O W N E R ’ S M A N U A L

CR-X Multimedia Monitors

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Minimum distance (5 cm) around the apparatus for sucient ventilation.

9. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including ampliﬁers) that produce heat.

10. No naked ﬂame sources, such as lighted candles, should be placed on the apparatus.

11. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding-type plug has two blades

and a third grounding prong. The wide blade or the third prong are provided for your safety.

If the provided plug does not ﬁt into your outlet, consult an electrician for replacement

of the obsolete outlet.

12. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

13. Only use attachments/accessories speciﬁed by the manufacturer.

14. Use only with a cart, stand, tripod, bracket, or table speciﬁed

by the manufacturer, or sold with the apparatus. When a cart

is used, use caution when moving the cart/apparatus combination

to avoid injury from tip-over.

15. Unplug this apparatus during lightning storms or when unused for long

periods of time.

16. Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

17. This apparatus shall not be exposed to dripping or splashing, and no object ﬁlled

with liquids, such as vases or beer glasses, shall be placed on the apparatus.

18. Do not overload wall outlets and extension cords as this can result in a risk of ﬁre or electric

shock.

PORTABLE CART

WARNING

WARNING — To reduce the risk of ﬁre or electric shock, do not

expose this apparatus to rain or moisture.

CAUTION – These servicing instructions are for use by

qualiﬁed service personnel only. To reduce the risk of electric

shock, do not perform any servicing other than that contained

in the operating instructions unless you are qualiﬁed to do so.

Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan.

Apparatet må tilkoples jordet stikkontakt.

Apparaten skall anslutas till jordat uttag.

CAUTION

The lightning ﬂash with arrowhead symbol within an equilateral

triangle is intended to alert the user to the prescence of uninsulated

“dangerous voltage” within the product’s enclosure, that may be of

signiﬁcant magnitude to constitute a risk of electric shock to persons.

RISK OF ELECTRIC SHOCK! DO NOT OPEN!

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED PERSONNEL.

The exclamation point within an equilateral triangle is intended

to alert the user of the prescence of important operating and

maintaining (servicing) instructions in the literature accompanying

the appliance.

19. This apparatus has been equipped with a rocker-style AC mains power switch.

This switch is located on the rear panel and should remain readily accessible to the user.

20. The MAINS plug or an appliance coupler is used as the disconnect device,

so the disconnect device shall remain readily operable.

21. Explanation of symbol, marking, signal lamp or similar means indicates that the apparatus

is completely disconnected from the mains.

22. WARNING: Please refer to the information on exterior bottom enclosure for electrical

and safety information before installing or operating the apparatus.

23. The use of apparatus is in tropical climates.

24. NOTE: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.

This equipment generates, uses, and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modiﬁcations to this device not expressly approved by LOUD Audio, CAUTION:

LLC. could void the user’s authority to operate the equipment under FCC rules.

25. This apparatus does not exceed the Class B limits for radio noise emissions from digital

apparatus as set out in the radio interference regulations of the Canadian Department

of Communications.

Canada ICES-003(B)/NMB-003(B)

ATTENTION

— Le présent appareil numérique n’émet pas de bruits radioélectriques

dépassant las limites applicables aux appareils numériques de class A/de class B

(selon le cas) prescrites dans le réglement sur le brouillage radioélectrique édicté

par les ministere des communications du Canada.

26. This equipment is a Class II or double insulated electrical appliance. It has been

designed in such a way that it does not require a safety connection to electrical

earth.

27. This device complies with Part 15 of the FCC rules and Industry Canada’s license-exempt

RSS standard(s). Operation is subjected to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may

cause undesired operation.

28. Exposure to extremely high noise levels may cause permanent hearing loss. Individuals

vary considerably in susceptibility to noise-induced hearing loss, but nearly everyone

will lose some hearing if exposed to suciently intense noise for a period of time.

The U.S. Government’s Occupational Safety and Health Administration (OSHA)

has speciﬁed the permissible noise level exposures shown in the following chart.

According to OSHA, any exposure in excess of these permissible limits could result in some

hearing loss. To ensure against potentially dangerous exposure to high sound pressure

levels, it is recommended that all persons exposed to equipment capable of producing high

sound pressure levels use hearing protectors while the equipment is in operation. Ear plugs

or protectors in the ear canals or over the ears must be worn when operating the equipment

in order to prevent permanent hearing loss if exposure is in excess of the limits set forth

here:

Duration, per

day in hours

Sound Level dBA,

Slow Response Typical Example

8 90 Duo in small club

6 92

4 95 Subway Train

3 97

2 100 Very loud classical music

1.5 102

1 105 Craig screaming at Troy about deadlines

0.5 110

0.25 or less 115 Loudest parts at a rock concert

Correct disposal of this product: This symbol indicates that this product should not be disposed of with your household waste, according to the WEEE directive (2012/19/EU)

and your national law. This product should be handed over to an authorized collection site for recycling waste electrical and electronic equipment (EEE). Improper handling

of this type of waste could have a possible negative impact on the environment and human health due to potentially hazardous substances that are generally associated

with EEE. At the same time, your cooperation in the correct disposal of this product will contribute to the eective usage of natural resources. For more information about

where you can drop o your waste equipment for recycling, please contact your local city oce, waste authority, or your household waste disposal service.

Important Safety Instructions

Owner’s Manual

Contents Features

Part No. SW1289 Rev. A 12/19

Signature CR Series Sound

• Professional studio-quality sound

• Perfect upgrade for your desktop speakers

• Great for home studios, content creators,

gaming, listening to your favorite tunes,

and more

Plug and Play

• Choose which side of your desk gets

the volume knob with the convenient

speaker placement switch

• Convenient front panel volume knob with gives

you on/o/volume control

• Front-facing headphone jack auto-defeats

speaker output

• Flexible inputs – 1/4", 1/8", and RCA

Fresh Look

• Brushed metal front panel

• Distinct outlined design in CR Green

Included Accessories

• 1/8" to stereo RCA cable to connect computer

output to speakers

• 1/8" to 1/8" cable to connect a smartphone

or media player to rear panel of speakers

• Speaker-to-speaker cable

• Acoustic isolation pads [CR5-X]

CR8S-XBT 8" subwoofer with Bluetooth oers dedicated

bass reinforcement

• Perfect addition to any CR Series monitors

• Included CRDV Desktop Volume control

for easy control over the whole system

with separate subwoofer level

Like us Follow us Watch our dang videos

Important Safety Instructions 2

....................

Contents 3

.......................................................

Features 3 ........................................................

Introduction 4 .................................................

Getting Started 4

............................................

Hookup Diagrams 5

........................................

CR-X: Rear Panel Features 7

..........................

1. AC Line Cord 7

.............................................

2. Power Switch 7

...........................................

3. Signal Inputs 7

............................................

4. 1/8" Stereo Input 7

......................................

5. Powered Speaker Position Switch..........8

6. Wire Terminals (±) 8 ...................................

7. Custom-Tuned Rear Port 8

.........................

CR-X: Front Panel Features 8 .........................

8. Phone Output 8 ...........................................

9. Volume Knob 8 ............................................

10. Running Man logo / LED 8 ........................

11. Season Knob 8 ...........................................

Input Signal Wiring 9 ......................................

Care and Cleaning 9 ........................................

Appendix A: Service Information 10 ..............

Appendix B: Technical Information 12 ..........

CR-X Dimensions 13 .......................................

CR-X Block Diagram 14 ..................................

Limited Warranty 15 .......................................
