Seite 1/2
marvelrefrigeration.com | 800.223.3900
Performance
• The quietest ice machine you can buy
• New energy-saving options conserve water and electricity
• Engineered to consistently produce pure, clear ice with unrivaled
clarity, immediate cooling and slower melt
• Produces up to 39 pounds of clear ice daily, the equivalent of nearly
eight convenientce-store ice bags
• Close Door Assist System™ prevents energy loss by automatically
drawing door to a gentle close
• Streamlined componentry and single-connection water tting
for simple installation
Storage Capabilities
• Large-capacity bin stores 35 pounds of clear ice
Touchpad Controls
• Multifunction Marvel Intuit™ Integrated Controls adapt ice production
to usage needs
• Eco Ice™ mode moderates ice production to conservative usage,
saving 25% water (91 gallons monthly) and 25% energy
($45 annually)**
• Audible alerts and programmed cleaning reminders
Aesthetics
• New Illuminice™ feature projects arctic white LED lighting through
clear ice for a dazzling illumination effect
• High-efciency, low-maintenance condenser design for built-in zero
clearance installations
• Finish options: stainless steel or overlay (panel ready)
Additional Convenience
• Low prole, ADA height allows for universal
installation applications
• Black toe kick adjustable to 4” with leveling legs
• 1-year parts and labor warranty, 5-year sealed system parts warranty
15” Marvel Low Prole Clear Ice
Machine with Arctic Illuminice™
Lighting
Model # MA15CL & MA15CP
Built in the USA
ADA
Height
ADA
Height
14 3/4" W
31" H
25 1/2" D
including
handle
Gravity Drain Applications
Solid Stainless Steel Door, Right Hinge MA15CLS1RS
Solid Stainless Steel Door, Left Hinge MA15CLS1LS
Panel-Ready Solid Overlay Panel Door,
Right Hinge* MA15CLP1RP
Panel-Ready Solid Overlay Panel Door,
Left Hinge* MA15CLP1LP
Factory Installed Pump
Solid Stainless Door, Right Hinge MA15CPS1RS
Solid Stainless Door, Left Hinge MA15CPS1LS
Panel-Ready Solid Overlay Panel Door,
Right Hinge* MA15CPP1RP
Panel-Ready Solid Overlay Panel Door,
Left Hinge* MA15CPP1LP
Accessories
Clear Ice Machine Cleaner, 4-oz bottle S41013789
Solid Overlay
(Panel Ready)*
Stainless Steel
Finish Options
marvelrefrigeration.com | 800.223.3900
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Right Hand Hinged Door
15" (38.1 cm) wide appliance
Right Hand Hinged Door
Clearance for
screw head,
4 places
Clearance
for hinge
2 places
Left Hand Hinged Door
15" (38.1 cm) wide appliance
Left Hand Hinged Door
47⁄ "8
(12.4 cm)
13
⁄16"
(3 cm)
31⁄ "8
(7.9 cm)
11⁄ "2
(3.8 cm)
typical
Hinge side of door
Top of door
143⁄ "4
(37.5 cm)
1⁄ " (6 mm) 4
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore
1⁄4
" (6 mm)
deep 4 places.
13⁄ "4
(4.4 cm)
2"
(5.1 cm) 311
⁄ "16
(9.4 cm)
1⁄ " (6 mm)4
radius is
permissible
111
⁄16"
(4.3 cm)
47⁄ "8
(12.4 cm)
1
3⁄
16"
(3 cm)
3
1⁄ "8
(7.9 cm)
11
⁄ "2
(3.8 cm)
typical
1
11⁄ "16
(4.3 cm)
Hinge side of door
143⁄ "4
(37.5 cm) 1⁄
4" (6 mm)
Deep
5"
(12.7 cm)
1" (25.4 mm) diameter
counter bore
1⁄ " (6 mm) 4
deep 4 places.
13⁄ "4
(4.4 cm)
2"
(5.1 cm)
311 ⁄ "16
(9.4 cm)
This side
facing interior
This side
facing interior
1
⁄ " (6 mm)4
radius is
permissible
15⁄ "32
(2.9 cm)
15⁄ "32
(2.9 cm)
30 11
⁄ "32
(77.1 cm)
3011⁄ "32
(77.1 cm)
Panel Overlay Dimensions
Rough-In Dimensions
A. Rough-In Width 15”
B. Rough-In Height 31 3/8” to 32 3/8”
C. Rough-In Depth 24”
Product Dimensions
D. Width 14 7/8”
E. Height 31 1/8 to 32 1/8
F. Depth 21 1/2”
G. Depth to Front of Door
Solid Door 23 5/8”
Overlay Door
22 7/8”
Without
Handle
H. Depth to Handle 25 1/2” (Stainless Steel)
I. Depth with door at 90˚
Solid Door 37 1/16’
Overlay Door 37 1/16’
Product Features
Interior Cabinet Finish White
Capacity Up to 35 lbs of clear ice
Shelving System NA
Shelf Fronts NA
Other Storage Ice Bin
Interior Lighting White LED
Toe Grill Finish Black
Hinge Classic Hinge
Handle
Slim Designer Handle
(Panel Overlay Does
Not Include Handle)
Control Type Intuit™
Temperature Range NA
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6’
Shipping Weight 120 lbs
Finishes Stainless Steel, Overlay
Vacation Mode Yes
Agency Approvals CSA
"A"
"B"
"C"
"D"
"E"
"I""G"
"H"
Product Dimensions
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
