Seite 1/8
W363, W563, W763, W553L, W383,
W583, W783, W873, W893
In-Wall Architectural
Loudspeaker
Instruction Manual
2In-Wall Architectural Loudspeaker
Instruction Manual
ABOUT REVEL® IN-WALL SPEAKERS
Since the first Revel® speakers in 1996, Revel products have stood at
the forefront of loudspeaker design and performance. Revel in-wall
loudspeakers draw upon the same research, resources and unique
perspective that put all Revel loudspeakers in a class by themselves.
Revel in-wall loudspeakers provide unparalleled value and are known
for their standard-setting low sonic coloration and their freedom from
distortion over an extraordinarily wide dynamic range.
IN-WALL LOUDSPEAKER HIGHLIGHTS
s Long-throw woofers with cast frames and rubber surrounds provide
high output with low distortion.
s 1-inch (25mm) angle-adjustable, metal-dome tweeter with an
integrated waveguide provides optimized response both on and off
axis.
s High-order crossover network with premium-quality components
delivers extraordinarily accurate timbre reproduction.
s Boundary compensation switch (W893/W873/W783/W763) lets you
adjust the speaker to maintain tonal accuracy when the speaker is
placed near an additional wall or the ceiling.
s Three-position tweeter level control (W893/W873/W783/W763/
W583/W563/W553L) lets you adjust for optimum response in
a variety of acoustical environments, or for using the speakers
without grilles.
PRODUCT REGISTRATION
Please take a moment to register your product on our Web site at www.
revelspeakers.com. You’ll enable us to keep you posted on our latest
advancements and help us to understand our customers and build
products that meet their needs and expectations.
BOX CONTENTS
Your Revel in-wall loudspeaker box should contain the following items:
1 x Revel in-wall loudspeaker
1 x rectangular grille
1 x extra scrim cloth for rectangular grille (with attached foam pads)
1 x mounting template
1 x instruction manual
UNPACKING THE SPEAKER
Carefully unpack the speaker. If you suspect damage from transit, report
it immediately to your dealer and/or delivery service. Keep the shipping
carton and packing materials for future use.
INSTALLATION CONSIDERATIONS
Your new Revel loudspeakers have been engineered to provide
extremely accurate performance. However, any speaker’s ultimate
performance will be affected by the speaker’s placement in the listening
room and the acoustics of the room. Not all listening spaces can
accommodate the ideal conditions of these two factors. Therefore,
careful attention to the placement of your Revel in-wall loudspeakers
will have a significant impact on the general performance of the
loudspeakers.
DOCUMENTATION CONVENTIONS
This document contains general safety, installation and operation
instructions for the Revel
® W893, W873, W783, W583, W383,
W763, W563, W363 and W553L in-wall loudspeakers. It is
important to read this document before attempting to use this
product. Pay particular attention to:
WARNING: Calls attention to a procedure,
practice, condition or the like that, if not
correctly performed or adhered to, could result
in injury or death.
CAUTION: Calls attention to a procedure, practice,
condition or the like that, if not correctly performed or
adhered to, could result in damage to or destruction of part
of or the entire product.
Note: Calls attention to information that aids in the
installation or operation of the product.
3
In-Wall Architectural Loudspeaker
Instruction Manual
Although the Revel W553L is designed for use primarily as front left,
center and front right speakers in a home theater system, the high-order
crossover networks employed in all Revel in-wall speakers provide very
smooth response over a wide listening area, allowing you to use any
model in any application with excellent results.
Note: All Revel in-wall speakers, including the W553L, can be used in
either horizontal or vertical orientation.
LOUDSPEAKER PLACEMENT FOR TWO-CHANNEL
STEREO
Place the left and right loudspeakers the same distance from the
primary listening area (or as close to the same distance as possible). The
distance from each speaker to its nearest side wall should also be the
as close to the same distance as possible.
Equal
Distance
Left
Speaker
Right
Speaker
Equal
Distance
Ideally, the distance between the left and right loudspeakers should be
slightly less than their distance from the primary listening area.
LOUDSPEAKER PLACEMENT FOR HOME THEATER
s The front left and front right loudspeakers should be located on
either side of the video display, with their tweeters as close to ear
level as possible.
2' (0.6m)
or less
As close to screen
as practical
s The front left and front right loudspeakers should be relatively close
to the sides of the video display. For example, front left and front
right loudspeakers used with a 50-in (1.3m) video display should
generally not be more than 80 in (2m) apart.
s The center loudspeaker should be aligned with the center of the
video display. Its tweeter should be no more than 2 ft (0.6m) above
or below the tweeters of the front left and front right speakers.
5.1-Channel Surround Speaker Placement
s In a 5.1-channel system, the surround left and surround right
loudspeakers should be located to the sides of the main listening
area, 5 ft – 7 ft (1.5m – 2.1m) from the floor.
Front Left Front RightCenter
Video Display
Surround
Left
Surround
Right
7.1-Channel Surround Speaker Placement
s In a 7.1-channel system, the surround left and surround right
loudspeakers should be located directly to the sides of the main
listening area, 5 ft – 7 ft (1.5m – 2.1m) from the floor.
s In a 7.1-channel system, the surround back left and surround back
right loudspeakers should be located on the rear wall, 3 ft – 6 ft
(0.9m – 1.8m) apart and at 5 ft – 7 ft (1.5m – 2.1m) from the floor.
Front Left Front RightCenter
Video Display
3' – 6'
(0.9m – 1.8m)
Surround
Left
Surround
Right
Surround
Back Right
Surround
Back Left
