PL360

PL360 Host Controller

Introduction

The PL360 is a multi-protocol modem for the Power Line Communication (PLC) device, implementing a very flexible

architecture and allowing the implementation of standard and customized PLC solutions. It has been conceived to be

bundled with an external Microchip MCU, which downloads the corresponding PLC firmware and controls the

operation of the PL360 device.

The purpose of the PL360 Host Controller is to provide the external microcontroller a way to control the PL360 device

and offer upper layers an easy way to get access to PLC communication.

As an example of the PLC system, the figure below shows the system architecture for G3 protocol based on a PL360

device being controlled by a SAM4C MCU.

Figure 1. G3 System Architecture

Embedded USI

G3-PLC Stack

PHY + PLC Transceiver

SAM4C

( ITU-T G.9903 )

( IEEE 802.15.4 )

( IETF RFC 4944 )

Adaptation Layer

MAC Layer

PAL Layer

sniffer_if

phy_if

mac_if

adp_if

app_if

Host Controller

PLC

USER APPLICATION

PL360

SPI

PLATFORM

IPv6 STACK

Detect

Interrupt

Carrier

The aim of this document is to clarify and detail the user interface of the PL360 Host Controller.

Features

• Compliant with PRIME 1.3 Physical Layer

• Compliant with PRIME 1.4 Physical Layer

• Compliant with G3 Physical Layer

• SPI Interface

• Secure Boot Option

PL360

Table of Contents

Introduction.....................................................................................................................................................1

Features......................................................................................................................................................... 2

1. PL360 Host Controller Architecture.........................................................................................................5

1.1. PL360 Host Controller File Structure............................................................................................5

1.2. Application Interface (API)............................................................................................................6

1.3. PLC Stack Wrapper......................................................................................................................6

1.4. Add-ons........................................................................................................................................ 7

1.5. Bootloader.................................................................................................................................... 7

1.6. Hardware Abstraction Layer (HAL).............................................................................................. 7

1.7. Sleep Mode.................................................................................................................................. 7

1.8. Debug Mode.................................................................................................................................8

2. PL360 System Architecture.....................................................................................................................9

2.1. Block Diagram..............................................................................................................................9

2.2. Bootloader.................................................................................................................................... 9

2.3. PL360 Memory.............................................................................................................................9

2.4. PL360 Drivers.............................................................................................................................10

2.5. PHY PLC Service....................................................................................................................... 10

2.6. PHY Host Application................................................................................................................. 11

3. Brief about ASF.....................................................................................................................................12

4. Initialization Example............................................................................................................................ 13

4.1. Init Controller Descriptor.............................................................................................................13

4.2. Set Controller Callbacks.............................................................................................................13

4.3. Enable Controller........................................................................................................................13

4.4. PLC Event Handling...................................................................................................................14

4.5. Code Example............................................................................................................................14

5. Configuration.........................................................................................................................................16

5.1. Configure Application................................................................................................................. 16

5.2. Configure Secure Mode............................................................................................................. 16

6. Host Interface Management..................................................................................................................17

6.1. Message Transmission...............................................................................................................17

6.2. Message Reception....................................................................................................................17

7. SPI Protocol.......................................................................................................................................... 18

7.1. Boot Command Format.............................................................................................................. 18

7.2. Boot Response Format.............................................................................................................. 18

7.3. Firmware Command Format...................................................................................................... 19

7.4. Firmware Response Format.......................................................................................................19

7.5. Firmware Data Memory Regions................................................................................................20

7.6. Message Flow for Basic Transactions........................................................................................21

8. Example Applications............................................................................................................................32

PL360

8.1. PHY Examples........................................................................................................................... 32

9. Supported Platforms............................................................................................................................. 34

9.1. Supported MCU Families........................................................................................................... 34

9.2. Supported Transceivers............................................................................................................. 34

9.3. Supported Boards...................................................................................................................... 34

10. Abbreviations........................................................................................................................................ 35

11. References............................................................................................................................................36

12. PL360 Host Controller API.................................................................................................................... 37

12.1. Common PHY API......................................................................................................................37

12.2. G3 PHY API............................................................................................................................... 41

12.3. PRIME PHY SAP....................................................................................................................... 63

13. Appendix B: ZC Offset Configuration.................................................................................................... 83

14. Revision History.................................................................................................................................... 84

14.1. Rev A – 03/2018.........................................................................................................................84

14.2. Rev B - 10/2018......................................................................................................................... 84

14.3. Rev C - 04/2019......................................................................................................................... 84

14.4. Rev D - 07/2019......................................................................................................................... 85

14.5. Rev E - 08/2020......................................................................................................................... 85

The Microchip Website.................................................................................................................................86

Product Change Notification Service............................................................................................................86

Customer Support........................................................................................................................................ 86

Microchip Devices Code Protection Feature................................................................................................ 86

Legal Notice................................................................................................................................................. 87

Trademarks.................................................................................................................................................. 87

Quality Management System....................................................................................................................... 88

Worldwide Sales and Service.......................................................................................................................89

PL360

1. PL360 Host Controller Architecture

The PL360 Host Controller is a C source code component which provides the host MCU application access to the

API of the Power Line Communications PHY layer running in the PL360 device. shows the architecture ofFigure 1-1

the software which runs on the host MCU. The components of the PL360 Host Controller are described in the

following subsections.

Figure 1-1. PL360 Host Controller Architecture

HOST MCU

PLC Application

PLC Application Interface API

Bootloader PLC Stack Wrapper Add-ons

PL360 Host Controller

Hardware Abstracion Layer

1.1 PL360 Host Controller File Structure

The PL360 Host Controller is provided as a component of Microchip ASF (Advanced Software Framework). The

image below shows the location of the main files of the PL360 Host Controller Software. Different blocks provide

different features. The next subsections describe the purpose of each block.

PL360

PL360 Host Controller Architecture

Figure 1-2. PL360 Host Controller File Structure

Add

ons

PLC Stack W

pper

Bootl oader

API

HAL

1.2 Application Interface (API)

This module provides an interface to the application for all PLC operations.

This API includes the following services:

• Set a custom hardware interface.

• Manage the bootloader process of the PL360 device.

• Manage the external configuration of the PL360 device.

• Enable / Disable PLC interface.

• Enable / Disable Secure mode.

• Enable / Disable add-on module (only for PHY firmwares).

• Enable / Disable Sleep mode.

• Enable / Disable Debug mode in run time. Manage extraction of data me memory from PL360.

This interface is defined in file and some of these services are configured in file (see atpl360.h conf_atpl360.h 5.1

Configure Application).

1.3 PLC Stack Wrapper

This module provides an interface compliant with the specific PLC communication stack, G3 or PRIME. It includes all

declarations and definitions relative to the specific communication stack.

The main function of this module is to parse/serialize frames between SPI protocol and API functions in order to

manage information from/to upper layers. It also provides a configuration function to set some hardware- specific

parameters during the initialization process.

For further details, please refer to header file.atpl360_comm.h

PL360

PL360 Host Controller Architecture

1.4 Add-ons

This module is responsible for providing compatibility with Microchip PLC tools. Its main function is to pack/unpack

frames so that they can be used by each PLC tool.

There are two add-ons available per PLC communication stack: one to connect with the Microchip PLC Sniffer PC

tool, and another one to connect with the Microchip PLC PHY Tester PC tool.

1.5 Bootloader

The PL360 device is RAM-based, so it is required to transfer the binary code to the device after each reset. The main

purpose of this module is to manage the binary download process.

During the bootloading process, the integrity of the SPI communication between the PL360 Host Controller and the

PL360 device is checked in each SPI transaction. If the SPI header does not match the expected value, the PL360

Host Controller resets the PL360 device and the bootloader restarts the download of the binary code to the device

again. The PL360 Host Controller tries this download process up to three times and reports a critical failure to upper

layers after the last unsuccessful download process.

There are two modes of operation for the bootloader: Normal mode or Secure mode.

In Secure mode, the downloaded binary must be encrypted.

The following points should be taken into account in order to enable the Secure Boot mode:

• Define in fileATPL360_SEC_BOOT_MODE conf_atpl360.h

• It is mandatory to include specific metadata in the binary file before downloading it to the PL360 device, such as

number of blocks to decypher, init vector and signature. A Microchip Python

® script is provided in PLC PHY

Workspace as an example of how to include this metadata information in the binary file

For further information about Secure mode, please refer to the PL360 Security Features document.

1.6 Hardware Abstraction Layer (HAL)

The Hardware Abstraction Layer provides full hardware compatibility with the host device.

There are four hardware peripherals that depend on customer platform/implementation:

• Access to SPI peripheral

• Access to interrupt system

• Access to delay system

• Access to carrier detect line

For further details, please refer to section .4. Initialization Example

1.7 Sleep Mode

In the Sleep mode of the PL360, the core of the device and the peripherals are reset reducing power consumption. In

this mode, RAM memory is still alive and the content of the memory is maintained, so program reloading is not

required when the PL360 returns to normal operating mode and wake-up time is reduced considerably.

The mean power consumption of the PL360 device in Sleep mode is 0.7mA / 2.3 mW.

The wake-up time is optimized and reduced to 4ms. Please note that the wake-up time only takes into account the

time for powering up the hardware and the initialization of the PL360 firmware. If any parameter (such as coupling

parameters) is required to be configured, the time of configuration of the PL360 must be added.

In order to handle Sleep mode from the host, the NRST and TST pins of the PL360 device must be connected to the

host controller.

There are 2 different ways to manage Sleep mode:

• Use standard API functions. Please refer to .12.1 Common PHY API

PL360

PL360 Host Controller Architecture

• Use PIB objects specification. Please refer to or 12.2.5 PIB Objects Specification and Access (G3) 12.3.4 PIB

Objects Specification and Access (PRIME)

1.8 Debug Mode

In the Debug mode of the PL360, the core of the device and the peripherals are reset. In this mode, RAM memory is

still alive and the content of the memory is maintained, but the PL360 is set in Bootloader mode. The bootloader

commands are used to access the memory contents.

Reloading of the program is not necessary to return to the PL360 normal operating mode.

Some requirements are mandatory to handle this mode:

• The NRST pin of the PL360 device must be connected to a host device.

• The PL360 Control fuses must be configured to allow read operations. For further information, please refer to

the .PL360 datasheet

There are two different ways to manage Debug mode:

• Using standard API functions. Please refer to .12.1 Common PHY API

• Using PIB objects specification. Please refer to or 12.2.5 PIB Objects Specification and Access (G3) 12.3.4 PIB

Objects Specification and Access (PRIME)

Please contact Microchip Support for further information.

PL360

PL360 Host Controller Architecture

2. PL360 System Architecture

2.1 Block Diagram

Figure 2-1 shows the PL360 system architecture of the embedded firmware. The PL360 device has an embedded

Cortex® M7 CPU running the PLC firmware. This firmware can either implement the G3 or the PRIME Physical layer,

depending on what has been loaded by the PL360 Host Controller. The components of the system are described in

the following subsections.

Figure 2-1. PL360 Embedded Firmware Architecture

PL360 SoC

PHY Host Application

PHY

UTILS

Chain

Coupling

PHY PLC Service

Application Interface (PHY API)

Bootloader

DACC

PL360 Drivers

ADCC SPI XDMAC XCORR PIO CRC

WDT SPU APMC

Chain

Shared

Memory

Host

Interface

Zero

Cross

Program

Memory

Data

Memory

2.2 Bootloader

The bootloader is an Internal Peripheral (IP) designed to load the program from an external master into the

instruction memory of the Cortex M7. This IP can access the instruction memory, data memory and peripheral

registers.

For further information, please refer to the PL360 datasheet.

2.3 PL360 Memory

There are two memory configurations controlled via MEM_CONFIG bit. In the firmware loading process, the

appropriate memory configuration is established by the PL360 Host Controller according to the firmware requisites.

PL360

PL360 System Architecture

MEM_CONFIG Program memory Data memory

0 128 KBytes 64 KBytes

1 96 KBytes 96 KBytes

The PL360 Host Controller code provided by Microchip sets MEM_CONFIG to 1 by default.

For further information, please refer to the PL360 datasheet.

2.4 PL360 Drivers

Each driver is responsible for managing a hardware peripheral:

• WDT: Watchdog system

• SPU: Signal Processing Unit

• APMC: Advanced Power Management Controller

• DACC: Digital to Analog Converter Controller

• ADCC: Analog to Digital Converter Controller

• SPI: Serial Peripheral Interface

• XDMAC: DMA Controller

• XCORR: Correlator

• PIO: Parallel Input/Output Controller

• CRC: Cyclic Redundancy Check

2.5 PHY PLC Service

There are several blocks in the PHY PLC service:

• Application Interface: The API provides a set of functions to access the physical medium and different

parameters relative to each communication stack

• Host Interface: This block is in charge of managing the communication with the PL360 Host Controller through

SPI. It is responsible for parsing/serializing the SPI data, managing PLC data regions and providing control on

PLC Interruption PIO

• Coupling: This block contains the hardware configuration associated to the reference design provided by

Microchip. If a customer needs to change this configuration to adapt it to its own design, Microchip provides a

specific tool called the PHY Calibration Tool which helps customers calculate the best values for all coupling

parameters. For further details, please refer to the PL360 Physical Calibration document

• TX Chain: The TX chain is responsible for handling messages from upper layers (passed through the API) to the

physical output. This block controls all drivers relative to transmission and adapts signal parameters in order to

use functionalities of the transmission chain PHY Utils block: convolutional encoder, scrambler, interleaver,

modulator, IFFT and interpolator. In addition, it handles the result of the transmission in order to report it to upper

layers through the API

• RX Chain: The RX chain is responsible for handling messages from the physical input to upper layers (passed

through the API). This block checks if the PLC signal is present on the PLC medium, synchronizes with this PLC

signal and drives the signal through functionalities of the reception chain in the PHY Utils block: decimator, FFT,

demodulator, deinterleaver, descrambler and Viterbi block. In addition, it builds the complete message and

reports it to upper layers through the API

• Shared Memory: This block defines the structure of the data memory to avoid collisions between TX and RX

chains

• Zero Cross: The Zero Cross is responsible for calculating the last Zero Cross value and providing it to the PLC

communication stack in use. For further information, please refer to 13. Appendix B: ZC Offset Configuration

• PHY Utils: This block contains several functionalities used by the TX/RX chains

PL360

PL360 System Architecture

2.6 PHY Host Application

The PHY Host Application is responsible for running the main application of the PL360 device. It is in charge of

initializing the hardware and clock systems, checking the watchdog timer and managing the PL360 PLC service

described in the previous chapter.

PL360

PL360 System Architecture

3. Brief about ASF

The Advanced Software Framework (ASF) is a MCU software library providing a large collection of embedded

software for Microchip Flash MCUs: megaAVR, AVR XMEGA, AVR UC3 and SAM devices.

For details on ASF, please refer to the Advanced Software Framework documentation:

•Advanced Software Framework - Website

• [PDF] Atmel AVR4029: Atmel Software Framework - Getting Started

• [PDF] Atmel AVR4030: Atmel Software Framework - Reference Manual

PL360

Brief about ASF

4. Initialization Example

This chapter aims to explain the different steps required during the initialization phase of the system. After powering

up the PL360 device, a set of initialization sequences must be executed in the correct order for the proper operation

of the PL360 device.

The steps are the following:

1. Init controller descriptor

2. Set controller callbacks

3. Enable controller

4. PL360 event handling

CAUTION

Failure to complete any of the these initialization steps will result in failure in the PL360 Host Controller

startup.

4.1 Init Controller Descriptor

The PL360 Host Controller is initialized by calling the function in the API. The PL360 Host Controlleratpl360_init

initialization routine performs the following actions:

• Disable PLC interrupt and component

• Register wrapper for Hardware Abstraction Layer (for further information, please refer to 12.1.1 Initialization

Function)

• Reset the PL360 device using corresponding host MCU control GPIOs

• Configure a GPIO as an interrupt source from the PL360 device

• Initialize the SPI driver

• Register an internal event handler for the external PLC interrupt

• If an add-on is required, initialize specific add-on (configured previously). See chapter 5.1 Configure Application

• Return a descriptor to the PL360 Host Controller. This descriptor will be used to manage the PLC

communication

4.2 Set Controller Callbacks

After initializing the PL360 Host Controller, it is important to set callbacks to manage PL360 events.

The PL360 Host Controller reports PLC events using callback functions.

The following callback functions are defined:

• Data indication: Used to report a new incoming message

• Data confirm: Used to report the result of the last transmitted message

• Add-on event: Used to report that a new add-on message is ready to be sent to the PLC application

• Exception event: Used to report if an exception occurs, such as a reset of the PL360 device

• Sleep mode event: Used to report that Sleep mode has been disabled

• Debug mode event: Used to report that Debug mode has been disabled

4.3 Enable Controller

The PL360 Host Controller is enabled by calling the function in the API. This PL360 Hostatpl360_enable

Controller routine performs the following actions:

• Disable/enable PLC interrupt and component

PL360

Initialization Example

• Transfer the PL360 firmware to the PL360 device and validate. In case of failure, report a critical error in host

communication with the PL360 device through exception callback

4.4 PLC Event Handling

Once the controller callbacks have been set up, the PL360 Host Controller component must be enabled. Then, the

host MCU application is required to call the PL360 Host Controller API periodically to handle events from PL360

embedded firmware.

The PL360 Host Controller API allows the host MCU application to interact with the PL360 embedded firmware. To

facilitate interaction, the PL360 Host Controller implements the host interface protocol described in section 6. Host

Interface Management. This protocol defines how to serialize and how to handle API requests and response

callbacks over the SPI bus interface.

Some PL360 Host Controller APIs are synchronous function calls, whose return indicates that the requested action is

completed. However, most API functions are asynchronous. This means that when the application calls an API to

request a service, the call is non-blocking and returns immediately, usually before the requested action is completed.

When the requested action is completed, a notification is provided in the form of a host interface protocol message

from the PL360 embedded firmware to the PL360 Host Controller, which, in turn, delivers it to the application via

callback functions. Asynchronous operation is essential when the requested service, such as a PLC message

transmission, may take significant time to complete. In general, the PL360 embedded firmware uses asynchronous

events to notify the host driver of status changes or pending data.

The PL360 device interrupts the host MCU when one or more events are pending in the PL360 embedded firmware.

The host MCU application processes received data and events when the PL360 Host Controller calls the

corresponding event callback function(s). In order to receive event callbacks, the host MCU application is required to

periodically call the function in the API.atpl360_handle_events

When host MCU application calls , the PL360 Host Controller checks for pendingatpl360_handle_events

unhandled interrupts from the PL360 device. If no interrupt is pending, it returns immediately. If an interrupt is

pending, function dispatches the PLC event data to the respective registered callback. Ifatpl360_handle_events

the corresponding callback is not registered, the PLC event is discarded.

It is recommended to call this function either:

• From the main loop or from a dedicated task in the host MCU application; or,

• At least once when the host MCU application receives an interrupt from the PL360 embedded firmware

WARNING

The Host driver function is . In the operating systematpl360_handle_events non re-entrant

configuration, it is required to protect the PL360 Host Controller from re-entrance.

4.5 Code Example

The code example below shows the initialization flow as described in previous sections.

/**

* \brief Handler to receive add-on data from ATPL360.

static void _handler_serial_atpl360_event(uint8_t *px_serial_data, uint16_t us_len)

{

/* customer application */

}

/**

* \brief Handler to receive add-on data from ATPL360.

static void _handler_sleep_mode_resume_event(void)

{

/* customer application : restore PL360 custom configuration */

}

PL360

Initialization Example

/**

* \brief Main code entry point.

int main( void )

{

atpl360_dev_callbacks_t x_atpl360_cbs;

atpl360_hal_wrapper_t x_atpl360_hal_wrp;

uint8_t uc_ret;

/* ASF function to setup clocking. */

sysclk_init();

/* ASF library function to setup for the evaluation kit being used. */

board_init();

/* Init ATPL360 */

x_atpl360_hal_wrp.plc_init = hal_plc_init;

x_atpl360_hal_wrp.plc_reset = hal_plc_reset;

x_atpl360_hal_wrp.plc_set_handler = hal_plc_set_handler;

x_atpl360_hal_wrp.plc_send_boot_cmd = hal_plc_send_boot_cmd;

x_atpl360_hal_wrp.plc_write_read_cmd = hal_plc_send_wrrd_cmd;

x_atpl360_hal_wrp.plc_enable_int = hal_plc_enable_interrupt;

x_atpl360_hal_wrp.plc_delay = hal_plc_delay;

atpl360_init(&sx_atpl360_desc, &x_atpl360_hal_wrp);

/* Callback configuration. Set NULL as Not used */

x_atpl360_cbs.data_confirm = NULL;

x_atpl360_cbs.data_indication = NULL;

x_atpl360_cbs.exception_event = NULL;

x_atpl360_cbs.addons_event = _handler_serial_atpl360_event;

x_atpl360_cbs.sleep_mode_cb = _handler_sleep_mode_resume_event;

x_atpl360_cbs.debug_mode_cb = NULL;

sx_atpl360_desc.set_callbacks(&x_atpl360_cbs);

/* Enable ATPL360 */

uc_ret = atpl360_enable(ATPL360_BINARY_ADDRESS, ATPL360_BINARY_LEN);

if (uc_ret == ATPL360_ERROR) {

printf("\r\nmain: atpl360_enable call error!(%d)\r\n", uc_ret);

while (1) {

}

while (1) {

/* Check ATPL360 pending events */

atpl360_handle_events();

}

PL360

Initialization Example

5. Configuration

The PL360 firmware has a set of configurable parameters that control its behavior. There is a set of configuration

APIs provided to the host MCU application to configure these parameters. The configuration APIs are categorized

according to their functionality: application, coupling parameters and secure mode.

Any parameter left unset by the host MCU application will use the default value assigned during the initialization of

the PL360 firmware.

Info: All configuration parameters described in this chapter can be found in file.conf_atpl360.h

5.1 Configure Application

The following parameters can be modified in the file to alter the behavior of the device.conf_atpl360.h

• : Use add-on capabilitiesATPL360_ADDONS_ENABLE

– Serial Interface: provides handling of messages to communicate with the Microchip PLC PHY Tester PC

tool and PLC Python scripts

– Sniffer Interface: provides handling of messages to communicate with the Microchip PLC Sniffer PC tool

Info: These add-on modules are included in the PLC PHY workspace provided by Microchip. This

workspace contains the projects to use with the Microchip PLC tools commented previously.

• : Only in case of G3 communication stack, the frequency band can be selected depending onATPL360_WB

customer requirements. G3 CENELEC-A, CENELEC-B, FCC and ARIB bands are available. Take into account

that this configuration requires the use of different firmware binary files in the PL360 device. For further

information, please refer to .12.2.1 Bandplan Selection

5.2 Configure Secure Mode

For information about configuration of the Secure mode, please consult the PL360 Security Features document.

PL360

Configuration

6. Host Interface Management

The PL360 Host Controller services are divided in two categories: synchronous and asynchronous services. Please

refer to section .4.4 PLC Event Handling

Most of the services implemented by the PL360 Host Controller are asynchronous.

The synchronous service is only used in the function in order to get specific internal parameters relativeget_config

to the communication stack.

When a function from the API is called, a sequence of actions is activated to format the request and to arrange to

transfer it to the PL360 device through the SPI protocol.

When an asynchronous event occurs, the PL360 Host Controller handles the PLC interrupt, checks the events

reported by the PL360 device and extracts the information relative to the notified event.

The associated callback will be invoked in the next call to function.atpl360_handle_events

6.1 Message Transmission

The following figure shows the steps involved in the transmission of a message from the PL360 Host Controller to the

PL360 device.

Figure 6-1. Sequence of Message Transmission

6.2 Message Reception

The following figure shows the steps involved in the reception of a message from the PL360 device to the PL360

Host Controller.

Figure 6-2. Sequence of Message Reception

PL360

Host Interface Management

7. SPI Protocol

The main interface of the PL360 device is the SPI port. The PL360 device employs a proprietary protocol to allow the

exchange of formatted data with the PL360 Host Controller. The PL360 SPI protocol uses raw bytes exchanged on

the SPI bus to form high-level structures like requests and callbacks.

The PL360 SPI protocol consists of two layers:

• Layer 1: bootloader commands to transfer the firmware and configure the PL360 device

• Layer 2: firmware commands to allow the host MCU application to exchange high-level messages (e.g. PLC

data transmission or PLC data reception) with the PL360 embedded firmware

The PL360 SPI Protocol is implemented as a command-response transaction and assumes that one part is the

master (PL360 Host Controller) and the other one is the slave (PL360 embedded firmware).

The format of Command, Response and Data frames is described in the following subsections. The following points

apply:

• There is a response for each command

• Transmitted/received data is divided into packets with variable size

• For a write transaction (slave is receiving data packets), the slave sends a response for each data packet

• For a read transaction (master is receiving data packets), the master does not send any response

• Boot commands require 8-bit transactions. Firmware commands require 16-bit transactions.

7.1 Boot Command Format

The following frame format is used for boot commands, where the PL360 device supports an address of four bytes.

Figure 7-1. Boot Command Fields

The address field contains any physical address of the PL360 device.

For further information regarding the boot command and payload fields, please see the PL360 datasheet.

7.2 Boot Response Format

The following frame format is used for boot responses.

The header field is formed by the first 15 bits and it contains the boot signature data (0b010101100011010). This data

is fixed by the PL360 device and it is used to identify the status of the PL360 device.

PL360

SPI Protocol

The flags field contains information about the reset type of the last reset event:

• USER_RST: User reset

• CM7_RST: Cortex reset

• WDG_RST: Watchdog reset

Table 7-1. Boot Signature Data

31 30 29 28 27 26 25 24

0 1 0 1 0 1 1 0

23 22 21 20 19 18 17 16

0 0 1 1 0 1 0 USER_RST

15 14 13 12 11 10 9 8

CM7_RST WDG_RST – – – – – –

7 6 5 4 3 2 1 0

– – – – – – – –

7.3 Firmware Command Format

The following frame format is used for firmware commands, where the PL360 device supports an address of two

bytes.

Figure 7-2. Firmware Command Fields

The address field contains the identification number of the region to access data. These region numbers are

described in section .7.5 Firmware Data Memory Regions

The CMD field (1 bit), which is the most significant bit of the length field, contains the SPI command:

• Read command: 0

• Write command: 1

The length field (15 bits) contains the number of 16-bit blocks to read.

The payload field depends on the region number to access and on the communication stack in use, G3 or PRIME.

For further information, please refer to file.atpl360_comm.h

7.4 Firmware Response Format

The following frame format is used for firmware responses.

PL360

SPI Protocol

Figure 7-3. Firmware Response Fields

The header field contains the firmware signature data (0x1122). This field is fixed by the PL360 embedded firmware

and is used to check if this firmware runs properly.

Info: Due to the 16-bit configuration used in this SPI firmware transaction, the firmware signature is

stored in memory as 0x2211.

The payload field depends on the PLC communication stack in use (G3 or PRIME). For further information, please

refer to file.atpl360_comm.h

7.5 Firmware Data Memory Regions

This section shows the data memory regions defined in the PL360 device depending on which PLC communication

stack is used.

The only difference between PRIME and G3 communication stacks regarding data memory regions is the number of

transmission messages that can be simultaneously queued. In case of G3, only one message can be queued. In

case of PRIME, two transmission messages can be queued simultaneously. This is possible because there are two

transmission buffers defined in the PRIME PL360 embedded firmware, TX0 and TX1.

CAUTION

In both cases, G3 and PRIME, upper layers are responsible for managing multiple TX times in order to

avoid collisions between them.

7.5.1 G3 Memory Regions

The following table defines memory regions to use with the G3 communication stack:

Table 7-2. G3 Memory Regions Table

Region Name Value Comments

ATPL360_STATUS_INFO_ID 0 Information relative to the system timer and system events

occurrences in the PL360 firmware

ATPL360_TX_PARAM_ID 1 Information relative to parameters of the last transmission

ATPL360_TX_DATA_ID 2 Information relative to data of the last transmission

ATPL360_TX_CFM_ID 3 Information relative to the confirmation of the last transmission

ATPL360_RX_PARAM_ID 4 Information relative to parameters of the last received message

ATPL360_RX_DATA_ID 5 Information relative to data of the last received message

ATPL360_REG_INFO_ID 6 Information relative to internal registers or PIB’s

7.5.2 PRIME Memory Regions

The following table defines memory regions to use with the PRIME communication stack:

PL360

SPI Protocol

Table 7-3. PRIME Memory Regions Table

Region Name Value Comments

ATPL360_STATUS_INFO_ID 0 Information relative to the system timer and system events

occurrences in the PL360 firmware

ATPL360_TX0_PARAM_ID 1 Information relative to parameters of the last transmission (buffer 0)

ATPL360_TX0_DATA_ID 2 Information relative to data of the last transmission (buffer 0)

ATPL360_TX0_CFM_ID 3 Information relative to the confirmation of the last transmission (buffer

ATPL360_TX1_PARAM_ID 4 Information relative to parameters of the last transmission (buffer 1)

ATPL360_TX1_DATA_ID 5 Information relative to data of the last transmission (buffer 1)

ATPL360_TX1_CFM_ID 6 Information relative to the confirmation of the last transmission (buffer

ATPL360_RX_PARAM_ID 7 Information relative to parameters of the last received message

ATPL360_RX_DATA_ID 8 Information relative to data of the last received message

ATPL360_REG_INFO_ID 9 Information relative to internal registers or PIB’s

7.6 Message Flow for Basic Transactions

This section shows the essential message exchanges and timings.

Related constants affecting below parameters:

/* ! FLAG MASKs for set G3 events */

#define ATPL360_TX_CFM_FLAG_MASK 0x0001

#define ATPL360_RX_DATA_IND_FLAG_MASK 0x0002

#define ATPL360_CD_FLAG_MASK 0x0004

#define ATPL360_REG_RSP_MASK 0x0008

#define ATPL360_RX_QPAR_IND_FLAG_MASK 0x0010

/* ! G3 Event Info MASKs */

#define ATPL360_EV_DAT_LEN_MASK 0x0000FFFF

#define ATPL360_EV_REG_LEN_MASK 0xFFFF0000

#define ATPL360_GET_EV_DAT_LEN_INFO(x) ((uint32_t)x & ATPL360_EV_DAT_LEN_MASK)

#define ATPL360_GET_EV_REG_LEN_INFO(x) (((uint32_t)x & ATPL360_EV_REG_LEN_MASK) >> 16)

/* ! FLAG MASKs for set PRIME events */

#define ATPL360_TX0_CFM_FLAG_MASK 0x0001

#define ATPL360_TX1_CFM_FLAG_MASK 0x0002

#define ATPL360_RX_DATA_IND_FLAG_MASK 0x0004

#define ATPL360_CD_FLAG_MASK 0x0008

#define ATPL360_REG_RSP_MASK 0x0010

#define ATPL360_RX_QPAR_IND_FLAG_MASK 0x0020

/* ! PRIME Event Info MASKs */

#define ATPL360_EV_DAT_LEN_MASK 0x0000FFFF

#define ATPL360_EV_REG_LEN_MASK 0xFFFF0000

#define ATPL360_GET_EV_DAT_LEN_INFO(x) ((uint32_t)x & ATPL360_EV_DAT_LEN_MASK)

#define ATPL360_GET_EV_REG_LEN_INFO(x) (((uint32_t)x & ATPL360_EV_REG_LEN_MASK) >> 16)

7.6.1 G3: Send Message

In a message transmission, there are 2 SPI blocks. The first one is relative to the transmission of G3 parameters of

the message, the second one is relative to the data part of the same message.

PL360

SPI Protocol

Figure 7-4. G3 Send Message SPI Sequence

7.6.1.1 G3: Send Parameters

Figure 7-5. G3 Send Parameters SPI Array

In a transmission of parameters, the following can be seen:

• Master (MOSI):

– Send ID memory region(16 bits): 0x0001 ( )ATPL360_TX_PARAM_ID

– Send SPI command (1 bit): 1 (write command)

– Send SPI params length (15 bits) (in blocks of 16-bits): 0x14 (40 bytes)

– Send configuration parameters of G3 transmission (40 bytes) [example in CEN-A band]

• Slave (MISO): PL360 device responds with the Firmware Header (0x1122)

• IRQ is not used in this request operation

7.6.1.2 G3: Send Data

Figure 7-6. G3 Send Data SPI Array

In a transmission of data, the following can be seen:

• Master (MOSI):

– Send ID memory region(16 bits): 0x0002 ( )ATPL360_TX_DATA_ID

– Send SPI command (1 bit): 1 (write command)

– Send SPI data length (15 bits) (in blocks of 16-bits): 0x04 (8 bytes)

– Send data of G3 transmission (8 bytes)

PL360

SPI Protocol

• Slave (MISO): PL360 device responds with the Firmware Header (0x1122)

• IRQ is not used in this request operation

7.6.2 G3: Read TX confirm Information

When message transmission is complete, the PL360 device reports the status of the last transmission. For that

purpose, IRQ is used to notify the PL360 Host Controller that an event has occurred.

Figure 7-7. G3 Read TX Confirm SPI Sequence

In the figure above, the following can be seen:

• IRQ is used to notify of PL360 events

• First SPI transaction corresponds to the retrieval of event information from the PL360 device

• Second SPI transaction corresponds to the retrieval of confirmation data from the PL360 device (if needed)

7.6.2.1 Get Events Information

Figure 7-8. G3 Get Events Information SPI Array

In the retrieval of event information, the following can be seen:

• Master (MOSI):

– Send ID memory region(16 bits): 0x0000 ( )ATPL360_STATUS_INFO_ID

– Send SPI command (1 bit): 0 (read command)

– Send SPI data length (15 bits) (in blocks of 16 bits): 0x04 (8 bytes)

• Slave (MISO):

– Send Firmware Header (16 bits): 0x1122

– Send Firmware Events (16 bits): 0x0001 ( )ATPL360_TX_CFM_FLAG_MASK

– Send Firmware Timer reference (32 bits)

– Send Firmware Events Information (32 bits). Only valid in case of data indication

( ) or register response ( ) events. It isATPL360_RX_DATA_IND_FLAG_MASK ATPL360_REG_RSP_MASK

used to report the length of the data to be read

PL360

SPI Protocol

7.6.3.1 Get Events Information and Data

Figure 7-11. G3 Get Events Information and Data SPI Arrays

If IRQ occurs (enabled in low), it is first needed to read events reported by the PL360 device.

• Master (MOSI):

– Send ID memory region(16 bits): 0x0000 ( )ATPL360_STATUS_INFO_ID

– Send SPI command (1 bit): 0 (read command)

– Send SPI data length (15 bits) (in blocks of 16-bits): 0x04 (8 bytes)

• Slave (MISO):

– Send Firmware Header (16 bits): 0x1122

– Send Firmware Events (16 bits): 0x0002 ( )ATPL360_RX_DATA_IND_FLAG_MASK

– Send Firmware Timer reference (32 bits)

– Send Firmware Events Information (32 bits)

• First 16 bits: Not valid

• Second 16 bits: Length of the data to be read in next transaction (D_LEN)

The next transaction gets the data part of the message:

• Master (MOSI):

– Send ID memory region(16 bits): 0x0005 ( )ATPL360_RX_DATA_ID

– Send SPI command (1 bit): 0 (read command)

– Send SPI data length (15 bits) (in blocks of 16-bits): Use (D_LEN/2) obtained in previous transaction

• Slave (MISO):

– Send Firmware Header (16 bits): 0x1122

– Send Firmware Events (16 bits): 0x0002 ( )ATPL360_RX_DATA_IND_FLAG_MASK

– Send Firmware RX data (variable)

7.6.3.2 Get Events Information and Parameters

Figure 7-12. G3 Get Events Information and Parameters SPI Arrays

If IRQ occurs (enabled in low), first it is needed to read events reported by the PL360 device.

• Master (MOSI):

– Send ID memory region(16 bits): 0x0000 ( )ATPL360_STATUS_INFO_ID

PL360

SPI Protocol

– Send SPI command (1 bit): 0 (read command)

– Send SPI data length (15 bits) (in blocks of 16-bits): 0x04 (8 bytes)

• Slave (MISO):

– Send Firmware Header (16 bits): 0x1122

– Send Firmware Events (16 bits): 0x0010 ( )ATPL360_RX_QPAR_IND_FLAG_MASK

– Send Firmware Timer reference (32 bits)

– Send Firmware Events Information (32 bits): Not valid

The next transaction gets the parameters part of the message:

• Master (MOSI):

– Send ID memory region(16 bits): 0x0004 ( )ATPL360_RX_PARAM_ID

– Send SPI command (1 bit): 0 (read command)

– Send SPI data length (15 bits) (in blocks of 16-bits): Variable length depending on G3 band

• Slave (MISO):

– Send Firmware Header (16 bits): 0x1122

– Send Firmware Events (16 bits): 0x0010 ( )ATPL360_RX_QPAR_IND_FLAG_MASK

– Send Firmware RX parameters. See rx_msg_t structure in fileatpl360_comm.h

7.6.4 PRIME: Send Message (Buffer 0)

In a message transmission, there is only one SPI transaction that includes both parameters and data.

Figure 7-13. PRIME Send Message SPI Array

In the figure above, the following can be seen:

• Master (MOSI):

– Send ID memory region(16 bits): 0x0001 ( )ATPL360_TX0_PARAM_ID

– Send SPI command (1 bit): 1 (write command)

– Send SPI params length (15 bits) (in blocks of 16-bits): (param length + data length) / 2, where param

length is 12 bytes

– Send configuration parameters of PRIME transmission (12 bytes)

– Send data part of message (variable)

• Slave (MISO): PL360 responds with Firmware Header (0x1122)

IRQ is not used in this request operation.

7.6.5 PRIME: Read TX confirm Information (Buffer 0)

When message transmission is complete, the PL360 device reports the status of the last transmission. For that

purpose, IRQ is used to notify the PL360 Host Controller that an event has occurred.

PL360

SPI Protocol

Figure 7-14. PRIME TX Confirm Information SPI Sequence

In the figure above, the following can be seen:

• IRQ is used to notify of PL360 events

• First SPI transaction corresponds to the retrieval of event information from the PL360 device

• Second SPI transaction corresponds to the retrieval of confirmation data from the PL360 device (if needed)

7.6.5.1 Get Events Information (Buffer 0)

Figure 7-15. PRIME Events Information SPI Array

It is similar to the flow described in section , but changing the firmware descriptors for7.6.2.1 Get Events Information

the ones applicable to the PRIME PL360 firmware.

7.6.5.2 Get Confirmation Data (Buffer 0)

Figure 7-16. PRIME Confirmation Data SPI Array

It is similar to the flow described in section , but changing the firmware descriptors for7.6.2.2 Get Confirmation Data

the ones applicable to the PRIME PL360 firmware.

PL360

SPI Protocol

7.6.6 PRIME: Receive Message

Figure 7-17. PRIME Receive Message SPI Sequence

It is similar to the flow described in section , but changing the firmware descriptors for the7.6.3 G3: Receive Message

ones applicable to the PRIME PL360 firmware.

In this case, two events are read simultaneously, andATPL360_RX_DATA_IND_FLAG_MASK

ATPL360_RX_QPAR_IND_FLAG_MASK, so there are two consecutive SPI transactions in order to get data and

parameters information from the PL360 device.

7.6.6.1 Get Events Information

Figure 7-18. PRIME Get Events SPI Array

It is similar to the flow described in section , but changing the firmware7.6.3.1 Get Events Information and Data

descriptors for the ones applicable to the PRIME PL360 firmware.

7.6.6.2 Get Data Information

Figure 7-19. PRIME Get Data SPI Array

It is similar to the flow described in section , but changing the firmware7.6.3.1 Get Events Information and Data

descriptors for the ones applicable to the PRIME PL360 firmware.

PL360

SPI Protocol

7.6.6.3 Get Parameters Information

Figure 7-20. PRIME Get Parameters SPI Array

It is similar to the flow described in section , but changing the7.6.3.2 Get Events Information and Parameters

firmware descriptors for the ones applicable to the PRIME PL360 firmware.

7.6.7 Read Register Information

It is possible to get internal information from the PL360 device.

Figure 7-21. Read Register Information SPI Sequence

In the figure above, three SPI transactions can be seen:

• Request register information

• Get events information

• Get register value

7.6.7.1 Request Register Information

Figure 7-22. Request Register Information Array

• Master (MOSI):

– Send ID memory region(16 bits): 0x0006 ( ) [example with G3]ATPL360_REG_INFO_ID

– Send SPI command (1 bit): 1 (write command)

– Send SPI params length (15 bits) (in blocks of 16-bits): 0x0004 (8 bytes)

PL360

SPI Protocol

– Send register identification (4 bytes). See section or 12.2.5 PIB Objects Specification and Access (G3)

12.3.4 PIB Objects Specification and Access (PRIME)

– Send length of the register to read (2 bytes)

• Slave (MISO): PL360 device responds with firmware header (0x1122)

7.6.7.2 Get Events Information

Figure 7-23. Get Events Information Array

• Master (MOSI):

– Send ID memory region(16 bits): 0x0000 ( )ATPL360_STATUS_INFO_ID

– Send SPI command (1 bit): 0 (read command)

– Send SPI data length (15 bits) (in blocks of 16 bits): 0x04 (8 bytes)

• Slave (MISO):

– Send Firmware Header (16 bits): 0x1122

– Send Firmware Events (16 bits): 0x0008 ( )ATPL360_REG_RSP_MASK

– Send Firmware Timer reference (32 bits)

– Send Firmware Events Information (32 bits)

• First 16 bits: Length of the register value to read in next transaction. (D_REG)

• Second 16 bits: Not valid

7.6.7.3 Get Register Value

Figure 7-24. Get Register Value SPI Array

• Master (MOSI):

– Send ID memory region(16 bits): 0x0006 ( )ATPL360_REG_INFO_ID

– Send SPI command (1 bit): 0 (read command)

– Send SPI data length (15 bits) (in blocks of 16 bits): Variable length depending on register to read (D_REG)

• Slave (MISO):

– Send Firmware Header (16 bits): 0x1122

– Send Firmware Events (16 bits): 0x008 ( )ATPL360_REG_RSP_MASK

PL360

SPI Protocol

– Send Firmware register value. See section or 12.2.5 PIB Objects Specification and Access (G3) 12.3.4

PIB Objects Specification and Access (PRIME)

PL360

SPI Protocol

8. Example Applications

CAUTION

Please note that all the provided application examples have been configured to work on Microchip

evaluation boards. When using other hardware, the firmware project must define a Board Support

Package (BSP) customized for that hardware.

Along with the PLC communication stacks, specific application examples are provided in order to show how to

integrate the PL360 Host Controller.

In addition, PHY examples using only the PL360 Host Controller are provided in order to evaluate some low level

parameters and to be used together with a Microchip PLC tool for demonstration purposes.

In case of a G3 stack, applications are provided for CENELEC A, CENELEC B and FCC bands (project folders with

suffixes “_cen_a”, “_cen_b” and “_fcc” in each example). Setting the appropriate band in each project is made by

means of , as explained in section .conf_atpl360.h file 5.1 Configure Application

In case of a PRIME stack, applications are provided for CENELEC A and FCC bands (the same project folder is used

in both bands depending on PRIME configured channel. See 12.3.4.30 ATPL360_REG_CHANNEL_CFG (0x4016)).

8.1 PHY Examples

8.1.1 PHY Tester

The PHY Tester is an application example that demonstrates the complete performance of the Microchip PLC PHY

layer. This example requires a board and a PC tool. In addition, the Microchip PLC PHY Tester PC tool (available in

the Microchip website) has to be installed on the user’s host PC to interface with the boards.

The Microchip PLC PHY Tester PC tool configures the devices and performs communication tests.

This example uses the serial interface configured through UART0 at 230400bps.

8.1.2 PHY Sniffer

The PHY Sniffer is an application example to monitor data traffic in the PLC network and then send it via serial

communications to a PC tool and the Microchip PLC Sniffer PC tool (available in the Microchip website), which has to

be installed in the user’s host PC to interface with the board. This example requires only one board and (obviously) a

PLC network to be monitored.

This example uses the serial interface configured through UART0 at 230400bps.

8.1.3 TX Console

Due to PC timing, the Microchip PLC PHY Tester PC tool may present limitations in those applications or tests that

require a very short time interval between consecutive frame transmissions.

The PHY TX Console is an application example that demonstrates the complete performance of the Microchip PLC

PHY Layer avoiding the limitations of timing in the PC host. This way, users can perform more specific PHY tests

(e.g., short time interval between consecutive frames).

This application offers an interface to the user by means of a command console. In this console, users can configure

several transmission parameters such as modulation, frame data length and time interval between frames. In the

console it is also possible to test transmission/reception processes.

This example uses the serial interface configured through UART0 at 921600bps.

8.1.4 PHY Getting Started

This example is intended to show the minimal application to be developed over the PL360 PHY layer (G3 or PRIME).

Two modes of operation can be configured: or . The former will startCONF_APP_TX_MODE CONF_APP_RX_MODE

sending PHY frames without user intervention, while the latter will wait for frame receptions from the PHY layer. Both

modes print messages on a Serial Console to inform the user about frames transmitted and received, respectively.

PL360

Example Applications

Thus, depending on G3 or PRIME PHY layer, the following configuration is allowed:

• G3 ( file):conf_project.h

– : or CONF_APP_MODE CONF_APP_TX_MODE CONF_APP_RX_MODE

– ( ): Time delay between transmitted frames in microsecondsTX_DELAY_US phy_getting_started.c

• PRIME ( file):conf_app_example.h

– : or CONF_APP_MODE CONF_APP_TX_MODE CONF_APP_RX_MODE

– : PRIME channel for transmission and reception (see CONF_PRIME_CHANNEL 12.3.4.30

ATPL360_REG_CHANNEL_CFG (0x4016))

– : Time delay between transmitted frames in microsecondsCONF_TX_DELAY_US

PL360

Example Applications

9. Supported Platforms

This chapter describes which hardware platforms are currently supported with the PL360 Host Controller source

code. Usually, a platform usually is comprised of three major components:

• An MCU

• A transceiver chip

• A specific board or even several boards that contain the MCU or the transceiver chip

9.1 Supported MCU Families

Currently the supported families are SAM4C, SAME70 and SAMG55 platforms.

The dedicated code for each device of the family can be found in the corresponding sub-directories of the FW

package.

9.2 Supported Transceivers

Currently the supported transceivers are PL360.

9.3 Supported Boards

The boards currently supported are:

• PL360MB

• PL360G55CB

• PL360G55CF

• PL360BN

• SAME70 Xplained board connected to PL360MB board through Xplained Port

PL360

Supported Platforms

10. Abbreviations

AGC Automatic Gain Control

API Application Programming Interface

APP Application

ASF Advanced Software Framework

BER Bit Error Rate

CINR Carrier to Interference + Noise Ratio

DT Delimiter Type

EK Evaluation Kit

EVM Error Vector Magnitude

FCH Frame Control Header

FFT Fast Fourier Transform

FW Firmware

GPIO General Purpose Input/Output

HAL Hardware Abstraction Layer

IP Internal Peripheral

IFFT Inverse Fast Fourier Transform

IRQ Interrupt Request

LQI Link Quality Indicator

MCU Microcontroller Unit

MISO Master Input Salve Output

MOSI Master Output Salve Input

PAL Platform Abstraction Layer

PDU Protocol Data Unit

PGA Programmable-Gain Amplifier

PHY Physical Layer

PIB PLC Information Base

PLC Power Line Communication

SPI Serial Peripheral Interface

RD Read

RRC Root Raised Cosine

RS Reed Solomon

RSSI Received Signal Strength Indication

RX Reception

SNR Signal to Noise Ratio

TX Transmission

WR Write

PL360

Abbreviations

11. References

•Microchip Smart Energy

•Microchip Power Line Communications

•Microchip Design Support

•G3-PLC Alliance

•PRIME Alliance

• PL360-EK User Guide, 2018

• PL360G55CB- EK, 2019

• PL360G55CF- EK, 2019

• PL360 Datasheet, 2019

• PL360 Physical Calibration, 2019

• PL360 Security Features, 2018

•Advanced Software Framework

•Atmel Studio

•Documents for supported families and boards

PL360

References

12. PL360 Host Controller API

This chapter describes all the data structures and functions which are part of the PL360 Host Controller component.

12.1 Common PHY API

12.1.1 Initialization Function

The PL360 Host Controller must always be initialized when the system starts the execution. The following function

initializes the hardware parameters and configures the controller descriptor:

void atpl360_init(atpl360_descriptor_t *const descr, atpl360_hal_wrapper_t *px_hal_wrapper);

Parameters:

descr Pointer to component descriptor

px_hal_wrapper Pointer to HAL wrapper structure

This function performs the following actions:

• Sets the handlers for the PLC interruption

• Initializes the PLC SPI service

• And, if necessary, initializes add-on interfaces

The component descriptor offers the customer a set of functions to get access to the PL360 device. It is defined as a

structure of function pointers as follows:

typedef struct atpl360_descriptor {

pf_set_callbacks_t set_callbacks;

pf_send_data_t send_data;

pf_mng_get_cfg_t get_config;

pf_mng_set_cfg_t set_config;

pf_addons_event_t send_addons_cmd;

} atpl360_descriptor_t;

where:

• function is used to set upper layers’ functions to be executed when a PL360 Host Controllerset_callbacks

event has been reported. For further information, please refer to the chapter12.1.2 Setting Callbacks

• function provides a mechanism to send a PLC message through the PL360 device. For further G3send_data

information, please refer to the G3 12.2.2 PHY-DATA.request chapter. For further PRIME information, please

refer to the PRIME 12.3.1 PHY-DATA.request chapter

• function provides a read access method to get PL360 internal data. For further information, pleaseget_config

refer to the 12.1.11.2 Get Configuration chapter

• function provides a write access method to set PL360 internal data. For further information, pleaseset_config

refer to the 12.1.11.1 Set Configuration chapter

• function provides a mechanism to connect PLC Microchip tools to the PL360 device. Allsend_addons_cmd

information received from these tools should be redirected to this function in order to pass the information to the

PL360 Host Controller

Function pointers are defined as follows:

typedef void (*pf_set_callbacks_t)(atpl360_dev_callbacks_t *dev_cb);

typedef uint8_t (*pf_send_data_t)(tx_msg_t *px_msg);

typedef bool (*pf_mng_get_cfg_t)(uint16_t us_param_id, void *px_value, uint8_t uc_len, bool

b_sync);

typedef bool (*pf_mng_set_cfg_t)(uint16_t us_param_id, void *px_value, uint16_t us_len);

typedef void (*pf_addons_event_t)(uint8_t *px_msg, uint16_t us_len);

PL360

PL360 Host Controller API

Tip: SPI critical error means that the PL360 firmware cannot be loaded into the PL360 device. A possible

reason for this would be that the SPI is not working properly.

12.1.3 Enable Function

Once the host descriptor has been initialized and the application callbacks have been set, the PL360 Host Controller

must be enabled using the following function:

atpl360_res_t atpl360_enable(uint32_t ul_binary_address, uint32_t ul_binary_len);

Parameters:

ul_binary_address Memory address where the PL360 firmware binary file is located

ul_binary_len Size of the PL360 firmware binary file

This function performs the following actions:

• Disable PLC interrupt

• Transfer firmware binary file to the PL360 device

• Check firmware integrity

• Enable PLC interrupt

12.1.4 Disable Function

The PL360 Host Controller provides a mechanism to disable the notification of PL360 Host Controller events to the

application in order to avoid interrupting the normal flow of the customer application. This mechanism implies that the

PLC activity is stopped in the PL360 device.

void atpl360_disable(void);

12.1.5 Event Handler Function

This function provides a mechanism to notify the PL360 Host Controller events to the customer application using the

previously configured callbacks.

The following function must be called every program cycle or at least once when the host MCU application receives

an interrupt from the PL360 embedded firmware:

void atpl360_handle_events(void);

First, this function checks all PLC events:

• PHY parameters and configuration

• End of transmission of PLC message

• End of reception of PLC message

• Exceptions

And then, it triggers the corresponding PL360 Host Controller callbacks.

12.1.6 Set Sleep Mode Function

This function provides a mechanism to control the Sleep mode capability in order to minimize the power consumption

of the PL360 device.

void atpl360_set_sleep(bool sleep);

Parameters:

sleep True to enable Sleep mode, False to disable.

PL360

PL360 Host Controller API

Please note that while being in Sleep mode, the core and peripherals of PL360 are reset; therefore, all the other PLC

capabilities are not available.

12.1.7 Get Sleep Mode Function

This function provides a mechanism to query the status of the Sleep mode.

bool atpl360_get_sleep(void);

This function returns True if Sleep mode is enabled, False when it is disabled.

12.1.8 Set Debug Mode Function

This function provides a mechanism to enable or disable the Debug mode capability in order to access to the internal

memory of PL360 device.

void atpl360_set_debug(bool debug);

Parameters:

debug True to enable Debug mode, False to disable.

Please note that when in Debug mode, the core and peripherals of PL360 are reset; therefore, all the other PLC

capabilities are not available.

12.1.9 Get Debug Mode Function

This function provides a mechanism to query the status of the Debug mode.

bool atpl360_get_debug(void);

This function returns True if Debug mode is enabled, False when it is disabled.

12.1.10 Read Debug Function

Once Debug mode has been enabled, the internal memory of PL360 device can be read by the host controller using

the following function:

uint16_t atpl360_debug_read(uint32_t ul_address, uint8_t *puc_data, uint16_t us_len);

Parameters:

ul_address Address of the internal memory of PL360 to read

*puc_data Pointer of data buffer to write with debug data

us_len Length of the debug data to read

Please note that the maximum length to get debug data per transaction is limited to 512 bytes.

For further information about the memory map of the PL360 binary file in use, please contact Microchip Smart Energy

Support team.

12.1.11 Management Primitives

12.1.11.1 Set Configuration

This is done by means of a specific function provided by the controller descriptor:

typedef bool (*pf_mng_set_cfg_t)(uint16_t us_param_id, void *px_value, uint8_t uc_len);

Parameters:

us_param_id PIB ID (see and 12.3.4 PIB Objects Specification and Access (PRIME) 12.2.5 PIB

Objects Specification and Access (G3))

*px_value Pointer to parameter value to set

PL360

PL360 Host Controller API

uc_len Length of parameter

The function returns 0 if the result is invalid, otherwise returns 1.

12.1.11.2 Get Configuration

This is done by means of a specific function provided by the controller descriptor:

typedef bool (*pf_mng_get_cfg_t)(uint16_t us_param_id, void *px_value, uint8_t uc_len, bool

b_sync);

Parameters:

us_param_id PIB ID (see and 12.3.4 PIB Objects Specification and Access (PRIME) 12.2.5 PIB

Objects Specification and Access (G3))

*px_value Pointer to parameter value to get

uc_len Length of parameter

b_sync Set synchronous (True) or asynchronous mode (False)

The function returns 0 if the result is invalid, otherwise returns 1.

12.2 G3 PHY API

12.2.1 Bandplan Selection

At compilation time, the G3-PLC bandplan must be defined (i.e.: CENELEC A, CENELEC B, FCC or ARIB) according

to user needs.

In there are four constant options for configuring the bandplan:general_defs.h

/* ! CENELEC A Band Plan (35 - 91 kHz) */

#define ATPL360_WB_CENELEC_A 1

/* ! FCC Band Plan (154 - 488 kHz) */

#define ATPL360_WB_FCC 2

/* ! ARIB Band Plan (154 - 404 kHz) */

#define ATPL360_WB_ARIB 3

/* ! CENELEC-B Band Plan (98 - 122 kHz) */

#define ATPL360_WB_CENELEC_B 4

The constant has to be set, in file , to the value of one of the constant options ofATPL360_WB conf_atpl360.h

general_defs.h so that the PHY layer is correctly configured.

12.2.2 PHY-DATA.request

This function sends a frame using the PHY layer. This is done by means of a specific function provided by the

controller descriptor:

typedef uint8_t (* )(tx_msg_t *px_msg);pf_send_data_t

The input parameter structure is the following:

typedef struct {tx_msg

uint8_t *puc_data_buf;

uint32_t ul_tx_time;

uint16_t us_data_len;

uint8_t puc_preemphasis[NUM_SUBBANDS_MAX];

uint8_t puc_tone_map[TONE_MAP_SIZE_MAX];

uint8_t uc_tx_mode;

uint8_t uc_tx_power;

mod_types uc_mod_type;enum

mod_schemes uc_mod_scheme;enum

uint8_t uc_pdc;

uint8_t uc_2_rs_blocks;

PL360

PL360 Host Controller API

delimiter_types uc_delimiter_type;enum

} ;tx_msg_t

Fields of the structure:

*puc_data_buf Pointer to data buffer

ul_tx_time Instant when transmission has to start referred to 1μs PHY counter (absolute or relative

value, depending on uc_tx_mode)

us_data_len Length of the data buffer in bytes

puc_preemphasis Preemphasis for transmission. Same as but for each subband (Relateduc_tx_power

constants explained below)

puc_tone_map Tone map to use in transmission (Related constants explained below)

uc_tx_mode Transmission mode (forced, delayed, ...) (Related constants explained below)

uc_tx_power Power to transmit [0 = Full gain, 1 = (Full gain - 3dB), 2 = (Full gain - 6dB) and so on].

Maximum value is 15 (Full gain - 45dBs). Value 0xFF is a special case used to apply zero-

gain (transmit all zeros)

uc_mod_type Modulation type (Related constants explained below)

uc_mod_scheme Modulation scheme (Related constants explained below)

uc_pdc Phase detector counter. Not used; calculated and filled internally by PHY layer

uc_2_rs_blocks Flag to indicate whether 2 Reed-Solomon blocks have to be used (only used in FCC

bandplan)

uc_delimiter_type DT field to be used in header (Related constants explained below)

Related constants affecting above parameters:

/* ! \name TX Mode Bit Mask */

/* ! TX Mode: Forced transmission */

#define TX_MODE_FORCED (1 << 0)

/* ! TX Mode: Absolute transmission */

#define TX_MODE_ABSOLUTE (0 << 1)

/* ! TX Mode: Delayed transmission */

#define TX_MODE_RELATIVE (1 << 1)

/* ! TX Mode: SYNCP Continuous transmission */

#define TX_MODE_SYNCP_CONTINUOUS (1 << 2)

/* ! TX Mode: Symbols Continuous transmission */

#define TX_MODE_SYMBOLS_CONTINUOUS (1 << 3)

/* ! TX Mode: Cancel transmission */

#define TX_MODE_CANCEL (1 << 4)

/* Modulation types */

enum mod_types {

MOD_TYPE_BPSK = 0,

MOD_TYPE_QPSK = 1,

MOD_TYPE_8PSK = 2,

MOD_TYPE_QAM = 3,

MOD_TYPE_BPSK_ROBO = 4

};

/* Modulation schemes */

enum mod_schemes {

MOD_SCHEME_DIFFERENTIAL = 0,

MOD_SCHEME_COHERENT = 1

};

/* Frame Delimiter Types */

enum delimiter_types {

DT_SOF_NO_RESP = 0, /* Data frame requiring ACK */

DT_SOF_RESP = 1, /* Data frame Not requiring ACK */

DT_ACK = 2, /* Positive ACK */

DT_NACK = 3 /* Negative ACK */

};

PL360

PL360 Host Controller API

/* ! Subbands for Cenelec-A bandplan */

#define NUM_SUBBANDS_CENELEC_A 6

/* ! Subbands for FCC bandplan */

#define NUM_SUBBANDS_FCC 24

/* ! Subbands for ARIB bandplan */

#define NUM_SUBBANDS_ARIB 18

/* ! Subbands for Cenelec-B bandplan */

#define NUM_SUBBANDS_CENELEC_B 4

/* ! Tone Map size for Cenelec bandplan */

#define TONE_MAP_SIZE_CENELEC 1

/* ! Tone Map size for FCC and ARIB bandplans */

#define TONE_MAP_SIZE_FCC_ARIB 3

/* ! Maximum number of tone map */

#define TONE_MAP_SIZE_MAX TONE_MAP_SIZE_FCC_ARIB

/* ! Maximum number of subbands */

#define NUM_SUBBANDS_MAX NUM_SUBBANDS_FCC

The function returns one of the following transmission result values:

/* TX Result values */

enum tx_result_values {

TX_RESULT_PROCESS = 0, /* Already in process */

TX_RESULT_INV_LENGTH = 2, /* Invalid length error */

TX_RESULT_NO_TX = 255, /* No transmission ongoing */

};

12.2.3 PHY-DATA.confirm

This data confirm callback executes the function set by the upper layer at the initialization of the PL360 Host

Controller (see ). It is called when a transmission request has been processed. The format12.1.2 Setting Callbacks

of the function is:

typedef void (* )(tx_cfm_t *px_msg_cfm);pf_data_confirm_t

The result is reported in the following structure:

typedef struct {tx_cfm

uint32_t ul_rms_calc;

uint32_t ul_tx_time;

enum tx_result_values uc_tx_result;

} ;tx_cfm_t

Fields of the structure:

ul_rms_calc RMS_CALC value after transmission. Allows estimation of Tx power injected

ul_tx_time Instant when frame transmission ended, referred to 1μs PHY counter

uc_tx_result Tx result (Related constants explained below)

Possible values of the field "uc_tx_result":

/* TX Result values */

enum tx_result_values {

TX_RESULT_SUCCESS = 1, /* End successfully */

TX_RESULT_INV_LENGTH = 2, /* Invalid length error */

TX_RESULT_BUSY_CH = 3, /* Busy channel error */

TX_RESULT_BUSY_TX = 4, /* Busy in transmission error */

TX_RESULT_BUSY_RX = 5, /* Busy in reception error */

TX_RESULT_INV_SCHEME = 6, /* Invalid modulation scheme error */

TX_RESULT_TIMEOUT = 7, /* Timeout error */

TX_RESULT_INV_TONEMAP = 8, /* Invalid tone map error */

TX_RESULT_INV_MODTYPE = 9, /* Invalid modulation type error */

TX_RESULT_INV_DT = 10, /* Invalid delimiter type */

TX_RESULT_NO_TX = 255, /* No transmission ongoing */

};

PL360

PL360 Host Controller API

12.2.4 PHY-DATA.indication

This data indication callback executes the function set by the upper layer at the initialization of the PL360 Host

Controller (see ). It is called when a frame has been received. The format of the function is:12.1.2 Setting Callbacks

typedef void (* )(rx_msg_t *px_msg);pf_data_indication_t

The information is reported in the following structure:

typedef struct {rx_msg

uint32_t ul_rx_time;

uint32_t ul_frame_duration;

uint16_t us_rssi;

uint16_t us_data_len;

uint8_t uc_zct_diff;

uint8_t uc_rs_corrected_errors;

enum mod_types uc_mod_type;

enum mod_schemes uc_mod_scheme;

uint32_t ul_agc_factor;

uint16_t us_agc_fine;

int16_t ss_agc_offset_meas;

uint8_t uc_agc_active;

uint8_t uc_agc_pga_value;

int16_t ss_snr_fch;

int16_t ss_snr_pay

uint16_t us_payload_corrupted_carriers;

uint16_t us_payload_noised_symbols;

uint8_t uc_payload_snr_worst_carrier;

uint8_t uc_payload_snr_worst_symbol;

uint8_t uc_payload_snr_impulsive;

uint8_t uc_payload_snr_band;

uint8_t uc_payload_snr_background;

uint8_t uc_lqi;

enum delimiter_types uc_delimiter_type;

uint8_t uc_crc_ok;

uint8_t puc_tone_map[TONE_MAP_SIZE_MAX];

uint8_t puc_carrier_snr[PROTOCOL_CARRIERS_MAX];

uint8_t *puc_data_buf;

} ;rx_msg_t

Fields of the structure:

ul_rx_time Instant when frame was received (end of frame), referred to 1μs PHY counter

ul_frame_duration Frame duration in μs (Preamble + FCH + Payload)

us_rssi Reception RSSI in dBμV

us_data_len Length of received frame in bytes

uc_zct_diff Phase difference with transmitting node

uc_rs_corrected_errors Errors corrected by Reed-Solomon

uc_mod_type Modulation type of the received frame (Related constants defined in section

12.2.2 PHY-DATA.request)

uc_mod_scheme Modulation scheme of the received frame (Related constants defined in

section 12.2.2 PHY-DATA.request)

ul_agc_factor Global amplifying factor of the main branch (21 bits)

us_agc_fine Factor that multiplies the digital input signal (13 bits)

ss_agc_offset_meas DC offset after the ADC that will be removed in case the DC Blocker is

enabled (10 bits)

uc_agc_active Flag to indicate if AGC is active

uc_agc_pga_value Gain value applied to the PGA (3 bits)

ss_snr_fch SNR of the header in quarters of dBs

PL360

PL360 Host Controller API

ss_snr_pay SNR of the payload in quarters of dBs

us_payload_corrupted_carriers Number of corrupted carriers in payload due to narrow/broad-band noise

us_payload_noised_symbols Number of corrupted symbols in payload due to impulsive noise

uc_payload_snr_worst_carrier SNR for the worst carrier of the payload in quarters of dBs

uc_payload_snr_worst_symbol SNR for the worst symbol of the payload in quarters of dBs

uc_payload_snr_impulsive SNR of corrupted symbols in payload due to impulsive noise in quarters of dBs

uc_payload_snr_band SNR of corrupted carriers in payload due to narrow/broad-band noise in

quarters of dBs

uc_payload_snr_background SNR without taking into account corrupted carriers and symbols in quarters of

dBs

uc_lqi Link Quality Indicator. SNR in quarters of dBs with offset of 10 dB (value 0

means -10 dB)

uc_delimiter_type DT field coming in header. Related constants defined in section 12.2.2 PHY-

DATA.request

uc_crc_ok CRC verification result (1: OK; 0: BAD; 0xFE: unexpected error; 0xFF: CRC

capability disabled). See 12.2.5.39

ATPL360_REG_CRC_TX_RX_CAPABILITY (0x401C)

puc_tone_map Tone Map in received frame (Related constants defined in section 12.2.2

PHY-DATA.request)

puc_carrier_snr SNR for each carrier in dBs with offset of 10dB (value 0 means -10dB)

(Related constants explained below)

puc_data_buf Pointer to data buffer containing received frame. The received frame includes

padding (if needed). CRC is included if the CRC capability in the PL360 is

disabled (see 12.2.5.39 ATPL360_REG_CRC_TX_RX_CAPABILITY

(0x401C))

Related constants affecting above parameters:

/* ! Carriers for Cenelec-A bandplan */

#define NUM_CARRIERS_CENELEC_A 36

/* ! Carriers for FCC bandplan */

#define NUM_CARRIERS_FCC 72

/* ! Carriers for ARIB bandplan */

#define NUM_CARRIERS_ARIB 54

/* ! Carriers for Cenelec-B bandplan */

#define NUM_CARRIERS_CENELEC_B 16

/* ! Maximum number of protocol carriers */

#define PROTOCOL_CARRIERS_MAX NUM_CARRIERS_FCC

12.2.5 PIB Objects Specification and Access (G3)

The default endianness of all PIBs is little endian, otherwise it is explicitly stated.

12.2.5.1 ATPL360_HOST_DESCRIPTION_ID (0x0100)

PL360 Host Controller description.

Access: Read-only.

Value Range: 10 bytes.

Default Value: “SAM4CMS16C” (for SAM4CMS16_0 core) or “SAM4C16C” (for SAM4C16_0 core).

12.2.5.2 ATPL360_HOST_MODEL_ID (0x010A)

Model identification number of the PL360 Host Controller.

PL360

PL360 Host Controller API

Access: Read-only.

Value Range: 2 bytes.

Default Value: 0x0002.

12.2.5.3 ATPL360_HOST_PHY_ID (0x010C)

Physical identification number of the PL360 Host Controller. It is composed of ATPL360_HOST_VERSION_ID

(0x0112) + ATPL360_HOST_BAND_ID (0x0116).

Access: Read-only.

Value Range: 4 bytes.

Default Value: 0x36010201 for CENELEC A band. 0x36010202 for FCC band. 0x36010203 for ARIB band.

0x36010204 for CENELEC B band.

12.2.5.4 ATPL360_HOST_PRODUCT_ID (0x0110)

Product identification number of the PL360 Host Controller.

Access: Read-only.

Value Range: 2 bytes.

Default Value: 0x3601.

12.2.5.5 ATPL360_HOST_VERSION_ID (0x0112)

Version number of the PL360 Host Controller.

Access: Read-only.

Value Range: 4 bytes.

Default Value: 0x36010200.

12.2.5.6 ATPL360_HOST_BAND_ID (0x0116)

Workband identification number of the PL360 Host Controller.

Access: Read-only.

Value Range: 1 byte.

Default Value: 1: CENELEC A, 2: FCC, 3: ARIB, 4: CENELEC B.

12.2.5.7 ATPL360_TIME_REF (0x0200)

Time reference in microseconds from the last reset of the PL360 device.

Access: Read-only.

Value Range: 4 bytes.

Default Value: Not applicable.

12.2.5.8 ATPL360_SLEEP_MODE_ID

Enable/Disable the Sleep mode of the PL360 device. This is useful to minimize the power consumption in conditions

of prolonged inactivity.

Access: Read-write.

Value Range: 1 byte [0: Disabled, 1: Enabled].

Default value: 0.

12.2.5.9 ATPL360_DEBUG_SET_ID

Enable/Disable the Debug mode of the PL360 device. This is useful to get debug data from the PL360 device. For

further information, please contact Microchip Smart Energy Support team.

Access: Read-write.

Value Range: 7 bytes

PL360

PL360 Host Controller API

• byte 0: Enable/Disable. Write 1 to enable Debug mode, 0 to disable Debug mode. In case of disabling Debug

mode, address and length values are not taken into account.

• bytes 1-4: Address of the data to read from PL360 internal memory.

• bytes 5-6: Length of the data to read. It is internally limited to 255 bytes.

Default value: Enable/Disable: 0, Address: 0, Length: 0.

12.2.5.10 ATPL360_DEBUG_READ_ID

Read debug data from PL360 device.

Access: Read only.

Value Range: 255 bytes.

Default value: 0.

12.2.5.11 ATPL360_REG_PRODID (0x4000)

Product Identifier of firmware embedded in PL360 device.

Access: Read-only.

Value Range: 8 bytes.

Default Value: “ATPL360”.

12.2.5.12 ATPL360_REG_MODEL (0x4001)

Model Identifier of firmware embedded in PL360 device.

Access: Read-only.

Value Range: 2 bytes.

Default Value: 0x3601.

12.2.5.13 ATPL360_REG_VERSION_STR (0x4002)

Version number of PL360 embedded firmware in string format. The format is "AA.BB.CC.DD", where:

• AA: Corresponds to device model ("36")

• BB: Corresponds to G3 band ["01": CEN A, "02": FCC, "03": ARIB, "04": CEN B]

• CC: Major version number

• DD: Minor version number

Access: Read-only.

Value Range: 11 bytes.

Example Value: “36.01.04.15”.

12.2.5.14 ATPL360_REG_VERSION_NUM (0x4003)

Version number of PL360 embedded firmware in hexadecimal format. The format is 0xAABBCCDD, where:

• AA: Corresponds to device model (0x36)

• BB: Corresponds to G3 band [0x01: CEN A, 0x02: FCC, 0x03: ARIB, 0x04: CEN B]

• CC: Major version number

• DD: Minor version number

Access: Read-only.

Value Range: 4 bytes.

Example Value: 0x36010415.

12.2.5.15 ATPL360_REG_TONE_MASK (0x4004)

Tone mask for static notching.

Access: Read-write.

Value Range: Depends on the number of carriers which are specified in the G3 band (one byte per carrier).

Default Value: 0.

PL360

PL360 Host Controller API

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.23 ATPL360_REG_TX_BAD_FORMAT (0x400C)

Number of times when the PL360 device received new data to transmit (send_data) and the transmission parameters

are not valid.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.24 ATPL360_REG_TX_TIMEOUT (0x400D)

Number of times when the PL360 device received new data to transmit (send_data) and it cannot transmit data in the

specified time provided by the transmission parameters.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.25 ATPL360_REG_RX_TOTAL (0x400E)

Number of successfully received PDUs.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.26 ATPL360_REG_RX_TOTAL_BYTES (0x400F)

Number of bytes in successfully received PDUs.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.27 ATPL360_REG_RX_RS_ERRORS (0x4010)

Number of corrected errors by RS block in received PDUs.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.28 ATPL360_REG_RX_EXCEPTIONS (0x4011)

Number of time-out errors in received PDUs.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.29 ATPL360_REG_RX_BAD_LEN (0x4012)

Number of errors in FCH length in received PDUs.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

PL360

PL360 Host Controller API

12.2.5.30 ATPL360_REG_RX_BAD_CRC_FCH (0x4013)

Number of errors in FCH CRC in received PDUs.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.31 ATPL360_REG_RX_FALSE_POSITIVE (0x4014)

Number of errors in PDU synchronization phase.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.32 ATPL360_REG_RX_BAD_FORMAT (0x4015)

Number of errors in modulation type field included in FCH of received PDUs.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.33 ATPL360_REG_ENABLE_AUTO_NOISE_CAPTURE (0x4016)

Flag to indicate if automatic noise analyzer is enabled in the reception chain. If Auto-mode is enabled, notch filter

parameters (12.2.5.36 ATPL360_REG_RRC_NOTCH_ACTIVE (0x4019) 12.2.5.37 ,

ATPL360_REG_RRC_NOTCH_INDEX (0x401A)) cannot be modified by the user.

See 12.2.5.34 ATPL360_REG_TIME_BETWEEN_NOISE_CAPTURES (0x4017) 12.2.5.62 ,

ATPL360_REG_RRC_NOTCH_THR_ON (0x4034) 12.2.5.63 ATPL360_REG_RRC_NOTCH_THR_OFF (0x4035),

to configure parameters related to the Auto-mode.

Access: Read-write.

Value Range: 1 byte [0: Disabled (Manual-mode), 1: Enabled (Auto-mode)].

Default Value: 1.

12.2.5.34 ATPL360_REG_TIME_BETWEEN_NOISE_CAPTURES (0x4017)

Time in milliseconds between noise captures.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 1000 (1 second).

CAUTION

It is recommended to keep the default value of this parameter. If reduced, the power consumption could

increase. Default value is optimum for power consumption and performance of noise detection.

12.2.5.35 ATPL360_REG_DELAY_NOISE_CAPTURE_AFTER_RX (0x4018)

Time in microseconds to start a new noise capture after PDU reception/transmission.

Access: Read-write.

Value Range: 4 bytes.

Default Value: 3000 (3 milliseconds).

CAUTION

It is recommended to keep the default value of this parameter. If reduced, there could be unexpected

results.

PL360

PL360 Host Controller API

12.2.5.36 ATPL360_REG_RRC_NOTCH_ACTIVE (0x4019)

Number of notched frequencies with RRC notch filter. For CENELEC-A, FCC and ARIB bands, up to 5 notched

frequencies are allowed. For CENELEC-B band, only one notched frequency is allowed.

Access: Depends on 12.2.5.33 ATPL360_REG_ENABLE_AUTO_NOISE_CAPTURE (0x4016) value:

• 1 (Automatic noise analyzer enabled): Read-only

• 0 (Automatic noise analyzer disabled): Read-write

Value Range: 1 byte [In CENELEC-A, FCC and ARIB bands, 0-5; In CENELEC-B, 0-1].

Default Value: 0 (No notched frequencies).

12.2.5.37 ATPL360_REG_RRC_NOTCH_INDEX (0x401A)

Array of RRC notch filter index values in format unsigned Q7.8. The 7 integer bits indicate the carrier index (0 –127)

for which the notch filter is applied. The 8 decimal bits allow to apply the notch filter to a frequency which is between

two consecutive carriers.

To convert the notch index to frequency (in Hz), the following formula is applied:

F = INDEX * Fs / 65536 , where Fs is the sampling rate in Hz:

• CENELEC-A, CENELEC-B bands: Fs = 400000 Hz

• FCC, ARIB bands: Fs = 1200000 Hz

For example:

• CENELEC-A, INDEX = 8192 (0x2000): F = 8192 * 400000 / 65536 = 50000 Hz

• FCC, INDEX = 20544 (0x5040): F = 20544 * 1200000 / 65536 = 376172 Hz

Access: Depends on 12.2.5.33 ATPL360_REG_ENABLE_AUTO_NOISE_CAPTURE (0x4016) value:

• 1 (Auto-mode): Read-only

• 0 (Manual-mode): Read-write

Value Range: 10 bytes (CENELEC-A, FCC, ARIB bands) or 2 bytes (CENELEC-B band). Each group of 2 bytes

corresponds to one notched frequency (Integer part: 0 - 127, Decimal part: 0-255). Number of valid values depends

on 12.2.5.36 ATPL360_REG_RRC_NOTCH_ACTIVE (0x4019).

Default Value: 0.

12.2.5.38 ATPL360_REG_NOISE_PEAK_POWER (0x401B)

Noise peak power. Power of the carrier with more noise power in dBuV. The value is updated only if Auto-mode is

enabled (see 12.2.5.33 ATPL360_REG_ENABLE_AUTO_NOISE_CAPTURE (0x4016)) or noise capture is triggered

through 12.2.5.47 ATPL360_REG_RRC_NOTCH_AUTODETECT (0x4024).

Access: Read-only.

Value Range: 2 bytes.

Default Value: Not applicable.

12.2.5.39 ATPL360_REG_CRC_TX_RX_CAPABILITY (0x401C)

CRC computation capability. If it is enabled, 16-bit CRC is computed in transmitted and received PDUs. The CRC

format is the same that uses the G3-PLC stack, which is described in the IEEE 802.15.4 standard.

In transmission, when it is enabled, padding and CRC are added to the data automatically. In order to ensure that all

OFDM symbols are filled with data, a zero-padding is inserted after data payload (if it is needed). The padding

guarantees that the last 16 bits in reception correspond to the 16-bit CRC. The 16-bit CRC is added after the

padding.

In reception, when it is enabled, CRC is computed over the received PDU and it is compared to the last 16 bits of the

data (corresponding to the CRC of the message) to check the integrity of the message. These two bytes are not

included in the data buffer containing the received frame reported in 12.2.4 PHY-DATA.indication. The field

uc_crc_ok in 12.2.4 PHY-DATA.indication shows whether the CRC is correct or not.

Microchip G3-PLC stack implementation does not use this functionality, since CRC is computed in MAC layer instead

of PHY layer. The aim of this PIB is to make it easier for customers to build applications over PHY layer.

Access: Read-write.

PL360

PL360 Host Controller API

Value Range: 1 byte [0: Disabled, 1: Enabled].

Default Value: 0.

12.2.5.40 ATPL360_REG_RX_BAD_CRC_PAY (0x401D)

Number of errors in payload CRC in received PDUs. It is only updated if CRC capability is enabled (see 12.2.5.39

ATPL360_REG_CRC_TX_RX_CAPABILITY (0x401C)).

Access: Read-write.

Value Range: 4 bytes.

Default Value: 0.

12.2.5.41 ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)

Auto-Detect Impedance Mode. Transmission Automatic Gain Control (Tx AGC) and Automatic Transmission Mode

Control (ATMC) can be enabled/disabled. There are 3 available modes:

• OFF [0]: Tx AGC disabled. ATMC disabled.

• ON [1]: Tx AGC enabled. ATMC enabled.

• AGC [2]: Tx AGC enabled. ATMC disabled.

Access: Read-write.

Value Range: 1 byte [0: OFF, 1: ON, 2: AGC].

Default Value: 1.

12.2.5.42 ATPL360_REG_CFG_IMPEDANCE (0x401F)

Transmission Mode (HIGH, LOW, VERY_LOW). It is automatically updated if ATMC is enabled (see 12.2.5.41

ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)).

Access: Read-write.

Value Range: 1 byte [0: HIGH, 1: LOW, 2: VERY_LOW].

Default Value: 0.

12.2.5.43 ATPL360_REG_ZC_PERIOD (0x4020)

Estimated last Zero Cross period in microseconds.

Access: Read-only.

Value Range: 4 bytes.

Default Value: Not applicable.

12.2.5.44 ATPL360_REG_FCH_SYMBOLS (0x4021)

Number of symbols in Frame Control Header. Depends on the G3 band in use and Tone Mask (see 12.2.5.15

ATPL360_REG_TONE_MASK (0x4004)).

Access: Read-only.

Value Range: 1 byte [13-78 (CENELEC-A); 12-144 (FCC); 16-144 (ARIB); 30-78 (CENELEC-B)].

Default Value: 13 (CENELEC-A), 12 (FCC), 16 (ARIB), 30 (CENELEC-B).

12.2.5.45 ATPL360_REG_PAY_SYMBOLS_TX (0x4022)

Number of payload symbols in last transmitted message.

Access: Read-only.

Value Range: 2 bytes [1-252 (CENELEC-A, CENELEC-B); 1-511 (FCC, ARIB)].

Default Value: Not applicable.

12.2.5.46 ATPL360_REG_PAY_SYMBOLS_RX (0x4023)

Number of payload symbols in last received message.

Access: Read-only.

PL360

PL360 Host Controller API

Value Range: 2 bytes [1-252 (CENELEC-A, CENELEC-B); 1-511 (FCC, ARIB)].

Default Value: Not applicable.

12.2.5.47 ATPL360_REG_RRC_NOTCH_AUTODETECT (0x4024)

Trigger to start noise analysis. If noise analyzer Manual-mode is enabled (see 12.2.5.33

ATPL360_REG_ENABLE_AUTO_NOISE_CAPTURE (0x4016)), noise capture can be triggered through this PIB by

writing 1. Writing 0 has no effect. If noise analyzer Auto-mode is enabled, writing any value has no effect.

Access: Write-only.

Value Range: 1 byte. [0: No effect, 1: Trigger (Manual-mode)]

Default Value: 0.

12.2.5.48 ATPL360_REG_MAX_RMS_TABLE_HI (0x4025)

Target value of RMS_CALC in HIGH Tx Mode (see 12.2.5.42 ATPL360_REG_CFG_IMPEDANCE (0x401F)).

RMS_CALC will tend to this value by automatically adjusting the gain after every transmission (see 12.2.5.64

ATPL360_REG_CURRENT_GAIN (0x4036) 12.2.5.41 ). These parameters are only used if Tx AGC is enabled (see

ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)).

Access: Read-write.

Value Range: 32 bytes (see Table 12-1).

Default Value: See Table 12-2.

Table 12-1. Structure of ATPL360_REG_MAX_RMS_TABLE_HI

Byte 0-3 Byte 4-7 Byte 8-11 Byte 12-15 Byte 16-19 Byte 20-24 Byte 25-27 Byte 28-31

RMS_HI_0 RMS_HI_1 RMS_HI_2 RMS_HI_3 RMS_HI_4 RMS_HI_5 RMS_HI_6 RMS_HI_7

where:

• RMS_HI_x: Target value of RMS_CALC in mode of transmission HIGH for the attenuation level x (attenuation

levels in 3dB steps)

Table 12-2. Default values of ATPL360_REG_MAX_RMS_TABLE_HI

G3 BAND RMS_HI_0 RMS_HI_1 RMS_HI_2 RMS_HI_3 RMS_HI_4 RMS_HI_5 RMS_HI_6 RMS_HI_7

CEN-A 1991 1381 976 695 495 351 250 179

FCC 1355 960 681 485 345 246 177 129

ARIB 872 618 438 311 221 158 113 83

CEN-B 1133 793 559 396 280 199 143 108

12.2.5.49 ATPL360_REG_MAX_RMS_TABLE_VLO (0x4026)

Target value of RMS_CALC in VERY_LOW Tx Mode (see 12.2.5.42 ATPL360_REG_CFG_IMPEDANCE (0x401F)).

RMS_CALC will tend to this value by automatically adjusting the gain after every transmission (see 12.2.5.64

ATPL360_REG_CURRENT_GAIN (0x4036) 12.2.5.41 ). These parameters are only used if Tx AGC is enabled (see

ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)).

Access: Read-write.

Value Range: 32 bytes (see Table 12-3).

Default Value: See Table 12-4.

Table 12-3. Structure of ATPL360_REG_MAX_RMS_TABLE_VLO

Byte 0-3 Byte 4-7 Byte 8-11 Byte 12-15 Byte 16-19 Byte 20-24 Byte 25-27 Byte 28-31

RMS_VLO_0 RMS_VLO_1 RMS_VLO_2 RMS_VLO_3 RMS_VLO_4 RMS_VLO_5 RMS_VLO_6 RMS_VLO_7

where:

PL360

PL360 Host Controller API

• RMS_HI_x: Target value of RMS_CALC in mode of transmission VERY_LOW for the attenuation level x

(attenuation levels in 3dB steps)

Table 12-4. Default values of ATPL360_REG_MAX_RMS_TABLE_VLO

G3 BAND RMS_VLO_0 RMS_VLO_1 RMS_VLO_2 RMS_VLO_3 RMS_VLO_4 RMS_VLO_5 RMS_VLO_6 RMS_VLO_7

CEN-A 6356 4706 3317 2308 1602 1112 778 546

FCC 5656 4174 2877 1987 1413 1020 736 532

ARIB 3383 2463 1689 1168 832 603 438 316

CEN-B 2871 2120 1498 1054 740 519 366 259

12.2.5.50 ATPL360_REG_THRESHOLDS_TABLE_HI (0x4027)

Table of thresholds to automatically update Tx Mode (see 12.2.5.42 ATPL360_REG_CFG_IMPEDANCE (0x401F))

from HIGH mode. These parameters are only used if ATMC is enabled (see 12.2.5.41

ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)).

Corrected RMS_CALC (see 12.2.5.61 ATPL360_REG_CORRECTED_RMS_CALC (0x4033)) is compared with

these thresholds after every transmission to select Tx Mode for next transmission. The decision is taken following the

steps shown below:

1. If corrected RMS_CALC is below TH_HI_VLO_x, Tx Mode will be updated to VERY_LOW mode

2. Else if corrected RMS_CALC is below TH_HI_LO_x, Tx Mode will be updated to LOW mode

3. Else Tx Mode will remain in HIGH mode

where:

• TH_HI_VLO_x: Threshold to change from HIGH to VERY_LOW mode for Tx attenuation level x (3 dB steps)

• TH_HI_LO_x: Threshold to change from HIGH to LOW mode for Tx attenuation level x (3 dB steps)

Access: Read-write.

Value Range: 64 bytes (see Table 12-5).

Default Value: See Table 12-6.

Table 12-5. Structure of ATPL360_REG_THRESHOLDS_TABLE_HI

Byte 0-3 Byte 4-7 Byte 8-11 Byte 12-15 Byte 16-19 Byte 20-24 Byte 25-27 Byte 28-31

TH_HI_LO_0 TH_HI_LO_1 TH_HI_LO_2 TH_HI_LO_3 TH_HI_LO_4 TH_HI_LO_5 TH_HI_LO_6 TH_HI_LO_7

Byte 32-35 Byte 36-39 Byte 40-43 Byte 44-47 Byte 48-51 Byte 52-55 Byte 56-59 Byte 60-63

TH_HI_VLO_0 TH_HI_VLO_1 TH_HI_VLO_2 TH_HI_VLO_3 TH_HI_VLO_4 TH_HI_VLO_5 TH_HI_VLO_6 TH_HI_VLO_7

Table 12-6. Default values of ATPL360_REG_THRESHOLDS_TABLE_HI

G3 BAND TH_HI_LO_0 TH_HI_LO_1 TH_HI_LO_2 TH_HI_LO_3 TH_HI_LO_4 TH_HI_LO_5 TH_HI_LO_6 TH_HI_LO_7

CEN-A 0 0 0 0 0 0 0 0

FCC 0 0 0 0 0 0 0 0

ARIB 0 0 0 0 0 0 0 0

CEN-B 0 0 0 0 0 0 0 0

G3 BAND TH_HI_VLO_0 TH_HI_VLO_1 TH_HI_VLO_2 TH_HI_VLO_3 TH_HI_VLO_4 TH_HI_VLO_5 TH_HI_VLO_6 TH_HI_VLO_7

CEN-A 1685 1173 828 589 419 298 212 151

FCC 1147 811 576 409 291 208 150 109

ARIB 744 527 374 266 188 134 96 67

CEN-B 950 667 471 334 238 169 122 90

PL360

PL360 Host Controller API

12.2.5.51 ATPL360_REG_THRESHOLDS_TABLE_LO (0x4028)

Table of thresholds to automatically update Tx Mode (see 12.2.5.42 ATPL360_REG_CFG_IMPEDANCE (0x401F))

from LOW mode. These parameters are only used if ATMC is enabled (see 12.2.5.41

ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)).

Corrected RMS_CALC (see 12.2.5.61 ATPL360_REG_CORRECTED_RMS_CALC (0x4033)) is compared with

these thresholds after every transmission to select Tx Mode for next transmission. The decision is taken following the

steps shown below:

1. If corrected RMS_CALC is below TH_LO_VLO_x, Tx Mode will be updated to VERY_LOW mode

2. Else if corrected RMS_CALC is above TH_LO_HI_x, Tx Mode will be updated to HIGH mode

3. Else Tx Mode will remain in LOW mode

where:

• TH_LO_VLO_x: Threshold to change from LOW to VERY_LOW mode for Tx attenuation level x (3 dB steps)

• TH_LO_HI_x: Threshold to change from LOW to HIGH mode for Tx attenuation level x (3 dB steps)

Access: Read-write.

Value Range: 64 bytes (see Table 12-7).

Default Value: See Table 12-8.

Table 12-7. Structure of ATPL360_REG_THRESHOLDS_TABLE_LO

Byte 0-3 Byte 4-7 Byte 8-11 Byte 12-15 Byte 16-19 Byte 20-24 Byte 25-27 Byte 28-31

TH_LO_HI_0 TH_LO_HI_1 TH_LO_HI_2 TH_LO_HI_3 TH_LO_HI_4 TH_LO_HI_5 TH_LO_HI_6 TH_LO_HI_7

Byte 32-35 Byte 36-39 Byte 40-43 Byte 44-47 Byte 48-51 Byte 52-55 Byte 56-59 Byte 60-63

TH_LO_VLO_0 TH_LO_VLO_1 TH_LO_VLO_2 TH_LO_VLO_3 TH_LO_VLO_4 TH_LO_VLO_5 TH_LO_VLO_6 TH_LO_VLO_7

Table 12-8. Default values of ATPL360_REG_THRESHOLDS_TABLE_LO

G3 BAND TH_LO_HI_0 TH_LO_HI_1 TH_LO_HI_2 TH_LO_HI_3 TH_LO_HI_4 TH_LO_HI_5 TH_LO_HI_6 TH_LO_HI_7

CEN-A 0 0 0 0 0 0 0 0

FCC 0 0 0 0 0 0 0 0

ARIB 0 0 0 0 0 0 0 0

CEN-B 0 0 0 0 0 0 0 0

G3 BAND TH_LO_VLO_0 TH_LO_VLO_1 TH_LO_VLO_2 TH_LO_VLO_3 TH_LO_VLO_4 TH_LO_VLO_5 TH_LO_VLO_6 TH_LO_VLO_7

CEN-A 0 0 0 0 0 0 0 0

FCC 0 0 0 0 0 0 0 0

ARIB 0 0 0 0 0 0 0 0

CEN-B 0 0 0 0 0 0 0 0

12.2.5.52 ATPL360_REG_THRESHOLDS_TABLE_VLO (0x4029)

Table of thresholds to automatically update Tx Mode (see 12.2.5.42 ATPL360_REG_CFG_IMPEDANCE (0x401F))

from VERY_LOW mode. These parameters are only used if ATMC is enabled (see 12.2.5.41

ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)).

Corrected RMS_CALC (see 12.2.5.61 ATPL360_REG_CORRECTED_RMS_CALC (0x4033)) is compared with

these thresholds after every transmission to select Tx Mode for next transmission. The decision is taken following the

steps shown below:

1. If corrected RMS_CALC is below TH_VLO_VLO_x, Tx Mode will remain in VERY_LOW mode

2. Else if corrected RMS_CALC is above TH_VLO_HI_x, Tx Mode will be updated to HIGH mode

3. Else Tx Mode will be updated to LOW mode

where:

• TH_VLO_VLO_x: Threshold to remain Tx mode in VERY_LOW mode for Tx attenuation level x (3 dB steps)

PL360

PL360 Host Controller API

• TH_VLO_HI_x: Threshold to change from VERY_LOW to HIGH mode for Tx attenuation level x (3 dB steps)

Access: Read-write.

Value Range: 64 bytes (see Table 12-9).

Default Value: See Table 12-10.

Table 12-9. Structure of ATPL360_REG_THRESHOLDS_TABLE_VLO

Byte 0-3 Byte 4-7 Byte 8-11 Byte 12-15 Byte 16-19 Byte 20-24 Byte 25-27 Byte 28-31

TH_VLO_HI_0 TH_VLO_HI_1 TH_VLO_HI_2 TH_VLO_HI_3 TH_VLO_HI_4 TH_VLO_HI_5 TH_VLO_HI_6 TH_VLO_HI_7

Byte 32-35 Byte 36-39 Byte 40-43 Byte 44-47 Byte 48-51 Byte 52-55 Byte 56-59 Byte 60-63

TH_VLO_VLO_0 TH_VLO_VLO_1 TH_VLO_VLO_2 TH_VLO_VLO_3 TH_VLO_VLO_4 TH_VLO_VLO_5 TH_VLO_VLO_6 TH_VLO_VLO_7

Table 12-10. Default values of ATPL360_REG_THRESHOLDS_TABLE_VLO

G3 BAND TH_VLO_HI_0 TH_VLO_HI_1 TH_VLO_HI_2 TH_VLO_HI_3 TH_VLO_HI_4 TH_VLO_HI_5 TH_VLO_HI_6 TH_VLO_HI_7

CEN-A 0 0 0 0 0 0 0 0

FCC 0 0 0 0 0 0 0 0

ARIB 0 0 0 0 0 0 0 0

CEN-B 0 0 0 0 0 0 0 0

G3 BAND TH_VLO_VLO_0 TH_VLO_VLO_1 TH_VLO_VLO_2 TH_VLO_VLO_3 TH_VLO_VLO_4 TH_VLO_VLO_5 TH_VLO_VLO_6 TH_VLO_VLO_7

CEN-A 8988 6370 4466 3119 2171 1512 1061 752

FCC 8153 5718 4007 2871 2080 1506 1083 778

ARIB 4914 3462 2458 1777 1288 931 669 465

CEN-B 3878 2749 1935 1362 965 686 493 353

12.2.5.53 ATPL360_REG_PREDIST_COEF_TABLE_HI (0x402A)

Equalization Coefficients table in HIGH Tx mode. There is one coefficient for each carrier in the used band. The

format of each coefficient is uQ0.16 (2 bytes). PL360 firmware compensates the total gain internally, so modifying the

gain is not needed (see 12.2.5.56 ATPL360_REG_GAIN_TABLE_HI (0x402D)) when equalization is modified.

Access: Read-write.

Value Range: 72 bytes (CENELEC-A), 32 bytes (CENELEC-B), 144 bytes (FCC) or 108 bytes (ARIB).

Default Value:

CENELEC-A

{0x670A, 0x660F, 0x676A, 0x6A6B, 0x6F3F, 0x7440, 0x74ED, 0x7792, 0x762D, 0x7530, 0x7938,

0x7C0A, 0x7C2A, 0x7B0E, 0x7AF2, 0x784B, 0x7899, 0x76F9, 0x76D6, 0x769F, 0x775D, 0x70C0,

0x6EB9, 0x6F18, 0x6F1E, 0x6FA2, 0x6862, 0x67C9, 0x68F9, 0x68A5, 0x6CA3, 0x7153, 0x7533,

0x750B, 0x7B59, 0x7FFF}

FCC

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

ARIB

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

PL360

PL360 Host Controller API

CENELEC-B

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

12.2.5.54 ATPL360_REG_PREDIST_COEF_TABLE_LO (0x402B)

Equalization Coefficients table in LOW Tx mode. There is one coefficient for each carrier in the used band. The

format of each coefficient is uQ0.16 (2 bytes). PL360 firmware compensates the total gain internally, so modifying the

gain it is not needed (see 12.2.5.57 ATPL360_REG_GAIN_TABLE_LO (0x402E)) when equalization is modified.

Access: Read-write.

Value Range: 72 bytes (CENELEC-A), 32 bytes (CENELEC-B), 144 bytes (FCC) or 108 bytes (ARIB).

Default Value:

CENELEC-A

{0x7FFF, 0x7DB1, 0x7CE6, 0x7B36, 0x772F, 0x7472, 0x70AA, 0x6BC2, 0x682D, 0x6618, 0x6384,

0x6210, 0x61D7, 0x6244, 0x6269, 0x63A8, 0x6528, 0x65CC, 0x67F6, 0x693B, 0x6B13, 0x6C29,

0x6D43, 0x6E26, 0x6D70, 0x6C94, 0x6BB5, 0x6AC9, 0x6A5F, 0x6B65, 0x6B8C, 0x6A62, 0x6CEC,

0x6D5A, 0x6F9D, 0x6FD3}

FCC

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

ARIB

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

CENELEC-B

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

12.2.5.55 ATPL360_REG_PREDIST_COEF_TABLE_VLO (0x402C)

Equalization Coefficients table in VERY_LOW Tx mode. There is one coefficient for each carrier in the used band.

The format of each coefficient is uQ0.16 (2 bytes). PL360 firmware compensates the total gain internally, so

modifying the gain is not needed (see 12.2.5.58 ATPL360_REG_GAIN_TABLE_VLO (0x402F)) when equalization is

modified.

Access: Read-write.

Value Range: 72 bytes (CENELEC-A), 32 bytes (CENELEC-B), 144 bytes (FCC) or 108 bytes (ARIB).

Default Value:

CENELEC-A

{0x7FFF, 0x7DB1, 0x7CE6, 0x7B36, 0x772F, 0x7472, 0x70AA, 0x6BC2, 0x682D, 0x6618, 0x6384,

0x6210, 0x61D7, 0x6244, 0x6269, 0x63A8, 0x6528, 0x65CC, 0x67F6, 0x693B, 0x6B13, 0x6C29,

0x6D43, 0x6E26, 0x6D70, 0x6C94, 0x6BB5, 0x6AC9, 0x6A5F, 0x6B65, 0x6B8C, 0x6A62, 0x6CEC,

0x6D5A, 0x6F9D, 0x6FD3}

FCC

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

PL360

PL360 Host Controller API

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

ARIB

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

CENELEC-B

{0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF,

0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF, 0x7FFF}

12.2.5.56 ATPL360_REG_GAIN_TABLE_HI (0x402D)

Table of gain values for HIGH Tx Mode.

Access: Read-write.

Value Range: 6 bytes (see Table 12-11).

Default Value: See Table 12-12.

Table 12-11. Structure of ATPL360_REG_GAIN_TABLE_HI

Byte 0-1 Byte 2-3 Byte 4-5

GAIN_HI_INI GAIN_HI_MIN GAIN_HI_MAX

where:

• GAIN_HI_INI: Initial gain value in HIGH Tx Mode. The minimum value is GAIN_HI_MIN.

• GAIN_HI_MIN: Minimum gain value in HIGH Tx Mode. The minimum value is 1.

• GAIN_HI_MAX: Maximum gain value in HIGH Tx Mode. The minimum value is GAIN_HI_INI.

GAIN_HI_MIN and GAIN_HI_MAX are only used if Tx AGC is enabled (see 12.2.5.41

ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)).

Table 12-12. Default values of ATPL360_REG_GAIN_TABLE_HI

G3 BAND GAIN_HI_INI GAIN_HI_MIN GAIN_HI_MAX

CENELEC-A 142 70 336

FCC 109 50 256

ARIB 120 60 281

CENELEC-B 248 119 496

12.2.5.57 ATPL360_REG_GAIN_TABLE_LO (0x402E)

Gain value in LOW Tx Mode.

Access: Read-write.

Value Range: 2 bytes. The minimum value is 1.

Default Value: CENELEC-A: 474; FCC: 364; ARIB: 403; CENELEC-B: 701.

12.2.5.58 ATPL360_REG_GAIN_TABLE_VLO (0x402F)

Table of gain values for VERY_LOW Tx Mode.

Access: Read-write.

Value Range: 6 bytes (see Table 12-13).

Default Value: See Table 12-14.

PL360

PL360 Host Controller API

Table 12-13. Structure of ATPL360_REG_GAIN_TABLE_VLO

Byte 0-1 Byte 2-3 Byte 4-5

GAIN_VLO_INI GAIN_VLO_MIN GAIN_VLO_MAX

where:

• GAIN_VLO_INI: Initial gain value in VERY_LOW Tx Mode. The minimum value is GAIN_VLO_MIN.

• GAIN_VLO_MIN: Minimum gain value in VERY_LOW Tx Mode. The minimum value is 1.

• GAIN_VLO_MAX: Maximum gain value in VERY_LOW Tx Mode. The minimum value is GAIN_VLO_INI.

GAIN_VLO_MIN and GAIN_VLO_MAX are only used if Tx AGC is enabled (see 12.2.5.41

ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)).

Table 12-14. Default values of ATPL360_REG_GAIN_TABLE_VLO

G3 BAND GAIN_VLO_INI GAIN_VLO_MIN GAIN_VLO_MAX

CENELEC-A 474 230 597

FCC 364 180 408

ARIB 403 200 451

CENELEC-B 701 350 883

12.2.5.59 ATPL360_REG_DACC_TABLE_CFG (0x4030)

Configuration values of DACC peripheral according to hardware configuration.

Access: Read-write.

Value Range: 68 bytes.

Default Value:

CENELEC-A:

{0x00000000, 0x00002120, 0x0000073F, 0x00003F3F, 0x00000333, 0x00000000, 0x610800FF,

0x14141414, 0x00002020, 0x00000044, 0x0FD20004, 0x00000355, 0x0F000000, 0x001020F0,

0x00000355, 0x0F000000, 0x001020FF}

FCC, ARIB:

{0x00000000, 0x10102120, 0x033F073F, 0x3F3F3F3F, 0x00000FFF, 0x00000000, 0x2A3000FF,

0x1B1B1B1B, 0x10101010, 0x00001111, 0x04380006, 0x000003AA, 0xF0000000, 0x001020F0,

0x00000355, 0x0F000000, 0x001020FF}

CENELEC-B:

{0x00000000, 0x00002120, 0x0000073F, 0x00003F3F, 0x00000333, 0x00000000, 0x58CA00FF,

0x19191919, 0x00002020, 0x00000044, 0x0FD20004, 0x00000355, 0x0F000000, 0x001020F0,

0x00000355, 0x0F000000, 0x001020FF}

12.2.5.60 ATPL360_REG_NUM_TX_LEVELS (0x4032)

Number of Tx attenuation levels (3 dB steps) for normal transmission behavior. When “uc_tx_power” field (see

12.2.2 PHY-DATA.request) is higher than or equal to the number of Tx attenuation levels, Tx Mode is internally

forced by the PL360 device to LOW mode. Maximum value is 8 levels.

Access: Read-write.

Value Range: 1 byte [0-8].

Default Value: 8.

12.2.5.61 ATPL360_REG_CORRECTED_RMS_CALC (0x4033)

RMS_CALC value obtained in the last transmitted message, compensated with gain applied by Tx AGC algorithm

(see 12.2.5.64 ATPL360_REG_CURRENT_GAIN (0x4036)). This is the value which is actually compared with

PL360

PL360 Host Controller API

thresholds (12.2.5.52 ATPL360_REG_THRESHOLDS_TABLE_VLO (0x4029) 12.2.5.50 ,

ATPL360_REG_THRESHOLDS_TABLE_HI (0x4027)) to automatically update Tx Mode.

Access: Read-only.

Value Range: 4 bytes.

Default Value: Not applicable.

12.2.5.62 ATPL360_REG_RRC_NOTCH_THR_ON (0x4034)

Activation threshold for narrow band noise (in quarters of dBμV, uQ14.2).

Access: Read-write.

Value Range: 2 bytes.

Default Value: CENELEC-A: 270 (67.5 dBμV); CENELEC-B: 281 (70.25 dBμV); FCC: 258 (64.5 dBμV); ARIB: 270

(67.5 dBμV).

12.2.5.63 ATPL360_REG_RRC_NOTCH_THR_OFF (0x4035)

Deactivation threshold for narrow band noise (in dBμV quarters, uQ14.2).

Access: Read-write.

Value Range: 2 bytes.

Default Value: CENELEC-A: 254 (63.5 dBμV); CENELEC-B: 265 (66.25 dBμV); FCC: 242 (60.5 dBμV); ARIB: 254

(63.5 dBμV).

12.2.5.64 ATPL360_REG_CURRENT_GAIN (0x4036)

Transmission Gain which will be used in the next transmitted message. It can vary after every transmission if Tx AGC

is enabled (see 12.2.5.41 ATPL360_REG_CFG_AUTODETECT_IMPEDANCE (0x401E)). Maximum and minimum

Gain values can be set in 12.2.5.56 ATPL360_REG_GAIN_TABLE_HI (0x402D) 12.2.5.58 and

ATPL360_REG_GAIN_TABLE_VLO (0x402F).

Access: Read-only.

Value Range: 2 bytes.

Default Value: Not Applicable.

12.2.5.65 ATPL360_REG_ZC_CONF_INV (0x4037)

Inverted output of Zero-Crossing Detector.

Access: Read-write.

Value Range: 1 byte [0: Normal mode, 1: Inverted mode].

Default Value: 1.

12.2.5.66 ATPL360_REG_ZC_CONF_FREQ (0x4038)

Initial frequency in Hz for Zero-Crossing Detector.

Access: Read-write.

Value Range: 1 byte.

Default Value: 50.

12.2.5.67 ATPL360_REG_ZC_CONF_DELAY (0x4039)

Time Delay in microseconds of external Zero-Crossing Detection circuit.

Access: Read-write.

Value Range: 2 bytes.

Default Value: 176.

12.2.5.68 ATPL360_REG_NOISE_PER_CARRIER (0x403A)

Estimation of noise (in dBµV) in each carrier belonging to the corresponding band. It is measured every time a noise

capture is executed (see 12.2.5.33 ATPL360_REG_ENABLE_AUTO_NOISE_CAPTURE (0x4016) 12.2.5.34 ,

PL360

PL360 Host Controller API

ATPL360_REG_TIME_BETWEEN_NOISE_CAPTURES (0x4017) 12.2.5.47 ,

ATPL360_REG_RRC_NOTCH_AUTODETECT (0x4024)).

This information is used internally for narrow band noise detection and notch filter activation.

The value is updated only if Auto-mode is enabled (12.2.5.33 ATPL360_REG_ENABLE_AUTO_NOISE_CAPTURE

(0x4016) 12.2.5.47 ATPL360_REG_RRC_NOTCH_AUTODETECT (0x4024)) or noise capture is triggered through .

Access: Read only.

Value Range: 1 byte per carrier.

Default Value: Not applicable.

12.2.5.69 ATPL360_REG_SYNC_XCORR_THRESHOLD (0x403B)

Correlation threshold for synchronization (preamble detection). The format is uQ0.16. It represents percentage with

respect to the maximum ideal value of correlation (computed internally in PL360).

Access: Read-write.

Value Range: 2 bytes.

Default value: 0x7400 (45.3%).

CAUTION

It is recommended to keep the default value of this parameter in order to maintain expected reception

performance.

12.2.5.70 ATPL360_REG_SYNC_XCORR_PEAK_VALUE (0x403C)

Correlation value in last received PDU. The format is the same described in 12.2.5.69

ATPL360_REG_SYNC_XCORR_THRESHOLD (0x403B).

Access: Read-only.

Value Range: 2 bytes.

Default value: Not applicable.

12.2.5.71 ATPL360_REG_SYNC_SYNCM_THRESHOLD (0x403D)

Threshold for SYNCM detection (once preamble is detected with correlation).

Access: Read-write.

Value Range: 2 bytes.

Default value: 15299.

CAUTION

It is recommended to keep the default value of this parameter in order to maintain expected reception

performance.

12.2.5.72 ATPL360_REG_TONE_MAP_RSP_ENABLED_MODS (0x403E)

Bitmask to enable/disable the available modulations for the algorithm to select modulation and Tone Map (see

12.2.5.16 ATPL360_REG_TONE_MAP_RSP_DATA (0x4005)). Each bit corresponds to a combination of modulation

type and modulation scheme (see Table 12-15). The modulation is enabled if the corresponding bit is 1.

Table 12-15. ATPL360_REG_TONE_MAP_RSP_ENABLED_MODS Bit-field

Bit 7 (MSB) Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 (LSB)

8PSK_D 8PSK_C QPSK_D QPSK_C BPSK_D BPSK_C ROBO_D ROBO_C

Access: Read-write.

Value Range: 1 byte (1-255).

PL360

PL360 Host Controller API

Default value: CENELEC-A, CENELEC-B, FCC: 0xFF (All modulations enabled); ARIB: 0x2A (Coherent Modulation

Scheme and 8PSK Modulation Type not supported).

12.2.5.73 ATPL360_REG_PPM_CALIB_ON (0x403F)

Enable the oscillator clock signal to go out through TXRX1 pad. This is useful to measure clock frequency deviation.

Access: Read-write.

Value Range: 1 byte [0: Disabled, 1: Enabled].

Default value: 0.

12.2.5.74 ATPL360_REG_SFO_ESTIMATION_LAST_RX (0x4040)

Estimation of clock frequency deviation on last received PDU. The estimated deviation is the difference between

transmitter and receiver devices. The format is sQ0.31 (signed). The unit is 0.001 ppm. To convert to ppm, the read

value has to be divided by 1000.

Access: Read-only.

Value Range: 4 bytes.

Default value: Not Applicable.

12.2.5.75 ATPL360_REG_PDC_LAST_RX (0x4041)

PDC value (field in G3 Frame Control Header) corresponding to last received PDU.

Access: Read-only.

Value Range: 1 byte.

Default value: Not Applicable.

12.2.5.76 ATPL360_REG_MAX_PSDU_LEN_PARAMS (0x4042)

Parameters used for the computation of the maximum PDU length (see 12.2.5.77 ATPL360_REG_MAX_PSDU_LEN

(0x4043)).

The format is defined by the structure shown below (fields and related constants are explained in 12.2.2 PHY-

DATA.request):

typedef struct {max_psdu_len_params

mod_types uc_mod_type;enum

mod_schemes uc_mod_scheme;enum

uint8_t uc_2_rs_blocks;

uint8_t puc_tone_map[TONE_MAP_SIZE_MAX];

} ;max_psdu_len_params_t

Access: Read-write.

Value Range: 6 bytes.

Default value: BPSK Robust modulation type (0x04), differential modulation scheme (0x00), 1 Reed Solomon block

(0x00) and full tone map (0x3F0000, in CENELEC-A; 0x0F0000, in CENELEC-B; 0xFFFFFF, in FCC; 0xFFFF03, in

ARIB) .

12.2.5.77 ATPL360_REG_MAX_PSDU_LEN (0x4043)

Maximum PDU length allowed by PHY layer depending on Modulation type, Modulation scheme, Tone map and

number of Reed-Solomon blocks (see 12.2.5.76 ATPL360_REG_MAX_PSDU_LEN_PARAMS (0x4042) to configure

these parameters). If CRC capability is enabled (see 12.2.5.39 ATPL360_REG_CRC_TX_RX_CAPABILITY

(0x401C)), the final result does not include the 2 bytes of the 16-bit CRC computed by the PL360.

Access: Read-only.

Value Range: 2 bytes (CENELEC-A, CENELEC-B: 0-239; FCC: 0-494; ARIB: 0-247).

Default value: 133 (CENELEC-A); 54 (CENELEC-B); 247 (FCC, ARIB).

12.2.5.78 ATPL360_REG_RESET_STATS (0x4044)

Writing any value (1 - 255) causes all PHY statistics (ATPL360_REG_TX_TOTAL, ATPL360_REG_RX_TOTAL, etc.)

to be reset to 0.

PL360

PL360 Host Controller API

Produktspezifikationen

Marke:	Microchip
Kategorie:	Nicht kategorisiert
Modell:	PL360B

Brauchst du Hilfe?

Wenn Sie Hilfe mit Microchip PL360B benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Nicht kategorisiert Microchip

Microchip ATECC608B Bedienungsanleitung

5 September 2024

Microchip HV860 Bedienungsanleitung

5 September 2024

Microchip EVB-LAN9255 Bedienungsanleitung

5 September 2024

Microchip LX4580 Bedienungsanleitung

5 September 2024

Microchip LX7720 Bedienungsanleitung

5 September 2024

Microchip MIC24067 Bedienungsanleitung

28 August 2024

Microchip MIC24066 Bedienungsanleitung

28 August 2024

Microchip LAN8671 Bedienungsanleitung

27 August 2024

Microchip PIC32CX1025SG60128 Bedienungsanleitung

24 August 2024

Microchip TC1016 Bedienungsanleitung

24 August 2024

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-

BEKO BBVM17400B Bedienungsanleitung

4 Dezember 2024

DeWalt DXV34PTA Bedienungsanleitung

4 Dezember 2024

DeWalt DCF414 Bedienungsanleitung

4 Dezember 2024

DeWalt DXIRFFP25 Bedienungsanleitung

4 Dezember 2024

DeWalt DXIR1A1A2P3 Bedienungsanleitung

4 Dezember 2024

DeWalt DCE450 Bedienungsanleitung

4 Dezember 2024

DeWalt DCMAS5713 Bedienungsanleitung

4 Dezember 2024

DeWalt DCMASBC1 Bedienungsanleitung

4 Dezember 2024

DeWalt DXKH180E Bedienungsanleitung

4 Dezember 2024

DeWalt DWE46150 Bedienungsanleitung

4 Dezember 2024
