Installation & Operation
AMPLIFIERS
P300X1 P300X2 P400X1
P400X2 P400X4 P500X1BD
P500X2 P600X4 P1000X1BD
P1000X2 P1000X5
2
Dear Customer,
Congratulations on your purchase of the worldās ļ¬nest brand of car audio
products. At Rockford Fosgate we are fanatics about musical reproduc-
tion at its best, and we are pleased you chose our product. Through
years of engineering expertise, hand craftsmanship and critical testing
procedures, we have created a wide range of products that reproduce
music with all the clarity and richness you deserve.
For maximum performance we recommend you have your new Rockford
Fosgate product installed by an Authorized Rockford Fosgate Dealer,
as we provide specialized training through Rockford Technical Training
Institute (RTTI). Please read your warranty and retain your receipt and
original carton for possible future use.
Great product and competent installations are only a piece of the puzzle
when it comes to your system. Make sure that your installer is using
100% authentic installation accessories from Rockford Fosgate in your
installation. Rockford Fosgate has everything from RCA cables and
speaker wire to power wire and battery connectors. Insist on it! After all,
your new system deserves nothing but the best.
To add the ļ¬nishing touch to your new Rockford Fosgate image order
your Rockford accessories, which include everything from T-shirts to
jackets.
Visit our web site for the latest information on all Rockford products;
www.rockfordfosgate.com
or, in the U.S. call 1-800-669-9899 or FAX 1-800-398-3985. For all other
countries, call +001-480-967-3565 or FAX +001-480-966-3983.
Table of Content
If, after reading your manual, you still have questions regarding this prod-
uct, we recommend that you see your Rockford Fosgate dealer. If you need
further assistance, you can call us direct at . Be sure to 1-800-669-9899
have your serial number, model number and date of purchase available
when you call.
Safety
This symbol with āWARNINGā is intended
to alert the user to the presence of important
instructions. Failure to heed the instructions
will result in severe injury or death.
This symbol with āCAUTIONā is intended to
alert the user to the presence of important
instructions. Failure to heed the instructions
can result in injury or unit damage.
ā¢ąøTo prevent injury and damage to the unit, please read and follow the
instructions in this manual. We want you to enjoy this system, not get
a headache.
ā¢ąøIf you feel unsure about installing this system yourself, have it installed
by a qualiļ¬ed Rockford Fosgate technician.
ā¢ąøBefore installation, disconnect the battery negative (-) terminal to
prevent damage to the unit, ļ¬re and/or possible injury.
Introduction
Ā©2013 Rockford Corporation. All Rights Reserved. ROCKFORD FOSGATE, PUNCH, and associated logos where applicable are registered trademarks of Rockford
Corporation in the United States and/or other countries. All other trademarks are the property of their respective owners. Speciļ¬cations subject to change without notice.
PRACTICE SAFE SOUND
Continuous exposure to sound pressure levels over 100dB may cause
permanent hearing loss. High powered auto sound systems may
produce sound pressure levels well over 130dB. Use common sense
and practice safe sound.
2 Introduction
3 Speciļ¬cations
4-5 Design Features
6-17 Installation
Installation Considerations
Mounting Locations
Battery and Charging
Wiring the System
18-19 Operation
Clip Indicator Setup
Adjusting Crossover Frequency
2/4 Channel Switch
Subwoofer Input Switch
Infrasonic Filter
Punch EQ
20 Troubleshooting
21 Limited Warranty Information
4
Design Features
Power/Protect LED
Power LED illuminates blue when the unit is turned on. Protect
LED illuminates yellow if a short circuit or to low of an impedance
is detected at the speaker connections. Thermal LED illuminates
red when ampliļ¬er overheats. The ampliļ¬er will automatically shut
down if this occurs.
Output Clip Indicator Chart
Reference chart for the output clip in-
dicator LED illumination color during
input level setup.
Speaker Terminals
The Speaker Terminals are nickel-plated
captive c-clamp wire connectors (+ and -)
will accommodate 8 AWG.
RCA Input/Pass-Thru
The RCA inputs are capable of accepting signal from either high-level(speaker) to low-
level(RCA). When utilizing high-level for input signal the auto turn-on feature is active.
The pass-thru RCAās are passive, including full input signal range and auto turn-on
functionality when active.
Subwoofer Input
Setting this switch to the āOnā position, utilizes the
āSubā inputs. (P1000X5)
Centering Indicators
Indicators are located on the bottom side of the
ampliļ¬er.
Output Clip Indicator
The output clip indicator works in conjunction with
the input level knob, illuminating to appropriate
color depending on the audio content used for the
setup.
Intput Clip Indicator
The input clip indicator works in con-
junction with the audio source volume
knob, illuminating red when audio
source reaches itās clipping point.
Input Level Knob
The input level control is used to match
the output of the audio source.
INPUT CLIP
FRONT REAR
RIGHTLEFT
BRIDGED
RIGHTLEFT
BRIDGED
SUB
BA
SPEAKERS
