Seite 1/128

Black plate (1,1)

Owner’s Manual

Mode d’emploi

Manuale d’istruzioni

Manual de instrucciones

Bedienungsanleitung

Handleiding

Руководство пользователя

CD RDS RECEIVER

AUTORADIO CD RDS

SINTOLETTORE CD RDS

REPRODUCTOR DE CD CON RECEPTOR RDS

CD RDS-EMPFÄNGER

CD RDS-ONTVANGER

CD RDS ПРИЕМНИК

FH-460UI

<QRD3247-A>1

English NederlandsDeutschEspañolItalianoFrançais Русский

Black plate (2,1)

Thank you for purchasing this PIONEER

product

To ensure proper use, please read through this

manual before using this product. It is especially

important that you read and observe WARN-

INGs and CAUTIONs in this manual. Please

keep the manual in a safe and accessible place for

future reference.

If you want to dispose this product, do not

mix it with general household waste. There is

a separate collection system for used elec-

tronic products in accordance with legislation

that requires proper treatment, recovery and

recycling.

Private households in the member states of the

EU, in Switzerland and Norway may return their

used electronic products free of charge to desig-

nated collection facilities or to a retailer (if you

purchase a similar new one).

For countries not mentioned above, please con-

tact your local authorities for the correct method

of disposal.

By doing so you will ensure that your disposed

product undergoes the necessary treatment, re-

covery and recycling and thus prevent potential

negative effects on the environment and human

health.

About this unit

The tuner frequencies on this unit are allocated

for use in Western Europe, Asia, the Middle

East, Africa and Oceania. Use in other areas

may result in poor reception. The RDS (radio

data system) function only works in areas that

broadcast RDS signals for FM stations.

WARNING

!Do not attempt to install or service this

product by yourself. Installation or serv-

icing of this product by persons without

training and experience in electronic

equipment and automotive accessories

may be dangerous and could expose you

to the risk of electric shock, injury or

other hazards.

!Do not attempt to operate the unit while driv-

ing. Make sure to pull off the road and park

your vehicle in a safe location before at-

tempting to use the controls on the device.

CAUTION

!Do not allow this unit to come into contact

with liquids. Electrical shock could result.

Also, damage to this unit, smoke, and over-

heating could result from contact with

liquids.

!The Pioneer CarStereo-Pass is for use only in

Germany.

!Always keep the volume low enough to hear

outside sounds.

!Avoid exposure to moisture.

CAUTION

This product is a class 1 laser product classi-

fied under the Safety of laser products, IEC

60825-1:2007.

If you experience problems

Should this unit fail to work properly, please con-

tact your dealer or nearest authorized PIONEER

Service Station.

Before you start

Section

Before you start

<QRD3247-A>2

Black plate (3,1)

Head unit

1 2 4 5

8 9

7 a c6 b d

1h(eject)

2iPod

31/to 6/

4Disc loading slot

5DISP

6SRC/OFF

7BAND/(iPod control)

8c/d

9MULTI-CONTROL (M.C.)

a(back)/DIMMER (dimmer)

b(list)

cAUX input jack (3.5 mm stereo jack)

dUSB port

CAUTION

Use an optional Pioneer USB cable (CD-U50E)

to connect the USB storage device as any device

connected directly to the unit will protrude out

from the unit, which could be dangerous.

Display indication

31 4 86

2 5 7 9

1(list)

(iPod control)

This unit’s iPod function is operated from

your iPod.

3Sub information section

4TA (traffic announcements)

5TP (traffic program identification)

6(sound retriever)

7LOC (local seek tuning)

8(repeat)

9(random)

Main information section

!Tuner: band and frequency

!RDS: program service name, PTY infor-

mation and other literal information

!CD player, USB storage device and iPod:

elapsed playback time and text informa-

tion

bAppears when a lower tier of folder or menu

exists.

Set up menu

1 After installation of this unit, turn the

ignition switch to ON.

SET UP appears.

2 Turn M.C. to switch to YES.

#If you do not use the unit for 30 seconds, the set

up menu will not be displayed.

#If you prefer not to set up at this time, turn M.C.

to switch to NO.

3 Press M.C. to select.

4 Follow these steps to set the menu.

To proceed to the next menu option, you need to

confirm your selection.

LANGUAGE (multi-language)

This unit can display the text information from a

compressed audio file even for information em-

bedded in English, Russian or Turkish.

!If the embedded language and the selected

language setting are not the same, text infor-

mation may not display properly.

!Some characters may not be displayed prop-

erly.

1Turn M.C. to select the desired setting.

ENG (English)—РУС (Russian)—TUR (Turk-

ish)

2Press M.C. to confirm the selection.

CLOCK SET (setting the clock)

1Turn M.C. to adjust hour.

2Press M.C. to select minute.

3Turn M.C. to adjust minute.

4Press M.C. to confirm the selection.

FM STEP (FM tuning step)

Use FM STEP to set FM tuning step options (seek

step settings).

1Turn M.C. to select the FM tuning step.

100 (100 kHz)—50 (50 kHz)

2Press M.C. to confirm the selection.

QUIT appears.

!The manual tuning step is fixed at 50 kHz.

!When AF and TA are turned off, the seek step

is fixed at 50 kHz even if set to 100.

5 To finish your settings, turn M.C. to select

YES.

#If you prefer to change your setting again, turn

M.C. to switch to NO.

6 Press M.C. to select.

Notes

!You can set up the menu options from the

system menu and initial menu. For details

about the settings, refer to System menu on

page 8 and Initial menu on page 9.

!You can cancel set up menu by pressing

SRC/OFF.

Basic operations

Turning the unit on

1Press SRC/OFF to turn the unit on.

Turning the unit off

1Press and hold SRC/OFF until the unit turns

off.

Selecting a source

1Press SRC/OFF to cycle between:

RADIO—CD—USB/iPod—APP (application)—

AUX

!USB MTP displays while the MTP connection

is in use.

!When there is an iPod connected and a source

other than iPod is selected, you can switch to

iPod by pressing iPod.

Adjusting the volume

1Turn M.C. to adjust the volume.

Note

When this unit’s blue/white lead is connected to

the vehicle’s auto-antenna relay control termi-

nal, the vehicle’s antenna extends when this

unit’s source is turned on. To retract the anten-

na, turn the source off.

English

Using this unit

Section

Using this unit

<QRD3247-A>3

Produktspezifikationen

Marke:	Pioneer
Kategorie:	Autoradio
Modell:	FH-460UI
Display-Typ:	LCD
FM-Radio:	Ja
Unterstützte Audioformate:	MP3, WAV, WMA
USB Anschluss:	Ja
Bluetooth:	Nein
Produktfarbe:	Black, Red
Unterstützte Bänder:	AM, FM
Anzahl voreingestellter Stationen:	21
Radio Data System (RDS):	Ja
Equalizer:	Ja
Eingebautes Display:	Ja
AUX-Eingang:	Ja
Playback MP3:	Ja
Lautstärkeregler:	Drehregler
Fernbedienung enthalten:	Nein
Audio Kanäle:	4.0 Kanäle
Audio-System:	MOS-FET
Line-Ausgänge (RCA):	1
Anzahl der USB-Anschlüsse:	1
USB-Version:	2.0
iPod-ready:	Ja
Ausgangsleistung:	200 W
Maximale Leistung pro Kanal:	50 W
Anzahl Entzerrerbänder:	5
Unterstützte Medien:	CD-R, CD-RW
USB-unmittelbare Wiedergabe:	Ja
CD-R-Wiedergabe:	Ja
CD-RW-Wiedergabe:	Ja
CD-Text:	Ja
Autom. digitales Tuning:	Ja
Pause-Funktion:	Ja
Hauptablichtung Farbe:	Rot
CD-Spieler:	Ja
iPod Direktsteuerung:	Ja
Anzahl an optischen Scheiben:	1 Disks
