Installation & Operation
M2-SVC - SINGLE VOICE COIL UBWOOFERSS
M A R I N E G R A D E
10" 12"
4-Ohm M210S4 M212S4
Length of Warranty
Speakers – 1 Year. Any Factory Refurbished Product – 90 days (receipt required)
What is Covered
Who is Covered
What is Not Covered
Limit on Implied Warranties
How to Obtain Service
RA# (Return
Authorization number)
EU Warranty
L WIMITED ARRANTY TATEMENTS
Check our website for additional information and
updates on these products.
www.RockfordFosgate.com
SEALED ENCLOSURES
Advantages of sealed enclosures:
VENTED ENCLOSURES
Advantages of vented enclosures:
INFINITE BAFFLE DESIGN
Advantages of infinite baffle design:
BUILDING AN ENCLOSURE
CALCULATING VOLUME
The graph shown here is a sample of how SPL and Excursion
differs between the various enclosures.
SPL & Excursion (@100 Watts) - Impedance (@1 Watt)
2
SAFETY
CARTON CONTENTS
CAUTION:
PRACTICE SAFE SOUNDâ„¢
R EECOMMENDED NCLOSURES
Box Volume Height"x Width"x Depth"
Divided by (cubic feet) 1728
3
NOTE:
NOTE:
NOTE:
NOTE:
NOTE:
S EEALED NCLOSURES
V EENTED NCLOSURES
I BNFINITE AFFLE
Specifications subject to change without notice
Optimum Sealed Enclosure Recommendation
Recommended Sealed Enclosure Volume Range
SEALED ENCLOSURES 10" 12"
M210S4 M212S4
Vb- Internal Area cu. ft. (Liter) 0.75 (21.24) 1.00 (28.33)
Fb- Tuning Frequency (Hz 60.3 53.5
F3- -3dB Point (Hz) 60.6 53.7
Qtc- Enclosure Damping 0.77 0.82
H - Height-inch (cm) 14.5 (36.83) 15.5 (39.37)
W - Width-inch (cm) 17.5 (44.45) 17.625 (44.77)
D - Depth-inch (cm) 8.5 (21.59) 12.0 (30.48)
SEALED ENCLOSURES 10" 12"
M210S4 M212S4
Vb- Volume Range cu. ft. 0.50 to 0.85 0.70 to 1.80
(Liter) (14.16 to 24.07) (19.82 to 50.97)
H
W
D
Position to
Align Holes
H
W
D
P
Position to
Align Holes
Specifications subject to change without notice
Number of ports noted in ( )
Optimum Vented (Ported) Enclosure Sizes
VENTED ENCLOSURES 10" 12"
M210S4 M212S4
Vb- Internal Area cu. ft. (Liter) 1.25 (35.40) 1.50 (42.50)
Fb- Tuning Frequency (Hz 48.6 40.0
F3- -3dB Point (Hz) 40.0 37.2
H - Height-inch (cm) 14.5 (36.83) 15.5 (39.37)
W - Width-inch (cm) 22.5 (57.15) 20.25 (51.44)
D - Depth-inch (cm) 10.0 (25.40) 12.5 (31.75)
P - Port Diameter and
Length-inch (1) 4 x 8.52 (1) 3 x 5.74
(cm) (1) (10.16 x 21.65) (1) (7.62 x 14.59)
Infinite Baffle 10" 12"
M210S4 M212S4
Fb- Tuning Frequency (Hz 57.5 50.1
F3- -3dB Point (Hz) 58.0 50.5
Vas - cu. ft. (Liter) 2.02 (50.80) 4.43 (63.50)
Qtc- Enclosure Damping 0.63 0.58
IMPORTANT:
