Seite 1/2
T E C H N I C A L D A T A
LANCOM, LANCOM Systems, LCOS, LANcommunity and Hyper Integration are registered trademarks. All other names or descriptions used may be trademarks or registered trademarks of their owners. This docu-
ment contains statements relating to future products and their attributes. LANCOM Systems reserves the right to change these without notice. No liability for technical errors and / or omissions. 111671/0322
Hardware
Power supply Exchangeable power supply (110-230 V, 50-60 Hz)
Power consumption Max. 800 W (when using one power supply, or redundancy mode with two power supplies)
Environment Temperature range 0–40° C; short-term temperature range 0-50° C; humidity 10–90 %, non-condensing
Housing Robust metal housing, 1 HU with removable mounting brackets and slide-in rails,
network connections at front and rear, dimensions 442 x 44 x 375 mm (W x H x D)
Number of fans 2
Interfaces
QSFP+ 2 * QSFP+ 40 Gbps uplink ports for connection to superordinate core switches or content servers, can also
be configured as stacking ports via software
TP Ethernet 12 TP Ethernet ports 10 / 100 / 1000 Mbps
12 TP Ethernet ports 100 / 1000 / 2500 Mbps
SFP+ 4 * SFP+ 1 / 10 Gbps, uplink ports for connection to superordinate core switches or content servers, can
also be configured as stacking ports via software
Console 1 * RJ-45 / 1 * Micro USB
USB 1 * USB host
OOB 1 * OOB
Declaration of Conformity
Hereby, LANCOM Systems GmbH | Adenauerstrasse 20/B2 | D-52146 Wuerselen, declares that this device is in compliance with
Directives 2014/30/EU, 2014/35/EU, 2011/65/EU, and Regulation (EC) No. 1907/2006. The full text of the EU Declaration of
Conformity is available at the following Internet address: www.lancom-systems.com/doc
Package Content
Manual Quick Reference Guide (DE/EN), Installation Guide (DE/EN)
Mounting brackets Two 19“ mounting brackets, two slide-in rails for rear stabilization in 19`` racks
Power supply 1x exchangeable power supply LANCOM SPSU-920, expandable to 2 LANCOM SPSU-920 power supplies
(hot swappable, for redundancy operation)
Cables 1 IEC power cord, 1 serial configuration cable, 1 micro USB configuration cable
M O U N T I N G A N D C O N N E C T I N G T H E D E V I C E
4
Please observe the following when setting up the device
AThe mains plug of the device must be freely accessible.
AFor devices to be operated on the desktop, please attach the adhesive rubber
footpads.
ADo not rest any objects on top of the device and do not stack multiple devices.
A Keep the ventilation slots on the side of the device clear of obstruction.
AMount the device into a 19” unit in a server cabinet using the provided screws and mounting brackets.
Both slide-in rails are attached as shown in the accompanying installation instructions
www.lancom-systems.com/slide-in-MI.
APlease note that support for third-party accessories (SFP and DAC) is not provided.
LANCOM GS-4530XP
Quick Reference Guide
C ud eadylo -r
Before initial startup, please make sure to take notice of the information regarding the intended use in the enclosed installation guide!
Operate the device only with a professionally installed power supply at a nearby power socket that is freely accessible at all times.
aConfiguration interfaces RJ-45 & micro USB (Console)
Connect the configuration interface via the included micro USB cable
to the USB interface of the device you want to use for configuring /
monitoring the switch. Alternatively, use the RJ-45 interface with the
provided serial configuration cable.
bUSB interface
Connect a USB stick to the USB interface to store general configuration
scripts or debug data.
You can also use this interface to upload a new firmware.
cTP Ethernet interfaces 10M / 100M / 1G
Connect the interfaces 1 to 12 via Ethernet cable to your PC or a LAN
switch.
dTP Ethernet interfaces 100M / 1G / 2.5G
Connect the interfaces 13 to 24 via Ethernet cable with at least CAT5e /
S/FTP standard to your PC or a LAN switch.
eSFP+ interfaces 1G / 10G
Insert suitable LANCOM SFP modules into the SFP+ interfaces 25 to 28.
Choose cables which are compatible with the SFP modules and connect
them as described in the SFP modules mounting instructions:
www.lancom-systems.com/SFP-module-MI.
fOOB interface (rear panel)
Use an Ethernet cable to connect this out-of-band service port for an IP interface independent of the
swi tching plane for management tasks or connection to a monitoring server.
gQSFP+ interfaces 40G (rear panel)
Plug suitable LANCOM QSFP+ modules into the QSFP+ interfaces 29 and 30. Select cables suitable for the
QSFP+ modules and connect them as described in the SFP modules mounting instructions:
www.lancom-systems.com/SFP-module-MI.
hPower connector (rear panel)
Supply power to the device via the power connector. Please use the IEC power cable supplied or a
country-specific LANCOM Power Cord.
iAdditional slot for power supply module with mains connection socket (rear panel)
To install an additional power supply module, remove the appropriate module slot cover by loosening both
associated screws and insert the power supply module.
Supply the device with voltage via the power supply module mains connector. Use the supplied power cord
(not for WW devices) or a country -specific LANCOM Power Cord.
To remove a power supply module, disconnect the device from the power supply and pull the power plug
out of the module. Then push the release lever to the left. Now you can pull the module out of the device J
by the handle .K
h
h
h
hh
g f i
i
i
ii
JK
b Mode / Reset button
Short press Port LED mode switch
~5 sec. pressed Device restart
7~12 sec. pressed Configuration reset and device restart
e SFP+ ports 1G / 10 G
Off Port inactive or disabled
Green Link 10 Gbps
Green, blinking Data transfer, link 10 Gbps
Orange Link 1 Gbps
Orange, blinking Data transfer, link 1 Gbps
a System / Fan / Stack / Link/Act / PoE
System: green Device operational
System: red Hardware error
Fan: red Fan error
Stack: green As manager: port activated and connected
with standby manager connected
Stack: orange As standby manager: port activated and
connected to connected manager
Link/Act: green Port LEDs show link / activity status
PoE: green Port LEDs show PoE status
gf
g QSFP+ ports 40 G
Off Port inactive or disabled
Green Link 40 Gbps
Green, blinking Data transfer, link 40 Gbps
f OOB port
Off OOB port inactive
Green Link 1000 Mbps
c TP Ethernet ports 10M / 100M / 1G
LEDs switched to Link/Act mode
Off Port inactive or disabled
Green Link 1000 Mbps
Green, blinking Data transfer, link 1000 Mbps
Orange Link < 1000 Mbps
Orange, blinking Data transfer, link < 1000 Mbps
LEDs switched to PoE mode
Off Port inactive or disabled
Green Port enabled, power supply to connected
device
Orange Hardware error
d TP Ethernet ports 100M / 1G / 2.5G
LEDs switched to Link/Act/Speed mode
Off Port inactive or disabled
Green Link 2500 - 1000 Mbps
Green, blinking Data transfer, link 2500 - 1000 Mbps
Orange Link < 1000 Mbps
Orange, blinking Data transfer, link < 1000 Mbps
LEDs switched to PoE mode
Off Port inactive or disabled
Green Port enabled, power supply to connected
device
Orange Hardware error
b eca d
c ea db
