10/17 7360BT/7460B/7460BT Page Model 7360B/ 1 of 4
1455 Kleppe Lane  Sparks, NV 89431-6467 (775) 359 Fax (775) 359-4712 -7424
E-mail: haws@hawsco.com website: www.hawsco.com
Model 7360B/7360BT/7460B/7460BT
Eye ash /Face W
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
No. 2080042(14)
LIMITED WARRANTY
HAWS® warrants that all of its products are guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing
to company within a reasonable period after receipt of the product. Where claims for
defects are made, the defective part or parts shall be delivered to the Company, prepaid,
for inspection. HAWS will not be liable for the cost of repairs, alterations or replacements,
or for any expense connected therewith made by the owner or his agents, except upon
written authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages
caused by defective materials or poor workmanship, except for replacements, as provided
above. Buyer agrees that Haws has made no other warranties either expressed or implied
in addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for
the purpose, which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions HAWS cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED
OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1- - - 800 766 5612
FOR CUSTOMER SERVICE: 1- - - 888 640 4297
10/17 Model 7360B/ of 4 7360BT/7460B/7460BT Page 2
LOCATION OF UNIT: The Model 7360B/7360BT/7460B/7460BT Emergency
Eyewash units should be installed in close proximity to potential accident areas.
They should be clearly identified free from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1/2" IPS with 30 90 psi (2- --
6 ATM) pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1/2" IPS. Waste outlet is 1-1/2"
IPS.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1. 1. No flow. Check the main shut- off valve.
2. Insufficient water flow. Verify minimum 30 psi (2 ATM) 2. a.
flowing supply line pressure.
b. Probable clogging of flow control due
to inadequate line flushing. Turn
water supply off. Unscrew eye/face
wash head and remove the four
screws to disassemble head. Clean
flow control and reassemble head.
See SP65 Installation Drawing for
details.
c. Remove cap located on L – Strainer
using a 3/8” Allen wrench to access
and clean filter screen.
3. Eyewash or facewash streams
do not meet desired eye level or
are not balanced.
3. Possible blocked flow control, see
above solution. Possible non-leveled
eyewash assembly.
4. Water does not drain properly. waste line of your 4. Check the main
building to see if it does handle the
capacity required for the entire
drainage system.
For more information about Haws products, see our website: www.hawsco.com
© 2017 Haws® – A Corporation ll Rights Reserved
HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
PARTS BREAKDOWN
2
4
6
73
STR. REPAIR KIT
L-STRAINER
TEST TAG
BRACKET
EYEWASH SIGN
VALVE ASSEMBLY
EYE/FACE WASH ASSY
BOWL
5
8
6
9
7
5
4
3
2
1
NOTE: SP95 TAILPIECE & TRAP INCLUDED
TAILPIECE & TRAP
8
SP65 EYE/FACE WASH ASSEMBLY
(INCLUDES: EYE/FACE WASH HEAD (SHOWN)
ADAPTER (SHOWN), EYEWASH FLOW
CONTROL (NOT SHOWN), DUST COVER (SHOWN))
1
SP65
SP90
SP229
SP175
SP80
SP170
SP509
SP95
VRKEWSTR
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
C
R
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: HAWS@HAWSCO.COM
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
CLF
2/23/93
14
0002080042
7360B-7460B/7360BT-7460BT
1:1
1 1
FV
11/23/17
VWC
3 of 4
PARTS BREAKDOWN
5175
2017
VWC
W/ MODEL 7360BT & 7460BT ONLY.
