PRODUCT SPECIFICATION camera solutions
C4021 / REVISED 2-23-17
International Standards
Organization Registered Firm;
ISO 9001 Quality System
Sarix® IMP Indoor and Environmental Mini Domes
UP TO 5 MEGAPIXEL, H.264, IR, DAY/NIGHT IP DOMES
Product Features
•Up to 5 megapixel (MPx) resolution
•Up to 30 images per second (ips) at 3 MPx
•Autofocus motorized remote zoom lens
•Integrated adaptive IR illumination (environmental IR models)
•Operating temperature up to 55°C (131°F)
•Up to 64 GB edge storage with Micro SD card
•Motion detection and camera sabotage detection
•Power over Ethernet (PoE+) Class 4, 24 VAC (environmental models),
PoE, Class 3, 24 VAC, 12 VDC (indoor models)
•Pelco Smart Compression Technology
•All models vandal resistant to IK10
•Compatible with Pelco and third-party video systems
•ONVIF Profile S, Profile G, and Profile Q conformant
•Full 3-year warranty and support
Sarix Professional Range
Powerful, versatile, and affordable, the Sarix® Professional (P)
range cameras pack the most popular features and functionality of
Sarix technology into a wide range of indoor and outdoor options,
including bullet cameras and mini domes. There are also indoor-only
options such as a vandal resistant wedge and micro dome. Mix and
match the performance options and form factor you need for almost
any lighting condition, environment, and application.
Camera
Within the Sarix Professional range, the Sarix IMP Series mini
dome cameras feature a remote zoom lens for wide angle or long
range surveillance needs. Autofocus capability ensures the camera
can be automatically refocused when needed. Additionally, the
Sarix IMP Series features advanced color science and a
mechanical IR cut filter for increased sensitivity in low-light
installations.
Video
Sarix Professional range cameras support up to two simultaneous
video streams and a third service stream. The two streams can be
compressed with efficient H.264 High or Main profiles or MJPEG
formats. The streams can be configured to a variety of frame rates
and variable bit rates to optimize image quality with bandwidth and
storage efficiency.
Edge Storage
Sarix Professional range cameras feature onboard edge storage
with a micro SD card. Video clips of varying lengths can be stored to
the card upon alarm, or video can be written continuously to the
SD card in the case of network outage. Video can be retrieved from
the card through the FTP protocol or by using an ONVIF Profile G
enabled client.
Sarix Professional range cameras feature a simple motion
detection algorithm that allows the camera to record or send an
alarm when there is motion detected in a selected zone or within the
entire scene. A camera sabotage alarm is triggered if the lens is
obstructed or when the camera is repositioned.
Open and Integrated
Sarix Professional range cameras seamlessly connect to Pelco
video management systems such as VideoXpert™, Endura® version
2.0 (or later), and Digital Sentry® version 7.3 (or later). Sarix
Professional range cameras integrate with major third-party
systems through the open Pelco API or the ONVIF Profile S, Profile G,
and Profile Q standards.
Standard Web Interface
Pelco cameras use a standard Web browser interface for easy
remote setup and administration. Controls are optimized for
convenient one-step camera configuration for features including
color, exposure, flicker control, and streaming.
TECHNICAL SPECIFICATIONS
BACK BOX FEATURES
VALUES IN PARENTHESES ARE INCHES; ALL OTHERS ARE CENTIMETERS.
Indoor Surface Mount
• Plastic body and trim ring; polycarbonate bubble
• White, RAL 9003
• IK10 (20J) Impact Resistance
• PoE, Class 3, 24 VAC, 12 VDC
Environmental Surface Mount
• Aluminum body and trim ring; polycarbonate bubble
• RAL 7047
• IP66 Ingress Protection
• Type 4X
• IK10 (20J) Impact Resistance
• 24 VAC and PoE+ Class 4 only
13.70
(5.39)
13.97
(5.50)
7.60
(2.99)
13.70
(5.39)
13.97
(5.50)
7.60
(2.99)
14.00 (5.51)
3.50
(1.38)
4.60
(1.81)
8.30
(3.27)
18.00 (7.09)
0.30
(0.12)
12.00
(4.72)
M4M4
M4
M4
M4
M4
M3M3
19.80 (7.80)
0.73
(0.29)
6.63
(2.61)
4.60
(1.81)
8.80 (3.46)
6.85
(2.70)
8.30 (3.27)
Ø
15.00
(5.91)
Ø 22.20
(8.74)
1-1/2” NPT
9.85
(3.88)
7.80
(3.07)
Ø 14.70
(5.79)
IMPPMB-1I WALL MOUNT BRACKET
IMPPM-1I AND IMPPM-1ER PENDANT ADAPTERIMPICM-1I AND IMPICM-1ER IN-CEILING MOUNT
TECHNICAL SPECIFICATIONS
CAMERA
Imager Type CMOS
Imager Readout Progressive scan
Electronic Shutter Range 1/5 ~ 1/30,000 sec (1 and 5 MPx),
1/5 ~ 1/25,000 sec (2 MPx),
1/5 ~ 1/45,000 sec (3 MPx)
Wide Dynamic Range 75 dB, 90 dB (Backlight Compensation On)
White Balance Range 2,000° to 10,000°K
3D Noise Reduction Yes (ON/OFF selectable)
Mechanical IR Cut Filter Yes (AUTO/MANUAL selectable), with different set points on lux
IR Illumination Adaptive IR up to 25 m; auto ON in night mode, or off
Signal to Noise Ratio ≥50 dB
LENS
Lens Type Built-in; varifocal
Focal Length f/1.4, 3 ~ 10.5 mm
Focus Autofocus, motorized
Zoom Remote
Auto Iris Type DC drive lens
*Field of view may vary with changes in resolution settings.
Imaging Device MPx Sensor Maximum Resolution
5 MPx 1/1.8-inch 2592 x 1944 (5.0 MPx)
3 MPx 1/2.8-inch 2048 x 1536 (3.1 MPx)
2 MPx 1/2.8-inch 1920 x 1080 (2.1 MPx)
1 MPx 1/3-inch 1280 x 960 (1.3 MPx)
Minimum Illumination MPx Sensitivity Color Mono
Mono (IR on)
33 ms 200 ms 33 ms 200 ms
5 MPx f/1.2 0.30 lux 0.03 lux 0.01 lux 0.002 lux 0.00 lux
3 MPx f/1.2 0.25 lux 0.03 lux 0.01 lux 0.002 lux 0.00 lux
2 MPx f/1.2 0.25 lux 0.03 lux 0.01 lux 0.002 lux 0.00 lux
1 MPx f/1.4 0.05 lux 0.03 lux 0.01 lux 0.002 lux 0.00 lux
Field of View* Lens Angle of
View 1 MPx 2 MPx 3 MPx 5 MPx
3 to 10.5 mm
Diagonal 110°~ 33° 116°~ 35° 115°~ 34° 110°~ 46°
Horizontal 85°~ 27° 100°~ 31° 88°~ 30° 88°~ 37°
Vertical 62°~ 19° 54°~ 17° 52°~ 16° 64°~ 27°
