O W N E R ’ S M A N U A L
Professional Studio Monitors
XR624 & XR824
2
XR SERIES MONITORS
XR Series Monitors
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding-type
plug has two blades and a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. This apparatus shall not be exposed to dripping or splashing, and no object filled
with liquids, such as vases or beer glasses, shall be placed on the apparatus.
16. Do not overload wall outlets and extension cords as this can result in a risk of fire
or electric shock.
17. This apparatus has been designed with Class-I construction and must be
connected to a mains socket outlet with a protective earthing connection
(the third grounding prong).
18. This apparatus has been equipped with a rocker-style AC mains power switch. This
switch is located on the rear panel and should remain readily accessible to the user.
19. The MAINS plug or an appliance coupler is used as the disconnect device,
so the disconnect device shall remain readily operable.
PORTABLE CART
WARNING
CAUTION
The lightning flash with arrowhead symbol within
an equilateral triangle is intended to alert the user
to the prescence of uninsulated “dangerous voltage”
within the product’s enclosure, that may be of significant ma-
gnitude to constitute a risk of electric shock to persons.
RISK OF ELECTRIC SHOCK! DO NOT OPEN!
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
The exclamation point within an equilateral triangle is
intended to alert the user of the prescence of important
operating and maintaining (servicing) instructions in the
literature accompanying the appliance.
20. NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications to this device not expressly approved by
LOUD Technologies Inc. could void the user's authority to operate the equipment
under FCC rules.
21. This apparatus does not exceed the Class A/Class B (whichever is applicable)
limits for radio noise emissions from digital apparatus as set out in the radio
interference regulations of the Canadian Department of Communications.
ATTENTION — Le présent appareil numérique n’émet pas de bruits
radioélectriques dépassant las limites applicables aux appareils numériques de
class A/de class B (selon le cas) prescrites dans le réglement sur le brouillage
radioélectrique édicté par les ministere des communications du Canada.
22. Exposure to extremely high noise levels may cause permanent hearing loss.
Individuals vary considerably in susceptibility to noise-induced hearing loss, but
nearly everyone will lose some hearing if exposed to sufficiently intense noise
for a period of time. The U.S. Government’s Occupational Safety and Health
Administration (OSHA) has specified the permissible noise level exposures shown
in the following chart.
According to OSHA, any exposure in excess of these permissible limits could result
in some hearing loss. To ensure against potentially dangerous exposure to high
sound pressure levels, it is recommended that all persons exposed to equipment
capable of producing high sound pressure levels use hearing protectors while the
equipment is in operation. Ear plugs or protectors in the ear canals or over the
ears must be worn when operating the equipment in order to prevent permanent
hearing loss if exposure is in excess of the limits set forth here:
8 90 Duo in small club
6 92
4 95 Subway Train
3 97
2 100 Very loud classical music
1.5 102
1 105 Jon screaming at Karl about deadlines
0.5 110
0.25 or less 115 Loudest parts at a rock concert
WARNING — To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or moisture.
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.
Apparatet må tilkoples jordet stikkontakt.
Apparaten skall anslutas till jordat uttag.
Part No. SW1177 Rev. A 06/16
©2016 LOUD Technologies Inc. All Rights Reserved. 3
Owner’s Manual
Owner’s Manual
IMPORTANT SAFETY INSTRUCTIONS ...............................................2
INTRODUCTION ...............................................................................4
QUICK START ...........................................................................5
HOOKUP DIAGRAMS...............................................................6
REAR PANEL DESCRIPTION .............................................................7
1. POWER CONNECTOR .......................................................7
2. POWER SWITCH ..............................................................7
3. AC SELECT SWITCH ...........................................................7
4. SIGNAL INPUTS ................................................................7
5. INPUT SENSITIVITY ..........................................................8
6. ACOUSTIC SPACE..............................................................8
7. LOW FREQUENCY FILTER ..................................................8
8. HIGH FREQUENCY FILTER .................................................8
9. POWER MODE .................................................................9
10. CUSTOM-TUNED REAR PORT .........................................9
FRONT PANEL DESCRIPTION ............................................................9
11. POWER/OVERLOAD LED ..............................................9
PROTECTION CIRCUITS ..................................................................10
OVEREXCURSION PROTECTION .........................................10
THERMAL PROTECTION ......................................................10
INTEGRATED MAGNETIC SHIELDING ...................................10
OVERLOAD PROTECTION ...................................................10
INPUT SIGNAL WIRING ......................................................10
CARE AND CLEANING ....................................................................10
APPENDIX A: SERVICE INFO ..........................................................11
TROUBLESHOOTING 11 ...........................................................
REPAIR 12 ...............................................................................
APPENDIX B: TECHNICAL INFORMATION .......................................13
XR SERIES SPECIFICATIONS ...................................................13
XR SERIES DIMENSIONS ........................................................14
XR SERIES LIMITED WARRANTY ....................................................15
Contents XR Series Features
•
Professional level performance
•
Logarithmic waveguide provides acoustic
alignment for balanced sound across the entire
frequency spectrum
•
ELP™ Bass Refl ex System engineered for zero
turbulence, providing greatly increased output
capability and extended low-frequency response
•
1” black anodized aluminum tweeter reveals the
fi nest details and upper harmonics of your mix.
•
6.5" (XR624) or 8" (XR824) Kevlar® woofer
offers fast transient recovery for incredibly
accurate low frequency response
•
160W bi-amplifi ed Class-D amplifi cation
(100LF / 60HF)
•
Frequency response: 45Hz – 22kHz (XR624)
or 36Hz – 22kHz (XR824)
• Optimize XR monitors for your sound and mixing
environment
•
Adjustable acoustic space fi lters maintain fl at
response in typical placement
•
HF fi lter applies boost or cut to compensate for
particularly dull or bright sounding rooms
•
LF fi lter rolls off the low end to simulate smaller
speakers for reference
• Attention to the detail
•
Eco-friendly auto turn-off / turn-on
•
Black wood grain fi nish for a classic studio feel
•
Specially designed internal bracing adds stiffness
for reduced distortion and enhanced clarity
•
Included custom acoustic isolation pad reduces
unwanted resonance and improves bass response
Like us
Follow us
Watch our dang videos
Please write your serial number here for future
reference (i.e., insurance claims, tech support,
return authorization, make dad proud, etc.)
Purchased at:
Date of purchase:
