Professional Audio Division
Phone: 310-333-0606 · 800-800-6608 · Fax: 310-333-0688
www.mxlmics.com · sales@mxlmics.com
Condenser Microphone
Tone Selectable
Thank you for choosing the MXL CR20 Condenser microphone. With proper
care, this mic will provide many years of satisfaction. To get the best results,
please take a few moments to read this manual.
Enjoy your microphone!
The MXL Team
General Characteristics
The CR20 microphone has a 22mm capsule with a gold-sputtered dia-
phragm and a fixed cardioid pickup pattern. The CR20 is a condenser mi-
crophone with a tube emulation switch. The switch changes the tonality
to resemble the warm, rich tone of a tube microphone. Condenser micro-
phones are very sensitive, readily revealing very subtle sonic details. They
also tend to pick up sounds outside the pattern more than some designs,
which can lead to powerful feedback if you are not careful. We strongly
advise experimentation with placement and isolation requirements with the
gain initially set low to avoid equipment (and ear) damage. It is strongly
advised to use a mesh pop-filter to prevent moisture from damaging the
capsule.
Contents
Unpack your MXL CR20 microphone carefully and verify that all of the
following items are included:
•MXL CR20 microphone
•Hard mount mic stand adapter
•Rugged Carrying Case
•Microfiber Cleaning Cloth
If any of these items are missing or damaged, contact the company from
which you purchased the microphone.
Power Requirement
IMPORTANT - This unit requires phantom power at 48 volts, +/- 4 volts.
Each unit has been thoroughly checked before shipping, so if you hear no
sound, check that the phantom power on your mixer or separate power
supply is switched on!
Microphone Cable
The microphone cable can have a profound effect on the sound of any
microphone. Even the finest microphones will sound poor if the interconnect
cable allows noise to enter, or causes distortion and loss of information.
Use only the best microphone cable your budget will allow.
Care
Dust and foreign material can degrade the performance of a microphone
over time so always store the unit in its case.
Specifications
Standard / Tube Emulation
Type Pressure-gradient condenser mic
Diaphragm Gold sputtered, 6 micron
Capsule 22mm
Frequency Response 20Hz-20kHz
Polar Pattern Cardioid
Impedance 200 ohms / 150ohms
Sensitivity -35dB re 1 V/Pa / -40dB re 1 V/Pa
S/N Ratio 78dB / 72dB
Equivalent Noise 16dBA (A-weighted IEC 651) / 22dBA (A-weighted
IEC 651)
Max SPL for 0.5% THD 140dB SPL
Power Requirement Phantom Power 48V ±4V
Current Consumption 5.5mA
Size 50mm x 178mm
Weight 0.705 lb (320g)
Metal Finish Black and Black Chrome
Polar PatternFrequency Chart
Warranty
This microphone is guaranteed against defects in material and workmanship
for one year from date of purchase. Should you encounter any problem with
this unit, promptly contact the company you purchased it from for assistance.
The original dated sales receipt will be necessary for any warranty claim. Do
not send any unit directly to us without prior authorization from our service
department! Warranty coverage is limited to repair or replacement (at our
option) of the microphone, and does not cover incidental damages due to
use of this unit, nor damage caused by accidental misuse of this product.
AD092116a
