Endless power for endless possibilities
All information provided in this document is subject to change without prior notice
15932
Picture shown may not represent model quoted
3707-3707/10 has a three phase side chanel blower that guarantees quiet
and continuous running. The suction unit is controlled by utilising soft start
technology which reduces power consumption during start up.
The 3707 and 3707/10 have the ability to collect high quantities of heavy
materials.
With power ratings of 5.5kW & 7.5kW, the 3707- 3707/10 offers high
performance whilst being extremely manouverable and versatile. Large
waste container designed for heavy duty use and constant service. With a
large 175 litre capacity waste bin, it is fitted with the drop down release
mechanism to ensure ease of removal and emptying. The large primary ' L'
class star filter provides effective and efficient filtration.The units can be
fitted with M and H class HEPA filtration if required for hazardous dusts.
Filter cleaning is done via the manual filter shaker or by an optional
electrical version. The machine body is manufactured to ensure stability,
robustness and a long service life.
• Low maintenance
• Continuous use
• Very high performance levels
• Large Primary "L" Class Star Filter
• Efficient filter cleaning system
• Filter blockage level monitoring
• Vacuum gauge
• Watertight control panel with soft start
• Electrical filter shaker option
• Highly manoeuvrable
• Stainless steel option
• L, M, H and ATEX versions
● Standard equipment
Included accessories Ref. no. Min.
required 3707 3707 AD 3707/10
FilterFilterFilterFilter
STAR FILTER 560 M Z8 17246 1
● Standard equipment
Included accessories Ref. no. Min.
required 3707/10 C 3707/10 SE 3707/10 C SC
MS
Filter
FilterFilter
Filter
STAR FILTER 560 M Z8 17246 1
Model 3707 3707 AD 3707/10
Ref. no. 4030700000 4030700008 4030700034
PRODUCT FEATURES
Electrical filter shaker
Cartridge filter incl. jet clean system with timer
Manual filter shaker ● ● ●
Star triangle starting ● ● ●
Industrial vacuum cleaners 3707-3707/10
Endless power for endless possibilities
All information provided in this document is subject to change without prior notice
15932
Model 3707 3707 AD 3707/10
Ref. no. 4030700000 4030700008 4030700034
PRODUCT FEATURES
Inversor switch ● ● ●
Relief valve ● ● ●
L class filter ● ● ●
M class filter
Cyclone plate
5 pin plug
Purge jet system
Hepa Downstream Filtration ●
Vacuum Gauge (Filter Surveillance) ● ● ●
Automatic stopping for liquids
Solid control
Model 3707/10 C 3707/10 SE 3707/10 C SC MS
Ref. no. 4030700061 4030700072 4030700695
PRODUCT FEATURES
Electrical filter shaker ●
Cartridge filter incl. jet clean system with timer ● ●
Manual filter shaker ●
Star triangle starting ● ● ●
Inversor switch ● ● ●
Relief valve ● ● ●
L class filter ●
M class filter ● ●
Cyclone plate
5 pin plug
Purge jet system ● ●
Hepa Downstream Filtration
Vacuum Gauge (Filter Surveillance) ● ● ●
Automatic stopping for liquids
Solid control ●
Industrial vacuum cleaners 3707-3707/10
Endless power for endless possibilities
All information provided in this document is subject to change without prior notice
15932
Technical specifications 3707 3707 AD 3707/10
Voltage (V) 230/400 230/400 230/400
Frequency (Hz) 50 50 50
IP protection class 55 55 55
Insulation class F F F
Rated power (kW) 5.5 5.5 7.5
Airflow without hose (m³/h - l/m) 486 - 8100 486 - 8100 810 - 13500
Max. vacuum (kPa - mbar) 36 - 360 36 - 360 25 - 250
Sound pressure level (dB(A)) 78 78 78
Container capacity (l) 175 175 175
Main filter type L CLASS
POLYESTER
L CLASS
POLYESTER
L CLASS
POLYESTER
Main filter area (cm²) 35000 35000 35000
Inlet (mm) 100 100 100
Length x width x height (mm) 1600x800x1810 1600x800x1810 1600x800x1810
Weight (kg) 291 291 305
Technical specifications 3707/10 C 3707/10 SE 3707/10 C SC MS
Voltage (V) 230/400 230/400 230/400
Frequency (Hz) 50 50 50
IP protection class 55 55 55
Insulation class F F F
Rated power (kW) 7.5 7.5 7.5
Airflow without hose (m³/h - l/m) 810 - 13500 810 - 13500 810 - 13500
Max. vacuum (kPa - mbar) 25 - 250 25 - 250 25 - 250
Sound pressure level (dB(A)) 78 78 78
Container capacity (l) 175 175 175
Main filter type L CLASS
POLYESTER
L CLASS
POLYESTER
L CLASS
POLYESTER
Main filter area (cm²) 70000 35000 70000
Inlet (mm) 100 100 100
Length x width x height (mm) 1600x800x1810 1600x800x1810 1600x800x1810
Weight (kg) 305 305 305
Industrial vacuum cleaners 3707-3707/10
