O W N E R ’ S M A N U A L
2
CR-XBT Multimedia Monitors
CR-XBT Multimedia Monitors
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Minimum distance (5 cm) around the apparatus for sucient ventilation.
9. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
10. No naked flame sources, such as lighted candles, should be placed on the apparatus.
11. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding-type plug has two blades
and a third grounding prong. The wide blade or the third prong are provided for your safety.
If the provided plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
12. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
13. Only use attachments/accessories specified by the manufacturer.
14. Use only with a cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
15. Unplug this apparatus during lightning storms or when unused for long
periods of time.
16. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
17. This apparatus shall not be exposed to dripping or splashing, and no object filled
with liquids, such as vases or beer glasses, shall be placed on the apparatus.
18. Do not overload wall outlets and extension cords as this can result in a risk of fire or electric
shock.
PORTABLE CART
WARNING
WARNING — To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
CAUTION – These servicing instructions are for use by
qualified service personnel only. To reduce the risk of electric
shock, do not perform any servicing other than that contained
in the operating instructions unless you are qualified to do so.
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.
Apparatet må tilkoples jordet stikkontakt.
Apparaten skall anslutas till jordat uttag.
CAUTION
The lightning flash with arrowhead symbol within an equilateral
triangle is intended to alert the user to the prescence of uninsulated
“dangerous voltage” within the product’s enclosure, that may be of
significant magnitude to constitute a risk of electric shock to persons.
RISK OF ELECTRIC SHOCK! DO NOT OPEN!
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
The exclamation point within an equilateral triangle is intended
to alert the user of the prescence of important operating and
maintaining (servicing) instructions in the literature accompanying
the appliance.
19. This apparatus has been equipped with a rocker-style AC mains power switch.
This switch is located on the rear panel and should remain readily accessible to the user.
20. The MAINS plug or an appliance coupler is used as the disconnect device,
so the disconnect device shall remain readily operable.
21. Explanation of symbol, marking, signal lamp or similar means indicates that the apparatus
is completely disconnected from the mains.
22. WARNING: Please refer to the information on exterior bottom enclosure for electrical
and safety information before installing or operating the apparatus.
23. The use of apparatus is in tropical climates.
24. NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this device not expressly approved by LOUD Audio, CAUTION:
LLC. could void the user’s authority to operate the equipment under FCC rules.
25. This apparatus does not exceed the Class B limits for radio noise emissions from digital
apparatus as set out in the radio interference regulations of the Canadian Department
of Communications.
Canada ICES-003(B)/NMB-003(B)
ATTENTION
— Le présent appareil numérique n’émet pas de bruits radioélectriques
dépassant las limites applicables aux appareils numériques de class A/de class B
(selon le cas) prescrites dans le réglement sur le brouillage radioélectrique édicté
par les ministere des communications du Canada.
26. This equipment is a Class II or double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical
earth.
27. This device complies with Part 15 of the FCC rules and Industry Canada’s license-exempt
RSS standard(s). Operation is subjected to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
28. Exposure to extremely high noise levels may cause permanent hearing loss. Individuals
vary considerably in susceptibility to noise-induced hearing loss, but nearly everyone
will lose some hearing if exposed to suciently intense noise for a period of time.
The U.S. Government’s Occupational Safety and Health Administration (OSHA)
has specified the permissible noise level exposures shown in the following chart.
According to OSHA, any exposure in excess of these permissible limits could result in some
hearing loss. To ensure against potentially dangerous exposure to high sound pressure
levels, it is recommended that all persons exposed to equipment capable of producing high
sound pressure levels use hearing protectors while the equipment is in operation. Ear plugs
or protectors in the ear canals or over the ears must be worn when operating the equipment
in order to prevent permanent hearing loss if exposure is in excess of the limits set forth
here:
Duration, per
day in hours
Sound Level dBA,
Slow Response Typical Example
8 90 Duo in small club
6 92
4 95 Subway Train
3 97
2 100 Very loud classical music
1.5 102
1 105 Craig screaming at Troy about deadlines
0.5 110
0.25 or less 115 Loudest parts at a rock concert
Correct disposal of this product: This symbol indicates that this product should not be disposed of with your household waste, according to the WEEE directive (2012/19/EU)
and your national law. This product should be handed over to an authorized collection site for recycling waste electrical and electronic equipment (EEE). Improper handling
of this type of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally associated
with EEE. At the same time, your cooperation in the correct disposal of this product will contribute to the eective usage of natural resources. For more information about
where you can drop o your waste equipment for recycling, please contact your local city oce, waste authority, or your household waste disposal service.
Important Safety Instructions
3
Owner’s Manual
Owner’s Manual
Contents Features
Part No. SW1290 Rev. A 12/19
©2019 LOUD Audio, LLC. All Rights Reserved.
Signature CR Series Sound
• Professional studio-quality sound
• Perfect upgrade for your desktop speakers
• Great for home studios, content creators,
gaming, listening to your favorite tunes,
and more
Bluetooth® Streaming
• Stream music from any Bluetooth enabled
device directly to your monitors
Plug and Play
• Choose which side of your desk gets
the volume knob with the convenient
speaker placement switch
• Convenient front panel volume knob with gives
you on/o/volume control
• Front-facing headphone jack auto-defeats
speaker output
• Flexible inputs – 1/4", Bluetooth, RCA
and 1/8" [CR5-XBT, CR8-XBT]
Fresh Look
• Brushed metal front panel
• Distinct outlined design in CR Green
Included Accessories
• 1/8" to stereo RCA cable to connect computer
output to speakers
• Speaker-to-speaker cable
• 1/8" to 1/8" cable to connect a smartphone
or media player to rear panel of speakers
[CR5-XBT, CR8-XBT]
• Acoustic isolation pads [CR5-XBT, CR8-XBT]
CR8S-XBT 8" subwoofer with Bluetooth oers dedicated
bass reinforcement
• Perfect addition to any CR Series monitors
• Included CRDV Desktop Volume control
for easy control over the whole system
with separate subwoofer level
Like us Follow us Watch our dang videos
Important Safety Instructions 2
....................
Contents 3
.......................................................
Features 3 ........................................................
Introduction 4 .................................................
Getting Started 4
............................................
Hookup Diagrams 5
........................................
CR-XBT: Rear Panel Features 7 .....................
1. AC Line Cord 7
.............................................
2. Power Switch 7
...........................................
3. Signal Inputs 7
............................................
4. 1/8" Stereo Input 7
......................................
5. Powered Speaker Position Switch..........8
6. Wire Terminals (±) 8 ...................................
7. Custom-Tuned Rear Port 8
.........................
CR-XBT: Front Panel Features 8 ....................
8. Phone Output 8 ...........................................
9. Volume Knob 8 ............................................
10. Running Man Bluetooth Button / LED 8 ..
11. Season Knob 9 ...........................................
Input Signal Wiring 9 ......................................
Care and Cleaning 9 ........................................
Appendix A: Service Information 10 ..............
Appendix B: Technical Information 12 ..........
CR-XBT Dimensions 13
...................................
CR-XBT Block Diagram 14
..............................
Limited Warranty 16
.......................................
