HCS connected to Raspberry Pi demonstration scenario
*NOTE : You should have basic knowledge on Raspberry Pi operation so that you can understand
terms using in this document.
Demonstration idea
The idea of the demonstration is to connect two HCS power supply to Raspberry Pi. A driver is
installed into Raspberry Pi to connect USB device to Ethernet. The driver will map each USB port to
TCP connect port. For example USB 1 is mapped to TCP port 4001. Then remote control software can
connect to HCS power supply by using IP address of Raspberry Pi and port number for USB.
E.g. Raspberry Pi IP address : 192.168.1.100
USB port 1 map to TCP port 4001
The connection setup is 192.168.1.100:4001
A load, which can be LED or DC FAN, is used to connect to power supply output so that the voltage
and current reading can be recorded. We can use programming feature in our application to program
different voltage and current for the output. Then the application can record variation of voltage and
current.
The demonstration will use application on iPad which can set HCS output, get reading from it, has 20
steps programed output and monitoring the output.
Demonstration setup
Equipments list
1. HCS power supply x 2
2. Raspberry Pi B+ model
3. 12V DC Fan
4. 12 LED (around 5W)5. iPad
with iOS 7 or above
Setup Raspberry Pi B+
Software required :
i. Raspbian – OS for Raspberry Pi
ii. Manson driver for Raspberry Pi
iii. Winscp – File transfer tools to transfer driver to Raspberry Pi
1. It is recommended to buy SD card with pre-installed Raspbian directly from shop to simplify the
installation.
2. Configure SSH server in Raspberry Pi for file transfer from Windows.
- Open terminal in Raspberry Pi.
- Run command “raspi-config” in raspberry pi console to get following interface.
- Select “Advanced Options” to configure SSH
- Select “A4 SSH” to set SSH server
- Select “Enable” to enable SSH server
- Press enter to exit the SSH server enabled message screen
