Seite 1/10
1
Description:
ROBINHOOD SLIDEOUTS
Model
Numbers:
RLES61SS/WH, RLES91SS/WH
RI61SS/WH
RO91SS/WH
RO61SS/WH/80
Issue: 8
RLES,RI,RO
All dimensions in mm
Model may vary slightly from images pictured
Safety Warnings
All electrical work must be done by a registered electrician in accordance with local and national
electrical codes as applicable. For your safety, this product must be earthed.
If the supply cord of this equipment is damaged, it must only be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
This rangehood is designed for indoor use only and must be in a dry location.
Disconnect the power supply when changing light bulbs.
This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
Young children should be supervised to ensure that they do not play with the appliance.
There shall be adequate ventilation of the room when the rangehood is used at the same time as
appliances burning gas or other fuels.
There is a fire risk if cleaning is not carried out in accordance with the instructions. You must read
the details concerning the method and frequency of cleaning.
Do not flambé under the rangehood.
Exhaust air must not be discharged into an existing flue which is used for exhausting fumes from
appliances burning gas or other fuels.
The minimum distance between the hob surface and the lowest part of the rangehood is 600mm.
This distance shall be at least 650mm, if the rangehood is installed over a gas hob. If the
instructions for the gas hob specify a greater distance, this has to be taken into account.
Attention should be given to ensure that any applicable regulations concerning the discharge of
exhaust air is fulfilled.
Product approvals
Product approval number
V08526
RT6WH, RT6SS, RT9WH, RT9SS
RLES6WH, RLES6SS, RLES9WH, RLES9SS
RI6WH, RI6SS, RI9WH, RI9SS
RO6WH, RO6SS, RO9WH, RO9SS
RO6WH80, RO6SS80
RV6WH, RV6SS, RV9WH, RV9SS
V090448
RLES61WH, RLES61SS, RLES91WH,
RLES91SS
RI61WH, RI61SS
RO61WH, RO61SS, RO91WH, RO91SS
RO61WH80, RO61SS80
Product rating
165W Max at 230-240V 50Hz ( 3 sp axial) RLES’s, RV’s –
160W Max at 230-240V 50Hz ( 2 sp axial) RO’s –
185W Max at 230- 3 sp centrif.) 240V 50Hz (RI’s, RT’s –
Electric approval
AS/NZS 60335.2.31: 2004 incl. A1-2
EMC approval
AS/NZS CISPR 14, 2002
Performance tested
AS2682-1984
3
Overview
Pre-installation
Thank you for purchasing a quality Robinhood rangehood. Robinhood has a high standard of quality control
and every rangehood is tested and approved before it leaves the factory.
Important:
Please read the entire instructions before installing the rangehood.
Always switch power off prior to installation.
All electrical work must be done in accordance with local and national electrical codes as applicable.
For safety, this product must be earthed.
A power outlet should be within 1000mm of the power cord exit from the rangehood.
The socket must be accessible and enable the end user to isolate the rangehood from the power for the purpose
of internal cleaning or maintenance.
Stainless steel or powder coat is very easily damaged during installation if abraded or knocked by tools. Protect
the rangehood with the cardboard box or plastic bag during installation.
All ducting must comply with local requirements and building codes.
Suitable fixings will be required to mount this rangehood.
See Ducting options next page.
Contents of packaging:
1 x rangehood
1 x Installation sheet
1 x Installation kit - “SIDE FIXING”
1 x Installation kit - “TOP FIXING”
1 x Charcoal Filter (RO61SS/WH/80 only)
Multiple Handle Colour Options
Typical equipment required:
oelectric drill
oscrewdriver
otape measure
ospirit level
oduct tape (if ducting)
ojig saw (if ducting)
oladder (if ducting)
Plan
Front
Side
