4 www.lacrossetechnology.com/support 04-1235UA-SS Page | 1
Model: 404- - 1235UA SS
Instruction Manual
DC: 092316
14” ULTRATOMIC WALL CLOCK
Thank you for purchasing the first and only clock in the market
that receives the NIST’s newly enhanced phase modulation based -
broadcast. The broadcast is based on a dual antenna scheme, -
making it insensitive to the orientation of installation. This clock is
designed for significantly better signal reception.
With optional custom settings, you are able to view times from
different time zones (+0 UTC to 11 UTC)-.
Use two or four
“C” batteries
+ C -
+ C -
+ C -
+ C -
+ C -
+ C -
4 www.lacrossetechnology.com/support 04-1235UA-SS Page | 2
Get Started Atomic Time-
1: Slide the time zone switch to your time zone.
= Pacific, PT MT = Mountain, = Central, = EasternCT ET
2: Select DST (Daylight Saving Time) setting ON/OFF.
When ON is selected, the clock will automatically adjust for
DST (most common).
3: Insert two or four fresh “C”, LR14 1.5 volt batteries according to
the polarity markings.
Important: When batteries are installed, the hands will move to
4 o’clock, 8 o’clock, or 12 o’clock position and the clock will start
receiving the Atomic Time signal from Colorado. When signal is
received, the hands will move to the correct time for the selected
time zone.
Optional Settings
Atomic Time with Custom Time Zone Selection
This clock allows you to select more than the
four major North American time zones by using
the CUSTOM ET setting.
1. Slide the Time Zone switch to CUSTOM ET.
2. Press and release the SET button to
advance the time in one hour increments.
3. The clock will keep time in the new time
zone selected.Time Zones available (+0 UTC to 11 UTC)-
Daylight Saving Time:
The new WWVB broadcast provided by the National Institute of
Standards and Technology includes a notification for the daylight
saving transitions well ahead of when they are to occur The .
UltrAtomic clock reads this information, at the appropriate and
instances, automatically advances the hands one hour in the
spring and eleven hours in the fall (to move back one hour), even
if the signal is not received on the day of the transition.
Sleep
PT
MT
CT
ET
Q-Mode
Custom
4 www.lacrossetechnology.com/support 04-1235UA-SS Page | 3
Q-Mode
Q-Run
Q-Set
DST
ON
OFF
Note: If the clock is to display the time in an area that does not
observe DST, the DST switch should be set to “OFF”.
WWVB Atomic Time Signal
For information about the WWVB broadcast, visit:
www.nist.gov/pml/div688/grp40/wwvb.cfm
Q Mode Manual Set Time- -
The clock can be set manually and used as a regular Quartz wall
clock even in areas that are beyond the range of the WWVB
broadcast, such as in Asia. It may also be helpful to set the clock
manually if one does not wish to wait for it to receive the signal
from the broadcast, which in some cases would only occur at
night.
1. Set DST switch to the OFF (Q Set).-
2. S Time Zone switch to the Q MODE.et -
Note: The movement will move to 4 o’clock 8 o’clock or 12
o’clock position and stop.
3. Hold the SET button to set the time quickly.
4. Press and release the SET button to change the time slowly.
5. When time is set, slide the DST switch to ON (Q RUN) -
position.
6. The second hand will start running from 12:00 and the clock
will keep time as manually set.
Set
