P1-SVC - S V C SINGLE OICE OIL UBWOOFERS
8" 10" 12" 15"
4-Ohm P1S4-8 P1S4-10 P1S4-12 P1S4-15
2-Ohm P1S2-8 P1S2-10 P1S2-12 P1S2-15
8-Ohm P1S8-8 P1S8-10 P1S8-12 P1S8-15
Serial Number: Date of Purchase:
3
Vb is the gross volume, which is the TOTAL internal volume, before any speaker and/or port displacement.
All external dimensions were based on the use of 3/4" (1.90cm) materials.
When using enclosures other than recommended, call Technical Support for correct application.
Vb is the gross volume, which is the TOTAL internal volume, before any speaker and/or port displacement.
All external dimensions were based on the use of 3/4" (1.90cm) materials.
When using enclosures other than recommended, call Technical Support for correct application.
SEALDED ENCLOSURES 8"
Vb- Internal Area cu. ft. 0.23 0.59 1.02 1.58
(Liter) (6.51) (16.71) (28.88) (44.74)
F3- -3dB Point (Hz) 64 48 43 40.8
Qtc- Enclosure Damping 0.72 0.83 0.87 1.05
H - Height-inch 10.0 12.0 14.0 18.0
(cm) (25.40) (30.48) (35.56) (45.72)
W - Width-inch 12.0 14.0 18.0 21.0
(cm) (30.48) (35.56) (45.72) (53.34)
D - Depth-inch 6.0 9.25 10.0 10.0
(cm) (15.24) (23.50) (25.40) (25.40)
SEALDED ENCLOSURES 8"
Vb- Volume Range cu. ft. 0.20 to 0.30 0.50 to 0.85 0.70 to 1.80 1.30 to 3.50
(Liter) (5.66 to 8.50) (14.16 to 24.07) (19.82 to 50.97) (36.81 to 99.10)
Number of ports noted in ( )
VENTED ENCLOSURES 8" 10" 12" 15"
Vb- Internal Area cu. ft. 0.65 1.40 1.79 2.66
(Liter) (18.41) (39.64) (50.69) (75.32)
Fb- Tuning Frequency (Hz) 42.7 37.3 36.3 34.4
F3- -3dB Point (Hz) 36.0 32.0 32.5 33.8
H - Height-inch 12.0 12.0 14.0 18.0
(cm) (30.48) (30.48) (35.56) (45.72)
W - Width-inch 18.0 20.0 25.0 28.0
(cm) (45.72) (50.80) (63.50) (71.12)
D - Depth-inch 8.0 14.0 12.0 12.0
(cm) (20.32) (35.56) (30.48) (30.48)
P - Port Diameter and
Length-inch (1) 2 x 6 (1) 3 x 8 (1) 3 x 6 (1) 4 x 8
(cm) (1) (5.08 x 15.24) (1) (7.62 x 20.32) (1) (7.62 x 15.24) (1) (10.16 x 20.32)
The port shown can be placed on any face of the enclosure as long as the port ends are not obstructed.
W
H
D
P
W
H
D
P1S2-8 / P1S4-8 / P1S8-8 P1S2-10 / P1S4-10 / P1S8-10 P1S2-12 / P1S4-12 / P1S8-12 P1S2-15 / P1S4-15 / P1S8-15
8" 10" 12" 15"
P1S2-8 / P1S4-8 / P1S8-8 P1S2-10 / P1S4-10 / P1S8-10 P1S2-12 / P1S4-12 / P1S8-12 P1S2-15 / P1S4-15 / P1S8-15
8"8" 10" 12" 15"
P1S2-8 / P1S4-8 / P1S8-8 P1S2-10 / P1S4-10 / P1S8-10 P1S2-12 / P1S4-12 / P1S8-12 P1S2-15 / P1S4-15 / P1S8-15
