SPLIT-TYPE AIR CONDITIONERS
INDOOR UNIT
MSY-GN50VF MSY-GN60VF MSY-GN71VF MSY-GN80VF
English
OPERATING INSTRUCTIONS For user
• To use this unit correctly and safely, be sure to read these operating
instructionsbeforeuse.
En-1
● OPERATING INSTRUCTIONS ●
SAFETY PRECAUTIONS
CONTENTS
■ SAFETY PRECAUTIONS 1
■ NAME OF EACH PART 3
■ PREPARATION BEFORE OPERATION 4
■ SELECTING OPERATION MODES 5
■ FAN SPEED AND AIRFLOW DIRECTION ADJUSTMENT 6
■ LONG OPERATION 7
■ POWERFUL OPERATION 7
■ I-SAVE OPERATION 7
■ ECONO COOL OPERATION 8
■ TIMER OPERATION (ON/OFF TIMER) 8
■ WEEKLY TIMER OPERATION 9
■ CLEANING 10
■ WHEN YOU THINK THAT TROUBLE HAS OCCURRED 11
■ WHEN THE AIR CONDITIONER IS NOT GOING TO BE USED FOR A LONG TIME 12
■ INSTALLATION PLACE AND ELECTRICAL WORK 12
■ SPECIFICATIONS 12
• Since rotating parts and parts which could cause an electric shock are used
in this product, be sure to read these “Safety Precautions” before use.
• Since the cautionary items shown here are important for safety, be sure to
observe them.
• After reading this manual, keep it together with the installation manual in a
handy place for easy reference.
• Be sure to receive a guarantee card from your dealer and check that the
purchased date and shop name, etc. are entered correctly.
Marks and their meanings
WARNING : Incorrect handling could cause serious hazard, such as
death, serious injury, etc. with a high probability.
CAUTION : Incorrect handling could cause serious hazard depending
on the conditions.
Meanings of symbols used in this manual
: Be sure not to do.
: Be sure to follow the instruction.
: Never insert your fi nger or stick, etc.
:
Never step onto the indoor/outdoor unit and do not put anything on them.
: Danger of electric shock. Be careful.
:
Be sure to disconnect the power supply plug from the power outlet.
: Be sure to shut off the power.
: Risk of fi re.
WARNING
Do not connect the power cord to an intermediate point, use
an extension cord, or connect multiple devices to a single
AC outlet.
• This may cause overheating, fi re, or electric shock.
Make sure the power plug is free of dirt and insert it securely
into the outlet.
• A dirty plug may cause fi re or electric shock.
Do not bundle, pull, damage, or modify the power cord, and do
not apply heat or place heavy objects on it.
• This may cause fi re or electric shock.
Do not turn the breaker OFF/ON or disconnect/connect the
power plug during operation.
• This may create sparks, which can cause fi re.
•
After the indoor unit is switched OFF with the remote controller,
make sure to turn the breaker OFF or disconnect the power plug.
Do not expose your body directly to cool air for a prolonged
length of time.
• This could be detrimental to your health.
The unit should not be installed, relocated, disassembled,
altered, or repaired by the user.
• An improperly handled air conditioner may cause fi re, electric
shock, injury, or water leakage, etc. Consult your dealer.
• If the power supply cord is damaged, it must be replaced by the
manufacturer or its service agent in order to avoid a hazard.
When installing, relocating, or servicing the unit, make sure
that no substance other than the specifi ed refrigerant (R32)
enters the refrigerant circuit.
• Any presence of foreign substance such as air can cause abnor-
mal pressure rise and may result in explosion or injury.
• The use of any refrigerant other than that specifi ed for the system
will cause mechanical failure, system malfunction, or unit break-
down. In the worst case, this could lead to a serious impediment
to securing product safety.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appli-
ance by a person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance.
Do not insert your fi nger, a stick, or other objects into the air
inlet or outlet.
• This may cause injury, since the fan inside rotates at high speeds
during operation.
In case of an abnormal condition (such as a burning smell),
stop the air conditioner and disconnect the power plug or turn
the breaker OFF.
• A continued operation in the abnormal state may cause a malfunc-
tion, fi re, or electric shock. In this case, consult your dealer.
WARNING
(Risk of fi re)
This unit uses a fl ammable refrigerant.
If refrigerant leaks and comes in contact with fi re or heating part, it will create harmful gas and there is risk of fi re.
Read the OPERATING INSTRUCTIONS carefully before operation.
Service personnel are required to carefully read the OPERATING INSTRUCTIONS and INSTALLATION MANUAL before operation.
Further information is available in the OPERATING INSTRUCTIONS, INSTALLATION MANUAL, and the like.
Meanings of symbols displayed on indoor unit and/or outdoor unit
En-2
SAFETY PRECAUTIONS
CAUTION
Do not touch the air inlet or the aluminum fi ns of the indoor/
outdoor unit.
• This may cause injury.
Do not use insecticides or fl ammable sprays on the unit.
• This may cause a fi re or deformation of the unit.
Do not expose pets or houseplants to direct airfl ow.
• This may cause injury to the pets or plants.
Do not place other electric appliances or furniture under the
indoor/outdoor unit.
• Water may drip down from the unit, which may cause damage or
malfunction.
Do not leave the unit on a damaged installation stand.
• The unit may fall and cause injury.
Do not step on an unstable bench to operate or clean the unit.
• This may cause injury if you fall down.
Do not pull the power cord.
• This may cause a portion of the core wire to break, which may
cause overheating or fi re.
Do not charge or disassemble the batteries, and do not throw
them into a fi re.
• This may cause the batteries to leak, or cause a fi re or explosion.
Do not operate the unit for more than 4 hours at high humidity
(80% RH or more) and/or with windows or outside door left open.
• This may cause the water condensation in the air conditioner, which
may drip down, wetting or damaging the furniture.
• The water condensation in the air conditioner may contribute to
growth of fungi, such as mold.
Do not use the unit for special purposes, such as storing food,
raising animals, growing plants, or preserving precision devices
or art objects.
• This may cause deterioration of quality, or harm to animals and
plants.
Do not expose combustion appliances to direct airfl ow.
• This may cause incomplete combustion.
Never put batteries in your mouth for any reason to avoid ac-
cidental ingestion.
• Battery ingestion may cause choking and/or poisoning.
Before cleaning the unit, switch it OFF and disconnect the power
plug or turn the breaker OFF.
• This may cause injury, since the fan inside rotates at high speeds
during operation.
When the unit will be unused for a long time, disconnect the
power plug or turn the breaker OFF.
• The unit may accumulate dirt, which may cause overheating or fi re.
WARNING
Consult your dealer for installing the air conditioner.
• It should not be installed by the user since installation requires
specialized knowledge and skills. An improperly installed air con-
ditioner may cause water leakage, fi re, or electric shock.
Provide a dedicated power supply for the air conditioner.
• A non-dedicated power supply may cause overheating or fi re.
Do not install the unit where fl ammable gas could leak.
• If gas leaks and accumulates around the outdoor unit, it may cause
an explosion.
Earth the unit correctly.
• Do not connect the earth wire to a gas pipe, water pipe, lightning
rod, or a telephone earth wire. Improper earthing may cause electric
shock.
CAUTION
Install an earth leakage breaker depending on the installation
location of the air conditioner (such as highly humid areas).
• If an earth leakage breaker is not installed, it may cause electric
shock.
Ensure that the drain water is properly drained.
• If the drain passage is improper, water may drip down from the
indoor/outdoor unit, wetting and damaging the furniture.
In case of an abnormal condition
Immediately stop operating the air conditioner and consult your dealer.
Replace all batteries of the remote controller with new ones of
the same type.
• Using an old battery together with a new one may cause overheat-
ing, leakage, or explosion.
If the battery fl uid comes in contact with your skin or clothes,
wash them thoroughly with clean water.
• If the battery fl uid comes in contact with your eyes, wash them
thoroughly with clean water and immediately seek medical attention.
Ensure that the area is well-ventilated when the unit is operated
together with a combustion appliance.
• Inadequate ventilation may cause oxygen starvation.
Turn the breaker OFF when you hear thunder and there is a pos-
sibility of a lightning strike.
• The unit may be damaged if lightning strikes.
After the air conditioner is used for several seasons, perform
inspection and maintenance in addition to normal cleaning.
• Dirt or dust in the unit may create an unpleasant odor, contribute
to growth of fungi, such as mold, or clog the drain passage, and
cause water to leak from the indoor unit. Consult your dealer for
inspection and maintenance, which require specialized knowledge
and skills.
Do not operate switches with wet hands.
• This may cause electric shock.
Do not clean the air conditioner with water or place an object that
contains water, such as a fl ower vase, on it.
• This may cause fi re or electric shock.
Do not step on or place any object on the outdoor unit.
• This may cause injury if you or the object falls down.
For installation
IMPORTANT
Dirty fi lters cause condensation in the air conditioner which will contribute
to the growth of fungi such as mold. It is therefore recommended to clean air
fi lters every 2 weeks.
WARNING
When the air conditioner does not cool or heat, there is a
possibility of refrigerant leakage. If any refrigerant leak-
age is found, stop operations and ventilate the room well
and consult your dealer immediately. If a repair involves
recharging the unit with refrigerant, ask the service techni-
cian for details.
• The refrigerant used in the air conditioner is not harmful.
Normally, it does not leak. However, if refrigerant leaks and
comes in contact with fi re or heating part of such a fan heater,
kerosene heater, or cooking stove, it will create harmful gas
and there is risk of fi re.
The user should never attempt to wash the inside of the
indoor unit. Should the inside of the unit require cleaning,
contact your dealer.
• Unsuitable detergent may cause damage to plastic material
inside the unit, which may result in water leakage. Should
detergent come in contact with electrical parts or the motor, it
will result in a malfunction, smoke, or fi re.
• The appliance shall be stored in a room without continuously
operating ignition sources (for example: open fl ames, an op-
erating gas appliance or an operating electric heater).
• Be aware that refrigerants may not contain an odour.
• Do not use means to accelerate the defrosting process or to
clean the appliance, other than those recommended by the
manufacturer.
• Do not pierce or burn.
The unit must be installed in rooms which exceed the fl oor
space specifi ed below.
• GN50 : 1.7 m²
• GN60 : 2.5 m²
• GN71/80: 3.9 m²

Produktspezifikationen

Marke: Mitsubishi
Kategorie: Klimaanlage
Modell: MSY-GN42VF

Brauchst du Hilfe?

Wenn Sie Hilfe mit Mitsubishi MSY-GN42VF benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Klimaanlage Mitsubishi

Mitsubishi

Mitsubishi MSZ-CB22VA Bedienungsanleitung

14 Oktober 2024
Mitsubishi

Mitsubishi FDK Bedienungsanleitung

8 Oktober 2024
Mitsubishi

Mitsubishi KITMSZ-EF25VEB Bedienungsanleitung

4 Oktober 2024
Mitsubishi

Mitsubishi SET-MSZ-SF50VE Bedienungsanleitung

2 Oktober 2024
Mitsubishi

Mitsubishi CompTroll SMS Bedienungsanleitung

30 September 2024
Mitsubishi

Mitsubishi MSY-GN25VF Bedienungsanleitung

30 September 2024
Mitsubishi

Mitsubishi MSZ-EF42VES Bedienungsanleitung

23 September 2024
Mitsubishi

Mitsubishi MSZ-GS80VFD-A1 Bedienungsanleitung

22 September 2024
Mitsubishi

Mitsubishi MSZ-A30YV Bedienungsanleitung

22 September 2024
Mitsubishi

Mitsubishi SLB-3ER Bedienungsanleitung

19 September 2024

Bedienungsanleitung Klimaanlage

Neueste Bedienungsanleitung für -Kategorien-

MundoClima

MundoClima MUCSR-H3 Bedienungsanleitung

16 Oktober 2024
Duux

Duux DXMA10 North Bedienungsanleitung

16 Oktober 2024
Duux

Duux DXAC04 Bedienungsanleitung

16 Oktober 2024
LG

LG HS-H076QPA0 Bedienungsanleitung

16 Oktober 2024
Klarstein

Klarstein Vita Pure 2G Bedienungsanleitung

16 Oktober 2024
Einhell

Einhell BMK 2400E Bedienungsanleitung

15 Oktober 2024
Qlima

Qlima P 126 Bedienungsanleitung

15 Oktober 2024
Amana

Amana PTC093K35AXXX Bedienungsanleitung

15 Oktober 2024
Amana

Amana AMAP121AB-2 Bedienungsanleitung

15 Oktober 2024
Amana

Amana PTC173J35AXXX Bedienungsanleitung

15 Oktober 2024
