marvelrefrigeration.com | 800.223.3900
Performance
β’ The quietest ice machine you can buy
β’ New energy-saving options conserve water and energy
β’ Engineered to consistently produce pure, clear ice with unrivaled
clarity, immediate cooling and slower melt
β’ Its uniform size and compact density prove to be the optimal shape
to provide faster cooling, while taking up less space in your glass
β’ Produces up to 39 pounds of clear ice daily, the equivalent of nearly
eight convenience-store bags of ice
β’ Streamlined componentry and single-connection water ο¬ tting
for simple installation
Storage Capabilities
β’ Large-capacity bin stores 35 pounds of clear ice, while preserving
quality and assuring fresh ice production
β’ Easy-to-clean, hygienic interior surface
Touchpad Controls
β’ Marvel Intuitβ’ Integrated Controls feature all-new settings for
ultimate programmability
β’ Eco Iceβ’ mode moderates ice production to conservative usage,
saving 25% water (91 gallons monthly) and 25% energy ($45
annually)**
β’ Delay Start/Vacation option automatically postpones operation by
1/4/6/8 (hour or day) intervals, preventing wasteful water use
β’ Audible alerts and programmed cleaning reminders
Aesthetics
β’ New Illuminiceβ’ feature projects arctic white LED light through clear
ice for a dazzling illumination effect
β’ First-ever glass door model with white interior adds drama to
entertaining at home
β’ Easy-to-install panel-ready option includes soft-close
integrated hinge
β’ Finish options: stainless steel, black or overlay panel
Additional Convenience
β’ Close Door Assist Systemβ’ prevents energy loss by automatically
drawing door to a gentle close
β’ Black toe kick adjustable to 4β with leveling legs
β’ 1-year parts and labor warranty, 5-year sealed system parts warranty
(see ownerβs guide for details)
15β Marvel Clear Ice Machine
with Arctic White Illuminiceβ’
Lighting
Model # ML15CL & ML15CP
Ordering Options
Gravity Drain Applications
Solid Stainless Steel Door, Right Hinge ML15CLS1RS
Solid Stainless Steel Door, Left Hinge ML15CLS1LS
Stainless Frame, Glass Door, Right Hinge ML15CLG1RS
Stainless Frame, Glass Door, Left Hinge ML15CLG1LS
Solid Smooth Black Door, Right Hinge ML15CLS1RB
Solid Smooth Black Door, Left Hinge ML15CLS1LB
Panel-Ready Solid Overlay Door,
Integrated Right Hinge* ML15CLP2RP
Panel-Ready Solid Overlay Door,
Integrated Left Hinge* ML15CLP2LP
Factory Installed Pump
Solid Stainless Door, Right Hinge ML15CPS1RS
Solid Stainless Door, Left Hinge ML15CPS1LS
Stainless Frame, Glass Door, Right Hinge ML15CPG1RS
Stainless Frame, Glass Door, Left Hinge ML15CPG1LS
Solid Smooth Black Door, Right Hinge ML15CPS1RB
Solid Smooth Black Door, Left Hinge ML15CPS1LB
Panel-Ready Solid Overlay Door,
Integrated Right Hinge* ML15CPP2RP
Panel-Ready Solid Overlay Door,
Integrated Left Hinge* ML15CPP2LP
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
Solid Overlay
(Panel Ready)*
BlackSolid Stainless
Steel
Stainless Steel
Frame
Finish Options
14 7/8" W
33 3/4" H
25 9/16β D
including
handle
marvelrefrigeration.com | 800.223.3900
15β "32
(2.9 cm)
15β "32
(2.9 cm)
Clearance
for hinge
2 places
143β "4
(37.5 cm)
Clearance for
screw head,
4 places
Figure 14
Left Hand Hinged Door
15" (38.1 cm) wide appliance
Hinge side of door
Clearance
for hinge
2 places
143β "4
(37.5 cm) 1β " (6 mm) 4
Deep
1" (25.4 mm) diameter
counter bore 1β " (6.4mm) 4
deep 4 places.
13β "4
(4.4 cm)
4
7β
8"
(12.4 cm)
3
27β "32
(9.7 cm)
1
11β "16
(4.3 cm)
5"
(12.7 cm)
31
β "8
(7.9 cm)
Minimum
2"
(5.1 cm)
41β "8
(10.5 cm)
Minimum
3011β "32
(77.1 cm)
13β "16
(3 cm)
31
β "8
(7.9 cm)
11
β "2
(3.8 cm)
typical
3
11 β "16
(9.4 cm)
31β "8
(7.9 cm)
Minimum
This side
facing interior This side
facing interior
1
β " (6 mm)4
radius is
permissible
Hinge side of door
Top of door
Clearance for
screw head,
4 places
Figure 16
Right Hand Hinged Door
15" (38.1 cm) wide appliance
327β "32
(9.7 cm)
1β " (6 mm) 4
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore 1β " (6 mm) 4
deep 6 places.
1β " (6 mm)4
radius is
permissible
3011
β "32
(77.1 cm)
4
7β
8"
(12.4 cm)
31β
8"
(7.9 cm)
11β "2
(3.8 cm)
typical
1
3β "4
(4.4 cm)
31β "8
(7.9 cm)
Minimum
2"
(5.1 cm) 311
β "16
(9.4 cm)
41β "8
(10.5 cm)
Minimum
111 β16"
(4.3 cm)
31β "8
(7.9 cm)
Minimum
1
3β "16
(3 cm)
Panel Overlay Dimensions (Frame Door)
Rough-In Dimensions
A. Rough-In Width 15β
B. Rough-In Height 34β to 35β
C. Rough-In Depth 24β
Product Dimensions
D. Width 14 7/8β
E. Height 33 3/4β to 34 3/4β
G. Depth to Front of Door
Solid Door 23 5/8β
Overlay Door 22 15/16β
H. Depth to Handle 25 9/16β (Stainless Steel)
I. Depth with door at 90Λ
Solid Door 37 13/32β
Overlay Door 38 5/8β
Product Features
Interior Cabinet Finish White
Capacity 35 lbs of Ice Storage
Shelving System NA
Shelf Fronts NA
Other Storage Ice Bin
Interior Lighting Illuminiceβ’ White LED
Toe Grill Finish Black
Hinge Classic Hinge
Handle
Slim Designer Handle
(Panel Overlay Does
Not Include Handle)
Control Type Intuitβ’
Temperature Range NA
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6β
Shipping Weight 127 lbs
Finishes Stainless Steel, Overlay, Black
Vacation Mode Yes
Agency Approvals CSA
"A"
"B"
"C"
"D"
"E"
"I""G"
"H"
Product Dimensions
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the ownerβs guide.
marvelrefrigeration.com | 800.223.3900
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Left Hand Hinged Door
15" (38.1 cm) wide appliance
Left Hand Hinged Door
15" (38.1 cm) wide appliance
47β "8
(12.4 cm)
13
β "16
(3 cm)
31β "8
(7.9 cm)
11β "2
(3.8 cm)
typical
Hinge side of door
Top of door
143β "4
(37.5 cm)
1β " (6 mm) 4
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore 1β " (6 mm) 4
deep 4 places.
13β "4
(4.4 cm)
2"
(5.1 cm) 311β "16
(9.4 cm)
1β " (6 mm)4
radius is
permissible
111 β16"
(4.3 cm)
47β "8
(12.4 cm)
13β "16
(3 cm)
31β "8
(7.9 cm)
11
β "2
(3.8 cm)
typical
111
β "16
(4.3 cm)
Hinge side of door
143β "4
(37.5 cm) 1β
4" (6 mm)
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore 1β " (6 mm) 4
deep 4 places.
13β "4
(4.4 cm)
2"
(5.1 cm)
311β "16
(9.4 cm)
This side
facing interior
This side
facing interior
1
β " (6 mm)4
radius is
permissible
15β "32
(2.9 cm)
15β "32
(2.9 cm)
30 11β "32
(77.1 cm)
30
11 β "32
(77.1 cm)
Panel Overlay Dimensions (Solid Door)
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the ownerβs guide.
