Seite 1/4

Installation &

Operation

SVC - SINGLE VOICE COIL WOOFERS

P18S4

P18S8

P110S4

P110S8

P112S4

P112S8

P115S4

P115S8

P28S4

P28S8

P210S4

P210S8

P212S4

P212S8

P215S4

P215S8

SEALED ENCLOSURES

WIRING CONFIGURATIONS

Check our website for updates on your products.

www.RockfordFosgate.com

CAUTION: Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury.

MISE EN GARDE : avant d'entamer l'installation, déconnectez la broche négative (-) de la batterie pour éviter tout risque de blessures, d’incendie ou de

dommages à l'appareil.

PRECAUCIÓN: Antes de la instalación, desconecte el terminal negativo de la batería (-) para prevenir daño a la unidad, incendio y/o posibles lesiones.

VORSICHT: Entfernen Sie vor dem Einbau den negative Batteriepol, um Schäden am Gerät, Feuer bzw. mögliche Verletzungen zu vermeiden.

ATTENZIONE: Prima dell’installazione, scollegate il terminale negativo (-) della batteria per evitare danni all’unità, pericoli d’incendio e/o potenziali

lesioni personali.

Series/Parallel Wiring

Câblage/en série/parallèle

Cableado en serie/paralelo

Reihen-/parallelgeschaltet

Cablaggio di serie/parallelo

Parallel Wiring

Câblage en parallèle

Cableado en paralelo

Parallelgeschaltet

Cablaggio di parallelo

Zur Volumen-Berechung benötigen sie die genauen Maße und

Dimensionen in Zentimetern.

Calcolare il volume é essenzialmente solo un problema di

misurazione delle dimensioni in centimetri della cassa e di

applicazione della formula:

Gehäuse-Volumen = Höhe (cm) x Breite (cm) x Tiefe (cm)

(Liter) 1000

Volume della cassa = Alteza(cm) x Larghezza(cm)x Profonditá(cm)

(litri) 1000

ITALIANO

DEUTSCH

INSTALLATION REFERENCE

CALCULATING VOLUMES

Calculating volume is merely a matter of measuring the internal

dimensions in inches and using the formula:

Para calcular el volumen sólo se han de medir las dimensiones

en centimetros y aplicar la fórmula:

On calcule le volume en mesurant la dimension de chaque

côté et en utilisant la formule suivante:

Box Volume = Height “ x Width” x Depth”

(cubic feet) 1728

Volumen du la caja = Alto(cm) x Ancho(cm) x Profundidad(cm)

(en litros) 1000

Volume du caisson = Hauteur (cm) x Longueur (cm) x Largeur (cm)

(Litres) 1000

ESPAÑOL

FRANÇAIS

INSTALLATION REFERENCE

SPECIFICATIONS

Model - Punch SVC P18S4 P18S8 P110S4 P110S8 P112S4 P112S8 P115S4 P115S8

Nominal Impedance (ohms) 4 8 4 8 4 8 4 8

Voice Coil Diameter-inch (mm) 1.5 (38.1) 1.5 (38.1) 1.5 (38.1) 1.5 (38.1) 1.5 (38.1) 1.5 (38.1) 2.0 (50.8) 2.0 (50.8)

FS (Hz) 35 36 30 31 25 26 22 23

QTS 0.518 0.538 0.513 0.524 0.594 0.624 0.680 0.697

VAS-cu.ft. (liter) 0.565 (16) 0.565 (16) 1.766 (50) 1.766 (50) 3.779 (107) 3.779 (107) 8.829 (250) 8.829 (250)

Xmax-inch (mm) 0.276 (7.0) 0.276 (7.0) 0.303 (7.7) 0.303 (7.7) 0.303 (7.7) 0.303 (7.7) 0.315 (8.0) 0.315 (8.0)

SPL (dB @ 1w/1m) 83.0 83.0 85.5 85.5 86.0 86.0 87.0 87.0

Power Handling (RMS) 150 150 150 150 150 150 200 200

Power Handling (Max) 300 300 300 300 300 300 400 400

Mounting Dia.-inch (mm) 7-1/16 (179.38) 7-1/16 (179.38) 9-1/4 (234.95) 9-1/4 (234.95) 11-1/8 (282.58) 11-1/8 (282.58) 13-7/8 (352.43) 13-7/8 (352.43)

Mounting Depth-inch (mm) 4-1/16 (103.19) 4-1/16 (103.19) 5-3/16 (131.76) 5-3/16 (131.76) 5-5/8 (142.88) 5-5/8 (142.88) 7-1/8 (180.98) 7-1/8 (180.98)

Speaker Dis.-cu. ft. (liter) 0.020 (0.508) 0.020 (0.508) 0.034 (0.864) 0.034 (0.864) 0.042 (1.067) 0.042 (1.067) 0.077 (1.956) 0.077 (1.956)

Sealed Box Vol.-cu. ft. (liter) 0.25 (7.08) 0.25 (7.08) 0.65 (18.41) 0.65 (18.41) 1.25 (35.40) 1.25 (35.40) 2.25 (63.71) 2.25 (63.71)

Vented Box Vol.-cu. ft. (liter) 0.65 (18.41) 0.65 (18.41) 1.25 (35.40) 1.25 (35.40) 1.75 (49.55) 1.75 (49.55) 2.50 (70.79) 2.50 (70.79)

Port Diameter & Length (in.) (1) 2 x 5.9 (1) 2 x 5.9 (1) 3 x 7.3 (1) 3 x 7.3 (1) 4 x 11 (1) 4 x 11 (1) 4 x 9 (1) 4 x 9

Port Diameter & Length (cm) (1) 5.08 x 14.99 (1) 5.08 x 14.99 (1) 7.62 x 18.54 (1) 7.62 x 18.54 (1) 10.16 x 27.94 (1) 10.16 x 27.94 (1) 10.16 x 22.86 (1) 10.16 x 22.86

Model - Punch SVC P28S4 P28S8 P210S4 P210S8 P212S4 P212S8 P215S4 P215S8

Nominal Impedance (ohms) 4 8 4 8 4 8 4 8

Voice Coil Diameter-inch (mm) 2.0 (50.8) 2.0 (50.8) 2.0 (50.8) 2.0 (50.8) 2.0 (50.8) 2.0 (50.8) 2.0 (50.8) 2.0 (50.8)

FS (Hz) 35 36 28 29 25 26 21 22

QTS 0.491 0.515 0.437 0.500 0.488 0.526 0.560 0.578

VAS-cu.ft. (liter) 0.565 (16) 0.565 (16) 1.483 (42) 1.483 (42) 3.426 (97) 3.426 (97) 8.829 (250) 8.829 (250)

Xmax-inch (mm) 0.315 (8.0) 0.315 (8.0) 0.433 (11.0) 0.433 (11.0) 0.433 (11.0) 0.433 (11.0) 0.433 (11.0) 0.433 (11.0)

SPL (dB @ 1w/1m) 84.0 84.0 85.8 85.8 86.0 86.0 87.5 87.5

Power Handling (RMS) 200 200 200 200 200 200 250 250

Power Handling (Max) 400 400 400 400 400 400 500 500

Mounting Dia.-inch (mm) 7-1/16 (179.38) 7-1/16 (179.38) 9-1/4 (234.95) 9-1/4 (234.95) 11-1/8 (282.58) 11-1/8 (282.58) 13-7/8 (352.43) 13-7/8 (352.43)

Mounting Depth-inch (mm) 4 (101.60) 4 (101.60) 5-5/8 (142.88) 5-5/8 (142.88) 6-1/16 (153.98) 6-1/16 (153.98) 7-3/8 (187.33) 7-3/8 (187.33)

Speaker Dis.-cu. ft. (liter) 0.024 (0.610) 0.024 (0.610) 0.040 (1.016) 0.040 (1.016) 0.049 (1.245) 0.049 (1.245) 0.076 (1.930) 0.076 (1.930)

Sealed Box Vol.-cu. ft. (liter) 0.25 (7.08) 0.25 (7.08) 0.65 (18.41) 0.65 (18.41) 0.85 (24.07) 0.85 (24.07) 2.25 (63.71) 2.25 (63.71)

Vented Box Vol.-cu. ft. (liter) 0.65 (18.41) 0.65 (18.41) 1.25 (35.40) 1.25 (35.40) 1.75 (49.55) 1.75 (49.55) 2.50 (70.79) 2.50 (70.79)

Port Diameter & Length (in.) (1) 2 x 5.9 (1) 2 x 5.9 (1) 3 x 7.3 (1) 3 x 7.3 (1) 4 x 11 (1) 4 x 11 (1) 4 x 9.4 (1) 4 x 9.4

Port Diameter & Length (cm) (1) 5.08 x 14.99 (1) 5.08 x 14.99 (1) 7.62 x 18.54 (1) 7.62 x 18.54 (1) 10.16 x 27.94 (1) 10.16 x 27.94 (1) 10.16 x 23.88 (1) 10.16 x 23.88

NOTE: All recommended volumes are

TOTAL internal volume, before

any speaker and/or port

displacement. All external

dimensions were based on the

use of 3/4" materials.

NOTE: When using enclosures other

than specified, call Technical

Support for correct application.

VENTED ENCLOSURES

Specifications subject to change without notice

Number of ports noted in ( )
