio OneConcept
- Autoradio Mercedes-Benz
- Autoradio Boston Acoustics
- Autoradio Harman Kardon
- Autoradio Magnat
- Autoradio XOMAX
- Autoradio Parrot
- Autoradio Smart
- Autoradio Alpine
- Autoradio Ford
- Autoradio Volkswagen
- Autoradio Volvo
- Autoradio Opel
- Autoradio MB Quart
- Autoradio Overmax
- Autoradio Crunch
- Autoradio Pure
- Autoradio NextBase
- Autoradio Norauto
- Autoradio AXTON
- Autoradio Clarion
- Autoradio Mac Audio
- Autoradio Conceptronic
- Autoradio Scott
- Autoradio Audiovox
- Autoradio Becker
- Autoradio ESX
- Autoradio Zenec
- Autoradio VDO
- Autoradio SPC
- Autoradio Roadstar
- Autoradio Tokaï
- Autoradio Audison
- Autoradio Macrom
- Autoradio Phonocar
- Autoradio Xblitz
- Autoradio Autovision
- Autoradio Boss
- Autoradio Hertz
- Autoradio Renault
- Autoradio Fiat
- Autoradio Kicker
- Autoradio Jensen
- Autoradio DLS
- Autoradio Eclipse
- Autoradio Eltax
- Autoradio Emphaser
- Autoradio Focal
- Autoradio Fusion
- Autoradio Ground Zero
- Autoradio Helix
- Autoradio Impulse
- Autoradio Lanzar
- Autoradio Mtx Audio
- Autoradio Naxa
- Autoradio Revo
- Autoradio Rodek
- Autoradio RTO
- Autoradio Sevic
- Autoradio Sirius
- Autoradio Soundstream
- Autoradio Spectron
- Autoradio Stinger
- Autoradio Tamashi
- Autoradio Toxic
- Autoradio Twister
- Autoradio Ultimate
- Autoradio US Blaster
- Autoradio VDO Dayton
- Autoradio Voxx
- Autoradio VW
- Autoradio Watssound
- Autoradio RetroSound
- Autoradio Kunft
- Autoradio Shuttle
- Autoradio Multilaser
- Autoradio Brigmton
- Autoradio Lark
- Autoradio Majestic
- Autoradio SoundMAX
- Autoradio Scion
- Autoradio Raveland
- Autoradio Planet Audio
- Autoradio Adcom
- Autoradio Sendai
- Autoradio Cartronix
- Autoradio Dension
- Autoradio Mystery
Neueste Bedienungsanleitung für -Kategorien-
16 Oktober 2024
16 Oktober 2024
12 Oktober 2024
12 Oktober 2024
8 Oktober 2024
7 Oktober 2024
7 Oktober 2024
6 Oktober 2024
5 Oktober 2024
5 Oktober 2024
