Mabe JCB630EJES Bedienungsanleitung

Mabe Ofen JCB630EJES

Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Mabe JCB630EJES (41 Seiten) in der Kategorie Ofen. Dieser Bedienungsanleitung war für 26 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet

Download PDF
Seite 1/41
Coil Top and
Radi t Top odels an M
Sta dan rd
Clean Models
JCBS630
JCBS660
Self-Clean
Models
JCB630
JCB635
183D6379P075 29-5853
Safety I ormnf ation . . . . . . . . . . . 2–5
Operating s ctionsIn tru
Cl k, Toc imer and
Conv ce Oenien utlet . . . . . . . . . . . . .15, 16
Controls . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 11
Cookware . . . . . . . . . . . . . . . . . . . . . . . . . .7 . .
Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . .12–14
Sabbath Feature . . . . . . . . . . . . . . . .19, 20
Self-Cleaning . . . . . . . . . . . . . . . . . . . .2 2, 23
Special
Steam C nlea
Features . . . . . . . . . . . . . . . . . . . .18
Sur ce Units fa . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . 24
6, 8
Temperature Conve irs ons . . . . . . . . . . 11
Thermostat . . . . . . . . . . . . . . . . . . . . . . .21 . .
Timed ng and RoastingBaki . . . . . . . .17
Care and Cleaning . . . . . . . . . . . . . 31
Troubleshooting Tips . . . . . . 32–36
Accessories . . . . . . . . . . . . . . . . . . . . . . 37
Consumer Support
Cons er Supportum . . . . . . . . . . . . . . . . .41
Pro ct Rdu egistration . . . . . . . . . . . . 3 398,
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Write the model and serial
numbers here:
Model # __________________
Serial # __________________
You can find them on a label,
behind the storage drawer
on the oven frame.
Owner’s Manual
Ranges
Elect c ri Coil & Radiant
www.GEAppliances.ca
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
2
Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions
Read all safety instructions before using the product. Failure to follow these instructions may result in fire, electric
shock, serious injury or death.
WARNING
ANTI-TIP DEV EIC
To reduce the risk of tipping the range, the range must be
secured by a properly installed anti-tip bracket. See installation
instructions shipped with the bracket for complete details before
attempting to install.
For Freestanding Ranges:
To check if the bracket is installed and engaged properly,
remove the storage drawer or kick panel and look underneath
the range to see that the leveling leg is engaged in the bracket.
On models without a storage drawer or kick panel, carefully tip
the range forward. The bracket should stop the range within
10.2 cm (4 inches) If it does not, the bracket must be reinstalled
If the range is pulled from the wall for any reason, always repeat
this procedure to verify the range is properly secured by the
anti-tip bracket.
Never completely remove the leveling legs or the range will not
be secured to the anti-tip device properly.
If you did not receive an anti-tip bracket with your purchase,
call. 1 800 561 3344 to receive at no cost. For installation
instructions of the bracket, visit GEAppliances.ca
3
GEAppliances.ca
Safety Instructions Operating Instructions
Care and Cleaning Troubleshooting Tips Consumer Support
Use this appliance for its intended purpose as described
in this Owner’s Manual.
CAUTION:
Do not store items of interest to
children above a range or on the backguard of a
range―children climbing on the range to reach items
could be seriously injured.
Use only dry pot holders―moist or damp pot holders on
hot surfaces may result in burns from steam. Do not let
pot holders touch hot surface units or heating elements.
Do not use a towel or other bulky cloth in place of pot
holders.
Never use your appliance for warming or heating the
room.
Do not touch the surface units, the heating elements
or the interior surface of the oven. These surfaces may
be hot enough to burn even though they are dark in
color. During and after use, do not touch, or let clothing
or other flammable materials contact the surface units,
areas near by the surface units or any interior area of
the oven; allow sufficient time for cooling first. Other
surfaces of the appliance may be come hot enough
to cause burns. Potentially hot surfaces include the
cooktop, areas facing the cooktop, oven vent opening,
surfaces near the opening and crevices around the
oven door.
Do not heat unopened food containers. Pressure could
build up and the container could burst, causing an
injury.
Do not use aluminum foil to line drip pans or any where
in the oven, except as described in this manual. Foil can
trap heat or melt, resulting in damage to the product
and a shock or fire hazard.
Avoid scratching or impacting glass doors, cook tops or
control panels. Doing so may lead to glass breakage. Do
not cook on a product with broken glass Shock, fire or
cuts may occur.
Cook meat and poultry thoroughly ―meat to at least
an internal temperature of 71.1 °C (160 °F) and poultry
to at least an internal temperature of 82.2 °C (180°F)―
Cooking to these temperatures usually protects
against foodborne illness.
GENERAL SAFETY INSTRUCTIONS
Do not store or use flammable materials in an oven or
near the cooktop, including paper, plastic, pot holders,
linens, wall coverings, curtains, drapes and gasoline or
other flammable vapors and liquids.
Never wear loose-fitting or hanging garments while
using the appliance. These garments may ignite if they
contact hot surfaces causing severe burns.
Do not let cooking grease or other flammable materials
accumulate in or near the range. Grease in the oven or
on the cooktop may ignite.
Clean ventilating hoods frequently. Grease should not
be allowed to accumulate on the hood or filter.
KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE
WARNING
WARNING
Be sure your appliance is properly installed and
grounded by a qualified installer in accordance with the
provided installation instructions.
Do not attempt to repair or replace any part of your
range unless it is specifically recommended in this
manual. All other servicing should be referred to a
qualified technician.
Before performing any service, unplug the range
or disconnect the power supply at the household
distribution panel by removing the fuse or switching off
the circuit breaker.
Do not leave children alone―children should not be left
alone or unattended in an area where an appliance is in
use. They should never be allowed to climb, sit or stand
on any part of the appliance.

Produktspezifikationen

Marke: Mabe
Kategorie: Ofen
Modell: JCB630EJES
