Seite 1/22
1
403002-04-05-07-08-09-10_en_ma_2011
GRAVITY SLICERS
403.008
403.002
403.010
403.004
403.007
403.009
403.005
INSTALLATION USE AND
MAINTENANCE MANUAL
2
403002-04-05-07-08-09-10_en_ma_2011
CONTENTS
FOREWORD ................................................................................................................ 3
SCOPE OF THIS MANUAL .......................................................................................3
GENERAL INFORMATION .......................................................................................... 3
LIMITS OF USE-SAFETYNORMS .............................................................................3
GENERAL SAFETY REGULATIONS ..........................................................................3
MANUFACTURER’S WARRANTY AND LIABILITY ...................................................4
PLATES – CONFORMITY MARKS ............................................................................4
ENVIRONMENTAL CONDITIONS OF USE ................................................................4
PACKING ..................................................................................................................... 5
OPENING THE BOX ..................................................................................................5
TECHNICAL DESCRIPTION AND PROPOSED CONDITIONS OF USE ................... 6
GENERAL DESCRIPTION .........................................................................................6
MECHANICAL AND ELECTRICAL SAFETYDEVICES...............................................6
WARNING: RESIDUAL RISKS ...................................................................................6
DIMENSIONS ............................................................................................................7
MAIN TECHNICAL DATA ...........................................................................................7
SUPPLIED LITERATURE AND ACCESSORIES .........................................................8
PRODUCTS THAT CAN BE SLICED .........................................................................8
PRODUCTS THAT MUST NOT BE SLICED: .............................................................8
MAIN COMPONENTS I .............................................................................................9
MAIN COMPONENTS .............................................................................................10
MACHINE COMMISSIONING AND FUNCTION TESTS .......................................... 11
INSTALLING THE MACHINE ...................................................................................11
ELECTRICAL CONNECTION ..................................................................................11
COMMANDS ........................................................................................................... 12
USING THE MACHINE .............................................................................................. 13
LOADING THE PRODUCT ON THE TRAY AND SLICING ....................................... 13
CLEANING THE SLICER 14...........................................................................................
GENERAL ................................................................................................................ 14
DISASSEMBLING THE MACHINE FOR CLEANING ...............................................14
REASSEMBLING THE MACHINE ...........................................................................15
MAINTENANCE ......................................................................................................... 15
GENERAL ................................................................................................................ 15
BLADE SHARPENING .............................................................................................15
SHARPENING ........................................................................................................ 16
LUBRICATION .........................................................................................................18
ADJUSTING THE MOTOR BELT TENSION ............................................................19
TROUBLESHOOTING AND REMEDIES .................................................................. 20
DISMANTLING THE SLICER ...................................................................................21
ELECTRICAL DIAGRAM SIG. 97 (versions 403.002) .............................................. 22
3
403002-04-05-07-08-09-10_en_ma_2011
FOREWORD
SCOPE OF THIS MANUAL
This manual contains all the necessary information to install, use and service the gravity
slicers for food (please see models in paragraph "Technical Description"). The scope of
this document, hereinafter the "manual", is to permit users, and especially end users, to
take all the cautions and provisions possible for using this machine safely and for a long
time.
GENERAL INFORMATION
LIMITS OF USE – SAFETY NORMS
These machine were designed and built to slice foodstuff in compliance to the
norms of the 89/392 - 89/336 Directive and following amendments CE 91/368 -
93/44 - 93/68 CE, EN 1974 directive 89/109.
GENERAL SAFETY REGULATIONS
The slicers must be used only by suitably trained personnel. Furthermore, this personnel
must have read this manual carefully.
In particular, please comply to the following instructions
 Install the machine according to the instructions contained in the "Installation" section.
 Do not remove the transparent protections, do not modify nor exclude the mechanical
and electrical safety devices.
 Do no use the machine with improvised connections, or provisional or non insulated
cables.
 Check the power cable and gland plate on the machine body regularly and when
necessary have them replaced by qualified personnel.
 In case of anomalies, defective operation, incorrect movement, unusual noise, etc
stop the machine immediately.
 Before cleaning or servicing, disconnect the machine from the mains.
 Always use scratch-proof and non-slip gloves during cleaning or maintenance.
 Lay or remove the goods to be sliced on the sliding plate only when the latter is
completely pushed back and the thickness control knob positioned to 0.
 To move the carriage tray when slicing, use the handle or the product grip handle.
 For extraordinary maintenance (to replace the sharpener wheels, the blade, or others)
please contact the manufacturer or qualified and duly authorized personnel.
 Avoid running the slicers with no product on it
 The slicers are equipped with a ventilated motor, except for the 403.008 model for which
operating time must not exceed 15 minutes to avoid motor overheating. After a period
of rest, operation can be resumed.
WARRANTY: 1 YEAR except for the electrical parts
