Seite 1/10
1
Description:
ROBINHOOD SLIDEOUTS
Model
Numbers:
RLES61SS/WH, RLES91SS/WH
RI61SS/WH
RO91SS/WH
RO61SS/WH/80
Issue: 10
RLES,RI,RO
All dimensions in mm
Model may vary slightly from images pictured
2
Safety Warnings
All electrical work must be done by a registered electrician in accordance with local and national
electrical codes as applicable. For your safety, this product must be earthed.
If the supply cord of this equipment is damaged, it must only be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
This rangehood is designed for indoor use only and must be in a dry location.
Disconnect the power supply when changing light bulbs.
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Young children should be supervised to ensure that they do not play with the appliance.
There shall be adequate ventilation of the room when the rangehood is used at the same time as
appliances burning gas or other fuels.
There is a fire risk if cleaning is not carried out in accordance with the instructions. You must read
the details concerning the method and frequency of cleaning.
Do not flambé under the rangehood.
Exhaust air must not be discharged into an existing flue which is used for exhausting fumes from
appliances burning gas or other fuels.
The minimum distance between the hob surface and the lowest part of the rangehood is 600mm.
This distance shall be at least 650mm, if the rangehood is installed over a gas hob. If the
instructions for the gas hob specify a greater distance, this has to be taken into account.
Attention should be given to ensure that any applicable regulations concerning the discharge of
exhaust air is fulfilled.
The 600mm models RLES61SS/WH, RI61SS/WH, RO61SS/WH/80 are intended for use above hobs
with four elements.
CAUTION: Accessible parts may become hot when used with cooking appliances.
Product approvals
Product rating
165W Max at 230-240V 50Hz ( 3 sp axial) RLES’s, RV’s –
160W Max at 230-240V 50Hz ( 2 sp axial) RO’s –
185W Max at 230- 3 sp centrif.) 240V 50Hz (RI’s, RT’s –
Electric approval
AS/NZS 60335.2.31
EMC approval
AS/NZS CISPR 14.1
Performance tested
AS2682-1984
3
Overview
Pre-installation
Thank you for purchasing a quality Robinhood rangehood. Robinhood has a high standard of quality control and
every rangehood is tested and approved before it leaves the factory.
Important:
Please read the entire instructions before installing the rangehood.
Always switch power off prior to installation.
All electrical work must be done in accordance with local and national electrical codes as applicable.
For safety, this product must be earthed.
A power outlet should be within 1000mm of the power cord exit from the rangehood.
The socket must be accessible and enable the end user to isolate the rangehood from the power for the purpose
of internal cleaning or maintenance.
Stainless steel or powder coat is very easily damaged during installation if abraded or knocked by tools. Protect
the rangehood with the cardboard box or plastic bag during installation.
All ducting must comply with local requirements and building codes.
Suitable fixings will be required to mount this rangehood.
See Ducting options next page.
Contents of packaging:
1 x rangehood
1 x Installation sheet
1 x Installation kit - “SIDE FIXING”
1 x Installation kit - “TOP FIXING”
1 x Charcoal Filter (RO61SS/WH/80 only)
Multiple Handle Colour Options
Typical equipment required:
o electric drill
o screwdriver
o tape measure
o spirit level
o duct tape (if ducting)
o jig saw (if ducting)
o ladder (if ducting)
Front
Side
Plan
