Rockford Fosgate Punch P312D4 Bedienungsanleitung

Rockford Fosgate Subwoofer Punch P312D4

Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Rockford Fosgate Punch P312D4 (36 Seiten) in der Kategorie Subwoofer. Dieser Bedienungsanleitung war für 11 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Download PDF
Seite 1/36
Installation &
Operation
Installation et fonctionnement
Instalación y funcionamiento
Einbau und Betrieb
Installazione e funzionamento
Punch Series
DVC - Dual Voice Coil Woofers
P38D2
P38D4
P310D2
P310D4
P312D2
P312D4
P315D2
P315D4
INTRODUCTION
2
TABLE OF CONTENTS
Dear Customer,
Congratulations on your purchase of the world's nest brand of car audio speakers. At Rockford Fosgate we are
fanatics about musical reproduction at its best, and we are pleased you chose our product.Through years of engi-
neering expertise, hand craftsmanship and critical testing procedures, we have created a wide range of products
that reproduce music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rockford Fosgate product installed by an
Authorized Rockford Fosgate Dealer, as we provide specialized training through Rockford Technical Training Institute
(RTTI). Please read your warranty and retain your receipt and original carton for possible future use.
Great product and competent installations are only a piece of the puzzle when it comes to your system. Make sure
that your installer is using 100% authentic installation accessories from Connecting Punch in your installation.
Connecting Punch has everything from RCA cables and speaker wire to Power line and battery connectors. Insist on
it! After all, your new system deserves nothing but the best.
To add the finishing touch to your new Rockford Fosgate image order your Rockford accessories, which include
everything from T-shirts and jackets to hats and sunglasses.
To get a free brochure on Rockford Fosgate products and Rockford accessories,
visit our web site at: www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985.
For all other countries, call +001-480-967-3565 or FAX +001-480-967-8132.
PRACTICE SAFE SOUND™
Continuous exposure to sound pressure levels over 100dB may cause permanent
hearing loss. High powered auto sound systems may produce sound pressure levels well
over 130dB. Use common sense and practice safe sound.
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Instructions . . . . . . . . . . . . . . . . . . . 3
Design Features. . . . . . . . . . . . . . . . . . . . . . 3
Recommended Enclosures . . . . . . . . . . . 4-5
Sealed Enclosures . . . . . . . . . . . . . . . . . . . . . 4
Vented Enclosures . . . . . . . . . . . . . . . . . . . . . 5
NOTE: Review each section for more detailed information.
If, after reading your manual, you still have questions regarding this product, we recommend that you see
your Rockford Fosgate dealer. If you need further assistance, you can call us direct at 1-800-669-9899. Be
sure to have your serial number, model number and date of purchase available when you call.
The serial number can be found on the outside of the box. Please record it in the space provided below as
your permanent record.This will serve as verication of your factory warranty and may become useful in
recovering your product if it is ever stolen.
Serial Number: ______________________________________
Model Number: _____________________________________
Wiring Congurations . . . . . . . . . . . . . . . . 6
Building an Enclosure . . . . . . . . . . . . . . . . . 7
Calculating Volumes . . . . . . . . . . . . . . . . . . . . 7
Subwoofer Crossovers . . . . . . . . . . . . . . . . 7
Specications. . . . . . . . . . . . . . . . . . . . . . . . 8
Limited Warranty Information . . . . . . . . . 9
3
www.rockfordfosgate.com
SAFETY INSTRUCTIONS
CONTENTS OF CARTON
Visit our web site for the latest information on all Rockford products.
GETTING STARTED
Welcome to Rockford Fosgate! This manual is designed to provide information for the owner,
salesperson and installer. For those of you who want quick information on how to install this product,
please turn to the Installation Section of this manual. Other information can be located by using the
Table of Contents.We, at Rockford Fosgate, have worked very hard to make sure all the information in
this manual is current. But, as we are constantly nding new ways to improve our product, this
information is subject to change without notice.
This symbol with “WARNING” is intended to alert the user to the
presence of important instructions. Failure to heed the instructions
will result in severe injury or death.
This symbol with “CAUTION” is intended to alert the user to the
presence of important instructions. Failure to heed the instructions
can result in injury or unit damage.
CAUTION:To prevent injury and damage to the unit, please read and follow the
instructions in this manual.We want you to enjoy this system, not get a
headache.
CAUTION If you feel unsure about installing this system yourself, have it installed by a
qualied Rockford Fosgate technician.
CAUTION Before installation, disconnect the battery negative (-) terminal to prevent
damage to the unit, re and/or possible injury.
Punch DVC Woofer
Trim Ring
Screw Pack
Installation & Operation Manual
The Punch DVC Woofers are high performance, low frequency drivers with dual voice coils.These
woofers were designed for use primarily in small sealed and small ported enclosures. By utilizing the latest
materials and construction techniques, we are able to oer a speaker with high output at low frequencies
while requiring a minimum of operating space.
DESIGN FEATURES
