O W N E R ’ S M A N U A L

Powered Loudspeakers

SRM350v3 and SRM450v3

SRM350v3 and SRM450v3 Powered Loudspeakers

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves,

or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug.

A polarized plug has two blades with one wider than the other. A grounding-type

plug has two blades and a third grounding prong. The wide blade or the third prong

are provided for your safety. If the provided plug does not ﬁt into your outlet,

consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories speciﬁed by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table speciﬁed

by the manufacturer, or sold with the apparatus. When a

cart is used, use caution when moving the cart/apparatus

combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when

unused for long periods of time.

14. Refer all servicing to qualiﬁed service personnel. Servicing is

required when the apparatus has been damaged in any way, such as power-supply

cord or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not operate

normally, or has been dropped.

15. This apparatus shall not be exposed to dripping or splashing, and no object ﬁlled

with liquids, such as vases or beer glasses, shall be placed on the apparatus.

16. Do not overload wall outlets and extension cords as this can result in a risk of ﬁre

or electric shock.

17. This apparatus has been designed with Class-I construction and must be

connected to a mains socket outlet with a protective earthing connection

(the third grounding prong).

18. This apparatus has been equipped with a rocker-style AC mains power switch. This

switch is located on the rear panel and should remain readily accessible to the user.

19. The MAINS plug or an appliance coupler is used as the disconnect device,

so the disconnect device shall remain readily operable.

PORTABLE CART

WARNING

CAUTION

The lightning ﬂash with arrowhead symbol within

an equilateral triangle is intended to alert the user

to the prescence of uninsulated “dangerous voltage”

within the product’s enclosure, that may be of signiﬁcant

magnitude to constitute a risk of electric shock to persons.

RISK OF ELECTRIC SHOCK! DO NOT OPEN!

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED PERSONNEL.

The exclamation point within an equilateral triangle is

intended to alert the user of the prescence of important

operating and maintaining (servicing) instructions in the

literature accompanying the appliance.

WARNING — To reduce the risk of ﬁre or electric

shock, do not expose this apparatus to rain or moisture.

CAUTION — To prevent electric shock hazard, do not

connect to mains power supply while grille is removed.

20. NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorientorrelocatethereceivingantenna.

• Increasetheseparationbetweentheequipmentandthereceiver.

• Connecttheequipmentintoanoutletonacircuitdifferentfromthatto

which the receiver is connected.

• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

CAUTION: Changes or modiﬁcations to this device not expressly approved by

LOUD Technologies Inc. could void the user's authority to operate the equipment

under FCC rules.

21. This apparatus does not exceed the Class A/Class B (whichever is applicable)

limits for radio noise emissions from digital apparatus as set out in the radio

interference regulations of the Canadian Department of Communications.

ATTENTION —

Le présent appareil numérique n’émet pas de bruits radioélectriques

dépassant las limites applicables aux appareils numériques de class A/de class B

(selon le cas) prescrites dans le réglement sur le brouillage radioélectrique édicté

par les ministere des communications du Canada.

22. Exposure to extremely high noise levels may cause permanent hearing loss.

Individuals vary considerably in susceptibility to noise-induced hearing loss, but

nearly everyone will lose some hearing if exposed to sufﬁciently intense noise

for a period of time. The U.S. Government’s Occupational Safety and Health

Administration (OSHA) has speciﬁed the permissible noise level exposures shown

in the following chart.

According to OSHA, any exposure in excess of these permissible limits could result

in some hearing loss. To ensure against potentially dangerous exposure to high

sound pressure levels, it is recommended that all persons exposed to equipment

capable of producing high sound pressure levels use hearing protectors while the

equipment is in operation. Ear plugs or protectors in the ear canals or over the

ears must be worn when operating the equipment in order to prevent permanent

hearing loss if exposure is in excess of the limits set forth here:

Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.

Apparatet må tilkoples jordet stikkontakt.

Apparaten skall anslutas till jordat uttag.

Correct disposal of this product: This symbol indicates that this product should not be disposed of with your household

waste, according to the WEEE directive (2012/19/EU) and your national law. This product should be handed over to

an authorized collection site for recycling waste electrical and electronic equipment (EEE). Improper handling of this type

of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances

that are generally associated with EEE. At the same time, your cooperation in the correct disposal of this product will

contribute to the effective usage of natural resources. For more information about where you can drop off your waste

equipment for recycling, please contact your local city ofﬁce, waste authority, or your household waste disposal service.

8 90 Duo in small club

6 92

4 95 Subway Train

3 97

2 100 Veryloudclassicalmusic

1.5 102

1 105 Greg screaming at Troy about deadlines

0.5 110

0.25 or less 115 Loudest parts at a rock concert

Owner’s Manual

Contents Features

Part No. SW1051 Rev. A 03/14

• 1000Wsystempowerpairedwithcustom 

  transducersdelivergig-levelvolumeswith

  roomtospare

 • 10"high-outputLFdriver[SRM350v3]

 • 12"high-outputLFdriver[SRM450v3]

 • 1.4"titaniumdomecompressiondriver

• High-DenitionAudioProcessingforprofessional

  soundwithunmatchedclarity

 • Patentedacousticcorrectiondevelopedwith

   touringgeniusesatEAW®

 • Precision2-waycrossover

 • Drivertimealignmentandphasecorrection

• Quickone-buttonSpeakerModeselection

  forapplication-specicvoicing(PA,DJ,Monitor

  andSoloist)

• Effortlesslyeliminatenastyfeedbackwith

  one-buttonautomaticFeedbackDestroyer

• Integrated2-channelmixerfeaturingdual 

  Wide-Z™inputs

 • Handlesanythingfrommicstoguitarsto 

   mixerswithasingletwistofthegainknob

 • IncludesstereoRCAinputsforeasyconnection

   tomusicsource

 • Perfectforthesinger/songwriter,

   pluginandleavethemixerathome

• SmartProtect™DSPkicksintoprotect

  yourinvestmentwhenthingsgetpushed

  alittletoohard

• Monitor-specicangleandvoicingmode 

  perfectforcuttingthroughonstage

• Flyableforpermanentinstall

• Provenhighly-durable,portabledesign

 • 23.0lb/10.4kg[SRM350v3]

 • 37.0lb/16.8kg[SRM450v3]

Like us

Watch our dang videos

Important Safety Instructions 2 ..................................

Contents 3

.................................................................

Features 3

.................................................................

Introduction 4

............................................................

How To Use This Manual 4 .........................................

Getting Started 4

.......................................................

Things To Remember 4

................................................

Hookup Diagrams 5

....................................................

SRMv3 Loudspeaker: Rear Panel Features 9

................

1. Power Connection 9

.........................................

2. Power Switch 9

...............................................

3. XLR and 1/4" Combo Inputs 9

..........................

4. Gain Knobs 10

.................................................

5. RCA Inputs [Channel 2 Only] 10 .......................

6. Thru Output 10

................................................

7. Ch 1/Mix Switch [Thru Output] 11

...................

8. Speaker Mode 11 ............................................

9. Feedback desTROYer 11

...................................

10. Main LED Switch / Limit LED 11

.....................

11. Breakfast Mode 11

........................................

Smart Protect 12 .......................................................

Limiting ..........................................................

Overexcursion Protection 12 ................................

Thermal Protection 12

..........................................

AC Power 12

.............................................................

Care and Maintenance 12

...........................................

Placement 13

.............................................................

Room Acoustics 14

...............................................

Rigging 15 ...............................................................

Rigging Design Practices 15

..................................

Rigging Hardware and Accessories 15

...................

Rigging Notes 15

.................................................

SRMv3 Inserts & Fly Points 15

.............................

Appendix A: Service Information 16

............................

Appendix B: Connections 17

.......................................

Appendix C: Technical Information 18 ..........................

SRMv3 Loudspeaker Dimensions 20

......................

SRMv3 Loudspeaker Frequency Responses 21 .......

SRMv3 Loudspeaker Block Diagram 22 .................

Limited Warranty 23

..................................................
