Seite 1/2
marvelrefrigeration.com | 800.223.3900
Performance
• The quietest ice machine you can buy
• New energy-saving options conserve water and energy
• Engineered to consistently produce pure, clear ice with unrivaled
clarity, immediate cooling and slower melt
• Its uniform size and compact density prove to be the optimal shape
to provide faster cooling, while taking up less space in your glass
• Produces up to 39 pounds of clear ice daily, the equivalent of nearly
eight convenience-store bags of ice
• Streamlined componentry and single-connection water tting for
simple installation
Storage Capabilities
• Large-capacity bin stores 35 pounds of clear ice, while preserving
quality and assuring fresh ice production
• Sleek scoop design is positioned for easy reach
• Easy-to-clean, hygienic interior surface
Touchpad Controls
• Marvel Intuit™ Integrated Controls feature all-new settings for
ultimate programmability
• Eco Ice™ mode moderates ice production to conservative usage,
saving 25% water (91 gallons monthly) and 25% energy
($45 annually)**
• Delay Start/Vacation option automatically postpones operation by
1/4/6/8 (hour or day) intervals, preventing wasteful water and energy
use
• Audible alerts and programmed cleaning reminders
Aesthetics
• New Illuminice™ feature projects waterproof LED light through clear
ice for a dazzling illumination effect
• At the touch of a button, change the interior light color to
sapphire blue, amber glow, or arctic white
• Two-stage theater-style lighting offers full or half illumination
• Midnight black interior and the rst-ever glass door option add drama
to the ice presentation, perfect for entertaining
• Soft-close integrated hinge provides a seamless zero clearance
installation and a smooth, gentle close
• Finish options: stainless steel (solid or glass door)
or overlay (panel ready)*
Additional Convenience
• Includes factory installed drain pump
• Close Door Assist System™ prevents energy loss by automatically
drawing door to a gentle close
• Stainless steel toe kick adjustable to 4” with leveling legs
• 3-year parts and labor warranty, 5-year sealed system parts warranty
15” Marvel Professional Clear
Ice Machine with Tri-Color
Illuminice™ Lighting
Model # MP15CP
Ordering Options
Solid Stainless Steel Door, Integrated Right Hinge,
Professional Handle MP15CPS2RS
Solid Stainless Steel Door, Integrated Left Hinge,
Professional Handle MP15CPS2LS
Stainless Steel Frame Glass Door,
Integrated Right Hinge, Professional Handle MP15CPG2RS
Stainless Steel Frame Glass Door,
Integrated Left Hinge, Professional Handle MP15CPG2LS
Panel-Ready Solid Overlay Door,
Integrated Right Hinge (Handle Not Included)* MP15CPP2RP
Panel-Ready Solid Overlay Door,
Integrated Left Hinge (Handle Not Included)* MP15CPP2LP
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
Built in the USA
14 7/8" W
33 3/4" H
25 5/8” D
including
handle
Solid Stainless
Steel
Stainless Steel
Frame
Solid Overlay
(Panel Ready)*
Finish Options
marvelrefrigeration.com | 800.223.3900
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Left Hand Hinged Door
15" (38.1 cm) wide appliance
Left Hand Hinged Door
15" (38.1 cm) wide appliance
47⁄ "8
(12.4 cm)
13
⁄16 "
(3 cm)
31⁄ "8
(7.9 cm)
11⁄ "2
(3.8 cm)
typical
Hinge side of door
Top of door
143⁄ "4
(37.5 cm)
1⁄ " (6 mm) 4
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore 1⁄ " (6 mm) 4
deep 4 places.
13⁄ "4
(4.4 cm)
2"
(5.1 cm) 311
⁄ "16
(9.4 cm)
1⁄ " (6 mm)4
radius is
permissible
111
⁄16"
(4.3 cm)
47⁄ "8
(12.4 cm)
1
3⁄ "16
(3 cm)
3
1⁄ "8
(7.9 cm)
11
⁄ "2
(3.8 cm)
typical
111
⁄ "16
(4.3 cm)
Hinge side of door
143⁄ "4
(37.5 cm) 1⁄ " (6 mm) 4
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore 1⁄ " (6 mm) 4
deep 4 places.
13⁄ "4
(4.4 cm)
2"
(5.1 cm)
311 ⁄ "16
(9.4 cm)
This side
facing interior
This side
facing interior
1
⁄ " (6 mm)4
radius is
permissible
15⁄ "32
(2.9 cm)
15⁄ "32
(2.9 cm)
30 11
⁄ "32
(77.1 cm)
3011
⁄ "32
(77.1 cm)
Panel Overlay Dimensions
Rough-In Dimensions
A. Rough-In Width 15”
B. Rough-In Height 34 1/4” to 35 1/25”
C. Rough-In Depth 24”
Product Dimensions
D. Width 14 7/8”
E. Height 34” to 35”
F. Depth 21 1/2”
G. Depth to Front of Door
Solid Door 23 23/32”
Overlay Door
22 7/8”
Without
Handle
H. Depth to Handle 26 7/32” (Stainless Steel)
I. Depth with door at 90˚
Solid Door 37 13/32”
Overlay Door 37 1/2”
Product Features
Interior Cabinet Finish Black
Capacity Up to 35 lbs of clear ice
Shelving System NA
Shelf Fronts NA
Other Storage Ice Bin
Interior Lighting Tri-Color LED
Toe Grill Finish Stainless Steel
Hinge Soft Close Integrated Hinge
Handle
Professional
(Panel Overlay Does Not
Include Handle)
Control Type Intuit™
Temperature Range NA
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6’
Shipping Weight 127 lbs
Finishes Stainless Steel, Overlay
Vacation Mode Yes
Agency Approvals CSA
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
"A"
"B"
"C"
"D"
"E"
"D" "I"
"G"
"G"
"H"
"H"
"I"
Product Dimensions
